Raychart 420/
420D
Chartplotter
Owner’s
Handbook
Document number: 81162_2
Date: January 2000

i
RayChart 420 and 420D
Chartplotter
Owner’s Handbook
SAFETY NOTICES
1.HIGHVOLTAGE.
Thedisplay unit containshigh voltages. Adjustmentsrequire specialised
serviceprocedures and toolsonly availabletoqualified servicetechnicians
–thereare no userserviceablepartsoradjustments. The operatorshould
neverremove the displayunitcover orattemptto service theequipment.
2.NAVIGATIONAID.
Thisdeviceis onlyanaidto navigation.Itsaccuracycan beaffectedby
many factors, including equipment failure or defects, environmental
conditionsandimproper handlingoruse.
Itisthe user’sresponsibilityto exercise commonprudenceand
navigationaljudgement,and this deviceshouldnot be relieduponas a
substitutefor suchprudenceand judgement.

RayChart 420/420D Chartplotter
ii
RAYTHEONMARINEproductsaresupportedbyanetworkof Authorized
ServiceRepresentatives.For information on Raytheon productsandservices,
contact either of the following:
UNITED STATES Raytheon MarineCompany
22CottonRoad, Suite 280
Nashua,NH03063-4219
Telephone: [phone]
1-800-539-5539
Fax: [phone]
EUROPE RaytheonMarineLimited
AnchoragePark
Portsmouth
HampshirePO35TD
England
Telephone: [phone]
Fax: [phone]
Website www.raymarine.com
Copyright© Raytheon Marine Company 1999
Thetechnical and graphicalinformationcontained in thishandbook,to the best
ofourknowledge,was correct as it went to press. However, theRaytheon
policyofcontinuous improvement and updating may change product
specifications without prior notice. As a result, unavoidable differences
betweentheproductandhandbookmayoccurfromtimeto time, for which
liabilitycannotbe accepted by Raytheon.
Raytheonisa registered trademark of RaytheonCompany.
Navionicsisaregisteredtrademark.

Preface iii
Preface
Thishandbookcovers the RayChart 420/420D Chartplotter manufacturedby
RaytheonMarineCompany.
Itcontains very important information onthe installation and operation ofyour
newequipment. In order to obtainthebest results in operation andperformance,
pleasereadthis handbook thoroughly.
Raytheon’sProduct Support representativesor your authorised dealerwill be
availabletoanswer any questions you may have.
Warranty
Toregister your RayChart 420/420D Chartplotterownership,please take a few
minutesto fill outthewarranty registration card foundat the end ofthis
handbook.Itisveryimportantthatyoucompletetheownerinformationand
returnthe card tothe factory in orderto receive full warrantybenefits.
EMC Conformance
AllRaytheonequipment and accessories are designedto thebestindustry
standardsfor use in the leisuremarineenvironment.
Thedesignandmanufacture of Raytheon equipment and accessories conform
to the appropriate Electromagnetic Compatibility (EMC) standards, but correct
installationis required toensurethat performance is notcompromised.

iv RayChart 420/420D Chartplotter

Table of Contents v
Contents
Preface ................................................................................................ iii
Warranty ................................................................................... iii
EMCConformance .................................................................... iii
Chapter 1: Overview ......................................................................... 1-1
1.1 Introduction ............................................................................. 1-1
HowthisHandbookis organised ............................................... 1-1
General .................................................................................... 1-2
1.2 The chartplotter display ............................................................ 1-2
Displayfunctions ..................................................................... 1-2
Displayoptions ................................................................... 1-3
1.3 Operating controls .................................................................... 1-3
Trackpad and cursor ................................................................. 1-4
Dedicatedkeys ......................................................................... 1-5
Function bar ............................................................................. 1-5
Pop-upmenus .......................................................................... 1-6
Database lists ........................................................................... 1-6
Chapter 2: Getting started ................................................................ 2-1
2.1 Introduction ............................................................................. 2-1
Conventionsused ..................................................................... 2-1
Simulator ................................................................................. 2-1
2.2 Switchingon/off....................................................................... 2-2
Changingthelightingandcontrast............................................. 2-2
2.3 Chartsimulator......................................................................... 2-3
2.4 Controllingthedisplay.............................................................. 2-4
Selectingthedisplaymode ........................................................ 2-4
Movingaroundthe chart ........................................................... 2-6
UsingFINDSHIP ............................................................... 2-6
Changingthechartscale ...................................................... 2-7
2.5 UsingNavionics Nav-Chart cards.............................................. 2-8
Insertinga Nav-Chartcard ........................................................ 2-9
RemovingaNav-Chartcard .................................................... 2-10
Displaying the chartdata ......................................................... 2-10
Displayingchartinformation................................................... 2-10

vi RayChart 420/420D
Chapter 3: Operation ........................................................................ 3-1
3.1 Introduction ............................................................................. 3-1
3.2 Workingwithwaypoints........................................................... 3-1
Introduction ............................................................................. 3-1
Placingawaypoint ................................................................... 3-2
Selectingawaypoint................................................................. 3-4
Waypointdata display .............................................................. 3-5
Editingthe waypoint details ...................................................... 3-5
3.3 Working with routes ................................................................. 3-8
Creatinganewroute ................................................................. 3-9
SavingtheCurrentRoute ........................................................ 3-10
Clearingthe current route fromthescreen ................................ 3-11
Retrievingaroutefrom the database ........................................ 3-11
Displayingroutelegandwaypoint information ....................... 3-12
Erasingor(re)naminga route .................................................. 3-12
Inserting/deletingwaypointsin a route................................ 3-13
3.4 Following routes and going totarget points .............................. 3-14
Followa route ........................................................................ 3-15
Reversearoute ....................................................................... 3-15
Target point arrival ................................................................. 3-16
Altera route ........................................................................... 3-16
Join a route ....................................................................... 3-16
Advanceto a waypoint ...................................................... 3-17
Goingtoan individual target ................................................... 3-18
Gotoawaypoint ............................................................... 3-18
Gotocursor ...................................................................... 3-19
Gotoa port ....................................................................... 3-19
Stopfollow or stop goto .......................................................... 3-20
3.5 Changingthe display mode ..................................................... 3-20
CDIdisplay ............................................................................ 3-21
BDIdisplay ............................................................................ 3-22
Waypoint data ........................................................................ 3-23
Navigationdata ...................................................................... 3-24
Time/DateData ...................................................................... 3-25
3.6 Transferringwaypoints and routes ........................................... 3-26
Displayedwaypoints .............................................................. 3-26
Managingdatabase lists ..................................................... 3-26

Table of Contents vii
3.7 Usingtracks ........................................................................... 3-27
Clearingthe current track ........................................................ 3-29
SmartRoute............................................................................ 3-29
3.8 Man Overboard (MOB) .......................................................... 3-29
3.9 Alarms................................................................................... 3-30
Chapter 4: Setting up the chartplotter ............................................. 4-1
4.1Introduction .............................................................................. 4-1
4.2Systemset upparameters ........................................................... 4-1
Bearingmode ........................................................................... 4-3
Keybeep.................................................................................. 4-3
Units........................................................................................ 4-3
Variation ................................................................................. 4-3
Dateformat .............................................................................. 4-3
Time offset .............................................................................. 4-4
Language ................................................................................. 4-4
Simulator ................................................................................. 4-4
SimulatedSOG ........................................................................ 4-4
SimulatedCOG........................................................................ 4-4
4.3Chartset up parameters.............................................................. 4-5
Orientation............................................................................... 4-7
Plottermode............................................................................. 4-7
Showwaypoints ....................................................................... 4-7
Waypointsymbol ..................................................................... 4-7
Autozoom ................................................................................ 4-7
Screen amplifier ....................................................................... 4-8
COGvector.............................................................................. 4-8
Arrival circle ............................................................................ 4-8
Anchoralarm ........................................................................... 4-8
XTE alarm ............................................................................... 4-8
Chart text ................................................................................. 4-8
Chart boundaries ...................................................................... 4-9
Depthcontours <5M................................................................. 4-9
Depth contours10M ................................................................. 4-9
Depthcontours>20M............................................................... 4-9
Position calibration................................................................... 4-9
4.4 GPS setup .............................................................................. 4-10

viii RayChart 420/420D
Chapter 5: Installation ...................................................................... 5-1
5.1 Introduction ............................................................................. 5-1
EMC InstallationGuidelines ..................................................... 5-1
Suppression ferrites .................................................................. 5-2
Connectionsto other equipment ................................................ 5-2
5.2 Unpackingandinspecting the components................................. 5-2
ItemsMissing? ......................................................................... 5-3
Registeringthis Product ............................................................ 5-3
5.3 Location .................................................................................. 5-3
Selecting the best location ......................................................... 5-3
5.4 Connectingtootherequipment.................................................. 5-5
5.5 Mounting the chartplotter.......................................................... 5-5
Trunnion(yoke)mounting ........................................................ 5-5
Panelmounting ........................................................................ 5-5
5.6 Cabling .................................................................................... 5-7
Introduction ............................................................................. 5-7
Chartplotter connectors............................................................. 5-7
GPSconnector .................................................................... 5-7
POWER/NMEAconnector ................................................. 5-8
5.7 SystemCheckandInitial Switch On .......................................... 5-9
EMCConformance .................................................................. 5-9
SystemCheck ........................................................................ 5-10
InitialSwitchOn .................................................................... 5-10
Checkingthe Chartplotter Operation ....................................... 5-11
Chapter 6: Maintenance & fault finding ........................................... 6-1
6.1 Maintenance ............................................................................ 6-1
Warnings ................................................................................. 6-1
Routinechecks ......................................................................... 6-1
ServicingandSafety ................................................................. 6-1
6.2 Resettingthesystem ................................................................. 6-2
6.3 Problem solving ....................................................................... 6-3
Fault finding ............................................................................ 6-3
6.4 Worldwidesupport ................................................................... 6-4
Howtocontact Raytheon Marine (US) ...................................... 6-4
Foraccessories and parts...................................................... 6-4
For technical support ........................................................... 6-4
Forproduct repair and service .............................................. 6-4

Table of Contents ix
Howto contact Raytheon Marine (Europe) ................................ 6-5
Foraccessories and parts...................................................... 6-5
For technical support ........................................................... 6-5
Appendix A: Specification ................................................................ A-1
Appendix B: NMEA data .................................................................... B-1
Appendix C: List of abbreviations .................................................... C-1
Installation Template ....................................................................... T-1

xRayChart 420/420D

Chapter 1: Overview 1-1
Chapter 1: Overview
1.1 Introduction
How this Handbook is organised
Thishandbook describes theRayChart420 Chartplotter.
Thehandbook is organised asfollows:
Chapter1- Overview (this chapter) provides anoverview of the featuresand
functionsof the RayChart 420Chartplotter. You should readthis chapter to
familiarise yourself with the chartplotter.
Chapter2-GettingStarted providesan overviewofthecontrols. It also
explains how to start using the chartplotter.
Chapters3- Operation providesdetailed operating information forthe main
chartplotterfunctions - plottingwaypoints and routes, followingroutes,
showingtracks and man overboard.
Chapter4- SettingUptheChartplotterprovides instructionsfor setting up
yourchartplotter system to suityour preferences. It includes instructionsfor
settingup a differential GPS.Youshould read this chaptertodetermine how to
setupyoursystempreferences.
Chapter5- Installationprovides planning considerations and detailed
instructions for installing the chartplotter.
Chapter6 - Maintenance& Fault Findingprovides information on user
maintenanceandwhatto do if you experience problems.
AppendixA lists the technical specifications for the Chartplotter.
AppendixBdefines the NMEA datatransmittedby the Chartplotter.
AppendixCprovides a list of abbreviationsusedinthis handbook.
AnInstallationTemplate andWarranty information areincluded at theend
ofthishandbook.

1-2 RayChart 420/420D Chartplotter
General
TheRayChart 420 Chartplotteris waterproof and canbe installed either above
orbelowdeck. The equipment comprises:
•6 inLCDdisplaywithChartholdercompartmentforaNavionics®Nav-Chart
electronic chart card
•GPSreceiver (RC420) or Differential/GPS(dGPS) receiver (RC420D)
TheRayChart 420 Chartplotter can outputGPSand Waypoint data (SOG and
COG)to operate with otherequipment,eg. an autopilot or repeaterinstrument
connectedvia the NMEA 0183 interface.
1.2 The chartplotter display
Display functions
The RayChart 420 Chartplotter includes the following functions:
•Create,Place, Move, Edit orErasea Waypoint.
•GoTo Waypoint, Port, Facility or Cursor.
•Create,Save,Name,EditorFollowa Route.
•ReviewRouteandWaypointLists.
•Displayvessel’strack on-screen; Convert a track toaroute(SmartRoute).
•SetUpAlarmsandTimers.
•ManOverBoard(MOB) to navigate back to a missingperson orobject.
•Satellite acquisition data (including a Differential GPS Setup page).
•Usespositionalinformation from GPS (RC420) or dGPS(RC420D) to
display vessel’s position.
•Thedisplayandkeyscanbeilluminated for night-time use.
Thechartplotter includes a 64nmworldmap that can be usedforroute planning.
DetailednavigationinformationisdisplayedwhenaNavionics®Nav-Chart
card is installed.
Yourvessel’sposition is shown as a boat symbol pointingin yourcurrent
direction.
Atthe top ofthe chartplotter screen astatus bar displays chartscale, cursor
positionplus range and bearing, the vessel’s position, Speed Over Ground
(SOG)andCourseOverGround(COG).
Waypointsyouhave placed are displayed and thecurrentrouteis shown. Data
can be viewed for current route or chart object.

Chapter 1: Overview 1-3
The chartplotter screen can also show additional information, depending on
yourcurrently selected options, setup selections and data availablefrom other
equipment.
Anexample chart display inits default configuration, with achart card
installed, is shown in Section1.3,Operating controls.
Severalfunctions are availableto control the displayas follows:
•Zoomin/out
•PantheDisplay.
•Centre the Chart around the Vessel.
Operation of these functions is describedin Chapter 2.
Display options
Displayoptionsare selected in System Set UpandChartSet Up as described in
Chapter 4.
1.3 Operating controls
The chartplotter is operated by means of the following controls:
•Atrackpadprovidingup, down, left, right and diagonal controlof anon-
screen cursor.
•Sixdedicated push-button (labelled) keys.
•Pop-upmenus,displayed on-screen, from which you select options.
•Databaselists,displayed on-screen, which enable you to edititems.
Note:The cursor is the cross-hairsymbol (+) visible onthedisplay. You move
thecursor with the trackpadanduse it to selectaposition or item onthechart.
Thecontrols are shown inthe following illustration. Theyare back-lit for night-
timeuse.
The following paragraphs describe the controls and on-screen facilities.

1-4 RayChart 420/420D Chartplotter
PA G E
GOTO
MOB
CLEAR
ENTER
D4667_1
TOPSHAM
EXETER
TEIGNMOUTH
EXMOUTH
TORQUAY
DARTMOUTH
PLYMOUTH
ENPORT
SALCOMBE
PORTLAND
HARBOUR
ISLE O
CAP DE
LA HAGUE
ALDERNEY
GUERNSEY
JERSEY PORTB
CSR 48°30.367'N
POS °35.636'W
128 nm
FIND SHIP ROUTES WAYPOINTS
BRG 23 °T
RNG 40.9 nm
GOTO key
PAGE key
CLEAR key
RANGE key
ENTER key
Trackpad
POWER key
Navionics®
Nav-Chart
compartment
Cursor
Primary
Function Bar
Status Bar
Trackpad and cursor
The trackpad has several functions:
•Tomove the cursor aroundthechart screen.
•Toselectanitem from a pop-up menu or databaselist.
•To adjust a control setting.
•Toenter names in databaselists .
Pressthecorresponding edge of the trackpad to movethecursor horizontally,
verticallyordiagonally; the longer you press,thefasterthe cursor moves. The
currentcursor position is shownin the status bar atthe top of thescreen.
Note:Duringmany operations you cannot move thecursoraroundthescreen,
eg.whilst a function baris displayed, the cursoris used exclusively for
selection.
The cursor is used to:
•Select a position on the chart.
•Select,accessand,ifvalid,move an item, eg. a waypoint, on the chart.
•Panthe chart display.

Chapter 1: Overview 1-5
Thecursoris context-sensitive. Some items on thescreen, suchas waypoints
andchart objects have information associatedwiththem. When you placethe
cursorover such objects, theinformationis displayed in thestatusbar. In
addition,a function bar is displayedforcertainitems. For example, when you
placethe cursor over a waypoint,thewaypointdata is displayed in thestatusbar
andthe waypoint options functionisdisplayed.
Dedicated keys
Thesekeyshavefixedfunctions.Somekeyscanbeusedintwoways:
•Press:Press the key momentarily andthenrelease it. This method is usedfor
mostkey operations.
•Pressandhold: Press thekeyand hold it down fortheperiod of time stated
(eg. 3seconds), then release it.
Whenyoupress a dedicated key, one ofthe followingoccurs:
1. Theassociatedoperationis actioned, eg. change chart scale(RANGE key).
2. Apop-upmenuisdisplayed,providingfurther options.
3. Asetof functions is displayed.
Asyoupress a key, a single audio beep confirms thekeyaction.Ifthekey-press
isnot valid for thecurrent screen or mode, threerapid beeps sound toindicate
thatnoresponse is available. If required,you canturnthekey beeps off as part
of your set up procedure(see Chapter 4).
Function bar
Thefunction bar at thebottom of the screencontainsa number of functions
whichchange according to thecurrent operation. The functionsare grouped
intorelated sets andsubsetsproviding access to thevarious functions. The
primaryfunctionbarisdisplayed when you press the ENTER key.
Thecurrentlyselectedfunction is highlighted by means of a greybackground.
Whenyouinvoke a function, one ofthe followingoccurs:
1. Theassociatedoperation is actioned, eg.GOTOWAYPOINT.
2. Asub-setoffunctions is displayed.
3. Apop-upmenuisdisplayed,providingfurther options.
4. The appropriate database list (route or waypoint) is displayed.
Aswithdedicatedkeys,whenyouinvoketheaction,asingleaudio beep
confirmsthe action. If the selectionisnot valid for thecurrentscreen or mode,
threerapid beeps indicate invalid action. Ifrequired,you can turn the keybeeps
off as part ofyour set up procedure (see Chapter 4).

1-6 RayChart 420/420D Chartplotter
Pop-up menus
Pop-upmenususually provide various options. When a pop-up menu is
on-screen,a set of associatedfunctionsis also displayed.
Usethe trackpad to select anoption fromthemenu, then use the appropriate
functionto set the option, eg.youcan specify the radius ofthewaypoint arrival
alarmandyou can set selected navigation dataon/off.
Database lists
Thewaypoints and routesthat you create onthe chartplotter are storedin
databaselists. You can view theselistsand select items forediting.
Aswithpop-upmenus, when a database list is on-screen,a setof associatedsoft
keysisalso displayed; use the trackpadto selectanitemfrom the list, then use
theappropriate function to edit theitem,eg.you can erase awaypointora route.

Chapter 2: Getting Started 2-1
Chapter 2: Getting started
2.1 Introduction
This chapter provides information, instructions and a simple exercise to allow
youtopractice using the RayChart 420 Chartplotter.Itisintended to help you
becomefamiliar with thecontrolsbefore you startusing the chartplotter for
routine navigation.
Note:There is often morethanone method of performing aparticular task.
Normaloperatingproceduresare detailed in Chapter 3. When you become
familiarwith the system youcanadapt these procedures to suityourmethod of
operation.
Conventions used
Throughoutthis handbook, the dedicated(labelled)keys are shown in bold
capitals;for example, ENTER. The functions andoptionsare shown in normal
capitals,eg.LIGHT.
Operatingprocedures,whichmayconsistofasinglekey-press,ora sequence of
numberedsteps,areindicatedbya ä symbolinthemargin.
Whentextual data is displayed onscreen,anyunavailable data is shown as
dashes,one per character.
Whereprocedures refer toSelect,thisimplies using the trackpadtohighlight a
function,then pressing the ENTERkey to action that function.
Simulator
TheChartplotter display unit includesasimulator mode, which allows youto
practiceoperating your chartplotter without datafromaGPS system. You will
need to usethe set up optionsto switch the displayto simulator mode, as
described in Section2.2, Switching on/off. You can useitin either of twoways:
•Beforethe chartplotter has been installedon yourvessel.In this case, you
onlyneed to connect theChartplotterdisplay unit to a12V dcpower supply,
fusedat 1A, connecting the redcorefrom the power lead topositive(+) and
the black core tonegative (-); see Chapter 5for fulldetails.
•Afterthe chartplotter has beeninstalled on your vessel,but while in the
marinaor at anchor.
