Installation Instructions:
RSCAC-1333-P-240-A
RSCAC-1333-PS-240-A
RSCAC-1333-PH-240-A
www.raycap.com
INSTALL INSTRUCTIONS RSCAC-1333-P/PS/PH-240-A
RSCAC-1333-P-240-A RSCAC-1333-PS-240-A RSCAC-1333-PH-240-A
www.raycap.com
©Raycap • All rights reserved
(320-1370) Rev.A
Page 1 of 10
INSTALL INSTRUCTIONS RSCAC-1333-P/PS/PH-240-A
Contents
1 Copyright 2
1.1 Disclaimer 2
1.2 Warnings 2
2 Introduction 3
3 OVP Package Contents 3
3.1 Prerequisites 3
3.2 Required Tools and Supplies 3
4 Mounting the Bracket - Options 4
5 PortDenitions 4
6 WiringConguration 5
7 Closing and Securing Unit 9
8 Optional Lock-Out Feature 9
RSCAC-1333-P/PS/PH-240-A INSTALL INSTRUCTIONS
www.raycap.com
©Raycap • All rights reserved
(320-1370) Rev.A
Page 2 of 10
1.0 Copyright
©Raycap, Inc. 2018 - All Rights Reserved
1.1 Disclaimer
The information in this document is subject to change without notice and describes only the product
dened in the introduction of this documentation. This documentation is intended for the use of
Raycap customers only for the purposes of the agreement under which the document is submitted,
and no part may be used, reproduced, modied or transmitted in any form or means without the prior
written permission of Raycap. The documentation has been prepared to be used by professional
and properly trained personnel, and the customer assumes full responsibility when using it. Raycap
welcomes customer comments as part of the process of continuous development and improvement
of the documentation.
Raycap has made all reasonable efforts to ensure that the instructions contained in this document
are adequate and free of material errors and omissions. Raycap will, if deemed necessary, explain
issues which may not be covered by this document.
The contents of this document are subject to revision without notice due to continued progress in
methodology, design and manufacturing. Raycap shall have no liability for any error damage of any
kind resulting from the use of this document.
1.2 Warnings
Please read this manual prior to use to become familiar with the product’s numerous features and
operating procedures. To maintain the maximum degree of safety, follow the sequences as outlined.
Before using the product, read all instructions and cautionary markings on the product and on any
equipment connected to the product.
CAUTION – Unless otherwise noted, product usage that is not recommended or sold by the product
manufacturer can result in risk of re, electric shock, or injury to persons.
CAUTION – Do not operate the product if it has been damaged in any way. Return damaged
products to Raycap for repair or replacement.
CAUTION – Do not disassemble the product. Incorrect re-assembling can cause the risk of electrical
shock or re.
WARNING – Disconnect or disable the AC power source to the product prior to beginning its
installation. Ensure that the AC power source to the product remains de-energized until the
completion of the installation and after all connections have been veried to be correctly congured.
For conditions other than those described above, please phone a Raycap Account Representative at
(208) 777-1166, (800) 890-2569 or www.raycap.com
Thank you for choosing quality products from Raycap
www.raycap.com
©Raycap • All rights reserved
(320-1370) Rev.A
Page 3 of 10
INSTALL INSTRUCTIONS RSCAC-1333-P/PS/PH-240-A
2.0 Introduction
The small cell architecture is a crucial component of 4G LTE and 5G networks because they
increase network capacity, density and service coverage to the end user for both in-building
and outdoor wireless service. Newer small cell designs include clusters of ‘virtualized cells’
run from a central controller, and low power remote radio heads. Small cell equipment is
exposed to the elements on street lights, utility poles, buildings and other structures powered
and connected by copper cabling. Power runs along this conductive path, making the active
equipment at each site vulnerable to damage by direct lightning strikes. Protection systems
installed in front of both the BBU and the RRH must be able to withstand direct lightning
currents in order to protect the sensitive equipment. Raycap’s small cell solutions featuring
Strikesorb® SPD technology signicantly enhance the reliability & availability of the site by
providing superior electrical protection.
3.0 Raycap AC Disconnect Package Contents
1 each
Enclosure, Mounting Hardware
Metal Mounting Bracket
Bracket Hardware Kit
Note:
• Models with “-PS” in the model number incorporate a Shunt Trip for emergency
disconnect means from outside of the enclosure
• Models with “-PH” in the model number have the option of a screw down hingless
lid design for use in tight quarters, such as inside light pole Small Cell structures
3.1 Prerequisites
This document describes how to install the RSCAC-1333-P/PS/PH-240-A on-site and how to
mount, and connect it to external interfaces.
Installers of Raycap’s RRH surge protective and power management solutions must be
industry professionals who have attended training on the proper installation of the equipment
by Raycap and/or the mobile operator. Installers are required to read this installation guide
thoroughly prior to installation of the Raycap RRH protection equipment.
3.2 Required Tools & Supplies
7/16" Nut driver (mounting bracket)
Wire cutter
Wire strippers
#1 Philips head screwdriver
RSCAC-1333-P/PS/PH-240-A INSTALL INSTRUCTIONS
www.raycap.com
©Raycap • All rights reserved
(320-1370) Rev.A
Page 4 of 10
Procedure
Mounting the Bracket
4.1 Enclosure mounted on bracket
4.2 Option 1: Pole Mount
Pole mount can be used in horizontal
or vertical conguration.
4.3 Option 2: Monopole
4.4 Option 3: Unistrut
Metal mounting bracket NOT used
Procedure
PortDenitions
5.1 See picture to identify
Base Port
Assembly Denitions
5.2 Torque Values for Sealing
Cable Glands
AC Cables: 44.2 in-lb (5.0 N-m)
AC (Out)AC (In) Ground
Banding Locations
www.raycap.com
©Raycap • All rights reserved
(320-1370) Rev.A
Page 5 of 10
INSTALL INSTRUCTIONS RSCAC-1333-P/PS/PH-240-A
Procedure
WiringConguration
6.1 Loosen the 4 thumbscrews
(RSCAC-1333-PH-240-A) on outside
cover or unclasp latch to open cover.
6.2 Flip all breakers to “OFF” position to ensure
there is no power to circuits.
6.3 Remove (4) Philips head screws and set the
screws and dead-front aside.
RSCAC-1333-P/PS/PH-240-A INSTALL INSTRUCTIONS
www.raycap.com
©Raycap • All rights reserved
(320-1370) Rev.A
Page 6 of 10
6.3 NOTE: Suitable for Use Service Entrance (SUSE).
6.4 Install Ground Cable as shown.
RSCAC-1333-PS-240-A (Shunt Trip version shown)
www.raycap.com
©Raycap • All rights reserved
(320-1370) Rev.A
Page 7 of 10
INSTALL INSTRUCTIONS RSCAC-1333-P/PS/PH-240-A
6.5 Install AC Power “IN” as shown.
Note: Ground Cable not shown for clarity.
RSCAC-1333-P/PS/PH-240-A INSTALL INSTRUCTIONS
www.raycap.com
©Raycap • All rights reserved
(320-1370) Rev.A
Page 8 of 10
6.6 Install AC Power “OUT” as shown.
Note: Ground Cable and AC Power IN Cables not shown for clarity.
One of available eight circuits installed.
AC (Out) AC (Out) AC (In) Ground
www.raycap.com
©Raycap • All rights reserved
(320-1370) Rev.A
Page 9 of 10
INSTALL INSTRUCTIONS RSCAC-1333-P/PS/PH-240-A
6.7 Ground cable, AC Power (IN) and AC Power (OUT) (1 circuit) installed.
6.8 Replace dead-front, ip breaker “ON” to power circuits.
Procedure
Closing and securing unit
7.1 Close cover. Secure cover clip (if equipped)
and tighten the 4 thumbscrews.
7.2 Installation Complete.
Optional Lock-Out Feature
8.1 With cover clip engaged, secure with lock
(not provided).
Note: Clip not equipped on the RSCAC-1333-PH-240-A,
therefore there is not a lock-out feature.
