2.0 Introduction
The small cell architecture is a crucial component of 4G LTE and 5G networks because they
increase network capacity, density and service coverage to the end user for both in-building
and outdoor wireless service. Newer small cell designs include clusters of ‘virtualized cells’
run from a central controller, and low power remote radio heads. Small cell equipment is
exposed to the elements on street lights, utility poles, buildings and other structures powered
and connected by copper cabling. Power runs along this conductive path, making the active
equipment at each site vulnerable to damage by direct lightning strikes. Protection systems
installed in front of both the BBU and the RRH must be able to withstand direct lightning
currents in order to protect the sensitive equipment. Raycap’s small cell solutions featuring
Strikesorb® SPD technology signicantly enhance the reliability & availability of the site by
providing superior electrical protection.
3.0 Raycap AC Disconnect Package Contents
1 Enclosure
3.1 Prerequisites
This document describes how to install the RSCAC-7239 Series on-site and how to mount, and
connect it to external interfaces.
Installers of Raycap’s RRH surge protective and power management solutions must be
industry professionals who have attended training on the proper installation of the equipment
by Raycap and/or the mobile operator. Installers are required to read this installation guide
thoroughly prior to installation of the Raycap RRH protection equipment.
3.2 Required Tools & Supplies
Wire cutter
Wire strippers
#1 Phillips head screwdriver
#2 Phillips head screwdriver
9/16" socket and/or open end wrench
QUESTIONS? VISIT WWW.TALLEYCOM.COM OR CONTACT TALLEY AT 800.949. 7079 OR [email protected] TODAY.

RSCAC-7239 Series INSTALL INSTRUCTIONS
www.raycap.com
©Raycap • All rights reserved
(320-1391) Rev.B
Page 4 of 10
Washer
Lock-Washer
Nut
Bolt
Inside holes
long bolts
outside holes
short bolts
Procedure
Mounting the Bracket
Enclosure mounted on bracket
4.1 Pull long bolts through inside holes in
bracket, do NOT add washer, lock-washer
or nut.
4.2 Attach bracket to the enclosure through
outer holes with short bolts, washer,
lock-washer and nut using a 9/16" socket
and/or open end wrench.
Torque: 23 ft-lbs
4.3 Place enclosure with bracket up to pole,
add v-brackets over the long bolts. Secure
with washer, lock-washer and nut using a
9/16" socket and/or open end wrench.
Torque: 23 ft-lbs
QUESTIONS? VISIT WWW.TALLEYCOM.COM OR CONTACT TALLEY AT 800.949. 7079 OR [email protected] TODAY.

www.raycap.com
©Raycap • All rights reserved
(320-1391) Rev.B
Page 5 of 10
INSTALL INSTRUCTIONS RSCAC-7239 Series
To isolate power prior to installing or
performing maintenance, push external shunt
trip button.
Shunt trip disconnects power. Main breaker must
be turned on manually once work is complete.
Procedure
PortDenitions
5.1 See picture to identify
Portdenitions
5.2 Torque Values for Sealing
Cable Glands
AC Cables: 44.2 in-lb (5.0 N-m)
ComponentDenitions
5.3 Component call-outs.
Power (OUT)
x3
Power (IN)
x9
Power (IN)
x3
Ground
Inserts can be replaced with
standard conduit ttings.
Strikesorb
Surge Protection
Smart Power Meter
120VAC GFCI
Courtesy Outlet
Branch Circuit Breaker
Main Circuit
Breaker
Shunt Trip for external
main power disconnect
Additional Branch
Circuit Breaker Slots
RSCAC-7239-PS-240-A
QUESTIONS? VISIT WWW.TALLEYCOM.COM OR CONTACT TALLEY AT 800.949. 7079 OR [email protected] TODAY.

RSCAC-7239 Series INSTALL INSTRUCTIONS
www.raycap.com
©Raycap • All rights reserved
(320-1391) Rev.B
Page 6 of 10
Procedure
Wiring Installation
6.1 Remove dead-front by removing the
two (2) Phillips head screws and set aside.
6.2 Connection call-outs.
Ground Busbar
Neutral Busbar
Neutral Input
L1 (IN) L2 (IN) Ground
RSCAC-7239-P-240-A
QUESTIONS? VISIT WWW.TALLEYCOM.COM OR CONTACT TALLEY AT 800.949. 7079 OR [email protected] TODAY.

www.raycap.com
©Raycap • All rights reserved
(320-1391) Rev.B
Page 7 of 10
INSTALL INSTRUCTIONS RSCAC-7239 Series
6.3 Install breakers in open slots as needed.
Ensure CT label orientation is right side up.
(CT’s shall be secured in place a minimum
of one inch from the breaker terminals.)
QUESTIONS? VISIT WWW.TALLEYCOM.COM OR CONTACT TALLEY AT 800.949. 7079 OR [email protected] TODAY.

RSCAC-7239 Series INSTALL INSTRUCTIONS
www.raycap.com
©Raycap • All rights reserved
(320-1391) Rev.B
Page 8 of 10
6.4 Install Power-OUT cables as shown.
Note: Power-IN cables not shown for clarity.
Closing and securing unit
7.1 Replace dead-front, ip breaker “ON” to
power circuits.
7.2 Close cover. Secure two (2) cover screws.
7.3 Installation Complete.
QUESTIONS? VISIT WWW.TALLEYCOM.COM OR CONTACT TALLEY AT 800.949. 7079 OR [email protected] TODAY.
