Ravelli Aria User manual

USE AND MAINTENANCE MANUAL
Aria

SCHEDA PRODOTTO
PRODUCT DATASHEET
FICHE DE PRODUIT
PRODUCTKAART
PRODUKTDATENBLATT
FICHA DEL PRODUTO
EU 2015/1186
Marca / Trademark / Marque / Merk / Marke / Marca Ravelli
Modello / Model / Modèle / Model / Modell / Modelo Aria
Classe di efficienza energetica / Energy Efficiency class /Classe d’Efficacité
Énergétique / Energie-efficiëntieklasse / Energieeffizienzklasse / Clase de eficiencia
energética
A+
Potenza termica diretta / Direct thermal power / Puissance thermique directe /
Directe warmteafgifte / Direkte Wärmeleistung / Potencia calorífica directa 5,7 kW
Potenza termica indiretta / Indirect thermal power / Puissance thermique indirecte /
Indirecte warmteafgifte / Indirekte Wärmeleistung / Potencia calorífica indirecta --
Indice di efficienza energetica /Energy Efficiency Index / Indice de eficiencia
energética / Energie-efficiëntie-index / Energieeffizienzindex / Índice de eficiencia
energética
129
Efficienza utile (Potenza nominale) / Useful efficiency (Nominal power) / Rendement
utile (puissance nominale) / Nuttig rendement (bij nominale) / Brennstoff-
Energieeffizienz (Nennwärmeleistung) / Eficiencia energética útil (potencia nominal)
91,5 %
Efficienza utile (Potenza ridotta)/ Useful efficiency (Reduced power) / Rendement
utile (puissance minimale) / Nuttig rendement (bij minimale) / Brennstoff-
Energieeffizienz (Mindestlast) / Eficiencia energética útil (potencia minima)
93,8 %
Rispettare le avvertenze e le indicazioni di installazione e manutenzione periodica riportate nel manuale di
istruzioni. / Comply with the warnings and instructions concerning installation and routine maintenance provided in
the instruction manual. / Respecter les avertissements et les indications sur l’installation et l’entretien périodique
fournis dans le manuel d’instructions. / Neem de waarschuwingen en instructies voor installatie en periodiek
onderhoud in acht zoals aangegeven in de hoofdstukken van de gebruiksaanwijzing. / Beachten Sie die Warnungen
und Hinweise betreffend die Installation und regelmäßige Wartung in der Bedienungsanleitung. / Respete las
advertencias y las indicaciones de instalación y mantenimiento periódico, detalladas en los capítulos del manual de
instrucciones.
5,7
Aria
PRODUCT DATASHEET
FICHA DO PRODUTO
ΔΕΛΤΙΟ ΠΡΟΪΟΝΤΟΣ
PRODUKTBLAD
KARTA PRODUKTU
PODATKOVNI LIST IZDELKA
EU 2015/1186
Trademark / Marca / Μάρκα / Mærke / Marka / Blagovna znamka Ravelli
Model / Modelo / Μοντέλο / Model / Model / Model Aria
Energy Efficiency class / Classe de Eficiência Energética / Κατηγορία ενεργειακής
απόδοσης / Energiklasse / Klasa efektywności energetycznej / Razred energetske
učinkovitosti
A+
Direct thermal power / Potência calorífica direta / Άμεση θερμική ισχύς / Direkte
varmeydelse / Bezpośrednia moc produktu / Neposredna izhodna toplotna moč 5,7 kW
Indirect thermal power / Potência calorífica indireta / Έμμεση θερμική ισχύς /
Indirekte varmeydelse / Pośrednia moc produktu / Posredna izhodna toplotna moč --
Energy Efficiency Index / Índice de eficiência energética / Δείκτης ενεργειακής
απόδοσης / Indeks energieffektivitet / Wskaźnik efektywności energetycznej / Kazalo
energetske učinkovitosti
129
Useful efficiency (Nominal power) / Eficiência energética útil (potência nominal) /
Ωφέλιμη ενεργειακή απόδοση (ονομαστική ισχύ) / Virkningsgrad (nominel
varmeydelse) / Sprawność użytkowa (nominalnej mocy) / izkoristek energije (nazivni
izhodni moči)
91,5 %
Useful efficiency (Reduced power) / Eficiência energética útil (potência mínima) /
Ωφέλιμη ενεργειακή απόδοση (ελάχιστο ισχύ) / Virkningsgrad (mindste varmeydelse)
/ Sprawność użytkowa (minimalnym mocy) / izkoristek energije (nazivni izhodni moči)
93,8 %
Comply with the warnings and instructions concerning installation and routine maintenance provided in the
instruction manual. / Respeitar as advertências e as indicações de instalação e manutenção periódica referidas nos
capítulos do manual de instruções. / Τηρείτε τις προειδοποιήσεις και τις οδηγίες εγκατάστασης και περιοδικής
συντήρησης που αναφέρονται στα κεφάλαια του εγχειριδίου των οδηγιών. / Overhold advarslerne og angivelserne
for installation og vedligeholdelse, som angivet i kapitel i brugsvejledningen. / Należy przestrzegać ostrzeżeń i
wskazówek dotyczących instalacji i okresowej konserwacji podanych w rozdziałach w instrukcji obsługi. / Upoštevajte
opozorila in navodila za namestitev in redno vzdrževanje, navedena v poglavjih priročnika z navodili.
Aria
5,7

INFORMATION ON SOLID FUEL HEATING APPLIANCES
According to Regulation (EU) No. 1185/2015
EN
Fuel type Preferred fuel
(only one):
Other
suitable
fuel(s):
ηs
[x%]
Space heating emissions at
nominal heat output(*)
Space heating emissions at
minimum heat output (*) (**)
PM
OGC
CO
NOx
PM
OGC
CO
NOx
[x] mg/Nm3 at 13%O
2
[x] mg/Nm3 at 13%O
2
Wood logs with moisture
content
≤25 % no no
Compressed wood with
moisture
content < 12 % yes no
87,8
14,9
4
45
116
14
4
215
101
Characteristics when operating with the preferred fuel only
Item
Symbol
Value
Unit
Type of heat output/room temperature control (select one)
Heat output
single stage heat output, no room temperature control
No
Nominal heat output
P
nom
5,7
kW
two or more manual stages, no room temperature control
No
Minimum heat output (indicative)
P
nom
2,7
kW
with mechanic thermostat room temperature control
No
Useful efficiency (NCV as received)
with electronic room temperature control
No
Useful efficiency at nominal heat output
η
th,nom
91,5
%
with electronic room temperature control plus day timer
No
Useful efficiency at minimum heat output (indicative)
η
th,min
93,8
%
with electronic room temperature control plus week timer
Yes
Auxiliary electricity consumption
Other control options (multiple selections possible)
At nominal heat output
el
max
0,050
kW
room temperature control, with open window detection
No
At minimum heat output
el
min
0,030
kW
room temperature control, with presence detection
No
In standby mode
el
SB
0,004
kW
with distance control option
Yes
(*) PM = particulate matter, OGCs = organic gaseous compounds, CO = carbon monoxide, NOx = nitrogen oxides
(**) Only required if correction factors F(2) or F(3) are applied.
Manufacturer
Aico
Aico
Model identifier(s)
Aria
Aria
Brand
Ravelli
Ravelli
Indirect heating functionality
No
No kW
Direct heat output
5,7 kW
12 kW
Indirect heat output
-- kW

DECLARATION OF PERFORMANCE
Declaration of performance according to Regulation (EU) 305/2011
n. : 276CPR13.07
1. Unique identification code of the product type:
10015BR06, residential space heating appliance fired by wood pellets
EN 14785:2006
2. Type, batch or serial number or any other element allowing identification of the construction product as required under Art. 11(4):
Aria,
3. Intended use or uses of the construction product, in accordance with the applicable harmonised technical specification, as foreseen by the manufacturer:
Residential space heating appliance fired by wood pellets
4. Name, registered trade name or registered trademark and contact address of the manufacturer as required by Art. 11 (5):
Ravelli
Aico S.p.A.
Via Consorzio Agrario, 3/D
25032 Chiari (Bs) Italia
5. Where applicable, name and contact address of the authorised representative whose mandate covers the tasks specified in Article 12(2):
---
6. System or systems of assessment and verification of constancy of performance of the construction product as set out in Annex V:
System 3, System 4
7. In case of the declaration of performance concerning a construction product covered by a harmonised standard:
The notified laboratory TÜV Rheinland Energy GmbH (NB 2456) performed the determination of the product type on the basis of type testing
under system 3 and issued test report K31932021T1
8. Declared performances:
Harmonized technical specification:
EN 14785:2006
Essential characteristics
Performance
Fire safety
Reaction to fire
A1
Distance to combustible materials
Minimum distances (mm):
rear = 100
sides = 200
front = 800
ceiling = 400
floor = 0
Risk of burning fuel falling out
Pass
Emission of combustion products
(at 13% of O2)
Nominal heat output
CO 0,004 % - 45 mg/Nm3
NOx 116 mg/Nm3
OGC 4 mg/Nm3
PM 14,9 mg/Nm3
Reduced heat output
CO 0,017 % - 215 mg/Nm3
OGC 4 mg/Nm
3
Surface temperature
Pass
Electrical safety
Pass
Cleanability
Pass
Maximum operating pressure
--
Flue gas temperature at nominal heat output
121 °C
Mechanical resistance(to carry a chimney/flue)
NPD
Nominal heat output
5,7 kW
Room heating output
5,7 kW
Water heating output
--
Efficiency Ƞ
91,5 % Nominal heat output
Ƞ
93,8 % Reduced heat output
9. The performance of the product identified in points 1 and 2 is in conformity with the declared performance in point 8. This declaration of performance
is issued under the sole responsibility of the manufacturer identified in point 4.
Signed for and on behalf of the manufacturer Claudio Mezzalira, Operations Manager
Place Chiari Date 16/12/2021 Sign _______________
