Raydon RA-170 User manual

RAYDON Electronics
Universal USB Analyzer
User Manual
Model: RA-170
© RAYDON Electronics Technology Co., Ltd.
All rights reserved
RAYDON

This document Version contains confidential information which represents trade secrets of RAYDON
Electronics and may not be copied or disclosed except as provided in the permission from RAYDON
Electronics.
The information in this document is subject to change without notice and should not be construed as a
commitment by RAYDON Electronics. RAYDON Electronics assumes no responsibility for any errors that
may occur in this document.
All brand or product names are trademarks or registered trademarks of their respective holders.
Version Control
Version Description Date
V1.0 Draft 19 Nov 2018
Notices

RAYDON Electronics Technology Co., Ltd
187 Nanda Rd Dashi Town Panyu District GuangZhou City, GuangDong PRC.
TEL: [phone] FAX: [phone]
URL
：
http://www.batterytesting.com.cn
Email
：
[e-mail]
Page 3 of 12 Pages
RAYDON
目录
1 Summary .................................................................................................................................................... 4
1.1 Product Introduction ......................................................................................................................... 4
1.2 Product Function Objective .............................................................................................................. 4
1.3 File Introduction ................................................................................................................................ 4
2 Surface and Structure .............................................................................................................................. 5
3 Instructions for Full Color Display .......................................................................................................... 6
3.1 Function Interface: ........................................................................................................................... 6
4 Instructions for Operation ........................................................................................................................ 7
4.1 Power bank: ..................................................................................................................................... 7
4.1.1 Power bank charging ............................................................................................................ 7
4.1.2 Power bank Discharge and capacity detective ..................................................................... 7
4.2 Charger/Adapter: .............................................................................................................................. 8
4.2.1 Charger/Adapter charging feature ........................................................................................ 8
4.3 Device .............................................................................................................................................. 9
4.3.1 Device charging feature ........................................................................................................ 9
4.4 Cables .............................................................................................................................................. 9
4.4.1 Cables test feature ................................................................................................................ 9
5 Specification ............................................................................................................................................ 10
6 Accessories ............................................................................................................................................. 11

RAYDON Electronics Technology Co., Ltd
187 Nanda Rd Dashi Town Panyu District GuangZhou City, GuangDong PRC.
TEL: [phone] FAX: [phone]
URL
：
http://www.batterytesting.com.cn
Email
：
[e-mail]
Page 4 of 12 Pages
RAYDON
1 Summary
1.1 Product Introduction
This product is named “Universal USB Analyzer”.
This device provides complete solutions for power bank, adapter/chargers, cables, cell phone battery, or any
other USB/ micro USB/Type C devices charging, discharging status detecting, and capacity calculation. It
includes Charging, Discharging, Capacity calculation etc. functions.
At the meantime, this device use high resolution colorful LCD display, shows voltage, current, capacity,
power, temperature data, build-in CC loader, micro USB, USB, Type-C ports, to cover almost of device.
Ideal Power bank, charger/adapter, cables, cell phone and pad analyzing device for consumer electronics
retailers and stores.
1.2 Product Function Objective
Here are Analyzer’s base functional applications:
 All USB/Micro USB/Type C device supporting
 High resolution colorful LCD display, shows voltage, current, capacity, power, temperature data.
 Build-in CC loader that can fully discharge power bank to measure the current total capacity.
 Automatic recognize fast charger protocol.
 Detect power bank / other device discharging equivalent impedance and power.
 Power bank charging testing.
 This device can fully discharge power bank to measure the current total capacity
 Power interrupt data auto-save
 Temperature display
 Not just only power bank, build-in CC loader, micro USB, USB, Type-C ports, to cover almost of
device.
1.3 File Introduction
This manual illustrates Device’s surface, function specification, connection and operation flow in detail, for
Industrial Version.

RAYDON Electronics Technology Co., Ltd
187 Nanda Rd Dashi Town Panyu District GuangZhou City, GuangDong PRC.
TEL: [phone] FAX: [phone]
URL
：
http://www.batterytesting.com.cn
Email
：
[e-mail]
Page 5 of 12 Pages
RAYDON
2 Surface and Structure
This chapter illustrates Analyzer’s surface and structure.
LCD Display
Internal loader
External Outputs
AC Adapter input
Battery bank
input

RAYDON Electronics Technology Co., Ltd
187 Nanda Rd Dashi Town Panyu District GuangZhou City, GuangDong PRC.
TEL: [phone] FAX: [phone]
URL
：
http://www.batterytesting.com.cn
Email
：
[e-mail]
Page 6 of 12 Pages
RAYDON
3 Instructions for Full Color Display
3.1 Function Interface:
 Introduction of Icon Function
1. Press and hold the button to choose this icon to open or close the screen
2. Press and hold the button to choose this icon to switch the temperature unit.
3. Press and hold the button to choose this icon to switch data group
4. Press and hold the button to choose this icon to clear data group.
5. Press and hold the button to choose this icon rotate the screen
 Main Measurment Interface.
6. Voltage Measurement
7. Current Measurement
8. Accumulated Capacity
9. Accumulated Energy
10. Temperature Measurement
11. Number of the Data Group in use
12. Load Equivalent Impedance
13. Power Measurement

RAYDON Electronics Technology Co., Ltd
187 Nanda Rd Dashi Town Panyu District GuangZhou City, GuangDong PRC.
TEL: [phone] FAX: [phone]
URL
：
http://www.batterytesting.com.cn
Email
：
[e-mail]
Page 7 of 12 Pages
RAYDON
4 Instructions for Operation
Follow this operations, will check the detail data from LCD display.
4.1 Power bank:
4.1.1 Power bank charging
 Step 1: Connect your adapter/charger to RA-170 according cable’s port (USB, or Type C). In this example,
we assume it’s Type C.
 Step 2: Connect power bank to RA-170 by adapter’s port, which is Type C in this example.
 Step 3: Rotate the button 1 to “Type C” port.

Step 4: Rotate the button 2 to “EXTERNAL OUTPUS”-“Type C” port.

4.1.2 Power bank Discharge and capacity detective
Button
1
2
Button
Button 1
1
Button 2
Button 3

RAYDON Electronics Technology Co., Ltd
187 Nanda Rd Dashi Town Panyu District GuangZhou City, GuangDong PRC.
TEL: [phone] FAX: [phone]
URL
：
http://www.batterytesting.com.cn
Email
：
[e-mail]
Page 8 of 12 Pages
RAYDON
 Step 1: Connect power bank to RA-170 according cable’s port (USB, or Type C). In this example, we
assume it’s Type C.
 Step 2: Rotate the button 1 to “Type C” port.
 Step 3: Rotate the button 2 to “INTERNAL LOADER”-“Type C” port.
 Step 4: Rotate the button 3 and press button “Voltage” to select the current and voltage by your power
bank’s output specification.
4.2 Charger/Adapter:
4.2.1 Charger/Adapter charging feature
 Step 1: Connect your charger/adapter to RA-170 according cable’s port (USB, or Type C). In this example,
we assume it’s Type C.
 Step 2: Rotate the button 1 to “Type C” port.
 Step 3: Rotate the button 2 to “INTERNAL LOADER”-“Type C” port.
 Step 4: Rotate the button 3 and press button “Voltage” to select the current and voltage by your
charger/adapter’s output specification.
1
Button 1
Button 2
Button 3

RAYDON Electronics Technology Co., Ltd
187 Nanda Rd Dashi Town Panyu District GuangZhou City, GuangDong PRC.
TEL: [phone] FAX: [phone]
URL
：
http://www.batterytesting.com.cn
Email
：
[e-mail]
Page 9 of 12 Pages
RAYDON
4.3 Device
4.3.1 Device charging feature
 Step 1: Connect your adapter/charger to RA-170 according cable’s port (USB, or Type C). In this example,
we assume it’s Type C.
 Step 2: Connect power bank to RA-170 by adapter’s port, which is Type C in this example.
 Step 3: Rotate the button 1 to “Type C” port.
 Step 4: Rotate the button 2 to “EXTERNAL OUTPUS”-“Type C” port.
4.4 Cables
4.4.1 Cables test feature
* Please check power bank operations.
1
Button 1
Button 2
2

RAYDON Electronics Technology Co., Ltd
187 Nanda Rd Dashi Town Panyu District GuangZhou City, GuangDong PRC.
TEL: [phone] FAX: [phone]
URL
：
http://www.batterytesting.com.cn
Email
：
[e-mail]
Page 10 of 12 Pages
RAYDON
5 Specification
Voltage Range 3.70-25.00V
Voltage Resolution 0.01V
Voltage Accuracy ±
（
0.8
％
+0.01
）
V
Current Range 0-3.000A
Current Resolution 0.001A
Current Accuracy ±
（
1
％
+0.004
）
A
Capacity Range 0-99999mAh
Energy Range 0-99999mWh-999.99Wh
Power Range 0-75W
Load impedance Range 1Ω-9999.9Ω
Temperature Range 0℃~80℃/32℉~176℉
Temperature Accuracy ± 3℃/ ± 6℉
Temperature normal limit 0-45℃/32℉~113℉
Fast charging recognition mode
QC1.0, QC2.0, QC3.0, QC4.0, SCP, FCP, MTP
Pump Express, APPLE, Android DCP, SAMSUNG,
USB-PD, VOOC
Charging input 5V/0-3A
