Raptor Captor 370 User manual

Captor 37
0
Motherboard
Installation Guide

Introduction
I
Table of Contents
Notice ...................................................... IV
Introduction........................................... V
Chapter 1 Pre-Configuration ......1
Step 1 Setting the Jumpers 3
Jumper Locations .............................................................4
CMOS Reset .......................................................................6
Disk-on-Chip Selection .....................................................6
Flash BIOS Write Protect..................................................6
Clock Speed Selection......................................................7
Watchdog Timer Selection ...............................................7
On-board Ethernet.............................................................8
On-board LCD(optional)/CRT video controller............... 8
ATX Power Supply Enhancements................................10
Step 2 DRAM, CPU, Disk-on-Chip and
Cables Installation 11
Captor 370 Memory Configuration ................................ 11
CPU Installation...............................................................11
Disk-on-Chip installation ................................................ 12
Installing Cables.............................................................. 12
Power and Control Panel Cables ...................................12
Installing Peripheral Cables ...........................................12
Index of Header Connectors .......................................... 15
Chapter 2 HIFLEX BIOS
Setup ..............................17
Standard Setup................................................................ 18
Advanced CMOS Setup ..................................................19
Advanced Chipset Setup ................................................ 23
Power Management Setup.............................................. 27
PCI/Plug and Play Setup.................................................30
Peripheral Setup..............................................................33

Captor 370 – Installation Guide
II
Auto Detect Hard Disk ....................................................36
Change User Password ..................................................36
Change Supervisor Password .......................................37
Change Language Settings ............................................37
Auto Configuration with Optimal Settings.................... 37
Auto Configuration with Fail-Safe Settings ..................38
Save Settings and Exit.................................................... 38
Exit without Saving .........................................................38
Chapter 3 Upgrading ....................39
Upgrading the System Memory .....................................39
Upgrading the Microprocessor...................................... 39
User's Notes: ...................................................................40
Appendix A Technical
Specifications..........41
Chipsets ...........................................................................41
System Memory...............................................................41
Bios...................................................................................41
Embedded I/O ..................................................................42
Industrial Devices............................................................43
Miscellaneous.................................................................. 44
Memory Map ....................................................................45
DMA Channels ................................................................. 45
I/O Map.............................................................................. 46
On-board Devices............................................................47
PCI Configuration Space Map........................................ 47
Interrupts..........................................................................48
PCI Interrupt Routing Map..............................................48
SMBUS.............................................................................. 49
Connectors Pin-out .........................................................49
Appendix B Flash BIOS
programming............55
Appendix C Disk-On-Chip..........57

Introduction
III
Appendix D On-Board Industrial
Devices........................59
Watchdog Timer ..............................................................59
Post Code Display........................................................... 60
Appendix E On-Board
Ethernet ....................71
Appendix F On-Board Video
Controller ...................73

Captor 370 – Installation Guide
IV
Notice
The company reserves the right to revise this publication or to change
its contents without notice. Information contained herein is for
reference only and does not constitute a commitment on the part of the
manufacturer or any subsequent vendor. They are in no way
responsible for any loss or damage resulting from the use (or misuse) of
this publication.
This publication and any accompanying software may not, in whole or
in part, be copied, photocopied, translated or reduced to any machine
readable form without prior consent from the vendor, manufacturer or
creators of this publication, except for copies kept by the user for
backup purposes.
Brand and product names mentioned in this publication may or may not
be copyrights and/or registered trademarks of their respective
companies. They are mentioned for identification purposes only and are
not intended as an endorsement of that product or its manufacturer.
First Edition.
February, 2001

Introduction
V
Introduction
Thank you for your purchase of the Captor 370™ industrial single
board computer motherboard. The Captor 370 design was based on the
Intel™ 440BX chipset providing the ideal platform to industrial
applications. The Captor 370 design is based on the Intel Celeron and
PIII processor.
With proper installation and maintenance, your Captor 370 will provide
years of high performance and trouble free operation.
This manual provides a detailed explanation into the installation and
use of the Captor 370 industrial single board computer. This manual is
written for the novice PC user/installer. However, as with any major
computer component installation, previous experience is helpful and
should you not have prior experience, it would be prudent to have
someone assist you in the installation. This manual is broken down into
3 chapters and 6 appendixes.
Chapter 1 - System Board Pre-Configuration
This chapter provides all the necessary information for
installing the Captor 370. Topics discussed include: installing
the CPU, (if necessary), DRAM installation, jumper settings
for CPU and standard I/O. Connecting all the cables from the
system board to the chassis and peripherals.
Chapter 2 - BIOS Configuration
This chapter shows the final step in getting your system
firmware setup.
Chapter 3 - Upgrading
The Captor 370 provides a number of expansion options
including memory. All aspects of the upgrade possibilities are
covered.

Captor 370 – Installation Guide
VI
Appendix A - Technical Specifications
A complete listing of all the major technical specifications of
the Captor 370 is provided.
Appendix B - Flash BIOS Programming (optional)
Provides all the information necessary to program your
optional AMIBIOS Flash BIOS.
Appendix C - Disk-on-Chip
One on-board socket for a solid state flash disk device.
Appendix D - Industrial Devices
Watchdog Timer and On-Board POST (Power On Self
Testing) code display.
Appendix E - Ethernet
On-board 10/100 Ethernet with Wake-on-Lan function.
Appendix F – LCD/CRT video controller
On-board LCD(optional)/CRT video controller 2MB (optional
4MB).
Static Electricity Warning!
The Captor 370 has been designed as rugged as possible but can still be
damaged if jarred sharply or struck. Handle the motherboard with care.
The Captor 370 also contains delicate electronic circuits that can be
damaged or weakened by static electricity. Before removing the Captor
370 from its protective packaging, it is strongly recommended that you
use a grounding wrist strap. The grounding strap will safely discharge
any static electricity build up in your body and will avoid damaging the
motherboard. Do not walk across a carpet or linoleum floor with the
bare board in hand.

Introduction
VII
Warranty
This product is warranted against material and manufacturing defects
for two years from the date of delivery. Buyer agrees that if this
product proves defective the manufacturer is only obligated to repair,
replace or refund the purchase price of this product at manufacturer's
discretion. The warranty is void if the product has been subjected to
alteration, misuse or abuse; if any repairs have been attempted by
anyone other than the manufacturer; or if failure is caused by accident,
acts of God, or other causes beyond the manufacturer's control.
Captor 370 - An Overview
The Captor 370 represents the ultimate in industrial single board
computer technology. No other system board available today provides
such impressive list of features:
CPU Support
• Supports full series of Intel Celeron and PIII PGA370
processors (up to 100MHz FSB).
Supported Bus Clocks
• 66 and 100MHz.
Memory
• Two DIMM sockets up to 256MB or 512MB(registered)
SDRAM, PC100 recommended (required for PIII or 100MHz).
On-Board I/O
• 2 Floppies up to 2.88 MB.
• Dual channel PCI 32-bit EIDE controller.
• Two high speed RS-232 serial ports 16 Bytes FIFO (16550).
• One Centronics™ compatible bidirectional parallel port.
EPP/ECP mode compatible.

Captor 370 – Installation Guide
VIII
• One PS/2 mouse and one PS/2 keyboard connector.
• Optional power connector through terminal block.
• Two Universal Serial Bus headers.
• One Disk-on-Chip on-board up to 288MB with FFS for
diskless applications.
• RJ45 Ethernet connector.
• One PC104 expansion/stack-up interface and power
connector.
ROM BIOS
• AMI BIOS™ BIOS HIFLEX with optional FLASH ROM
On-Board Ethernet
• On-board 10/100 Ethernet with Wake-on-Lan function.
LCD/CRT video controller
• On-board LCD(optional)/CRT video controller (C&T 65555)
2MB – 4MB(optional).
Conventions Used in this Manual

8

Notes - Such as a brief discussion of memory types.
Important Information - such as static warnings, o
r
very important instructions.
When instructed to enter keyboard keystrokes, th
e
text will be noted by this graphic.

Chapter 1: Pre-Configuration
1
Special Warranty Note:
Products returned for warranty repair will b
e
inspected for damage caused by imprope
r
installation and misuse as described in th
e
previous section and the static warning below.
Should the board show signs of abuse, th
e
warranty will become void and the customer wil
l
be billed for all repairs and shipping an
d
handling costs.
Chapter 1 Pre-Configuration
This chapter provides all the necessary information for installing the
Captor 370 into a standard PC chassis. Topics discussed include:
installing the CPU (if necessary), DRAM installation, jumper settings
for CPU and standard I/O.
Handling Precautions
The Captor 370 has been designed to be as rugged as possible but it can
be damaged if dropped, jarred sharply or struck. Damage may also
occur by using excessive force in performing certain installation
procedures such as forcing the system board into the chassis or placing
too much torque on a mounting screw.
Take special care when installing or removing the system memory
DIMMs. Never force a DIMM into a socket. Screwdrivers slipping off
a screw and scraping the board can break a trace or component leads,
rendering the board unusable. Always handle the Captor 370 with care.



Static Warning
The Captor 370 contains delicate electronic semiconductors that are
highly sensitive to static electricity. These components, if subjected to a
static electricity discharge, can be weakened thereby reducing the
serviceable life of the system board. BEFORE THE BOARD IS
REMOVED FROM ITS PROTECTIVE ANTISTATIC PACKAGING,

Captor 370 – Installation Guide
2
TAKE PROPER PRECAUTIONS! Work on a conductive surface that
is connected to the ground. Before touching any electronic device,
ground yourself by touching an unpainted metal object or, and highly
recommended, use a grounding strap.

Chapter 1: Pre-Configuration
3
Step 1 Setting the Jumpers
Your Captor 370 is equipped with a large number of peripherals and
has the ability to run at a variety of speeds without the need to change
any crystals or oscillators. As such, there is a large number of
configuration jumpers on the board. Taken step by step, setting these
jumpers is easy. We suggest you review each section and follow the
instructions.
Jumper Types
Jumpers are small copper pins attached to the system board. Covering
two pins with a shunt closes the connection between them. The Captor
370 examines these jumpers to determine specific configuration
information. There are three different categories of jumpers on the
Captor 370.
A. Two pin jumpers are used for binary selections such as enable,
disable. Instructions for this type of jumper are open, for no shunt over
the pins or closed, when the shunt covers the pins.
B. Three or four pin jumpers are used for multiple selection.
Instructions for these jumpers will indicate which two pins to cover.
For example: for JPx2-3 the shunt will be covering pins 2 and 3
leaving pins 1 and 4 exposed.
C. Grouped jumpers are used when a certain function has multiple
selections. There are two grouped jumpers on the board and careful
attention should be given when setting these jumpers. Instructions for
grouped jumpers are similar to those above.

Captor 370 – Installation Guide
4
Jumper Locations
Use the diagram below and the tables on the following pages to locate
and set the on-board configuration jumpers.
Figure 1-2 Jumper Locations - Front

Chapter 1: Pre-Configuration
5
Figure 1-3 Jumper Locations - Back

Captor 370 – Installation Guide
6
CMOS Reset
This option is provided as a convenience for those who need to reset
the CMOS registers. It should always be set to "Normal" for standard
operation. If the CMOS needs to be reset, turn off the system, move J1
to 2-3, turn the system on, move jumper to 1-2 and press reset.
Table 1-1 CMOS Reset
Reset CMOS Normal Clear CMOS
J1 1-2* 2-3
* Manufacturer's Settings.
Disk-on-Chip Selection
The jumper JP7 (SW6 and SW7) allows selection for the address on
Disk-on-Chip device.
Table 1-2 Disk-on-Chip Selection
Address JP7 (SW6) JP7 (SW7)
D000h* On On
D400h Off On
D800h On Off
DC00h Off Off
* Manufacturer's Settings.
* JP7 (SW8) is Reserved (default Off).
Flash BIOS Write Protect
To program the optional flash BIOS use JP8 to disable write protection.
For regular standard BIOS use default settings.
Table 1-3 Flash BIOS Programming Selection
Flash
Write-protect Enabled Disabled
JP8 1-2* 2-3
*Manufacturer's Settings.

Chapter 1: Pre-Configuration
7
Clock Speed Selection
The Captor 370 has a CPU automatic speed selector device. The
jumper JP1 allows selection for this option.
Table 1-4 Clock Frequency Selection
Clock
Frequency
JP1
(SW1)
JP1
(SW2)
JP1
(SW3)
JP1
(SW4)
AUTODETECT* On Off Off Off
66MHz Off On Off Off
100MHz Off Off Off Off
RESERVED Off Off On Off
RESERVED Off Off Off On
RESERVED Off On Off On
RESERVED Off On On Off
* Manufacturer's Settings.
DO NOT set the switches to RESERVED settings.
RESERVED settings are for internal testing purposes only.
Watchdog Timer Selection
The watchdog timer can be set as hardware, software or disabled
through JP7 (SW3 and SW4). JP7 (SW1 and SW2) sets the time-out
and JP7 (SW5) set the addresses. Please refer to appendix D for more
details.
Table 1-5 Watchdog Timer Selection
Watchdog
Type JP7 (SW3) JP7 (SW4)
Hardware On Off
Disabled* Off On
Software On On
Reserved Off Off
* Manufacturer's Settings.

Captor 370 – Installation Guide
8
Table 1-6 Watchdog Time-out Selection
Watchdog
Timeout JP7 (SW1) JP7 (SW2)
150 ms Off On
600 ms Off Off
1200 ms* On Off
Reserved On On
* Manufacturer's Settings.
Table 1-7 Watchdog Address Selection
Watchdog
Address JP7 (SW5)
110h* Off
310h On
* Manufacturer's Settings.
On-board Ethernet
The Captor 370 has a built-in 10/100 Ethernet. The jumper JP6 either
disables (2-3) or enables (1-2) this feature. For more information please
refer to Appendix E.
Table 1-8 Ethernet Selection
Ethernet
Selection Enabled Disabled
JP6 1-2* 2-3
* Manufacturer's Settings.
On-board LCD(optional)/CRT video controller
The Captor 370 has a built-in LCD(optional)/CRT video controller
(C&T 65555) 2MB – 4MB(optional). The jumper JP9 either disables
(2-3) or enables (1-2) the VGA. The switches JP11 select the LCD
panel type. The jumper JP5 selects the LCD operating voltage. For
more information please refer to Appendix F.

Chapter 1: Pre-Configuration
9
Table 1-9 On-board VGA LCD/CRT Selection
VGA
Selection Enabled Disabled
JP9 1-2* 2-3
* Manufacturer's Settings.
Table 1-10 LCD panel select
Panel
Number/Type
JP11
(SW1)
JP11
(SW2)
JP11
(SW3)
JP11
(SW4)
1- 1024x768 Dual
Scan Color STN
Color Panel
On On On On
2- 1280x1024 TFT
Color Panel On On On Off
3- 640x480 Dual
Scan Color Panel On On Off On
4- 800x600 Dual
Scan Color Panel On On Off Off
5- 640x480 Sharp
TFT Color Panel On Off On On
6- 640x480 18-bit
TFT Color Panel* On Off On Off
7- 1024x768 TFT
Color Panel On Off Off On
8- 800x600 TFT
Color Panel On Off Off Off
*Manufacturer's Settings.
Table 1-11 LCD Panel Operating Voltage Selection
Voltage
Selection 3.3V 5.0V
JP5 1-2* 2-3
*Manufacturer's Settings.

Captor 370 – Installation Guide
10
ATX Power Supply Enhancements
The Captor 370 has a Power on mode selection. The jumper JP2 selects
the power on mode.
This feature is only available when using an ATX power supply and a
cable connecting the backplane to J43.
Table 1-12 POWER ON Mode Select
Power on
mode
Power on
immediately
Power on upon
PWR_SW signal
(Button press)
JP2 1-2* 2-3
* Manufacturer's Settings.
