PHD50500
50" (Diagonal) Plasma HDTV
Monitor
Features Benefits
High Definition Monitor
TruScan™ Digital Reality Intelligent Signal Processing -
"Because the Picture Intended Should be the Picture
Presented"
Deep Encased Cell Structure
Black Stripe Coating
Pure Color Filter
10-Bit Display Technology
160 Degree Wide Viewing Angle - Both Horizontally and
Vertically
High resolution XGA monitor (1280 x 768) provides the
perfect instrument for high definition viewing.
Recognizes incoming signals & progressively converts
them to achieve optimum digital picture. Automatically
reverts converted film source material for best picture.
Extra deep plasma cell housings help prevent light and
color from leaking from one cell to the next, so colors are
more accurate and brightness remains at a high level.
Black stripes between the plasma cells are added to
absorb ambient light, minimize reflections and increase
contrast, even in a brightly lit room.
High-purity screen filter specially designed to reduce glare
and to deliver exceptional color accuracy.
Four times better video reproduction than conventional
TV's. Provides more detail – especially in dark scenes
where light gradation is important.
Whether standing, sitting or lying on the floor, get the full
bright picture.

PHD50500
Technical Specifications:
BRAND
Brand RCA Scenium
Screen Size - Diagonal 50 Inches
Category HDTV Monitor
Aspect Ratio 16:9
Screen Type 16 x 9
Picture Tube Type Plasma
Viewing Angle > 160 Degrees
Comb Filter 3D Y/C Digital Frame
Format Control 4x3 Full, Zoom, Wide
Format Control (Additional) -
9-Point Zoom (PC Mode) Yes
Peak Brightness - Set w/Front Filter 340 CD/M Squared
Contrast Ratio 1000:1
Panel Resolution 1280 x 768 Pixels
Horizontal Pitch .858 mm
Color Temp Yes
Digital Noise Reduction Yes
High Contrast Yes
3:2 Pulldown Reverse - TruScan™ Digital Reality
Progressive Scan TruScan™ Digital Reality
SOUND
Stereo (Watts per Channel) 2 x 5 Watts
Volume Control Yes
Tone Control N/A
Balance Control N/A
Speakers Optional - Model PLSP50S2
CONVENIENCE
Power ON/OFF Indicator Green LED
Standby Indicator Red LED
Power Management Settings PC Mode Only
Auto Power Off Yes
Multilingual On-Screen Display French/English/Spanish
Picture Reset Yes
Sleep Timer -
VIDEO FORMATS
Tuner -
Display Capability NTSC / ATSC
HD Ready Yes
PC Video Formats VGA, SVGA, XGA
Digital Video Formats 480P, 720P, 1080i
CONNECTIONS (REAR PANEL)
Video 1 RCA
S-Video 1 DIN 4 Pin
Audio (Mini Jack) 1 Stereo Mini Jack for Input
Audio(Shared with All Sources) 3 Pair RCA L&R (Stereo)
Component Video Input (YPrPb) 1 Set 5 BNC (Selectable)
RGB Analog Input 1 Set Mini D-Sub 15 Pin
RGB Analog Output 1 Set Mini D-Sub 15 Pin
DVI-HDCP DVI-D 24 Pin
RS-232 D Sub9 Pin
Speaker Terminals (Pair) L & R Speaker Out
Audio Out -
Subwoofer Out -
USER CONTROLS (FRONT PANEL)
Power Yes
Volume Yes
Screen Size Yes
Input Yes
Menu -
SPECIFICATIONS
Finish On Front Silver
Finish On Back Silver
Product Size (WxHxD) Inches 48 x 28 1/8 x 3 7/8
Packaging Size (WxHxD) Inches 53 x 53 1/3 x 16 3/4
Weight: Product/Packaged, lbs 90 / 112
Emissions FCC Class B¹ˆ
Safety UL1950/CSA22:2NO.950
REMOTE
Model Number RCR160TKLM1
Type Universal Partially Backlit
ACCESSORIES
Instruction Book French/English/Spanish
Stand Included
Wall Mount Kit Optional - Model # PLWM50J2
Speakers Optional - Model # PLSP50J2
1ˆ This model is rated as Class B - it has low EMI radiation and is suitable for either industrial or
consumer use. Class A models cannot be used for consumer use.
©2003 Thomson Inc.
Trademark(s) ® Registered
Marca(s) Registrada(s)
Photos and features subject to change without notice. Illustration of product finish may vary
from actual color.
Revised 10/7/03
