Rasha RP-1500 Owner's manual
Rasha Professional A/S 1800 Rustin Ave, Riverside CA, 92507
|
951-654-3585
rashaprofessional .com
|
1
QUICK USER MANUAL
RASHA PROFESSIONAL A/S
RP-1500
CO2-FOGGER
Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507
|
951-654-3585
rashaprofessional .com
|
2
Edition Notes
The RP-1500, User Manual Rev. 1 covers the description,
safety precautions, installation, programming, operation,
and maintenance of the RP-1500. Rasha released this
edition of the RP-1500 User Manual in July 2018.
Trademarks
Rasha®is a registered trademark of RASHA
PROFESSIONAL A/S. (d/b/a RASHA®or Rasha). The
RASHA® logo in its entirety including the RASHA®name
and the Globe wiht Rings, and all other trademarks in this
manual pertaining to services, products, or marketing
statements are owned or licensed by RASHA®. Any other
product names, logos, brands, company names, and other
trademarks featured or referred to within this document
are the property of their respective trademark holders.
Copyright
Notice
RASHA owns the content of this User Manual
in its entirety, including but not limited to
pictures, logos, trademarks, and resources.
© Copyright 2015 RASHA. All rights reserved.
Electronically published by Rasha in the United States of
America.
Manual Use
Rasha authorizes its customers to download and print this
manual for professional information purposes only. Rasha
expressly prohibits the usage, copy, storage, distribution,
modication, or printing of this manual or its content for
any other purpose without written consent from Rasha.
Document
Printing
For better results, print this document in color, on letter
size paper (8.5 x 11 in), double-sided. If using A4 paper
(210 x 297 mm), congure your printer to scale the content
accordingly.
Intended
Audience
Any person in charge of installing, operating, and/or
maintaining this product should completely read through
the guide that shipped with the product, as well as this
manual, before installing, operating, or maintaining this
product.
Document
Revision
The RP-1500 User Manual Rev. 1 supersedes all previous
versions of this manual. Discard any older versions of
this manual and replace with this version. Go to www.
rashaprofessional.com for the latest version.
Author Date Editor Date
Alex Gallegos 04/19/2019
Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507
|
951-654-3585
rashaprofessional .com
|
3
1. Before You Begin................................. 4
What Is Included .................................. 4
Claims .................................................. 4
Manual Conventions ............................ 4
Symbols ............................................... 4
Safety Notes......................................... 5
Personal Safety.................................... 5
Mounting And Rigging .......................... 5
Power And Wiring................................. 5
Operation ............................................. 5
2. Introduction.......................................... 7
Description ........................................... 7
Features ............................................... 7
Overview .............................................. 7
Dimensions .......................................... 7
3. Setup..................................................... 8
AC Power ............................................. 8
AC Plug ................................................ 8
Fuse Replacement ............................... 8
Power Linking....................................... 8
DMX Linking......................................... 8
DMX Personalities................................ 8
Mounting .............................................. 9
Orientation............................................ 9
Rigging ................................................. 9
Procedure............................................ 9
4. Operation............................................ 10
Control Panel Description .................. 10
Menu Map .......................................... 11
Menu Intro .......................................... 11
Operations.......................................... 12
Parameter Value Settings .................. 12
Submenu............................................ 12
5. DMX Channels ................................... 13
Channel 6........................................... 13
Channel 11 ......................................... 14
6. Technical Specications................... 15
Returns ............................................. 16
Contact Us ........................................ 17
Table of Contents
Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507
|
951-654-3585
rashaprofessional .com
|
4
What Is
Included
• Rasha RP-1500
• Power Cord ( IEC to Edison )
• Manual Controller
• DMX Cable
• Quick reference guide
Claims
Carefully unpack the product immediately
and check the box to make sure all the parts
are in the package are in good condition.
If the box or the contents (the product and included
accessories) appear damaged from shipping or show signs
of mishandling, notify the carrier immediately, not Rasha.
Failure to report damage to the carrier immediately may
Void your claim. In addition, keep the box and contents for
inspection. For other issues, such as missing components
or parts, damage not related to shipping, or concealed
damage, le a claim with Rasha within 7 days of delivery.
Manual
Conventions
Convention Meaning
1–512 DMX value range in number
50/60 A set of mutually exclusive values in the text
<SET> A button on the product’s control panel
Settings A product function or a menu option
0-512 A sequence of menu options
1-10 A range of menu values from which to choose in a menu
Yes/No A set of two mutually exclusive menu options in a menu
ON A unique value to be entered or selected in a menu
Symbols
Symbols Meaning
The term “DMX” used throughout this manual refers to the DMX512 digital
data transmission protocol
Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507
|
951-654-3585
rashaprofessional .com
|
5
Safety Notes
Read all the following Safety Notes before working with this product. These
notes include important information about the installation, usage, and
maintenance of this product. This product contains no user-serviceable
parts. Any reference to servicing in this User Manual will only apply to
properly trained Rasha certied technicians. Do not open the housing or
attempt any repairs. All applicable local codes and regulations apply to
proper installation of this product.
Please note that this machine is not meant to be used as a continuous
duration eect. The maximum running time is 30-60 second and can be
repeated but should not be done without 3 minute cooling time.
Personal
Safety
Avoid direct eye exposure to the light source while the product is on. Always
disconnect this product from its power source before servicing. Always
connect this product to a grounded circuit to avoid the risk of electrocution.
Do not touch this product’s housing during operation because it may be
very hot.
Rigging
This product is for indoor use only! To prevent risk of fire or shock, do
not expose this product to rain or moisture. (IP20) CAUTION: When
transferring product from extreme temperature environments, (e.g. cold
truck to warm humid ballroom) condensation may form on the internal
electronics of the product. To avoid causing a failure, allow
product to fully acclimate to the surrounding environment before
connecting it to power. Mount this product in a location with
adequate ventilation, at least 20 inches (50 cm) from adjacent
surfaces. Make sure there are no flammable materials close to this
product while it is operating. Always carry this product by the handles.
Do not carry from the head. When hanging this product, always secure to
a fastening device using a safety cable.
Power And
Wiring
Always make sure you are connecting this product to the proper
voltage in accordance with the specications in this manual or on the
product’s specication label. Never connect this product to a dimmer
pack or rheostat. Never disconnect this product by pulling or tugging
on the power cable. Warning: Dangerous voltages are prresent
in this machine . There is a danger of injury from electric shock.
Operation
Do not operate this product if you see damage to the housing or cables.
Have the damaged parts replaced by an authorized technician at once.
To eliminate unnecessary wear and improve its lifespan, during periods of
non-use completely disconnect the product from power via breaker or by
unplugging it. Do not cover the ventilation slots when operating to avoid
internal overheating. Do not aim this product toward the Sun. The maximum
ambient temperature is 113 °F (45 °C). Do not operate this product at a
higher temperature. In case of a serious operating problem, stop using
this product immediately! Use caution so that any liquids do not wet the
machine. Machine and Controller should be kept dry. Prevent anything
from entering the stream port, if this happens, clear obstructions before
continuing operation.
The term “DMX” used throughout this manual refers to the DMX512 digital data
transmission protocol
Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507
|
951-654-3585
rashaprofessional .com
|
6
Features • Create rich colors and pastels with RGBAW color led chips
• Create amazing eects and impact on spectators.
• Create coordinated light shows by linking other xtures
• Convenient wireless control using 2.4GHz
• Wireless control of sectional, eye-catching chase eects via DMX
Description
Rasha Professional RP-1500 is a CO2 fogger with (21) 3W RGB LED
which can make a strong vertical cylindrical smoke with color changing. It
suits for using in high level indoor place, and it can be placed horinzontal,
sided and it can be intall on the wall.
INTRODUCTION
Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507
|
951-654-3585
rashaprofessional .com
|
7
DMX CHART
Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507
|
951-654-3585
rashaprofessional .com
|
8
SETUP
Power Supply
Each RP-1500 has an auto-ranging power supply that works with an
input voltage range of 100 to 240 VAC, 50/60 Hz. To determine the power
requirements for each RP-1500 refer to the label axed to the product.
You can also refer to the Technical Specications chart in this manual.
The listed current rating indicates the maximum current draw during
normal operation. For more information, you may download Sizing Circuit
Breakers from the Rasha website: www.rashaprofessional.com
Always connect this product to a protected circuit with an appropriate
electrical ground to avoid the risk of electrocution or re. To eliminate
unnecessary wear and improve its lifespan, during periods of non-use
completely disconnect the product from power via breaker or by unplugging it.
Never connect this product to a rheostat (variable resistor) or dimmer circuit,
even if the rheostat or dimmer channel serves only as a 0 to 100% switch.
AC Plug
The RP-1500 comes with a power input cord terminated with a Neutrik®
powerCON®A connector on one end and an Edison plug on the other end
(U.S. market). If the power input cord that came with your product has no
plug, or if you need to change the Edison plug, use the table below to wire
the new plug.
Fuse
Replacement
e
1. Disconnect this product from the power outlet.
2. Using a flat-head screwdriver, lift the fuse holder cap from the housing.
3. Remove the blown fuse and replace with a another fuse of the sam
type and rating (T15 A) 250V.
4. press the fuse holder cap back in place and reconnect power.
Power Linking
Make sure to disconnect the product’s power cord before replacing a
blown fuse. Always replace the blown fuse with another of the same type
and rating
You can link 1 Fixture @ 110V and 2 fixtures @ 220V.
DMX
Personalities
•The RP-1500 uses a 3-pin DMX data connection for the 8 channel DMX
personality.
•Refer to the Introduction chapter for a brief description of each DMX
personality.
•Refer to the Operation chapter to learn how to congure the RP-1500 to
work in these personalities.
•The DMX Values section provides you with detailed information regarding
the DMX personalities
Connection Wire (U.S.) Wire (Europe) Screw Color
AC Live Black Brown Yellow or Brass
AC Neutral White Blue Silver
AC Ground Green/Yellow Green/Yellow Green
If you are not familiar with or need more information about DMX standards, Master/Slave connectivity,
or the DMX cables needed to link this product to a DMX controller, download the DMX Handbook from
the Rasha website: www.rashaprofessional.com
Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507
|
951-654-3585
rashaprofessional .com
|
9
Before mounting this product, read and follow the Safety Notes. For our
Rasha
®
Professional line of mounting clamps, go to
http://rashaprofessional.com/en/accesories
Orientation Always stand upwards this unit
Rigging • This is a free standing unit that should be set up on a at/leveled surface
MOUNTING
Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507
|
951-654-3585
rashaprofessional .com
|
10
- Add water base FOG Juice.
2. Operation
- Let Machine warm up for 5 minutes before operating.
3. Menu
4. - Press up/down to set DMX Address.
Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507
|
951-654-3585
rashaprofessional .com
|
11
RETURNS
You must send the product prepaid, in the original
box, and with the original packing and accessories.
Rasha Professional will not issue call tags.
Visit www.rashaprofessional.com to log into your account and
request a Return Merchandise Authorization (RMA) number before
shipping the product. Be prepared to provide the model number,
your order numver, serial number, and a brief description of the
Claim(s) for the return.
Clearly label the package with an RMA number. Rasha will refuse
any product returned without an RMA number.
DO NOT write the RMA number directly on the box. Instead, write it
on a properly axed label.
Once you have received the RMA number, include the following
information on a piece of paper inside the box:
•Name:
•Address:
•Phone number:
•RMA number:
• A brief description of the problem(s).
Be sure to pack the product properly. Any shipping damage
resulting from inadequate packaging will be the customer’s
responsibility.
Double-boxing is recommended. Rasha reserves the right to use its
own discretion to repair or replace returned product(s).
Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507
|
951-654-3585
rashaprofessional .com
|
12
WORLD HEADQUARTERS - RASHA GENERAL INFORMATION
ADDRESS: NO 501 FENGHUANG INDUSTRIAL ZONE,SANDONG
AVENUE,HUADU DISTRICT,GUANGZHOU,CHINA
VOICE: (00866) 020- 37726213
Technical Support
Email: [email protected]
www.rashaprofessional.com | www.rashalight.com
UNITED STATES Headquarters– Rasha Professional A/S LLC.
General Information
Address: 1800 Rustin Ave., Riverside CA 92507
Voice: +1 (951) 654 3585
Outside the U.S.contact the dealer of record. Follow their instructions
to request support or to return a product. Visit our website for contact
details.
CONTACT US
Table of contents
