Wireless Infrared (IR) Keyboard
WKB10WB1
1 Year Limited Warranty
Thank you for choosing the RCA Wireless Keyboard. You have select-
ed a fine product designed to provide years of performance. Before
attempting to use your wireless keyboard, please remove all parts from
the box and carefully read the instructions.
WKB10WB1_1100QXD.job 11/7/00 2:14 PM Page 1

2
CAUTIONS
• Your system is equipped with an IR control. The IR control
complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
1) The IR keyboard may not cause harmful interference.
2) The IR keyboard must accept any interference received,
including interference that may cause undesired operation.
• FCC Regulations state that unauthorized changes or modifications
to this equipment may void the user’s authority to operate it.
1. Read Instructions
All the safety and operating instructions should be read and understood
before the appliance is operated.
2. Object and Liquid Entry
Never push objects of any kind into the keyboard, as these objects may
touch dangerous voltage points or short out parts that could result in a
electrical shock. Never spill liquid of any kind on the keyboard.
Important Safeguards
Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Alternate Support Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Using The Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Battery Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Pointing & Operating Range . . . . . . . . . . . . . . . . . . . . . . . . . .4
Keyboard Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Keyboard Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Programming For TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
TV Code List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
TV Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Table Of Contents
WKB10WB1_1100QXD.job 11/7/00 2:14 PM Page 2

3
3. Damage Requiring Service
The appliance should be serviced by qualified service personnel when:
•Keyboard has fallen, or liquid has been spilled into the appliance; or
•The appliance does not appear to operate normally or exhibits a
marked change in performance; or
• The appliance has been dropped, or the enclosure damaged.
4. Servicing
The user should not attempt to service the appliance beyond that
described in the operating instructions. All other servicing should be
referred to qualified service personnel.
5. Care and Cleaning
Use a soft cloth or dusting attachment of your vacuum cleaner to dust
your keyboard. Plastic surfaces are easily scratched and with excessive
use of oil-based furniture polishes, materials on the keyboard will
accumulate more dust. A non-abrasive, anti-static cleaner / polisher is
recommended.
6. Power Source
This product should be operated only from the type of power source
indicated on the marking label or in the owner’s manual.
Alternate Support Mode
Your keyboard is defaulted to
operate the RCA receiver with
UltimateTV service.
If you have a WebTV Plus or
WebTV Classic receiver, you
must change the switch in the
battery compartment as shown
to operate these receivers.
WKB10WB1_1100QXD.job 11/7/00 2:14 PM Page 3

4
Your keyboard supports many of the features of the UltimateTV
and WebTV internet services. PIP functions are not provided on the
keyboard.
Your keyboard requires 2 new AA alkaline or zinc-carbon bat-
teries. The battery life may vary depending on what type of AA
batteries you are using.
1. Remove the battery compartment door.
2. Insert two AA batteries (included)
matching the batteries to the (+) and
(-) marks inside the battery case.
3. Replace the battery compartment door.
Keyboard works on line of sight, so if there are any obstructions
between the keyboard and the TV or receiver, it will seem like the
keyboard isn’t functioning correctly.
Using The Keyboard
Battery Installation
Pointing & Operating Range
WKB10WB1_1100QXD.job 11/7/00 2:14 PM Page 4

5
Keyboard Functions
These are the keys in order from left
to right and top to bottom.
ON•OFF
Turns the TV or receiver on or off
TV
The TV key is used to change the
device mode to operate your TV
Note:Most RCA, GE and ProScan TVs will not
require programming. Check to see if
your TV responds from the keyboard
before you begin programming.
WEBTV
The WEBTV key is used to change
the device mode to operate your
receiver
TV•WEB
Switches the RCA receiver with
UltimateTV service between
UltimateTV and WebTV viewing
INPUT
Scrolls through available video input
sources on your TV
MUTE
Mutes the TV volume
VOL- / VOL+
Turns TV volume down or up
CH- / CH+
Moves down or up one channel at a
time
CLEAR & ESC
Removes the on screen display to
return to normal viewing
REV, PLAY, FWD, REC, STOP &
PAUSE
These keys operate the same as on
your original remote
REPLAY
Jumps back 7 seconds and replays
your video (UltimateTV function)
SKIP
Jumps ahead approximately 30 sec-
onds of recorded video (UltimateTV
function)
GOTO
Displays the URL entry toolbar so that
you can type in a Web address to go
to that page
WKB10WB1_1100QXD.job 11/7/00 2:14 PM Page 5

6
SAVE
Saves the Web address in your
Favorites folder
MAIL
Displays the e-mail screen. You
have the option to send and receive
e-mail
FAVS
Takes you directly to your Web
Favorites list when you are on-line
SEARCH
Displays a Web Search screen
INFO
Provides additional information
(such as Web page or viewing
details for the Web site or
UltimateTV program)
MY SHOWS
Displays the My Shows screen
HOME
Takes you to the TV/Web Home
page
STANDARD KEYBOARD KEYS
• Number keys
• Alphabet keys
• Symbol keys
These keys function the same as any
other computer keyboard
GUIDE
Displays the program guide. Press
again to cycle through custom
guides
BACK
Takes you back to the previous
screen viewed
SCROLL UP / SCROLL DOWN
Scrolls up and down through Web
or Guide content one page at a
time
ARROWS
Moves the highlighted item on the
screen
RETURN & OK
Selects the item highlighted on the
screen
MENU & OPTION
Displays an options panel
RECENT
Displays the list of most recently
viewed Web pages when you are
on-line
Keyboard Functions Continued
WKB10WB1_1100QXD.job 11/7/00 2:14 PM Page 6

7
Keyboard Features
Basics for UltimateTV functions
The RCA receiver with UltimateTV service has a built-in hard drive that can
store many hours of recorded digital video. Below are the most commonly
used keys to operate the UltimateTV features. For more detail refer to the
owners manual included with the receiver unit.
Basics for WebTV functions
The WebTV network service provides capabilities such as e-mail, searching
the internet, and going to Web sites. Below are the most commonly used
keys to operate the the WebTV features. For more detail refer to the owner’s
manual included with the receiver unit.
WKB10WB1_1100QXD.job 11/7/00 2:14 PM Page 7

8
You will need to program the wireless keyboard to work with your
TV. Most RCA, GE & ProScan TVs will not require programming.
Check to see if your TV responds to the keyboard before you begin
programming. Use the following steps to program the
keyboard.
1Manually turn on the TV
2Find the 3-digit code for your TV from the Programmable Codes
listed on the next page. If more than one code is listed for your
brand of TV, use the one at the beginning of the list.
3Press and HOLD the TV key
4Enter the 3-digit code corresponding
to a particular TV brand
5Release the TV key
6Check to see if the code works. Aim the
keyboard at your TV and press the
ON•OFF key. If the TV responds, try
the CH +/- buttons.
Note: Your TV must have infrared (IR) remote control
receiving capability in order to be used with the
wireless keyboard.
Programming For TV
OR
WKB10WB1_1100QXD.job 11/7/00 2:14 PM Page 8

9
Admiral..................................116, 234
Advertura ......................................235
Aiko................................................126
Akai ..............................063, 091, 117
Alba ..............................................033
Alleron ..........................................151
A-Mark ..........................................029
Amstrad ........................................090
Amtron ..........................................145
Anam ............................028, 029, 083
..............................................105, 145
Anam National ..............248, 249, 269
AOC ......................014, 029, 099, 108
......................109, 118, 119, 120, 251
Archer............................................029
Audiovox................................029, 145
Bauer ............................................035
Belcor ............................................118
Bell & Howell ................116, 183, 230
Bradford ........................................145
Brockwood ............................014, 118
Candle ..................014, 095, 097, 098
......................108, 118, 120, 121, 235
Capehart........................................014
Celebrity ........................................117
Circuit City ....................................014
Citizen ..................018, 094, 095, 096
......................097, 098, 101, 108, 118
......................120, 121, 126, 145, 199
..............................................235, 236
Colortyme......................014, 118, 120
..............................................122, 254
Concerto........................097, 118, 120
Contec ..................................049, 083
Contec/Cony..................123, 124, 145
Craig..............................015, 083, 145
Crown....................................094, 145
Curtis Mathes................094, 101, 108
..............115, 118, 120, 125, 199, 230
CXC ......................................083, 145
Daewoo.................. ......002, 091, 092
......................094, 109, 118, 119, 120
......................126, 127, 213, 214, 256
Daytron..........................014, 118, 120
Dimensia ......................................115
Dixi ................................029, 052, 091
Dumont..................................014, 118
Electroband ..................................117
Electrohome..................003, 005, 094
..............118, 120, 128, 129, 130, 269
Elta ................................................091
Emerson ...............001, 012, 014, 083
..............084, 085, 086, 087, 089, 090
..............094, 118, 120, 123, 131, 132
..............133, 134, 135, 136, 137, 138
..............139, 140, 141, 142, 143, 144
..............145, 146, 147, 148, 149, 150
..............151, 152, 211, 230, 236, 237
..............................................260, 270
Envision ........................108, 118, 120
Etron..............................................091
Fisher ............................050, 082, 153
......................................154, 155, 230
Formenti ........................................035
Fortress ........................................039
Fujitsu............................015, 089, 151
Funai ............015, 083, 089, 145, 151
Futuretec ......................................145
Futuretech ............................015, 083
GE..........000, 014, 020, 080, 081, 084
..............102, 105, 106, 111, 115, 118
..............120, 130, 156, 187, 231, 232
..............................................239, 269
Genexxa........................................033
Gibralter ........................................118
Goldstar ................014, 052, 078, 079
..............094, 097, 109, 118, 119, 120
..............123, 128, 129, 159, 160, 161
......................................................228
Granda ..................................003, 014
Grand ............................................014
Grandiente ....................................003
Grundy ..................................045, 151
Hallmark........................014, 118, 120
Harvard..........................................145
Hinari ............................................089
Hitachi.... ..............003, 010, 024, 071
..............072, 073, 074, 075, 076, 077
..............094, 097, 118, 120, 123, 124
..............163, 164, 218, 221, 222, 223
......................................224, 237, 253
Hitachi Pay TV ..............................273
IMA................................................145
Infinity....................................064, 165
Janeil ............................................235
JBL........................................064, 165
JC Penny ..............046, 081, 094, 101
..............108, 109, 111, 115, 118, 119
..............120, 121, 130, 156, 161. 166
..............167, 174, 187, 199, 239, 255
JCB................................................117
Jensen ..........................070, 118, 120
TV Code List
WKB10WB1_1100QXD.job 11/7/00 2:14 PM Page 9

10
JVC..................066, 067, 068, 069, 123
................124, 163, 168, 169, 229, 240
Kawasho..................065, 117, 118, 120
Kenwood..........108, 118, 120, 128, 129
Kloss................................036, 098, 235
Kloss Novabeam ............170, 171, 241
KTV ................083, 084, 085, 094, 145
................................................172, 236
Lloyds ..............................................014
Loewe ..............................................165
Logik........................................183, 266
Luxman............................097, 118, 120
LXI...........025, 030, 047, 050, 064, 111
................115, 120, 153, 165, 173, 174
........................................175, 230, 239
Magnavox........004, 036, 064, 095, 099
........108, 118, 120, 121, 128, 165, 170
........171, 176, 177, 178, 184, 188, 215
................................216, 217, 241, 267
Majestic............................................183
Marants ....165, 052, 064, 108 118, 120
................................................165, 179
Matsui..............................................091
Megatron..................................014, 120
Memorex................. 014, 050, 091, 116
........................120, 182, 183, 230, 266
MGA ......................014, 062, 108, 109,
........110, 118, 119, 120, 128, 129, 130
........................................155, 180, 182
Midland............................054, 151, 171
................................................172, 181
Midland............................................239
Minutz..............................................156
Mitsubishi .......007, 014, 027, 061, 062
........063, 109, 110, 118, 119, 120, 128
........129, 130, 155, 180, 181, 182, 212
Motorola ..................................234, 269
MTC ................014, 097, 101, 108, 109
................................118, 119, 120, 199
Multitech ..........................................145
NAD ................014, 030, 112, 120, 173
................................................174, 243
National....................................013, 105
NEC ........023, 097, 100, 107, 108, 109
........118, 119, 120, 129, 185, 254, 269
Nikkai ......................................033, 034
Nikko................................014, 120, 126
Normande........................................276
NTC ................................................126
Onwa ......................................083, 145
Optimus ..........................................243
Optonica..................037, 039, 192, 234
Orion................................015, 142, 260
Osaki................................................034
Panasonic........006, 011, 012, 013, 060
................064, 104, 105, 106, 165, 263
................................................265, 269
Philco ..............036, 095, 108, 109, 118
........119, 120, 121, 123, 128, 165, 170
........171, 176, 178, 184, 241, 267, 269
Philips......052, 064, 118, 121, 123, 128
................165, 170, 171, 176, 177, 186
........................................187, 188, 269
Pilot..................................................118
Pioneer............059, 077, 112, 118, 120
..........................189,190, 237, 243, 264
Portland ..................094, 109, 118, 119
................................................120, 126
Price Club........................................199
Proscan ..................000, 111, 115, 239
Proton..............014, 026, 094, 103, 118
................................120, 123, 191, 244
Pulsar ......................................113, 118
Quasar ....011, 105, 106, 172, 263, 269
Radio Shack............034, 037, 083, 094
................115, 118, 120, 123, 145, 153
................................................192, 230
RCA ........000, 016, 017, 025, 053, 054
........055, 056, 057, 058, 077, 102, 109
........111, 115, 118, 119, 120, 128, 193
........194, 196, 197, 239, 245, 256, 269
................................................273, 274
Realistic ..........050, 118, 120, 123, 145
........................................153, 192, 230
Saisho......................................090, 091
Sampo ............................108, 118, 120
Samsung ........276, 008, 014, 034, 052
........091, 094, 097, 101, 108, 109, 118
........119, 120, 123, 125, 127, 128, 129
................................198, 199, 255, 275
Sansui..............................................260
Sanyo ..............049, 050, 051, 082, 118
........................153, 154, 180, 200, 230
SBR ................................................052
Schneider ........................................052
Scotch..............................................120
Scott........083, 087, 089, 094, 118, 120
........................123, 132, 142, 145, 151
Sears ......009, 014, 030, 040, 041, 042
........043, 044, 045, 046, 047, 050, 051
........082, 089, 097, 111, 118, 120, 124
........128, 129, 151, 153, 154, 155, 169
................173, 174, 201, 202, 230, 239
TV Code List Continued
WKB10WB1_1100QXD.job 11/7/00 2:14 PM Page 10

11
Seimitsu ..........................................014
Sharp ......021, 022, 037, 038, 039, 049
................094, 118, 120, 123, 137, 192
................................203, 205, 210, 234
Shogun ............................................118
Siemens ..........................................049
Signature ........................116, 183, 266
Simpson ..........................................121
Sony................114, 117, 259, 268, 272
Soundesign..............014, 083, 095, 118
................................120, 121, 145, 151
Spectricon................................029, 099
Squareview......................................015
SSS ........................083, 109, 118, 145
Starlite..............................................145
Supra ..............................................097
Supre-Macy ............................098, 235
Supreme..........................................117
Sylvania...........035, 036, 064, 095, 108
................118, 120, 121, 128, 165, 170
................171, 176, 177, 178, 184, 188
........................................207, 241, 267
Symphonic ......................015, 145, 270
Tandy ..............................033, 039, 234
Tatung..............................105, 237, 269
Technics ..........................................106
Techwood ................097, 118, 120, 157
Teknika ...........031, 032, 083, 089, 094
................095, 096, 097, 098, 101, 109
................110, 118, 119, 120, 121, 123
................124, 126, 145, 151, 177, 182
........................................183, 199, 266
Teletech ..........................................091
Tera..........................................103, 244
Thomas............................................014
Thompson........................................005
TMK ........................014, 097, 118, 120
Toshiba............019, 030, 046, 050, 101
........153, 173, 174, 199, 201, 230, 255
Totevision ........................................094
Toyomenko ......................................014
Universal..........................081, 156, 187
Vector Research..............................108
Victor ..............................069, 169, 240
Video Concepts ..............................063
Vidtech ............014, 109, 118, 119, 120
Viking ......................................098, 235
Wards..... 037, 081, 089, 102, 108, 109
........116, 118, 119, 120, 128, 132, 151
........156, 165, 170, 171, 176, 177, 183
........184, 187, 188, 192, 208, 209, 266
........................................267, 268, 270
Yamaha....................108, 109, 119, 120
................................................128, 129
York..................................................014
Zenith.......................113, 118, 183, 226
................................227, 261, 266, 271
Zonda ..............................................029
TV Code List Continued
TV Operation
The ON•OFF key is used to turn the programmed TV ON or OFF.
When the keyboard is programmed to a RCA, GE, or ProScan TV, the
TV key will also turn the TV ON.
Note: The INPUT key allows you to scroll through available video input sources.
WKB10WB1_1100QXD.job 11/7/00 2:14 PM Page 11

12
If the wireless keyboard is not working properly, check the following:
•Make sure you're pointing the keyboard at the front of the device you want
to control.
•The wireless keyboard may need to be programmed to operate your TV.
•Check operation of the keyboard at a shorter distance to the
receiver or TV.
•Make sure there is a clear line of sight between the keyboard and the
TV or receiver.
•Make sure the batteries are inserted correctly.
•The batteries may be weak. Replace all batteries with new
batteries. For best results, use alkaline batteries.
•Check for electrolyte leakage in the battery compartment. If
leakage has occurred, wipe the affected area of the battery
compartment with a clean, dry cloth. Replace the old batteries
with new ones.
•If the channel keys are not working, press TV or WEBTV depending
on which device you are trying to control.
•Your keyboard is defaulted to operate the RCA receiver with
UltimateTV service. If you have a WebTV Plus or WebTV Classic
receiver, you must change the switch in the battery compartment as
shown to operate these receivers.
Troubleshooting
WKB10WB1_1100QXD.job 11/7/00 2:14 PM Page 12

Thomson Consumer Electronics, Inc. warrants that for 1 year
from date of purchase, it will replace this product if found to be
defective in materials or workmanship. Return it postage prepaid
to the Product Exchange Center address for prompt, no charge
replacement with a current equivalent. This replacement is
Thomson Consumer Electronics, Inc.’s sole obligation under this
warranty. Thomson Consumer Electronics, Inc. will not be
responsible for any incidental or consequential damages, or for
any loss arising in connection with the use or inability to use this
product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation or
exclusion may not apply to you. This warranty excludes defects
or damage due to misuse, abuse, or neglect. This warranty gives
you specific legal rights, and you may also have other rights,
which vary from state to state.
UltimateTV, the UltimateTV logo, WebTV, and the
WebTV logo are either registered trademarks or
trademarks of Microsoft Corporation in the United
States and/or other countries. Logos shown are
registered trademarks of respective companies.
©2000 Thomson Consumer Electronics, Inc.
Product Exchange Center
11721 Alameda Ave.
Socorro, TX 79927
PWKB10WB1 Rev1100
Trademark(s) ® Registered Marca(s) Registrada(s)
Made in China
Limited 1 Year Warranty
13
WKB10WB1_1100QXD.job 11/7/00 2:14 PM Page 13

Other RCA Accessories
Several accessories are available that will enable you to expand your home
video system. To order any that are listed below or to find out what other
accessories are available contact your local RCA dealer, or call
1-800-338-0376.
Universal Remote Control
(RCU800)
A full featured remote that offers the versatility of
operating both video and audio components. It controls
up to 8 components and includes code search,
advanced PIP and menu controls, DBS satellite system
compatibility and a toll-free consumer help line.
Surge Suppressor
(SCP40)
Get full surge protection for your phone line, eliminate
interference from noise entering through power lines
and protect your valuable equipment from most harm-
ful power spikes. 6 heavy duty grounded outlets and
in/out phone line jack.
$39.95
$19.95
WKB10WB1_1100QXD.job 11/7/00 2:14 PM Page 14
