Rca Rtd315 User manual

It is important to read this instruction book prior to using your new product for the first time.

User manual

AUXIN

RTD315

This device complies with Part 15 of the FCC

Rules. Operation is subject to the following

two conditions: (1) This device may not

cause harmful interference, and (2) this

device must accept any interference

received, including interference that may

cause undesired operation.

This equipment has been tested and found

to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide

reasonable protection against harmful

interference in a residential installation. This

equipment generates, uses and can radiates

radio frequency energy and, if not installed

and used in accordance with the

instructions, may cause harmful interference

to radio communications.

However, there is no guarantee that

interference will not occur in a particular

installation. If this equipment does

causeharmful interference to radio or

television reception, which can be

determined by turning the equipment off

and on, the user is encouraged to try to

correct the interferebce by one or more of

the following measures:

• Reorient or relocate the receiving

antenna.

• Increase the separation between the

equipment and receiver.

• Connect the equipment into an outlet on

a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced

radio/TV technician for help.

WARNING: Changes or modifications to this

unit not expressly approved by the party

responsible for compliance could void the

user's authority to operate the equipment.

Ventilation

You must adequately ventilate the product.

Make sure there is adequate space around

the unit to provide proper air flow for

ventilation. See diagram.

10 cm 10 cm

7 cm 7 cm

10 cm

This product complies with DHHS Rules 21

CFR Subchapter J. Applicable at the date

of manufacture.

FCC Information

This Home Theater has

earned the ENERGY STAR.

For your safety

The AC power plug is

polarized (one blade is

wider than the other)

and only fits into AC

power outlets one way.

If the plug won’t go into

the outlet completely,

turn the plug over and

try to insert it the other

way.

If it still won’t fit, contact a qualified

electrician to change the outlet, or use a

different one. Do not attempt to bypass this

safety feature.

Removing the power plug is the only way to

completely remove power from your

product. Make sure the power plug remains

easily accessible.

Service information

This product should be serviced only by

those specially trained in appropriate

servicing techniques. For instructions on how

to obtain service, refer to the warranty

included in this Guide.

RFC: CTM-9800723-KS5

Important Information

Main plug is used as the disconnect device, it

shall remain operable and should not be

obstructed during intended use. To be

completely disconnected the apparatus from

supply mains, the main plug of the apparatus

shall be disconnected from the mains socket

outlet completely.

DVD copy protection

In accordance with the DVD standard, your

DVD player is equipped with a Copy

Protection system, which can be switched on

and off by the DVD disc itself, in order to

make any recording of the relevant DVD disc

onto a videotape of very poor picture quality,

or even impossible. This product

incorporates copyright protection technology

that is protected by method claims of certain

U.S. patents and other intellectual property

rights owned by Macrovision Corporation

and other rights owners. Use of this copyright

protection technology must be authorized

by Macrovision Corporation, and is intended

for home use only unless otherwise

authorized by Macrovision Corporation.

Reverse engineering or disassembly

is prohibited.

Note:

This DVD player is designed and manufactured

to respond to the Region Management

Information. If the Region number of a DVD

disc does not correspond to the Region

number of this DVD player, this player cannot

play the disc. The Region number for this

DVD player is Region 1.

Caution

Invisible laser radiation when open. Avoid

exposure to beam. Class 1 laser product.

This system must be opened only by qualified

technicians to prevent accidents caused by

the laser beam.

THE LIGHTNING FLASH AND ARROWHEAD

WITHIN THE TRIANGLE IS A WARNING

SIGN ALERTING YOU OF "DANGEROUS

VOLTAGE" INSIDE THE PRODUCT.

SEE MARKING ON BOTTOM / BACK OF PRODUCT

WARNING: TO PREVENT FIRE OR ELECTRICAL SHOCK HAZARD, DO NOT

EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF

PROCEDURES OTHER THAN THOSE SPECIFIED MAY RESULT IN HAZARDOUS

RADIATION EXPOSURE.

CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED.

REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE.

WARNING: MAINS PLUG IS USED AS DISCONNECT DEVICE AND IT SHOULD

REMAIN READILY OPERABLE DURING INTENDED USE. IN ORDER TO

DISCONNECT THE MAINS PLUG FROM MAINS COMPLETELY, THE MAINS PLUG

SHOULD BE DISCONNECTED FROM THE MAINS SOCKET OUTLET COMPLETELY.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

THE EXCLAMATION POINT WITHIN THE

TRIANGLE IS A WARNING SIGN ALERTING

YOU OF IMPORTANT INSTRUCTIONS

ACCOMPANYING THE PRODUCT.

CAUTION

CAUTION: TO REDUCE THE RISK OF

ELECTRIC SHOCK, DO NOT REMOVE COVER

(OR BACK). NO USERSERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

Important battery information

new and old batteries. Do not use

rechargeable batteries.

observe the polarities indicated inside the

battery compartment. Replace only with

the type of batteries specied. Do not

dispose of them in a re or

recharge them.

a long period of time, remove

the batteries.

Important Information

CAUTION

controls or adjustments or performance

of procedures other than those

specied herein may result in

open covers and do not repair yourself.

Refer servicing to qualied personnel.

rain or moisture. No objects lled with

liquids, such as vases, should be placed

on the apparatus.

Illustrations contained in this document are

for representation only.

This Class B digital apparatus complies

with Canadian ICES-003.

Cet appareil numérique de la class B est

conforme à la norme du NMB-003

du Canada

Please respect the environment

and prevailing regulations.

Before you dispose of batteries

or accumulators, ask your dealer

whether they are subject to

special recycling and if they will

accept them for disposal.

WARNING

placed on the apparatus.

CLASS 1 LASER PRODUCT

LASER KLASSE 1

LASERAPPARAT AV KLASS 1

AREIL A LASER DE CLASSE 1

LUOKAN 1 LASERLAITE

LASERPRODUKT AF KLASSE 1

Battery shall not be exposed to

excessive heat such as sunshine,

fire or the like.

Important Safety Instructions

Please read and save for

future reference

Some of the following information may not

apply to your particular product; however, as

with any electronic product, precautions

should be observed during handling and

use.

• Read these instructions.

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Clean only with dry cloth.

• Do not block any ventilation openings.

Install in accordance with the manufacturer’s

instructions.

• Do not install near any heat sources such as

radiators,heat registers, stoves, or other

apparatus (including amplifiers) that

produce heat.

• Do not defeat the safety purpose of the

polarized or grounding-type plug. A

polarized plug has two blades with one

wider than the other. A grounding type

plug has two blades and a third grounding

prong. The wide blade or the third prong is

provided for your safety. If the provided

plug does not fit into your outlet, consult

an electrician for replacement of the

obsolete outlet.

• Protect the power cord from being walked

on or pinched particularly at plugs,

convenience receptacles, and the point

where they exit from the apparatus.

• Only use attachments/accessories specified

by the manufacturer.

• Use only with the cart, stand, tripod,

bracket, or table specified by the

manufacturer, or sold with the apparatus.

When a cart is used, use caution when

moving the cart/apparatus combination to

avoid injury from tip-over.

• Unplug this apparatus during lightning

storms or when unused for long periods

of time.

• Refer all servicing to qualified service

personnel. Servicing is required when the

apparatus has been damaged in any way,

such as power-supply cord or plug is

damaged, liquid has been spilled or objects

have fallen into the apparatus, the

apparatus has been exposed to rain or

moisture, does not operate normally, or

has been dropped.

Additional safety information

• Apparatus shall not be exposed to dripping

or splashing and no objects filled with

liquids, such as vases, shall be placed on the

apparatus.

• Always leave sufficient space around the

product for ventilation. Do not place

product in or on a bed, rug, in a bookcase

or cabinet that may prevent air flow

through vent openings.

• Do not place lighted candles, cigarettes,

cigars, etc. on the product.

• Connect power cord only to AC power

source as marked on the product.

• Care should be taken so that objects do not

fall into the product.

• Do not attempt to disassemble the cabinet.

This product does not contain customer

serviceable components.

If your product operates on batteries,

adhere to the following precautions:

A. Any battery may leak electrolyte if mixed

with a different battery type, if inserted

incorrectly, or if all batteries are not

replaced at the same time.

B. Any battery may leak electrolyte or explode

if disposed of in fire or an attempt is made

to charge a battery not intended to be

recharged.

C. Discard leaky batteries immediately.

Leaking batteries can cause skin burns or

other personal injury. When discarding

batteries, be sure to dispose of them in the

proper manner, according to your state/

provincial and local regulations.

Table of Contents

Connections and Setup .........1

Connecting to your TV (VIDEO)....................2

Connecting to your TV (via HDMI input)

Connecting AUDIO from external sources

such a TV (Aux-in)

Connecting the speakers.....................4

Positioning speakers ........................5

Front speaker placement

Better surround placement ..................6

Test tone/Channel balance

Overview of Controls.............7

Front panel controls

Remote control

Remote control functions in TUNER

mode .......................................8

Using the remote to Navigate through

On Screen Menus............................9

Playing Discs –

Basic Functions .....................9

Compatible discs/formats

Regional coding

Operating the DVD receiver

Basic Playback Operations ..................10

Types of Menus

The Info Menu .................... 11

Using the Info menu

Title/chapter (DVD)/track

(audio CD)

Time Display ...............................12

Audio (DVD)/Subtitles (DVD)/

Camera Angle (DVD) .......................13

Play mode

Creating a Program list for Play Mode

Bookmark/Sleep/Introscan(CD) ............14

Mp3/WMA Files and

jpeg Files ............................ 15

Playing mp3/WMA Files or displaying

jpeg files

Radio.................................. 16

Manual Tuning

Storing radio stations

USB Device ......................... 17

Connecting/Disconnecting USB devices

to the Main Unit

USB Device Playback Features

Aux-In

.....................................

Connecting auxiliary components

Selecting the auxiliary mode

Sound output in the auxiliary mode

CD Ripping ......................... 18

An overview

Ripping CD to USB device

Start Ripping CD

File Names of Ripped Files

Deleting Files

The Setup Menu ................. 19

General Setup

Password

Rating ...................................20

Slide Time

Default

Lanugage Setup ............................20

Player Menu

Audio

Subtitles

Disc Menu

Audio Setup ...............................21

Night Mode

Distance

Test Tone

Video Setup ................................22

Video

TV Type

HDMI Setup

Brightness

Additional Information........ 23

Troubleshooting

Precautions ................................24

Compatible Formats ........................25

Sound Enhancement Systems...............26

Technical Specifications.....................27

Limited Warranty ................ 28

Connections and Setup

Remote control and

2 AAA batteries

Left and right

Surround

Speakers

Composite

Video Cable

One Pig-Tail

antenna wire

Left and right

front speakers

One external AM

loop antenna

SubwooferCenter speaker

Accessories provided

+ -

Things to consider before

you connect

• Ensure that the mains supply in your house

complies with that indicated on the

identification sticker located on the back of

your unit.

• Install your unit horizontally, away from

any source of heat (fireplace) or appliances

creating strong magnetic or electric fields.

The components of this unit are sensitive to

heat. The maximum ambient temperature

should not exceed 35°C/95°F.

• Leave enough space around the unit to

allow adequate ventilation: 10 cm/4 inches

on either side and above the top, and 5

cm/2 inches at the rear.

• The humidity of the room should not

exceed 75%. If you have to use the unit

outdoors, do not expose it to rain or

splashing water. The apparatus should not

be exposed to dripping or splashing and no

objects filled with liquids, such as vases,

should be placed on the apparatus.

• Moving the unit from a cold place to a

warm one can cause condensation on some

components inside the unit. Let the

condensation disappear on its own before

turning the unit on again.

• Before moving the unit, make sure the disc

tray is empty.

• Where the mains plug or an appliance

coupler is used as a disconnect device, the

disconnect device shall remain

readily operable.

• Other important use and cleaning

information at the end of the booklet.

Connecting the antennas

The AM and FM antennas connect to the

AM and FM terminals on the system’s back

panel. They must be hooked up in order to

receive clear reception.

AM Loop Antenna

1. Uncoil the AM Antenna wire.

2. Press down on the Antennas tab to open

the terminal.

3. Make sure the white wire on the AM loop

antenna is inserted into the AM loop

terminal and the other wire is inserted

into the ground loop terminal.

Connecting to your TV (VIDEO)

Connections and Setup

FM 75

Ω

Whit e

Antenna

GN D

Method 2

Component video jacks (Pr, Pb, Y)

• The component video jacks are color-coded

green, blue and red.

• Additional component video cables (not

supplied) are required to provide best picture

quality. They are usually color-coded green,

blue and red.

• Connect the component video OUT jacks on the

receiver to the component video IN jacks on

your TV so the video content goes from the

receiver to the screen.

Method 1

Composite video jack (yellow)

• The basic video jack is color-coded yellow.

• Video cable (yellow) is supplied for the

connection for good picture quality.

• Connect the video OUT jack on the receiver

to the IN jack on your TV so the video

content goes from the receiver to the

screen.

• If your television is a high

definition television, use the

unit's progressive scan output to

get the highest possible video resolution.

Set the Progressive Scan option in the

Video menu to On (See page 22).

• If one of the devices is not working, check

that all the cables have been inserted

properly into the jacks.

• If your component has only one input for

audio (mono), connect it to the left (white

L/Mono) audio jack on the TV and don’t

connect the right audio part of the cable.

Red

Blue

Green

VIDEOOUT

Video

cable

Component

video cable

Method 1 Method 2

Connecting AUDIO from external

sources such as TV (Aux-In)

Connecting to your TV (via HDMI

input)

HDMI stands for High Definition Multimedia

Interface. HDMI transfers digital audio and

uncompressed digital video on a single cable.

Press the HDMI button on the remote control to

change output signals as follows: 480p, 720p,

1080i and 1080p.

Notes:

• Refer to the owner's manual of the connected TV

as well.

• When using HDMI cable, do not connect to other

analog video outputs.

Using AUDIO IN (AUX 1) jacks

Using AUX IN 2 jacks

Notes:

• Audio cables (color-coded in red and white)

(not included) are required.

•

Press either SOURCE on the main unit or AUX1/

2 on the remote control to select AUX1 IN or

AUX2 IN mode.

• To listen to the audio input from the connected

component, press SOURCE on the main unit or

AUX on the remote control to select the

AUX mode. Refer to page 17 for details.

Connect the AUDIO IN (AUX 1) jacks from the unit

to the AUDIO OUT jacks on VCR, TV, Set Top Box or

other component.

Connect the AUX IN 2 jacks on the front panel of

the unit to the AUX OUT (AUDIO OUT) jacks on

VCR, TV, Set Top Box or other component.

VCR

Set To pBox

VIDEOOUT 1

HDMI

To HDMI

output

To HDMI

input

HDMIcable

(not supplied)

VC R

Set To pBox

AUDIO OU T

White

Red

VIDEOOUT 1

Audio

cable

VC R

Set To pBox

AUDIO OU T

Red

AUXIN

AUX IN

White

Audio cable (not supplied)

Connecting the speakers

Speaker wires are color-coded to match the terminals. Connect the speaker wire from the back of

each speaker to the corresponding color terminal at the back of the unit. Press down the tab to open

the terminal and insert the wire. Release the tab to lock wire in the terminal.

Note: When connecting the speakers, make sure the polarities (“+” speaker wire to “+” on

the receiver. For example, red wire to red terminal on the receiver) of speaker wires and terminals

match. If the cords are reversed, the sound will be distorted. Do not let the speaker wires touch

each other, it will damage the speaker.

SR SL SUB CEN FR FL

4 43

SPEAKERS

Green/Grey

or BlackStriped

Purple/Grey

or BlackStriped Red/Grey

or Black

Striped

Blue/Grey or

BlackStriped

Grey or

BlackStriped

Rear Speakers

(Surround Sound)

Front Speakers

White/Grey

or Black Striped

Right

Insert

Press

Release

Left

Center Speaker

Subwoofer

Courtesy Dolby Laboratories

Note: Front, Center speakers

provided with this unit are magnetically

shielded to protect your TV set. It is not

recommended to place the surround

speakers and subwoofer near the TV set.

Connections and Setup

Front speaker placement

For best results, follow the speaker placement

below.

Alignment

Align the center speaker evenly with (A) or

slightly behind (B) (the left and right speakers),

but not ahead of them.

Angle

Place the left and right speakers to form a

45-degree angle with your favorite viewing

position to duplicate the soundtrack mixer’s

perspective.

Height

The three front speakers should be as close as

possible to the same height. This often

requires placing the center speaker directly

on top (A) or beneath (B) the TV set.

Positioning speakers

1. Left, Right (Front Speakers)

Front speakers carry primarily music and

sound effects.

2. Center

In surround mode, the center speaker carries

most of the dialog as well as music and

effects.

It should be set between the left and right

speakers.

3. Surround (Rear Speakers)

The surround speakers’ overall sound balance

should be as close as possible to the front

speakers. Proper placement is vital to

establish

an evenly distributed sound field.

4. Subwoofer

A subwoofer is designed to reproduce

powerful low bass effects (explosions, the

rumble of spaceships, etc.).

Better surround placement

Location

If possible, place surround speakers to either

side of the listening area, not behind it.

Height

If space permits, install surround speakers 2-3

feet above viewers. This helps to minimize

localization effects.

Aiming

Aim surround speakers straight across the

room, not down at viewers, to help create a

more open, spacious surround sound field.

Alternative Surround Placement

Rear wall

If rear wall mounting is the only choice, aim

the speakers at each other (A), towards the

front (B) or towards the sidewalls (C, D).

Experiment with placement until sounds seem

to surround you, rather than come from

behind you.

No adjacent walls

Surround speakers can go on stands facing

each other to approximate sidewall mounting

(A), or to the sides or rear of the viewing area,

aimed upwards; they can go right on the

floor, or preferably, a few feet off the floor

such as on end tables (B).

Test tone/Channel balance

Channel balance

Your receiver is equipped with a test signal

generator for balancing the channels. As the

signal "travels" from channel to channel,

adjust the level controls until each channel

plays at the same lodness level (see page 20).

Level adjustment and surround channel

level expectation

Even though you adjust the surround channel

to be as loud as the others on the test signal,

on actual program material the surround

channel is adjust the surround level; program

producers use surround for subtle atmospherics

and ambience, and only rarely for special

effects.

Front panel controls

Overview of Controls

Switches the

unit on and off.

Toggles between

different

subwoofer

output levels

(among soft/

balance/ strong/

powerful).

Connects USB

devices for

playing music

and photos.

Remote control functions in DVD/CD

mode

ON•OFF – Switches the unit on and off (p.9).

DVD – Selects the DVD mode (p.9).

TUNER – Selects the TUNER and selects between

FM/AM (p.16).

USB – Selects the USB mode (p.17).

AUX 1/2

– Selects the Auxiliary input (for listening to

audio input from connected TV, VCR or Set Top

Box) (p.18).

0-9 – Number entry.

CLEAR – Quits the current setting manually from

the TV screen without saving change.

INFO – Accesses the Info menu (p.11).

TITLE – Accesses the title menu of DVD discs

(p.14).

DISC MENU – Accesses the disc menu during

playback.

OK – Confirms your selection.

– To navigate through the menus (read page 8

for details). The left and right arrows also tune the radio

frequency in the tuner mode.

MUTE – Mutes and restores the sound.

SETUP – Enters Setup menu (p.19).

RETURN – In DVD mode, returns to the

previous menu.

VOL +/- – Adjusts the sound volume.

CH +/ , CH –/ – Directly accesses the next or

previous chapter (DVD) or track (CD) (p.9). Selects

programmed stations in TUNER mode (p.15).

REV – Starts reverse accelerated play or reverse

slow motion (p.10).

PLAY – Starts playing a disc (p.10).

FWD – Starts forward accelerated play or forward

slow motion (p.10).

REC – Accesses or quits the CD Ripping menu

(p.18).

AUX IN jacks -

connects audio

devices.

Starts/pause

playing a disc.

Adjusts the

volume.

Stops disc

playback.

AUXIN

Selects the input sources.

Press repeatedly to select:

• DVD – to watch DVD videos

• TUNER – to listen to the radio

• USB – to play files stored on a

connected USB device

• AUX 1/ AUX 2

– to listen to the audio

input from the connected TV,

VCR or Set Top Box.

Opens and closes

the disc tray.

STOP – Stops playback. Press and hold to open

the disc tray (p. 9, 10).

PAUSE – Freezes frame, accesses frame advance

or slow motion function (p.10).

AUDIO – Accesses the audio function (p.12).

ANGLE – Accesses the camera angle function for

DVD disc (p.13).

ZOOM – Accesses the Zoom function (p.10, 15).

SUBTITLE – Selects the subtitle languages or

turns subtitle off (if available) (p.12).

HDMI – Changes video output signals (480p,

720p, 1080i or 1080p) (p.14).

SUBWOOFER – Selects among subwoofer output

levels (soft/balance/strong/powerful).

RANDOM – Turns on/off random playback on

CDDA/mp3/wma/jpeg discs.

REPEAT – Accesses the repeat function.

EQ. LEVEL – Toggles channels for different

channel level settings. Adjusts the value using

VOL +/-.

SURROUND – Changes the Surround sound

setting. In DVD mode, press the button to select

between Dolby Digital and Stereo modes (Dolby

ProLogic is available if the input is Dolby 2 ch). In

the Aux-In mode (analog input), press the button

to select between Dolby ProLogic and Stereo

modes. (Refer to page 27 for details on Dolby

Digital and Dolby ProLogic.)

Remote control functions in tuner

mode

TUNER – Selects the TUNER and switch between

FM/AM (p.16).

VOL+/– – Adjusts the sound volume.

MUTE – Mutes and Restores the sound.

TUNER +/– – Tunes down and up the radio

frequencies (p.16).

MEMORY – Stores a station (p.16).

CH+/– – Selects programmed stations (p.16).

AUDIO – Selects between Stereo and Mono mode

for Tuner (FM) (p.16).

RCR 192 AD2

HDMI

Overview of Controls

Playing Discs - Basic Functions

Compatible discs

• DVD, DVD-R,DVD-RW, DVD+R, DVD+RW

• CD, CD-R, CD-RW

Compatible formats

• DVD, JPEG

• CD, mp3, WMA

See page 24 and 25 for more information

about discs and compatible formats.

Regional coding

Your unit has been designed to process

regional management information stored on

DVD discs. The regional code for your unit

is 1. Discs that have a different regional code

will not play.

Operating the DVD receiver

1. Turn on your television set.

2. Press ON•OFF on the remote or ON/

STANDBY located on the unit’s front

panel. Press DVD on the remote control.

Loading disc

1. Press on the front panel or press and hold

STOP on the remote control to open the disc

tray.

2. Insert a compatible disc into the disc slot.

3. Press again to close the disc tray.

Note:

Insert 2 "AAA"("UM-4"/"R03")

batteries to the remote control prior to

use.

Using remote control to navigate

through the on-screen menus

Use and OK on the remote control to navigate

through the on-screen displays (the DVD player’s menu,

the Info Display that appears during playback, or a disc’s

menu).

Use on the remote to move through on-screen

menus in the direction of the arrow button (e.g., to move

right, press

). The arrow buttons are used to highlight an

option. Once highlighted, press OK to select the option

that is highlighted.

Basic playback operations

Playback

Switch the unit and the TV set on.

1. After loading a disc, playback starts

automatically, or the disc menu appears.

If the disc menu appears, select the Play

option to begin playback.

2. Press STOP to stop playback.

Accelerated play

While the disc is playing, press REVERSE or

FORWARD one or more times to vary the

speed and direction of the accelerated play.

Press PLAY to resume normal playback.

Pause

While the disc is playing, press PAUSE once

for freeze frame. Press PLAY to resume

normal playback.

Frame advance

1. Press PAUSE twice. FRAME is displayed.

2. Press FWD to move forward one frame at

a time.

3. Press PLAY to resume normal playback.

Variable slow motion

1. While the disc is playing, press PAUSE

once. PAUSE is displayed.

2. Press REV or FWD a number of times to

vary the speed.

3. Press PLAY to resume normal playback.

Changing chapter/track

While the disc is playing, press the CH+/-

button to go immediately to the next or

previous chapter, or to the next or

previous track.

Zoom

1. While a disc is playing, press ZOOM until

you reach the zoom size you want. The

ZOOM button toggles through 2x, 3x, 4x

and then zooms out to 1/2x, 1/3x and 1/4x,

then returns to normal playback.

2. Move from one area to another (pan)

using the arrow buttons.

3. To turn ZOOM off, press ZOOM unitil you

get to the ZOOM OFF option.

Types of menus

• Disc menu — The appearance and

contents of this menu varies according to

the type of disc you have inserted. It is

separate from the Setup menu.

• Info menu — The unit’s Info menu appears

at the top of the screen while the disc is

playing. Press INFO on the remote to

switch the Info menu on or off.

• Setup menu — Press SETUP to access

this menu.

General Setup

Password

Rating

Slide Time

Default

Using the Info menu

1. Press INFO on the remote while a disc is

playing to display the Info menu. The first

banner shows title, chapter, and time

display information.

2. Press INFO again for audio language,

subtitles, and camera angle.

3. Press INFO a third time for play mode,

bookmark and sleep timer.

4. Use the right/left arrow buttons on the

remote to select an icon.

5. Use the up/down buttons to scroll through

the options.

Playing Discs - Basic Functions

Note:

INVALID KEY will be displayed if the

function you select is not available.

Notes:

• When you press STOP, the unit stores the

point where playback was interrupted. If

you press PLAY again, playback resumes

from this point. To stop playback

completely or to start again from the

beginning, press STOP twice. If the unit

is left in STOP mode for more than five

minutes without any user interaction, a

screen saver is activated. At the end of

30 minutes without any user interaction,

the unit switches off automatically.

The Info Menu

DVD Info Display

CD Info Display

Title Chapter Time display

Audio language Subtitles Camera angle

Play mode Bookmark Sleep timer

Track Time display

Sleep timer

Bookmark

Play mode

Title/chapter (DVD)/track

(audio CD )

To directly access a title, chapter (DVD) or a

track (audio CD), press INFO, press OK.

Select the Title(TT), Track(TRK) or

Chapter(CH) icon and enter a number

directly with the numeric buttons. Press OK

again to confirm.

Time display

To access the Time Display, press INFO on the

remote. Press the up/down buttons

repeatedly to display:

DVD: Chapter elapsed time, Chapter

remaining time, Title elapsed time and Title

remaining time.

Audio CD: Track elapsed time, track

remaining time, disc elapsed time, disc

remaining time.

To directly access a location on the disc

which does not correspond to the start of a

title or chapter, press INFO once and press

OK, highlight the Time Display icon using

the arrow buttons, then enter a time with

the number buttons (hh:mm:ss) and

press OK.

Audio (DVD)

Some discs have several audio tracks used for

different languages or different

audio formats.

To change the language or audio format during

playback:

1. Press the INFO button twice.

2. Use the left/right arrow buttons to select the

Audio icon, or press the AUDIO button on the

remote control.

3. Choose a language or an audio format with the

up/down arrow buttons.

This option is only available if the disc offers

dialog languages or audio formats. When

you change the dialog language using the

Info menu, it only changes the dialog

language of the disc being played. When

you eject the disc or switch off the unit, the

language will revert to the one you selected

in the Language Setup menu (see page 21).

Subtitles (DVD)

Subtitles are turned off by default. Turn on

Subtitles as follows:

1. While the disc is playing, press INFO twice,

then select the Subtitles icon using the

left/right arrow buttons.

2. Select a language using the up/down

arrow buttons.

3. To turn subtitles off, select the Off option

or press SUBTITLE on the remote.

When you change the language of the

subtitles using the Info menu, it only applies

to the disc currently being played. When you

eject the disc and switch off the unit, the

subtitles will default to the subtitle language

you selected in the Languages menu (see

page 21). This function may not be available

on all discs.

Note: Many discs only have

one title.

Note: Time display function may not

be available on all discs.

Camera angle (DVD)

Some discs offer different camera angles for

specific scenes.

1. To change the camera angle, press the

ANGLE button on the remote or press the

INFO button twice and select the Camera

angle icon with the left/right buttons.

2. Choose the angle with the up/down

arrow buttons.

If the disc was recorded using a single

camera angle, this function is not available.

Play mode (all discs except

mp3/WMA/jpeg)

1. While the disc is playing, press the INFO

button twice for CD/VCD and three times

for DVD.

2. Select the Play Mode icon using the left/

right arrow buttons.

3. Use the up/down arrow buttons to select

an option.

• DVD play modes: standard, program, A-B

repeat, title repeat, chapter repeat.

Program play mode is only available if a

program list has been created (see below).

Repeat mode is only available with discs

that display elapsed time and remaining

time. To repeat a sequence between

points A and B, choose the A-B repeat

option, and then follow the instructions

for entering the two points.

• Audio CD play modes: standard, introscan,

random, program, repeat A-B, repeat disc,

repeat track.

4. To stop repeat playback, select the Play

Mode icon and use the up/down arrow

buttons to choose the Standard option.

Creating a Program List for

Program Play Mode (Audio

CDs and DVD discs)

To use program play mode, you must first

create a program list.

1. To create a program list, press the INFO

button three times. Highlight the Play

Mode option and press the up arrow to

select the Program option.

2. Press OK. The Program screen is displayed.

3. The first spot in the list is highlighted. Use

the number buttons on the remote to

enter a track number. As for DVD discs: T

stands for Title while C stands for Chapter.

As for Audio CDs: T stands for Track.

4. Use the arrow buttons to move to the

next spot in the list. Enter the next

track number.

5. Continue entering tracks until you have

completed your list.

6. Highlight the Play option at the bottom of

the screen and press OK or press PLAY to

start playback. The program list will play

in the order you programmed it.

To stop program play, press STOP or select

Standard from the Play Mode option in the

INFO display.

If you want to cancel the list, repeat steps 1

and 2 to select CLEAR and press OK.

The Info Menu

Note:

• For mp3 play modes, please refer to

page 15.

Creating a program List for

program play mode (mp3 CDs)

To use program play mode with an mp3 disc,

you must first create a program list. You can

program up to 16 songs.

1. To create a program list, press the INFO

button twice. Highlight the Play Mode

option and press the down arrow to select

the Program option.

2. Press OK. The Program screen is displayed.

3. The F stands for Folder, and the T stands

for Track. Highlight the space below the

Folder indicator (F) and use the number

buttons to enter the desired

folder number.

4. Use the arrow buttons to move to the

space beneath the Track indicator (T). Use

the number buttons to enter the

track number.

5. Repeat steps 3 and 4 until you have

completed your list.

6. Highlight the Play option at the bottom of

the screen and press OK or press PLAY to

start playback. The program list will play

in the order you programmed it.

To stop program play, press STOP or select

Standard from the Play Mode option in the

INFO display.

If you want to cancel the list, repeat steps 1

and 2 to select CLEAR and press OK.

Bookmark (DVD and audio CD)

1. Press INFO twice for CD and three

times for DVD. Select the Bookmark icon

with the left/right buttons, and press OK.

A menu is displayed with five bookmarks.

2. The first bookmark space is highlighted.

Press OK to set the bookmark. The book

mark is saved and is indicated by the

number 1. You can set up to five

bookmarks on a disc.

3. To start playback from a bookmark, press

the PLAY button on the remote.

4. To delete a bookmark, highlight it and

press CLEAR.

Sleep

1. Press INFO twice for CD and three

times for DVD. Select Sleep icon with the

left/right arrow buttons.

2. Select one of the available options using

the OK button or pressing the SLEEP

button on the remote: Off, 30, 60, 90 or

120 minutes.

Introscan (CD)

This option plays the first ten seconds of

each track on a CD.

1. Press the INFO button twice, then select

the Playmode icon with the left/right

arrow buttons.

2. Press the up/down arrow buttons to select

the INTRO option and press OK to start

IntroScan.

3. Press STOP to stop Introscan, and press

PLAY to resume normal playback.

Note: This function is only

available with discs whose elapsed

time or remaining time appears in

the Info menu.

Note: This function is not available

in AUX/TUNER mode.

Other manuals for RTD315

Table of contents

Popular Home Theater System manuals by other brands

Definitive Technology

Definitive Technology Studio Advance Setup guide

LG LHB536 owner's manual

Sony

Sony DAV-DZ790K Quick setup guide

Sansui

Sansui HT5002 Service manual

Samsung

Samsung HT-DS400 instruction manual

LG MBD102I owner's manual

Sony

Sony 4-178-247-13(2) operating instructions

Sony

Sony BRAVIA DAV-HDX275 Connection guide

Sony

Sony HS-703 operating instructions

LG DH6531T owner's manual

legasy

legasy Home Theater Towers Connection guide

Sony

Sony SA-VE225 instruction manual

Sharp

Sharp HT-CN300H Operation manual

Samsung

Samsung HE20 user manual

Philips

Philips MCD139B/12 user manual

LENCO

LENCO MDV-3 Specifications

LG LM-K3761KZ owner's manual

Philips

Philips HTS3357 quick start guide

RCA RTD315 User manual

Popular Home Theater System manuals by other brands
