RCA RDW2480 User manual

For service assistance and product information, please call: 1-800-968-9853.
Curtis international Ltd. 7045 Beckett Drive, Unit 15 Mississauga, ON, L5S, 2A3 www.curtisint.com
This product has been manufactured and sold under the responsibility of Curtis International Ltd
24" FRONT CONTROL, 57 DBA, STAINLESS STEEL
BUILT IN DISHWASHER
Model No:RDW2480

2
1 IMPORTANT SAFETY INSTRUCTIONS ........................................................ 5
2 RECYCLING ..................................................................................................... 8
3 INSTALLATION .............................................................................................. .10
4 TECHNICAL SPECIFICATIONS ................................................................... .11
5 BEFORE USING THE APPLIANCE ............................................................. 12
6 LOADING YOUR DISHWASHER .................................................................. 19
7 PROGRAMS AND OPTIONS TABLE ........................................................... 25
8 OPERATING THE PRODUCT ....................................................................... 26
9 MAINTENANCE AND CLEANING ................................................................ 30
10 TROUBLESHOOTING ................................................................................ 33
11 PRACTICAL INFORMATION ...................................................................... 34
12 WARRANTY CARD ..................................................................................... 35

1
3
Thank you for choosing this product.
This User Manual contains important information on safety and instructions intended to
assist you in the operation and maintenance of your appliance.
Please take the time to read this User Manual before using your appliance and keep this
book for future reference.
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
FIRE Warning; Risk of fire / flammable materials
CAUTION Injury or property damage risk
IMPORTANT / NOTE Operating the system correctly

4
INTRODUCTION
Please read this user manual and particularly the safety instructions
completely and carefully. They will save you time and effort and help to
ensure optimum dishwasher performance.
Be sure to observe all listed warnings and cautions. Look particularly for
the icons with exclamation marks inside. The information icon will also
provide important references.
WARNING: Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not
avoided, may result in injury. It may also be used to alert against unsafe
practices.
NOTICE: Indicates a potentially hazardous situation which, if not
avoided, may result in damage to the dishwasher, the tableware, the
equipment or the environment.

5
1. IMPORTANT SAFETY INSTRUCTIONS
WARNING: When using the dishwasher, follow basic precations.
Read all instructions before using the dishwasher! Save these operating
instructions and pass them on to any future user.
• Use the dishwasher only for its intended purpose as described in
this user manual. This appliance is intended for normal household use
only. Do not change the specification of the appliance. The manufacturer
disclaims responsibility for damage or injury caused by improper use of
this appliance.
• The information in this user manual must be followed to minimize
the risk of fire or explosion and to prevent property damage, personal
injury or loss of life
• Use only detergents or wetting agents recommended for use in a
dishwasher and keep them out of the reach of children.
• When loading items to be washed.
1) Locate sharp items so that they are not likely to damage the door
seal, and
2) Load sharp knives with the handles up to reduce the risk of type
injuries.
• Do not wash plastic items unless they are marked
“dishwasher safe”or the equivalent. For plastic items not so marked,
check the manufacturer’s recommendations.
• Do not touch the HEATING ELEMENT during or immediately after
use.
• Do not operate your dishwasher unless all ENCLOSURE panels
are properly in place.
• Do not tamper with controls.
• Do not abuse, sit on, or stand on the door or dish rack of the
dishwasher.

6
• The cup racks are designed to support cups, glasses and kitchen
utensils. When the cup racks are in the dishwasher do not lean on or use
the cup racks to support your body weight.
• This appliance must be grounded. In the event of a malfunction or
breakdown, grounding will reduce the risk of electric shock by providing a
path of least resistance for electric current. This appliance is equipped
with a cord having an equipmentgrounding conductor and a grounding
plug. The plug must be plugged into an appropriate outlet that is installed
and grounded in accordance with all local codes and ordinances.
WARNING:
Improper connection of the equipment-grounding conductor can result in
a risk of electric shock. Check with a qualified electrician or service
representative if you are in doubt whether the appliance is properly
grounded. Do not modify the plug provided with the appliance, if it will not
fit the outlet, have a proper outlet installed by a qualified electrician.
• Some dishwasher detergents are strongly alkaline. They can be
extremely dangerous if swallowed. Avoid contact with the skin and eyes
and keep children and infirm persons away from the dishwasher when
the door is open.
Consult a doctor immediately if detergent has been swallowed or inhaled.
• Do not remove the dishes from the appliance until the program is
complete. Some detergent may remain on the dishes.
• Check that the detergent dispenser is empty after the completion of
each wash program.

7
• Do not drink and play with the water in the appliance. Harmful residues
could be present.
• To reduce the risk of injury, do not allow children to play in or on a
dishwasher.
• When children become old enough to operate the appliance, it is the
responsibility of the parents/legal guardians to ensure the children are
instructed in safe practices by qualified persons.
• Do not leave the appliance with the open door unattended to avoid
stepping accidentally onto it.
WARNING: Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the socket.
• Do not use high pressure water sprays and/or steam to clean the
appliance.
• Ensure that there are no visible water leaks during and after the first use
of the appliance.
• To avoid floor damage and possible mold growth, do not allow wet
areas to remain around or under the dishwasher.
• To avoid dishwasher damage, do not allow water to remain in your
dishwasher systems through extended periods of freezing.
RISK OF INJURY: To avoid risk of injury, always use caution when
opening the door during or following a wash cycle as hot water or steam
may escape.

8
• Do not store or use flammable liquids or vapors in the area of the
dishwasher, near or on the appliance.
• Under certain conditions, hydrogen gas may be produced in a hot-
water system that has not been used for two weeks or more.
HYDROGEN GAS IS EXPLOSIVE. If the hotwater system has not been
used for such a period, before using the dishwasher turn on all hotwater
faucets and let the water flow from each for several minutes. This will
release any accumulated hydrogen gas. As the gas is flammable, do not
smoke or use an open flame during this time.
• Please check the water supply line periodically. It is susceptible to
breakage. It becomes less flexible as time goes by. Replace it
immediately when it is torn, cut, swollen or there is water leakage.
2. RECYCLING
Remove the door to the washing compartment when removing an old
dishwasher from service or discarding it. Ensure that the appliance
presents no danger to children while being stored for disposal. Before
disposing the dishwasher:
• Disconnect the appliance from the mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent children and pets to get closed in the
appliance.
Old appliances may contain materials that can be recycled. Please
contact your local recycling authority about the possibility of recycling
these materials.
Please check the water supply line periodically. It is susceptible to
breakage. It becomes less flexible as time goes by. Replace it
immediately when it is torn, cut, swollen or there is water leakage.
Please keep the dishwasher package out of the reach of children after
unpacking it.

9
WARNING!:
Risk of injury or suffocation! Ensure that any plastic wrappings, bags,
small pieces etc. are disposed of safely and kept out of the reach of
children.
SAVE THESE INSTRUCTIONS

10
3. INSTALLATION
WARNING: When installing the dishwasher, follow basic precautions,
including the following:
Please check the standards and local codes for placement of machine.
• Installation, maintenance and repair should be performed by a qualified installer. Work
by unqualified persons could be dangerous and may void the warranty.
• Do not operate the appliance if damaged, malfunctioning, partially disassembled or if it
has missing or broken parts.
• Before installation or service, disconnect the power supply to the work area by
unplugging the unit, “tripping” the circuit breaker or removing the fuse.
• Only connect the dishwasher to the power supply when all installation and plumbing
work is complete.
• Never connect the ground wire to gas lines, or hot water pipes, plumbing lines.
• Do not install or store the dishwasher where it can be ex-posed to below freezing
temperatures or exposed to weather.
• Dishwasher must be secured to adjacent cabinetry using the brackets provided. Failure
to do this may cause damage to property or bodily injury.
• Connect to a properly rated, protected and sized power supply circuit to avoid electrical
overload. The dishwasher is designed for an electrical supply of 120 V (volts), 60 Hz
(hertz),
AC, connected to a dishwasher-dedicated, properly grounded electrical circuit with a fuse
or breakers rated for 15 amperes. Electrical supply conductors shall be a minimum of #
16 AWG copper wire rated at 75 °C (167 °F) or higher. These requirements must be met
to prevent injury and machine damage. Consult a qualified electri-cian if in doubt.
• Do not use any extension cord or portable outlet device to connect the dishwasher to a
power supply.
WARNING: Danger of suffocation! Ensure that any plastic
wrap-pings, bags, small pieces etc. are disposed of safely and kept out of the reach of
children.

11
4.TECHNICAL SPECIFICATIONS
4
9
11
7
8
6
3
2
1
10
5
12
General Appearance
1. Upper basket with racks
2. Upper spray arm
3. Lower basket
4. Lower spray arm
5. Top nozzle (Model Depending)
6. Filters
7. Rating plate
8. Control panel
9. Detergent and rinse-aid dispenser
10. Salt dispenser (Model Depending)
11. Upper basket track latch
12. Drying Unit: This system provides
better drying performance for your
dishes.
Technical Specifications
Permissible
water
pressure
43.5-145psi
(0.3 - 10
bars)
Electrical
connection
120 V
(volts), 12
A (amps),
60Hz
(hertz)
Total power 1400 (W)
Heater power 1100 (W)
NOTICE: Because we continually
strive to improve our products, we may
change our specifications and design
without prior notice. This device
corresponds to the following directives:
UL 749 Household Dishwasher
directive.

12
5. BEFORE USING THE APPLIANCE
Preparing Your Dishwasher For
First Use
• Make sure the electricity and supply
water specifications match the values
indicated in the installation instructions for
the machine.
• Open the door of the dishwasher.
• Remove all packaging material inside
the machine.
• Set the water softener level. (See
chapter of setting the water softener)
( model depending).
• Set the rinse aid dosage (See chapter of
filling the rinse-aid and setting).
• Fill the salt container (see chapter of
filling the dishwasher salt dispenser)
(model depending).
• Fill the rinse aid compartment. (See
chapter of filling the rinse aid and setting).
• Place the dishes in accordance with the
instructions in the user manual.
• Put adequate amount of detergent into
the detergent dispenser. (See chapter of
filling the detergent).
• Make sure that the upper and lower
impellers rotate freely.
• Select program according to amount of
dirt (See chapter of Program table).
• Close the door of the dishwasher. (Push
the baskets in. Then lift the door upwards
and push until it clicks into position).
CAUTION: To prevent injuries, ensure
that your hand is not jammed or crushed
between the door and appliance
WARNING: While the appliance is
running if you open the door all functions
are automatically interrupted
CAUTION: There may be a escape of
hot steam when you open the door of
your machine. Be careful of getting
injured.
Setting the Water Softener
( Model Depending )
Dishwasher needs soft water for good
cleaning results. Hard water results in a
build-up of calcium deposits on
dishware and in the dishwasher. Your
dishwasher has a special water
softening system to remove the
hardness of the tap water. Setting this
system correctly will increase the
washing effectiveness.
Water supplies with a hardness level
higher than 9 °f (French Water
Hardness) needs to be softened.
If the hardness level of the water that
you use is above 9 °f (French standard
for water hardness) or if you are using
well water, than it is recommended to
use filter and water purification devices.
The dishwasher is programmed at the
factory setting level 1 (inactive) of water
hardness If this setting corresponds to
the hardness of your water, you do not
need to do anything more.
The dishwasher must be programmed
for the water hardness in your area.
To find out the hardness level of water
in your area, contact your local Water
Board or Determine water hardness
level by the help of test strip provided.
WARNING: If you move to a
different location, the level of water
hardness will possibly be different. It is
essential to setting again the water
hardness in order to obtain optimum
washing efficiency.

13
Test Strip ( For Models With Water Softener )
The washing effectiveness of your machine depends on the softness of the tap water. For
this reason, your machine is equipped with a system that reduces the hardness in mains
water supply. The washing effectiveness will increase when the system is correctly set. To
find out the water hardness level of water in your area, contact your local water board or
determine water hardness level by using the test strip(if available). Follow step in the
image when use the test strip.
Run water
through the
tap (1min.)
Keep the
strip in the
water (1sec)
Shake the
strip. Wait (1min.) Set the hardness level of your machine.
1
2
3
4
5
6
1
munite
1
second
1
munite
WARNING: If the water is well water or has a hardness level above 9 °f, we
recommend that you use filter and refinement devices.

14
Water Hardness Table
Level German °dH French °f British °E Indicator
1 0-5 0-9 0-6 L1 is shown on the display.
2 6-11 10-20 7-14 L2 is shown on the display.
3 12-17 21-30 15-21 L3 is shown on the display.
4 18-22 31-40 22-28 L4 is shown on the display.
5 23-31 41-55 29-39 L5 is shown on the display.
6 35-50 56-90 40-63 L6 is shown on the display.
Adjust the water hardness setting of your machine according to the level specified on
the test strip (if available).
NOTE: Hardness level is adjusted to level 1 as a factory setting.
NOTE: If you only ever use combination products in your dishwasher, you can
change the softener level.
Salt Indicator
Please check the salt indicator on the control panel to see whether there is adequate
amount of softening salt in the dishwasher or not. You need to refill the salt reservoir
with salt whenever salt warning indicator appears on the control panel of your machine.
In order to change the salt level, follow the below steps:
1. Press the Program button and hold it down when the machine is off position.
2. Turn on the machine by pressing On/Off button and continue to press Program
button at least for 3 seconds.
3. If “Hardness set” is recognized “SL” is shown for 2 seconds.
4. Release Program button. The last setting level is viewed.
5. Set the level by pressing the Program button.
6. Turn off the machine to save the setting.

15
Filling The Dishwasher Salt Dispenser
( Model Depending)
WARNING: Culinary and table salts do
not dissolve in water easily, using these
kind of salts will damage water softener
system in your machine.
NOTE: Machine can only be used by
special dishwasher salt to soften the
water. Do not use any small grained or
powdered type of salts which can easily
soluble. Using any other type of salt can
damage your machine. The manufacturer
is not liable for damages result-ing from
the use of the wrong type of salt
WARNING: Dishwasher detergent will
damage the softener assembly. Do not fill
the salt container with dishwasher
detergent.
WARNING: If the water in your area is
very soft and consistently lower than 9°f
(French Water Hardness) you do not have
to add dishwasher salt.
3 4
1 2
SALT
1.To put softener salt, first remove the lower
basket and then open the salt compart-ment
cap by turning it counter clockwise. (fig 1-2)
2.Add first fill the compartment with 1kg salt
and water (fig 3) at overflowing level If
available,using the funnel (fig 4) provided will
make filling easier.
3.Refit the cap and close it.
WARNING: Starting the machine with any
wash program is recommended after filling the
salt container, in case of any spilled salt
solutions. This prevents damage to the
machine.
NOTE: Fill the salt compartment with water
only for the first time you fill the salt
compartment.
NOTE: If the salt warning lamp on the
control panel illuminates fill the salt
compartment with salt again.
WARNING: Use softener salt specifically
produced for use in dishwashers .
WARNING: If you switch to using
detergent that does not contain salt or rinse
aid, it is important to remember to add
dishwasher salt and rinse aid.
Salt Refill Indicator
(Model Depending)
WARNING: If the salt indicator light comes
on during a program you need to wait until the
end of the program to fill the salt reservoir with
dishwasher salt.
After the salt reservoir has been filled, the refill
indicator may still be lit up if the salt con-
centration has not yet reached the correct
level. It will go out when the correct
concentration is reached.
NOTE: The salt refill indicator will be
turned off if you have programmed the
dishwasher for a water hardness below 9 °f.

16
Detergent Usage
WARNING: Use a detergent specifically
designed for use in
domestic dishwashers.
You can find powder, gel,and tablet
detergents in the market that have been
designed for household dishwashers.
Detergent should be put into the
compartment prior to starting the machine.
Add the proper detergent for the selected
program to ensure the best performance.
Use less detergent if the dishes are only
lightly soiled. Using excess detergent can
leave a film on dishes and in the dishwasher
resulting in poor wash performance. Do not
use detergent tablets for shorter wash
cycles. The tablet may not dissolve
completely, causing detergent residue on
dishes and inefficient
cleaning.
NOTE: The amount of detergent needed
depends on the cycle, load size, and soil
level of dishes. Too much detergent in soft
water may cause glass corrosion and does
not dissolve in water.
WARNING: Do not use too much
detergent if your water supply is soft.
WARNING: Keep your detergents in
cool, dry places out of reach of children. See
the detergent manufacturer’s instructions for
further information.
WARNING: Detergent tablets do not fully
dissolve with short programmes.
To prevent detergent residues on the
tableware, we recommend that you use the
tablets with long programmes.
WARNING: Do not use detergent in
Rinse cycle (model depending).
If you do not know the hardness of your
water supply, use 15 ml / 3 tsp detergent.
Increase the amount of detergent if you see
white water marks especially on the surface
of the glassware.
Should you need more information
concerning the detergent you will use,
contact detergent manufacturers directly.
Check that the detergent dispenser is empty
after the completion of each wash program
Filling The Detergent
NOTE: The dispenser should be refilled
just before the start of each program.
1. Push the latch to open the detergent
container as shown in the image( fig 1).
DETERGENT
2. Pour/put the detergent into the dispenser.
( fig 2)
3. Detergent pod has level lines inside. It is
possible to measure the right detergent
amount using these lines. Detergent pod can
take totally 40 cm³ detergent. Open the
dishwasher detergent and pour into the larger
compartment 25 cm³ if your dishes are
heavily soiled or 15 cm³ if they are less
soiled. You may have to add more detergent
into your machine, depending on the degree
of soil and on the water hardness level in
your area.
4. Close the flap of dispenser.
NOTE: The flap is always open at the end
of a program.
WARNING: Follow instructions on the
package of the detergent when using liquid
dishwasher detergent, concentrated powder
detergent, or tablet detergent.

17
WARNING: Amounts may vary if you
use liquid or concentrated powder
detergent. Tablet detergents should be
placed in detergent container.
WARNING: Deviations are possible
depending on how dirty the dishes are
and how hard the water is in your
location.
WARNING: Use only the proper
amount of detergent. Continued use of
too much detergent may cause machine
damage.
Using Combined Detergents
Detergent manufacturers also
manufacture combined detergents that
are called 2 in
1 – 3 in 1-5 in 1...
The 2 in1 detergents contain detergent+
salt or rinse aid . While using the 2 in 1
detergents, it should be observed which
functions the tablet consists of.
The other tablet detergents also have
detergent+rinse aid +salt+various extra
functions.
Generally, combined detergents produce
sufficient results under certain usage
conditions only. Such detergents contain
rinse aid and/or salt in preset amounts.
Points to consider when using this
type of products:
• Always make sure to check the
specifications of the product you will use
or whether or not it is a combined
product.
• Check if the detergent used is
appropriate for the hardness of mains
water thatma-chine is appertaining to.
• Observe the instructions on packagings
when using such products.
• If such detergents are in the form of
tablets, never put them into the interior
section or the cutlery basket of the
dishwasher. Always put the tablets into
the detergent compartment in the
detergent dispenser.
• They produce good results for certain
types of usage only. If you are using
this type of detergents, you need to
contact the manufacturers and find out
about the suitable conditions of use.
• When the conditions of use of such
products and the machine settings are
appro-priate, they ensure savings in
salt and/or rinse aid consumption.
• Contact the detergent manufacturers
if you are not obtaining good wash
results (if your dishes stay calcareous
and wet) after having used 2 in 1 or 3
in 1 detergents. The scope of warranty
for your machine does not cover any
complaints caused by the use of these
types of detergents.
Recommended usage: If you want to
obtain better results while using
combined detergents, add salt and
rinse aid into your machine and adjust
the water hardness setting and the
rinse aid setting to the lowest position.
CAUTION: Solubility of the tablet
detergents produced by different
companies can vary depending on the
temperature and time. Therefore, it is
not recommended to use such
detergents in short programs. It is
more suitable to use powder
detergents in such programs.
Warning: Should any problem,
which you have not encountered
before, arise with the use of this type of
detergents, contact the detergent
manufacturers directly.
When you give up using combined
detergents
• Fill the salt and rinse aid
compartments.
• Adjust the water hardness setting to
the highest position and run an
emptywash.
• Adjust the water hardness level.
• Make the suitable rinse aid setting.

18
Rinse - aid Usage
Rinse-aid makes dishes sparkle and helps
them to dry without spotting. Rinse-aid is
required for stain-free utensils and clear
glasses.
(!)Use only rinse-aid for domestic
dishwashers.
(!)Filling the rinse aid reservoir with
detergent will damage the reservoir. Only
pour rinse aid formulated for residential
dishwashers into the reservoir.
NOTE: When the Rinse Aid indicator
lights up, the rinse aid reservoir contains
sufficient rinse aid for 2 - 3 programs only.
When using “Tab” detergents rinse aid is
not needed.
5.9 Filling The Rinse-aid and Setting
1. To fill the rinse aid compartment, open
the rinse-aid compartment cap (Fig.A)
2. Fill the compartment with rinse aid to
the MAX level and then close the
cap.Be careful not to overfill the rinse
aid compartment and wipe up any
spills.
3. Close the cap until it click. Otherwise
water can enter the rinse aid reservoir
during a program.
In order to change the rinse aid level,
follow the below steps before turning
on the machine
1. Press the Program button and hold
it down when the machine is off
position.
2. Turn on the machine by pressing
On/Off button and continue to press
Program but-ton until “rA”
disappears from the display. Rinse
aid setting follows water hardness
setting.
3. The machine will display the last
setting.
4. Set the level by pressing the
Program button.
5. Turn off the machine to save the
setting.
The factory setting is “4”.
NOTE: If the dishes are not drying
properly or are spotted, increase the
level If blue stains form on your dishes,
decrease the level.
Level Brightener Dose Indicator
1 Rinse - aid not
dispensed r1 is shown on the display.
2 1 dose is
dispensed r2 is shown on the display
3 2 doses are
dispensed r3 is shown on the display.
4 3 doses are
dispensed r4 is shown on the display.
5 4 doses are
dispensed r5 is shown on the display.

19
6. LOADING YOUR DISHWASHER
If you properly place your dishes into the
machine, you will be using it in the best
way in terms of energy consumption,
washing and drying performance.
You can load into the lower basket such
round and deep items as pots with long
handles, pot lids, plates, salad plates,
cutlery sets. The upper basket has been
designed for dessert plates, salad bowls,
cups and glasses. When placing long
stem glasses and goblets, lean them
against the basket edge, rack or glass
supporter wire and not against other
items. Do not lean long glasses against
one another or they cannot remain
steady and may receive damage. It is
more appropriate to locate the thin
narrow parts into the middle sections of
baskets. You can place spoons among
the other cutlery sets in order to prevent
them from sticking to one another.
You are recommended to use the cutlery
grid in order to obtain the best result. To
avoid any possible injuries, always place
such long-handle and sharp-pointed
dishes as serving fork, bread knife etc.
with their sharp points facing down or
horizontally on the baskets.
WARNING: Place your dishes into
your machine in a way that they will not
prevent the upper and lower spray arms
from spinning.
NOTE: Place all large and very dirty
items in the lower rack.
WARNING: Do not put in the
appliance items that can absorb water
(sponges,household cloths).
NOTE: Place all containers such as
cups, glasses and pots into the
dishwasher with the opening facing
downwards (so that no water can collect).
NOTE: Dishes and cutlery should not
be placed above each other.
NOTE: Do not overload your
dishwasher and pay attention to
manufacturer instructions regarding
dishes
which are appropriate for use in a
dishwasher. Only with suitable dishes
(mentioned in section 5) will you obtain
optimal washing results with a sensible use
of energy.
High temperature water and dishwasher
detergent may form a chemical synthesis
that can damage certain items.
WARNING: Be careful when loading
and unloading sharp items. Load sharp
knives with the handles up to reduce the
risk of personal injury.
Follow the below steps before loading
dishwasher.
1. Open the door.
2. Remove coarse food leftovers from
tableware.
3. Load the dishwasher.
NOTE: While the appliance is running
if you open the door all functions are
automatically interrupted. Once the
door is closed functions will continue
to work.

20
Upper Rack
Load the upper rack with dessert plates,
cups, glasses etc.
Top rack load
pattern for 10
place settings.
Additional
Loading
Pattern 12
place settings
Lower Rack
You can load into the lower basket such
round and deep items as pots with long
handles, pot lids, plates, salad plates,
cutlery sets. The lower rack should not
be used for small items such as cups,
wine glasses.
Bottom rack load
patterns for 10
place settings.
Additional Loading
patterns 12 place
settings
NOTE: Place all large and very dirty
items in the lower rack.
WARNING: Large knives and other
utensils with sharp tips and edges must
be placed horizontally into the upper rack
due to risk of injury. Other smaller knives
and sharp utensils should be placed with
sharp side down in the cutlery basket.
NOTE: Make sure that large items do
not interfere with the rotation of the spray
arms, and do not prevent the detergent
dispenser from opening.
Loading cutlery basket
(Model Depending)
Cutlery Basket load pattern for
12 place settings .
1: Salad Fork
2: Teaspoon
3: Dinner fork
4: Knife-solid handle
5: Serving spoon
6: Serving fork
WARNING: Sharp cutlery may have
shifted position during the wash
operation and can be also wet and
slippery. Carefully remove them to
prevent injury.
NOTE: Small items should therefore
be placed in the cutlery tray or cutlery
basket (model depending). Because
small items can fall through the holders
from the baskets.
