RCA DVR2080 User manual
DVR2080/DVR2160
Digital Video
Recorder
User’s Guide
TOCOM 16395340
English/Français/Español
16395340_Cover 8/5/04, 5:28 PM1
Important Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICING PERSONNEL.
The lightning ash with arrowhead symbol, within an equilateral triangle,
is intended to alert the user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may be of sufcient magni-
tude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
Caution: To prevent electric shock, match wide blade of plug to wide slot,
fully insert.
Product Registration
Please ll out the product registration card (packed separately) and return it immediately.
Returning the card allows us to contact you if needed.
Product Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it
here and record the serial and model numbers in case you need them. These numbers are located
on the product.
Model No. _______________________________________________________________
Serial No. _______________________________________________________________
Purchase Date: ___________________________________________________________
Dealer/Address/Phone: _____________________________________________________
Cautions on Installation
Noise or disturbance of the picture may be generated if this unit or any other electronic
equipment using microprocessors is used near a tuner or TV.
If this happens, take the following steps:
• Install this unit as far as possible from the tuner or TV, but no further than 15 feet for
1394 cable.
• Set the antenna wires from the tuner or TV away from this unit’s power cord and input/
output connection cords.
• Noise or disturbance tends to occur particularly when using indoor antennas or 300 ohms
feeder wire. It is recommended that you use outdoor antennas and 75 ohm coaxial cables.
16395340_Cover 8/5/04, 5:28 PM2
Safety Information
1
Safety Instructions
1. Read Instructions – All the safety and operating instructions should be read before operating
this device.
2. Heed Warnings – All warnings on the device and in the User Manual should be adhered to.
3. Follow Instructions – All operating and user instructions should be followed.
4. Water and Moisture – The device should not be used near water – for example, near a bath-
tub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, and
the like.
5. Ventilation – The device should be situated so that its location or position does not interfere
with its proper ventilation. For example, the appliance should not be situated on a bed, sofa,
rug, or similar surface that may block the ventilation openings; or, placed on a built-in instal-
lation, such as a bookcase or cabinet that may impede the ow of air through the ventilation
openings.
6. Heat – The device should be situated away from heat sources such as radiators, heat registers,
stoves, or other appliances (including ampliers) that produce heat.
7. Power Sources – The device should be connected to a power supply only of the type de-
scribed in the operating instructions or as marked on the device.
8. Power-cord Protection – Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them, paying particular attention
to cords at plugs, convenience receptacles, and the point where they exit from the appliance.
9. Non-use Periods – The power cord of the device should be unplugged from the outlet when
left unused for long periods of time.
10. Object and Liquid Entry – Care should be taken so that objects do not fall and liquids are not
spilled into the enclosure through the openings.
11. Damage Requiring Service – The device should be serviced by qualied service personnel
when:
a. The power-supply cord or the plug has been damaged; or
b. Objects have fallen, or liquid has been spilled into the enclosure; or
c. The device does not appear to operate normally or exhibits a marked change in perfor-
mance; or
d. The device has been dropped, or the enclosure damaged.
12. Servicing – The user should never attempt to service the device beyond that described in the
operating instructions. All other servicing should be referred to qualied service personnel.
16395340_00 8/5/04, 5:28 PM1
Table of Contents
2
Chapter 1: Overview and Setup
Introduction ........................................................................................................................3
Requirements ......................................................................................................................3
List of Contents ..........................................................................................................................3
Device Description..............................................................................................................3
DVR Front.................................................................................................................................... 3
DVR Back .....................................................................................................................................4
Things to Consider Before You Connect...........................................................................4
Ensure Proper Ventilation of the DVR......................................................................................4
IEEE-1394 Cables: 4-Pin and 6-Pin.........................................................................................5
Protect Against Power Surges ................................................................................................... 5
Connecting the DVR...........................................................................................................5
Connecting Other IEEE 1394 Devices ..............................................................................5
Component Connection Methods..............................................................................................6
Incorrect Hub Connection.......................................................................................................... 7
When Connecting Other IEEE 1394 Devices...........................................................................7
Adding IEEE 1394 Devices Automatically................................................................................7
DVR Device Conguration .................................................................................................7
Recording Device Setup .....................................................................................................8
DTVLink Recording...................................................................................................................... 9
Chapter 2: Using the DVR
Using the DVR................................................................................................................... 11
Controlling Live TV........................................................................................................................... 11
Pausing Live TV and Recorded Shows..................................................................................... 11
Transport Functions.................................................................................................................. 11
RECORD............................................................................................................................................. 11
STOP................................................................................................................................................... 11
Fast FORWARD and Fast REVERSE Playback ................................................................................12
PAUSE, Frame Advance, and Multi-speed Slow Motion..............................................................12
Instance Replay and Jump Ahead...................................................................................................13
Next and Previous Track..................................................................................................................13
Deleting Recorded Programs (Tracks).....................................................................................13
Status Bar..................................................................................................................................14
Program Information (TV's Channel Banner).........................................................................14
TV's Recordings Menu..............................................................................................................15
Chapter 3: Other Information
Troubleshooting ................................................................................................................16
Specications....................................................................................................................17
Limited Warranty .............................................................................................................18
Copy-Protected Materials ...............................................................................................19
Care and Cleaning ............................................................................................................19
FCC Declaration of Conformity.......................................................................................20
16395340_00 8/5/04, 5:28 PM2
Chapter 1: Overview & Setup
Illustrations contained in this document are for representation only.
Chapter 1 3
Introduction
The Digital Video Recorder, or DVR, is designed specically for recording and playback of High
Denition Television (HDTV). The DVR connects to a Digital Television (DTV) via DTVLink® (IEEE
1394) to offer control over digital video playback. Think of it as a “tape-less” digital VCR for
digital television. You can pause, fast forward, reverse, or use instant replay, so you’ll never miss
a moment. But unlike a traditional VCR where you wait for a program to nish recording before
you start watching it, the DVR allows you to “Pause Live TV.” This means you can pause, rewind,
and play back a digital program as it is being recorded without losing any of the recording.
Record all of your favorite digital programs while maintaining the same high quality digital
picture that it was broadcast in.
The DVR is sometimes referred to as an Audio Video Hard Drive (AVHD).
Requirements
Digital Television with at least one IEEE 1394 jack and support of Audio/Video commands (AV/C)
List of Contents
• DVR Unit
• A/C Power Cord
• IEEE 1394 Cable
• User's Guide
Device Description
DVR Front
The front of the DVR has a clean professional look to coincide with your other high-end audio/
video equipment. It has backlit text display to indicate the status of the unit.
• POWER – illuminated when the unit is plugged in to an AC power source.
• PLAY – illuminated when a previously recorded program is being played back.
• RECORD – illuminated while a new program is being recorded for future playback.
Note: The DVR can record and play back different programs at the same time or can play back the program currently
being recorded. During these instances, both the RECORD and PLAY lights are illuminated.
DTVLink® Certication Logo is a U.S. registered mark of CEA.
16395340_1 8/5/04, 5:28 PM3
Overview & Setup
4 Chapter 1
Illustrations contained in this document are for representation only.
Overview & Setup
Chapter 1 5
Illustrations contained in this document are for representation only.
DVR Back
The back of the DVR has two 6-pin DTVLink® or IEEE 1394 ports and an A/C power cord connector.
Devices using IEEE 1394 interface can be connected to either port. Devices certied as DTVLink
use the same IEEE 1394 interface but also include advanced copy protection schemes to send and
receive encrypted or copy protected content.
Things to Consider Before You Connect
Ensure Proper Ventilation of the DVR:
• Leave at least 4 inches (10 cm) of space between the top and back of the DVR and a wall,
shelf, or other component.
• Leave at least 1” (2.5 cm) of space on the front and sides.
• Do not block ventilation holes on any of the components.
• Arrange the components so that air can circulate freely.
• Do not stack components on top of the DVR.
• When you place components in a stand, make sure you allow adequate ventilation.
• If you connect an audio receiver or amplier, place it on the top shelf so the heated air from
it won’t ow around other components.
DVR Top View
DVR Front View
Note: The DVR uses an internal fan to ensure proper
cooling of the electrical circuits and the AV hard drive.
Upon startup, the fan will briey run at 100% and then
quickly slow down to the minimal speed required to cool
the unit.
DTVLink (1394) Ports AC Power Cord Connector
16395340_1 8/5/04, 5:28 PM4
Overview & Setup
4 Chapter 1
Illustrations contained in this document are for representation only.
Overview & Setup
Chapter 1 5
Illustrations contained in this document are for representation only.
IEEE-1394 Cables: 4-Pin and 6-Pin
There are two different types of connectors used on IEEE 1394
devices: a 4-pin connector, and a 6-pin connector.
The 4-pin connector is capable of sending digital audio signals,
digital video signals and digital control signals back and forth
between devices. The 6-pin connector is capable of sending the
same data and signal information as the 4-pin but has two
To connect the DVR to a DTVLink enabled TV, follow these steps:
1. Connect the female end of the AC power cord to the DVR and male end into an AC outlet
or surge protector.
2. Connect the 1394 cable to any DTVLink port on the HDTV and to either DTVLink port on
the DVR.
INPUT 1
L
RS-VIDEO
V
CABLE
INPUT
ETHERNET G-LINK
TV
DIGITAL
AUDIO
OUTPUT
AUDIO/VIDEO
OUTPUT
V
RL
CableCARD™
COMPOSITE INPUTS
INPUT 2
ANTENNA INPUT
COMPONENT/COMPOSITE INPUTS
Use menu for composite video.
L
RPRPB
Y/VIDEO
HDMI/DVI INPUT
Use menu for DVI audio.
POWER
(AC 120V~60Hz)
FIXED/VARIABLE AUDIO OUTPUTS
EXTERNAL AMP
MAX POWER RATING!
(60 WATTS into 8 OHMS)
CENTER SPEAKER INPUT
SUBWOOFER
CENTER R REAR L REAR
MATRIX
SURROUND
OUTPUTS
RL
WIRED
IR
INPUT 3
L
RS-VIDEO
V
INPUT 4
L
RP
R
P
B
Y/VIDEO
additional pins for sending low voltage electrical power. The purpose of this electrical power is to
provide the needed operating power to a device that is not connected directly to the household
AC power such as some camcorders. The DVR uses 6-pin IEEE 1394 connectors but does not supply
power to other devices. To connect other devices, such as a digital camcorder, that uses a 4-pin
connector, you need to obtain a 4-pin to 6-pin adapter cable. These cables are available from
electronic and computer stores.
Note: When the DVR is connected to an RCA HDTV, the HDTV does not supply power to the DVR. The DVR must be
plugged into a source of power (wall outlet).
Protect Against Power Surges
• Connect all components before you plug any power cords into the wall outlet.
• Turn off the TV and/or component before you connect or disconnect any cables.
• Make sure all antennas and cables are properly grounded.
Connecting the DVR
16395340_1 8/5/04, 5:28 PM5
Overview & Setup
6 Chapter 1
Illustrations contained in this document are for representation only.
Overview & Setup
Chapter 1 7
Illustrations contained in this document are for representation only.
Connecting Other IEEE 1394 Devices
One of the great advantages to 1394 components is the ability to connect one device to the next
in a single chain. This is known as “daisy-chaining.” Previous audio and video components often
required connections of each component to a single source such as an audio/video receiver or TV.
With IEEE 1394, simply connect one device to the next in a continuous chain using 1394 cables.
The 1394 interface reduces the number of cables needed to connect each device and simplies
the connection process. There is no need to ensure that you are connecting the correct audio or
video cable to the correct jack. IEEE 1394 devices use a single cable to transfer audio, video, and
interface data between all devices connected within the chain.
The DVR has two 1394 ports. This allows you to use one port for connection to your digital
television and still have another port for connection of additional 1394 components. Each
compatible DTVLink device connected on the IEEE 1394 chain is shown on the TV. Information can
be sent between 1394 connected components. DTVLink and other compatible components can be
controlled from your TV.
Component Connection Methods
There are two ways to connect IEEE 1394 and DTVLink devices: component-to-component and
hub connection. The component-to-component method has each component connected in a
chain-like fashion, with the DTV as the rst component. The hub method is basically the same but
uses both 1394 jacks on the DTV with two chains of components connected to it.
Note: Use a single 1394 cable to connect one device to any available 1394 port on the next device. If devices such as a
digital camera only have one 1394 port, these devices should be placed at the end of the 1394 chain.
16395340_1 8/5/04, 5:28 PM6
Overview & Setup
6 Chapter 1
Illustrations contained in this document are for representation only.
Overview & Setup
Chapter 1 7
Illustrations contained in this document are for representation only.
Incorrect Hub Connection
Some IEEE 1394 devices have more than two ports. These devices can act as a hub allowing you
to branch out the 1394 chain. This provides increased exibility in the device location and cable
routing of additional 1394 devices. Ensure that you do not connect to a device already in the
1394 chain. There should be only one path between any two devices.
When Connecting Other IEEE 1394 Devices
• No two 1394 components should have more than one connection path between them. Do
not loop the last device in the chain back to the TV. If the component chain is connected in a
loop, the TV may not be able to work with any of the other devices.
• Place devices that have only a mechanical (two-position) power switch at the end of the
chain or leave the power switch in the ON position. When turned OFF, IEEE 1394 signals may
not be able to pass through the device to other devices.
• If a device only has one 1394 port, place it at the end of the 1394 chain.
• Place the slower components at the end of the chain and the faster ones closest to the TV in
the chain for faster communication speed. See component's guide for 1394 network speed.
• Do not use an IEEE 1394 cable longer than 15 feet between each device or from device to the
TV.
Adding IEEE 1394 Devices Automatically
When an IEEE 1394 device is connected into the TV network and is powered ON, the new device
may automatically be recognized by the TV. This is called “device discovery” and can take up to
1 minute. Some non-audio/video or non-compatible IEEE 1394 devices, such as Personal
Computers (PCs), may not announce their presence to the TV. The TV does not show these devices
in the input list, however, they may still be available to other devices on the IEEE 1394 network
that are compatible with these non-audio/video devices.
DVR Device Conguration
Once connected, the following outlines how to congure and use the DVR with some RCA HDTVs.
If you are using the DVR with other DTVLink enabled televisions, consult your TV Owner’s Manual
for Audio/Video Hard Drive (AVHD) conguration and use.
Don't Loop Connections
16395340_1 8/5/04, 5:28 PM7
Overview & Setup
8 Chapter 1
Illustrations contained in this document are for representation only.
Overview & Setup
Chapter 1 9
Illustrations contained in this document are for representation only.
Channel Search
2
�
�
�
Recording Device Setup
To record digital content to the DVR, you may need to set up the Recording Device screen from
the TV’s Connections menu. Use the MENU button on the TV's remote control to access the
Connections menu and set up the DVR as a preferred recording device through the DTVLink (1394)
connection.
1. Press TV button on the TV remote to put the remote into TV mode.
2. Press MENU on the TV’s Remote control.
3. Use the Down Arrow to highlight Connections and press OK or right arrow (4) on the
remote.
4. Highlight DTVLink Setup and press OK or right arrow (4) on the remote.
5. Highlight Recording Device and press OK or right arrow (4) on the remote.
Note: The “DTVLink Connect” menu is for recognizing and conguring some DTVLink devices, that require an
additional analog connection, and does not pertain to the DVR.
The Recording Device screen conveys to the TV which DTVLink component is capable of receiving
transport commands (e.g., Record, Play, etc.) when a DTVLink component is not currently being
tuned. With this screen, you can select the default DTVLink recorder and the functionality level
for a DTVLink recording device. When the DVR is connected and powered on, it appears at the
top of the screen. If you have more than one DTVLink recording device, you may need to highlight
the Recording Device eld at the top of the screen. Press OK to scroll through the DTVLink
components and select the DVR you would like to be the default recording device for digital.
16395340_1 8/5/04, 5:28 PM8
Overview & Setup
8 Chapter 1
Illustrations contained in this document are for representation only.
Overview & Setup
Chapter 1 9
Illustrations contained in this document are for representation only.
The three functionality levels give you more exibility in the conguration of DTVLink recording.
• Select the rst level if a DVCR is connected and you want to use as the default recording
device. When you select RECORD, the digital program is streamed to your digital recorder but
the TV stays tuned to the channel you're watching without tuning to the digital recorder's
input on the TV.
• Select the second level if you don't want continuous recording (buffering), but want to
manually autotune to the DTVLink component by pressing RECORD. Pressing RECORD while
watching a digital program tunes to the DTVLink device and begins recording. This lets you
watch the program you're recording and use Instant Replay, Jump Ahead, and time-shifting
while still recording the program.
• Select the third level if you want to continuously record (buffer) digital programs and
autotune the TV to the DTVLink component by pressing most transport buttons. When the
DVR is turned on, it begins recording digital channels. The continuous recording creates a
temporary "live-TV" buffer by continuously recording a digital channel.
The maximum space allowed for the temporary information varies depending on the bitrate
of the programming. It could be many hours if the bitrate is low to approximately 3.5 hours
of full-stream ATSC. For QAM channels (common on cable systems), the space is anywhere
from 1.75 hours for really good HD programming to many hours, if the bitrate is low. The
better the quality of the digital signal, the more memory it takes to record the picture
which shortens the recording time. The scan lines (resolution) for the digital stream you are
receiving are displayed in the TV's INFO banner.
Note: If you don’t choose level 2 or 3, pressing RECORD only starts the recording— it doesn’t switch the TV to the
DVR’s DTVLink input—(you’ll need to use the INPUT button to channel through the inputs).
DTVLink Recording
The DVR uses the 2-way IEEE 1394 interface for connection to compatible digital televisions.
This allows you to control the DVR’s record and playback functions using the TV remote in the TV
mode.
You should know:
• Only digital content (ATSC and QAM signals) can be recorded. Analog TV programs (NTSC
signals) cannot be output or recorded through the TV’s DTVLink jack.
• Only the subchannel you are watching can be recorded. For more information about
subchannels, see page 14.
• When an on-screen guide is built into your TV, any guide-based recording takes precedence
over the DTVLink recording.
• The DVR has built-in hardware for support of copy protection standards and is able to record
authorized copy protected content. If the content provider does not authorize content
recording of any type, the program cannot be recorded to the DVR.
• The remote must be in the TV mode to enable transport functions, such as RECORD, STOP,
FAST FORWARD, REVERSE, PAUSE, and PLAY.
• If you're recording and you change the TV to an analog or digital channel, you are warned
that the recording may be stopped and asks if you really want to change channels. If you
change to a digital channel, the new digital channel is recorded. If you change to a video
input, the channel you were recording continues to record. Changing to analog stops
recording and the program is lost. This functionality is only available when the AVHD is
congured in the DTVLink Setup menu for the second or third levels of conguration.
16395340_1 8/5/04, 5:29 PM9
Overview & Setup
10 Chapter 1
Illustrations contained in this document are for representation only.
• A status bar provides on-screen feedback when recording and playing back programs. See
page 14.
• A scheduled recording takes place even if the TV's Parental Control has blocked the source.
To schedule a timed DTVLink recording, use the Record/Wake Timer screen. Ensure the DVR is
selected in the Recording Device menu and see your TV Owner’s Manual for more information on
scheduled recordings.
You can also schedule a timed recording by using your TV's built-in, on-screen program guide (if
available in your TV). See TV User's Guide for details.
16395340_1 8/5/04, 5:29 PM10
Illustrations contained in this document are for representation only.
Chapter 2 11
Chapter 2: Using the DVR
Using the DVR
Controlling Live TV
The DVR gives you the power to watch television the way you have always wanted. You can
watch what you want to watch, when you want to watch it. You can also control what you are
watching like never before.
Whether it’s the big game, that classic movie, or your favorite soap, you’re in control if you select
Level 3 for the DVR. Then the digital program begins recording to your DVR and enables you to
Stop, Pause, or even Rewind the digital program that you are watching. Press the Left Arrow for
an Instant Replay of the last 7 seconds or the Right Arrow to Jump Ahead 30 seconds. Press OK to
go to "live" and catch back up with the current action.
You can even Pause the program to answer the phone without missing one minute. Just press
PLAY to begin right where you left off or press OK to go back to "live." You can use the Jump
Ahead feature (right arrow) or Fast Forward to catch up to the “live broadcast.”
Pausing Live TV and Recorded Shows (Level 2 or 3)
The Pause feature lets you attend to interruptions without missing a moment of your favorite
digital-TV show. You can pause whatever you’re watching, whether it’s a live television broadcast
you’re currently recording or a previously recorded show. When you Pause a live broadcast, the
DVR continues to record so you won’t miss a single moment.
Transport Functions
Transport Functions are commands that most people are familiar with from using a standard
VCR. They include: RECORD, STOP, FORWARD, REVERSE, PAUSE, and PLAY. Pressing the transport
buttons on the remote control causes the DVR to act like a Digital VCR with a few bonus features.
When the TV is tuned to a DTVLink device, the commands are sent to that DTVLink device.
RECORD (Level 2 or 3) (not using TV's on-screen guide)
If the TV is set up to auto tune as previously described, pressing RECORD automatically tunes the
TV to the DVR’s DTVLink input and begins recording.
Note: If you use the TV's on-screen guide, highlight the digital show in the Listings that you want to record, press
RECORD. The recording automatically stops when the show is scheduled to end.
STOP (not using TV's on-screen guide)
Pressing STOP during a recording ends the recording process. If a STOP command is issued when
recording and playing back simultaneously, the TV stops the recording, but keeps the playback
going. Pressing STOP again will stop the playback.
16395340_2 8/5/04, 5:29 PM11
Using the DVR
12 Chapter 2
Illustrations contained in this document are for representation only.
Using the DVR
Chapter 2 13
Illustrations contained in this document are for representation only.
Fast FORWARD and Fast REVERSE Playback
The DVR gives you the power to Fast Forward or Fast Reverse through both live (currently
recording) and previously recorded programs. You cannot Fast Reverse a program to a point
before you started recording it, nor can you Fast Forward a program to a point beyond the live
broadcast.
To use Fast Forward while watching a show:
1. Press FORWARD for 3x Fast Forward.
2. Press FORWARD again for 15x Fast Forward.
3. Press FORWARD again for 60x Fast Forward.
4. Press PLAY or STOP, to stop Fast Forwarding.
Note: Pressing REVERSE from 60x Fast Forward takes you to 15x Fast
Forward and so forth.
To use Fast Reverse while watching a show:
1. Press REVERSE for 3x reverse playback.
2. Press REVERSE again for 15x Reverse playback.
3. Press REVERSE again for 60x Reverse playback.
4. Press PLAY or STOP to stop Reverse playback.
Note: Pressing FORWARD from 60x Reverse takes you to 15x Reverse and so forth.
Note: The appearance of your TV
remote may vary.
When using FORWARD to advance through a recording or track, the DVR moves through that
recording until it reaches the end of the recording and stops. The same applies to REVERSE, but it
takes you to the beginning of the recording.
PAUSE, Frame Advance, and Multi-speed Slow Motion
Press PAUSE to pause the screen during the watching and/or recording of live programs and
playback of previously recorded programs. If PAUSE is pressed during a recording, the TV pauses
the playback but keeps the recording going.
Frame advance and multi-speed slow motion are used in conjunction with PAUSE. Press the
PAUSE button repeatedly for a frame-by-frame advance. Press the FORWARD and REVERSE
buttons for slow motion playback.
To use Pause, Frame Advance and Multi-speed Slow Motion while watching a show:
1. Press PAUSE to pause the screen.
2. Press and hold PAUSE (or press PAUSE repeatedly) to advance a single frame at a time.
3. Press FORWARD or REVERSE for 1/8 speed normal speed slow motion
4. Press FORWARD or REVERSE again for 1/4 speed normal speed slow motion.
5. Press FORWARD or REVERSE again for 1/2 peed normal speed slow motion.
6. Press FORWARD or REVERSE again or PLAY at any time for normal speed playback.
Other Pause options include:
• Press INFO to view program information.
• Press CLEAR to remove the on-screen display.
Note: If a program has been paused for more than a few minutes, a screen saver appears to prevent damage to TVs
that are susceptible to screen burn, like TV's that have picture tubes or CRT-based projection screens.
16395340_2 8/5/04, 5:29 PM12
Using the DVR
12 Chapter 2
Illustrations contained in this document are for representation only.
Using the DVR
Chapter 2 13
Illustrations contained in this document are for representation only.
Instant Replay and Jump Ahead
You only look away for a few seconds but you know you missed something big. Maybe it was just
too great of a moment to only see once. The Instant Replay feature lets you jump back 7 seconds
during a live or recorded show. It’s the perfect way to ensure you don’t miss a single word of
dialog in your favorite movie, or if you want to watch a great play over again.
You can use the Jump Ahead feature to quickly skip 30 seconds ahead during delayed or recorded
shows. Jump Ahead is perfect for jumping past programs and undesired scenes without having to
watch them as you would using Fast Forward.
To use Instant Replay while watching a live or recorded show:
• Press Left Arrow on the TV’s remote control to replay the
previous 7 seconds in the recording.
• Press repeatedly to leap back in 7-second intervals.
To use Jump Ahead while watching a recorded or delayed show:
• Press Right Arrow on the TV’s remote control to jump ahead 30
seconds into a recording.
• Press repeatedly to leap ahead in 30-second intervals.
Next and Previous Track (Program)
Next and Previous Track features allow you to jump quickly to
the next or previously recorded program on the DVR. Press the Up
Arrow to skip to the next track. Press the Down Arrow to skip to
the previous track. The track being played and the total number of
tracks recorded is shown in the channel banner when the track is
changed. (See below.)
Note: Use CH+/CH- to tune to different subchannels (if available) on each
track/program.
Deleting Recorded Programs (Tracks)
When the digital video recorder's hard drive is full, a message appears on screen. In order to
be able to record additional content on the recorder, you must delete some of the recorded
information. Some TVs that do not have a Recording list use the CLEAR button to delete the track
that is presently being played. A yes/no conrmation screen may appear.
To delete a track/program:
1. Press MENU.
2. Highlight Recording menu and press OK.
3. Use arrows to highlight the program you want to delete.
4. Press OK.
5. Select Delete from the on-screen display.
6. Select Yes from the on-screen display.
7. Repeat the process described above to delete additional tracks.
16395340_2 8/5/04, 5:29 PM13
Using the DVR
14 Chapter 2
Illustrations contained in this document are for representation only.
Using the DVR
Chapter 2 15
Illustrations contained in this document are for representation only.
Status Bar
The TV's status bar provides on-screen feedback when watching, recording, and playing back
programs on the DVR. The left side of the bar displays the time when the recording is started. The
right side of the bar displays the current time as well as representing "live" time. If you play back
a recorded program, the left side begins at 00:00:00 and the right side shows the total program
duration in HH:MM:SS.
You will notice that the bar color changes from Yellow to Red when a recording is started. Icons
for PAUSE, FWD, REV, PLAY, RECORD, STOP, LIVE, INSTANT REPLAY, and JUMP AHEAD appear
when a transport button is pressed. If you want to see the status bar, just press the INFO button
when tuned to the DVR.
If an icon in the channel banner is grayed out (dim), the feature is not available. The following list
describes the items on the Channel Banner screen applicable to the DVR. Other displays that are
not described here are self-explanatory or further explained in the television user's guide.
Subchannel - Sub-channel and the station call letters, if available. For the different
sub-channels, press the CH+ or CH- buttons.
Note: Digital channels are often noted by the use of a sub-channel. (Channel 2 may denote an analog
channel while channel 2-1 is often a digital version of the channel 2 broadcast.)
Track – Displays the total number of recorded programs or tracks on the DVR and which track
is currently being displayed. Press the Up/Down Arrow buttons to scroll through the track
numbers (recordings) recorded on the DVR.
DTVLink - DVR model is listed when playing from the device.
16:9 1080i HD - Aspect ratio (4:3 or 16:9); original resolution of the broadcast (e.g., 480i,
1080i, etc.), not the resolution of the TV; HD denotes High Denition and SD denotes Standard
Denition digital broadcasts; screen format (for example, Normal, Zoom, etc.)
00h:00m:00s of 00h:00m:00s – Denotes the present location within the total recorded time
of a program or track.
Program Information (TV's Channel Banner)
At any time while recording a digital program or playing back a recorded program, you can press
the INFO button on your remote control to get more information from the channel banner. The
program name, channel, track number, DTVLink recording device, and elapsed time for DTVLink
recordings appear in the channel banner.
16395340_2 8/5/04, 5:29 PM14
Using the DVR
14 Chapter 2
Illustrations contained in this document are for representation only.
Using the DVR
Chapter 2 15
Illustrations contained in this document are for representation only.
TV's Recordings Menu
The Recordings menu allows you to view the list of programs you've recorded to components
connected to your DTVLink jacks. When you highlight and select a program with OK, the options
Cancel, Play, and Delete appear. To play a program listed, highlight Play and press OK or highlight
a program and press PLAY. The program starts playing in the small video window. To view full
screen, press CLEAR or MENU.
You can see other DTVLink component's recordings by pressing the INPUT button with this menu
displayed.
Web Browser
8
�
Note: This menu screen does not apply to DVCR models.
16395340_2 8/5/04, 5:29 PM15
16 Chapter 3
Chapter 3: Other Information
Illustrations contained in this document are for representation only.
Other Information
Chapter 3 17
Illustrations contained in this document are for representation only.
Troubleshooting
DVR won’t work
• Try unplugging the AC power cord and plugging it back in at both ends.
• Make sure the DVR is connected and cables are seated properly.
• If the unit doesn’t appear on the TV or set-top box screen, unplug the 1394 cable (DTVLink)
and reconnect.
• Make sure TV is tuned to the DVR video input.
Program(s) not recorded
• Make sure you have selected a digital channel; the DVR does not record analog channels.
• If the channel is changed when the DVR is recording, the DTV may stop sending the program
and the recording process ends.
• Check the timed recording in the Record/Wake Timer screen on the TV to make sure the
correct channel and tuner were selected. Also, check listing in TV's built-in on-screen guide,
if available.
• When playing back a recorded sub-channel, you might have to channel through the sub-
channels to get to the sub-channel you recorded. Press CH+ or CH-.
DVR Too Hot
• If the DVR is currently “playing” content and senses an over temperature condition, it
will display a warning. The DVR has built-in sensors that monitor the unit's temperature.
Extremely high temperatures adversely affect the unit's longevity and may affect its ability to
effectively record and play digital content.
• All front panel LEDs ash on and off to indicate an over temp condition. Disconnect the 1394
and power cables and move the unit to cooler location. When the unit has been allowed to
cool, plug in the power cord to power up the unit. Once the DVR is powered up, connect the
1394 cable to the television.
DTVLink Component No Longer Connected
If a non-correctable error has occurred or the power or 1394 cable has been disconnected, the
following message appears: “A DTVLink component is no longer connected to the network. If this
was unintentional, please check your connections.”
• Press OK to clear screen.
• Check all cables to make sure they’re connected and rmly seated.
• If all cables are rmly attached, disconnect the 1394 cable, wait 10 seconds, and reconnect.
This will re-initialize the DVR on the 1394 network.
TV and/or DVR is not responding to commands
If the TV and/or DVR is not responding to commands, try one of the solutions below:
• Try changing channels.
• Turn off the TV and then turn it back on.
• If you have an RCA HDTV, try simultaneously pressing the POWER and CHANNEL DOWN
buttons on the front of the TV for a few (5-7) seconds to perform a "soft reset."
• Unplug the TV and/or the DVR and wait for one minute, then plug it back in.
• Put remote into TV mode.
• Replace the batteries of the remote.
16395340_3 8/5/04, 5:29 PM16
16 Chapter 3
Chapter 3: Other Information
Illustrations contained in this document are for representation only.
Other Information
Chapter 3 17
Illustrations contained in this document are for representation only.
Specications*
Interface Specications
• IEEE 1394/DTVLink compliant
• AV/C compliant
• SBP-2 compliant
• Supports serial bus data transfer rates of 100, 200, and 400 Mb/sec
• Two external 6-pin FireWire® connectors
• Hot-plug capability
Drive Specications
Hard Disk Drive (HDD) contains two partitions: 1GB for use with computers with
asynchronous data, and the rest of the drive for digital A/V with isochronous data.
(1GB=1,000,000,000 Bytes):
DVR2080 80 GB
DVR2160 160 GB
High Denition (HD) Recording Capacity (19.3 Mbits/sec):
DVR2080 9 hrs
DVR2160 18 hrs
Standard Denition (SD) Recording Capacity (4.3 Mbits/sec):
DVR2080 40 hrs
DVR2160 80 hrs
Environmental Conditions
Operating Temperature 5° to 35°C
Non-Operating Temperature -20° to 65°C
Acoustics (typical) Idle Mode: 33 dBA average
Power Requirements
AC Input Voltage 120VAC +/-10%
AC Input Frequency 50-60 Hz
AC Input Current 0.3A max (RMS)
Physical Dimensions
Height 2.0 in. (5 cm)
Length 10.28 in. (25.7 cm)
Width 8.45 in. (21.13 cm)
*Specications are subject to change without notice.
FireWire® is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.
16395340_3 8/5/04, 5:29 PM17
Other Information
18 Chapter 3
Illustrations contained in this document are for representation only.
Other Information
Chapter 3 19
Illustrations contained in this document are for representation only.
Limited Warranty
What your warranty covers:
• Defects in materials or workmanship.
For how long after your purchase:
• 90 days from date of purchase for labor.
• One year from date of purchase for parts.
The warranty period for rental units begins with the rst rental or 45 days from date of shipment
to the rental rm, whichever comes rst.
What we will do:
• Exchange the Digital Video Recorder unit with a new or, at our option, refurbished unit.
How you get service:
• Call 1-877-722-4388 and have your unit's date of purchase and model/serial number ready.
The model/serial number information is on the back of your unit.
• A representative will troubleshoot your problem over the phone.
• If the representative determines that you should receive a replacement unit, you will be
provided with a Service Request (SR number and the location of a nearby exchange point if
one exits. No returns will be accepted without the SR number.
• Proof of purchase in the form of a bill of sale or receipted invoice, which is evidence that
the product is within the warranty period, must be presented to obtain warranty service. For
rental rms, proof of rst rental is also required.
What your warranty does not cover:
• Acts of nature, such as but not limited to lightning damage.
• Adjustment of customer controls.
• Damage from misuse or neglect.
• A unit that has been modied or incorporated into other products or is used for institutional
or other commercial purposes.
• Batteries.
• Software/stored program content.
• Units purchased or serviced outside the U.S.A.
• Shipping damage if the unit was not packed and shipped in the manner prescribed by TTE
Technology, Inc.
Product Registration:
• Please complete the online Product Registration on www.rca.com or complete and mail the
Product Registration Card packed with your unit. It will make it easier to contact you should
it ever be necessary. The return of the card is not required for warranty coverage.
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT.
ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED.
NO VERBAL OR WRITTEN INFORMATION GIVEN BY TTE TECHNOLOGY, INC., ITS AGENTS OR
EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS
WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE
REMEDY OF THE CONSUMER. TTE TECHNOLOGY, INC. SHALL NOT BE LIABLE FOR
16395340_3 8/5/04, 5:29 PM18
Other manuals for DVR2080
1
This manual suits for next models
1
Table of contents
Languages:
Other RCA DVR manuals
