i70InstrumentdisplayUserreference

Chapter2:Handbookinformation
Chaptercontents
•2.1 About this handbook
•2.2 i70 Handbooks
•2.3 Before using the i70
Handbookinformation

2.1Aboutthishandbook
Thishandbookdescribeshowtooperateyourproductinconjunction
withcompatibleperipheralequipment.
Itassumesthatallperipheralequipmentconnectedtothesystem
iscompatible,correctlyinstalledandcommissionedinaccordance
withtheproductsinstallationinstruction.Thishandbookisintended
forusersofvaryingmarineabilities,butassumesagenerallevelof
productknowledge,nauticalterminologyandpractices.
2.2i70Handbooks
Thei70Instrumenthasthefollowinghandbooksavailable:
i70Handbooks
DescriptionPartnumber
Installationandcommissioning
instruction
87131
Operatinginstructions(quick
reference)
86141
Userreferencehandbook81330
Mountingtemplate87130
Additionalhandbooks
DescriptionPartnumber
SeaTalkngreferencemanual81300
i70InstrumentdisplayUserreference

2.3Beforeusingthei70
Beforeusingtheinstrumentunderwayitisimportantthatitis
properlysetupasdescribedintheinstallationinstruction.
Firsttimesetup
Thersttimetheinstrumentispoweredononly,i70provides
on-screeninstructionsfortheinitialsetup.Ifyourinstrumenthas
beeninstalledbyaprofessionalinstaller,thisprocessmayalready
havebeencarriedout.
Thersttimesetupscreenstakesyouthroughthefollowing:
•Languageselection
•Vesseltypeselection
Note:Firsttimesetupmaybebypassedifthedataisalready
availableonthesystem,e.g.viaanalreadyinstalledinstrument
display.
Calibrateessentialdata
Beforeusingthei70youmustcalibrateessentialdatatoensurethat
thereadingsdisplayedareaccurate.
UsethetransducerSetupmenu:Mainmenu>Setup>Transducer
setuptocalibrate.
•Wind
•Speed
•Depth
•T emperature
Youshouldperformtheaboveforanyinstallationaffectingthe
transducers.
Pleaserefertotheinstallationinstructionfordetailsonsettingup
theinstrumentdisplayandassociatedtransducersforrstuse.
Handbookinformation

Chapter3:Gettingstarted
Chaptercontents
•3.1 System integration
•3.2 Instrument controls
•3.3 Instrument power
•3.4 Display settings
Gettingstarted

3.1Systemintegration
Thei70Instrumentprovidesmultiplemarineinstrumentfunctionsinasingleunit.Theinstrumentdisplaysinformationreceivedfrom
transducersandothersensorsaroundtheboat.Therearemultiplepagesofinformationavailable,whichyoucancustomizetosuityour
needs.
Thediagrambelowillustratessomeofthevariousexternaldevicesthatcanbeconnectedtoyourinstrumentdisplay.
2
10 11 12
345 67
8
1
9
D12 069-1
ItemDevicetype
1.i70Instrumentdisplay
2.SeaTalkInstrumentdisplays
3.SeaTalkngInstrumentdisplays
4.MOB(connectivityviaSeaTalktoSeaTalkngconverter
i70InstrumentdisplayUserreference

ItemDevicetype
5.SeaTalkngGPSreceiver
6.SeaTalkngPilotcontrollers
7.RaymarineMultifunctiondisplays
8.AISreceiver/transceiver
9.Transducerpods
10.Analoguewindtransducers
11.Analoguespeedtransducers
12.Analoguedepthtransducers
Otherdevicesnotshown:Smarttransducers(e.g.DST800,DT800)
NMEA2000devices(e.g.trimtabcontrol,enginedata)
Gettingstarted

3.2Instrumentcontrols
Controllayoutandfunctions.
1234
D12065-1
ItemDescription
1.LEFTSOFTBUTTONPower,
brightness,cancel,back
2.UPARROWUpnavigation,AdjustUp
3.DOWNARROWDownnavigation,
AdjustDown
4.RIGHTSOFTBUTTONMenu,select,
OK,Save
3.3Instrumentpower
Poweringtheinstrumenton
1.PressandholdtheLEFTSOFTbuttonfor1second,untilthe
Raymarinelogoappears.
Theinstrumentwillloadtofavoritespageone.
Poweringthedisplayoff
1.FromanyfavoritepagepressandholdtheLEFTSOFTbutton.
After1secondapowerdownpopupwillappear.
2.ContinuetoholdtheLEFTSOFTbuttonforafurther3seconds
tocompletethepoweroff
i70InstrumentdisplayUserreference

3.4Displaysettings
Displayandsharedbrightness
Youcanchangethebrightnessoftheindividualdisplay,or
networkeddisplays.
Youcanonlyuseandsetsharedbrightnessondisplayswhich
supportsharingandareassignedtonetworkgroups.
Youwillnotbeabletosetsharedbrightnesslevelsondisplays
whichdonotsupportsharing.
Adjustingthedisplaysbrightness
Toadjustthebrightnessoftheindividualdisplay:
1.WhilstinafavoritepagemomentarilypresstheLEFTSOFT
button.
Thiswillopenthebrightnesssettingscreen.
2.UsetheUPandDOWNbuttonstochangethebrightness
percentagetotherequiredlevel.
3.PresstheRIGHTSOFTbuttontoconrmnewbrightnessandgo
backtothefavoritespageyouwereon.
AssigningANetworkGroup
Whenassignedtoanetworkgroupyoucanchangebrightnesslevel
andcolorschemeondisplayswhichsupportsharing.
Toenablesharedbrightnessandcolorschemesthedisplaymust
beassignedtoanetworkgroupasfollows:
1.NavigatetoMenu>SetUp>SystemSetUp>NetworkGroup.
Alistofnetworkgroupswillbedisplayed:
•None(default)
•Helm1
•Helm2
•Cockpit
•Flybridge
•Mast
•Group1—Group5
2.UsetheUPandDOWNbuttonstohighlighttherequiredgroup.
3.PresstheSELECTbuttontoassignthedisplayyouareusing
tothatnetworkgroup.
4.NavigatetoMenu>SetUp>SystemSetUp>
Brightness/ColourGroup.
Youwillbepresentedwiththefollowingoptions:
•ThisDisplay
•ThisGroup
5.Highlightandselecttherequiredsetting.
6.Carryoutsteps1to5onalldisplaysyouwishtoshare.
Adjustingthesharedbrightness
Sharedbrightnessisonlyaccessibleifthedisplayhasbeen
assignedtoanetworkgroup.
1.WhilstonafavoritespagepresstheLEFTSOFTbuttonto
displaythebrightnesssetting.
2.PresstheLEFTSOFTbuttonagaintoaccesstheshared
brightnesssettings.
3.UsetheUPandDOWNbuttonstochangethesharedbrightness
level.
DisplayandsystembrightnesscanalsobeaccessedviaMenu>
Displaysettings>Brightness.
Displayandsharedcolor
Thei70cansetacolorschemefortheindividualdisplayorforthe
system(ifcolorisavailableonthenetworkdisplays).
ColorsettingscanbeaccessedviaMenu>Displaysettings>
Colors.
Colorschemesavailableare:
Gettingstarted

ExampleColorScheme
Day1
Day2
Inverse
Red/Black
Changingthecolorscheme
1.Fromthecolormenuhighlightacolorscheme.
Oncehighlightedthedisplaywillpreviewtheselectedcolor
scheme.
2.PressSELECTtoconrmthecolorschemeandreturntothe
colorsettingsmenu.
Iftheunitispartofanetworkgroup,thecolorschemeselectedwill
changeonalldisplayswhicharepartofthatgroup.Ifcolorisnot
availableonthenetworkeddisplaystheywillremainunchanged.
Displayresponse
Settingthedisplayresponse
Settingtheresponsetoalowvaluewillprovideamorestable
readingofcurrentconditions.Settingresponsetoahighvaluewill
makereadingsmoreresponsive.
1.FromMenu>DisplaysettingsselectDisplayResponse.
2.UsetheUPandDOWNbuttonstoselectthedatatype:
•Speed
•Depth
•Windspeed
•Windangle
•Heading
3.PressSELECTtosettheresponsevalue:
1—15
4.PressSAVEtosavethevalueandreturntothedisplayresponse
optionsscreen.
i70InstrumentdisplayUserreference

Chapter4:FavoritePages
Chaptercontents
•4.1 Favorite pages
•4.2 Favorite page frames
•4.3 Resetting maximum, minimum and trip data
•4.4 Customizing pages
FavoritePages

4.1Favoritepages
D12070-1
Thei70presentsinstrumentdataonaseriesofpages.Youcan
haveaminimumof1andamaximumof10favoritepagesavailable,
Therearesixteendifferentpagelayoutstochoosefromwhichcan
becustomizedwithdifferentdatatypes.
Therearealsoanumberofbe-spokepagesyoucanchoosefrom.
Selectingpages
1.UsetheUP/DOWNarrowstoselectbetweentheavailable
pages.
AlternativelyusetheRolloverfeaturewithinthesetupmenutocycle
throughthepagesautomatically.
i70InstrumentdisplayUserreference

4.2Favoritepageframes
Eachpieceofinformationisdisplayedinaframewithinthepage.
Theframessupportanumberofdifferentstylesandformatsfor
presentingthedata.
Tridataframe
D12 071-1
Thetridataframeenablesdigitaldatatobedisplayedinnumerical
format.
Digitalframes
D118 39 -1
Thedigitalframesprovidesdatainanumericalformat.
Analogframes
D118 38 -1
Analogframesprovidereal-timedataintheformofananaloggauge.
Analoggaugesareonlyavailableforfulland2/3screenframes.
Maximumandminimumindicators
Maximum,minimumandaveragevalueindicatorsaredisplayedon
analogspeed,windspeedandwindanglescreens.
D118 45 -1
18 0
15 015 0
12 0
9 09 0
6 06 0
3 03 0
0
12 0 3
2
1
FavoritePages

1Minimumvalue
2Averagevalue
3Maximumvalueindictor
Graphframes
D11840-1
Graphsprovideameansofshowinghowaparticularreadinghas
changedovertime.
Bargraphframes
D118 69 -1
Therudderbarisanexampleofabargraphframe.
Multigaugeframes
Thei70providesthreemulti-gaugeframesforuseasfavoritepages
whichyoucanseebelow:
Multi-gauge—sailingvessel
D
12072-1
Multi-gauge—singleenginevessel
D
12073-1
i70InstrumentdisplayUserreference

Multigauge—twinenginevessel
D
12074-1
Trimtabframe
D
12075-1
Thetrimtabframeprovidesinformationonthepositionofthetrim
tabs.
Racetimerframe
Ra c e tim e r
START
D
12076-1
Theracetimerprovidestheabilityforupto3countdowntimers.
SeeRacetimerchapterformoredetails.
AISframe
D
12077-1
TheAISframeshowsobjectpositionsrelativetoyouvessel’s
position.
FavoritePages

Rollingroadframe
D
11861-1
Therollingroadprovideswaypointandcoursedeviationinformation.
4.3Resettingmaximum,minimumand
tripdata
Thevaluesofsomedataareaccruedovertime.Theseinclude
informationsuchatripdistance,andmaximumandaveragespeed.
Thistypeofinformationcanberesetasandwhenrequired.
Withthedatatoberesetdisplayedontheinstrumentscreen:
1.PresstheRIGHTSOFTbuttontoopenthemenu.
2.SelectQuickoptionsbypressingtheRIGHTSOFTbutton.
3.Selectresetagainstthedatayouwanttoresetandpressthe
RIGHTSOFTbutton.
i70InstrumentdisplayUserreference

4.4Customizingpages
YoucanusetheFavoritespagemenutochangeanyinstrument
pagetosuityourrequirements.Youcan:
•Editanexistingpage.
•Addnewpages.
•Deletepages.
•Changethepageorder.
•Setpagestorollover
Editinganexistingpage
Followtheseinstructionstochangethelayoutorinformation
displayedonaninstrumentpage.
1.Withaninstrumentpagedisplayedonthescreenpressthe
RIGHTSOFTbuttontoopenthemainmenu.
2.SelectFavoritespagefromthemenu.
3.SelectEditpagefromtheFavoritespagemenu.
4.UsingtheUPandDOWNbuttonsselectthepageyouwantto
edit,andthenpressSELECT.
5.UsingtheUPandDOWNbuttonsselectthedatapaneyouwant
tochange,andthenpressSELECT.
6.Highlightandselectthedatayouwishtodisplayandpress
SELECT.
7.HighlightthetickiconandpressSELECTtosaveyourchoice.
TheEditpagemenuisalsoavailablefromtheQuickoptions
menu:Mainmenu>Quickoptions>Editpage.
Addingapage
Youcanadduptoamaximumof10pagesinyourfavorites.
1.Withaninstrumentpagedisplayedonthescreenpressthe
RIGHTSOFTbuttontoopenthemainmenu.
2.SelectFavoritespagefromthemenu.
3.SelectNewpagefromthemenu.
Ifyoualreadyhavethemaximumnumberofpagessetupyou
willnotbeallowedtoaddanotherpagewithoutdeletingan
existingpagerst.Otherwiseyouwillbetakentoapagelayout
optionscreen.
4.HighlightandselecttherequiredpagelayoutandpressSELECT.
5.Youcannowselecttherequireddatatobedisplayedinyour
newpagebyfollowingtheEditinganexistingpageprocedure.
Deletingapage
Inordertodeleteapagefollowthestepsbelow.
1.FromtheFavoritepagesmenuselectDeletepage.
Ifyouhavetwoormorepagessetupyouwillbeabletodelete
apagefromyourfavoritepages.Iyouonlyhaveonepageset
upyouwillnotbeallowedtodeleteapageasyoumustalways
haveaminimumofonefavoritepage.
2.Whentheconrmdeleteisdisplayedyoucancontinuetodelete
thepagebypressingtheYESbutton.
Changingthepageorder
Followthesestepstochangetheorderinwhichtheinstrument
pageswillbedisplayed.
1.FromtheFavoritepagesmenuselectPageorder.
2.Selectthepageyouwishtomove.
3.UsingtheUPandDOWNbuttonsmovethepagetotherequired
locationandpressSAVE.
Settingpagerollover
UsingtheRolloverpagefeatureenablestheFavoritepagestocycle
automaticallywithnouserinteraction.
1.FromtheFavouritepagesmenuselectRollover.
FavoritePages
