RCA RWD200 User manual

COMPACT PORTABLE
WASHING MACHINE
INSTRUCTION MANUAL
Model No.:RWD200

P.02
Contents
3-4
5
5
6
6
6
7
8
8
9
10
10
10
10
11
12
12
13
17-18
19
19-20
21
22-24
25
26
27
28
SAFETY PRECAUTIONS
Important safety instructions
Before operating this machine
Grounding instructions
Attention shall be paid to protecting the machine
Cautions during handling machine
Cautions when washing clothes
INSTALLATION REQUIREMENTS
Tools and parts
Location requirements
Electrical requirements
Unpacking the washing machine
INSTALLATION INSTRUCTIONS
Dispose the packing materials
Remove transport bolts
Select the location
Connect the inlet hoses
Drain system options
Level the washer
Electrical connection
OPERATING INSTRUCTIONS
Checklist and preparation before washing clothes
View of control panel
Washing clothes at first time
Select the procedure
Table of washing procedures
CARE AND CLEANING
TROUBLESHOOTING TIPS
REMOVE THE PROBLEMS
APPENDIX
TECHNICAL SPECIFICATIONS

P.03
SAFETY PRECAUTIONS
IMPORTANT SAFETY INSTRUCTIONS
Save these instructions
WARNING - To reduce the risk of fire, electric shock, or injury to persons when using
your appliance, follow basic precautions, including the following:
- Read all instructions before using the appliance.
- Do not wash articles that have been previously cleaned in, washed in, soaked in,
or spotted with gasoline, dry-cleaning solvents, or other flammable or explosive
substances, as they give off vapours that could ignite or explode.
- Do not add gasoline,dry-cleaning solvents, or other flammable or explosive substances
to the wash water. These substances give off vapours that could ignite or explode.
- Under certain conditions, hydrogen gas may be produced in a hot-water system that
has not been used for 2 weeks or more. HYDROGEN GAS IS EXPLOSIVE.If the hot-water
system has not been used for such a period, before using a washing machine, turn on all
hot-water faucets and let the water flow from each for several minutes. This will release
any accumulated hydrogen gas. As the gas is flammable, do not smoke or use an open
flame during this time.
- Always unplug the washing machine from the power supply before attempting any service.
Disconnect the power cord by grasping the plug, not the cord.
- To reduce the risk of fire, clothes, cleaning rags, mop heads and the like which have
traces of any flammable substance, such as vegetable oil, cooking oil, petroleum based
oils or distillates,waxes,fats,ect.,must not be placed in the washing machine.These items
may contain flammable substances which ,even after washing, may smoke or catch fire.
- Never place items in the washer that have been dampened with gasoline or any
combustible or explosive substance. Do not wash or dry anything that has been soaked
in or spotted with any type of oil(including cooking oils).Doing so can result in fire ,
explosion, or death.
- Do not allow children to play on or in the appliance. Close supervision of children is
necessary when the appliance is used near children.
- Pets and kids may climb into the machine. Check the machine before every operation.
- Glass door or protector may be very hot during the operation. Keep kids and pets far
away from the machine during the operation.
- This machine is not intended for use by persons (including kids) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the machine by a person
responsible for their safety.
- Kids should be supervised to ensure that they do not play with the machine.
- When children become old enough to operate the appliance, it is legal responsibility of
the parents or legal guardians to ensure that they are instructed in safe practices by qualified
persons.
- Do not machine wash fiberglass materials (such as curtains and window coverings that
use fiberglass materials.)Small particles may remain in the washing machine and stick
to fabrics in subsequent wash loads causing skin irritation.
- Before the appliance is removed from service or discarded, remove the door and cut off
the power cord .
.

P.04
SAFETY PRECAUTIONS
- Do not reach into the appliance if the tub or agitator is moving.
- Do not install or store this appliance where it will be exposed to the weather.
- Do not tamper with controls.
- Do not repair or replace any part of the appliance or attempt any servicing unless
specifically recommended in the user-maintenance instructions or in published
user-repair instructions that you understand and have the skills to carry out.
- Never stop a tumble dryer before the end of the program and spread out so that the heat
is dissipated.
- Pull out its plug from the power socket before cleaning or maintenance.
- Make sure that all pockets are emptied.
- Sharp and rigid items such as coin, brooch, nail, screw or stone etc. may cause serious
damages to this machine.
- Pull out its plug and cut off water supply after the operation.
- Please check whether the water inside the drum has been drained before opening its
door. Please do not open the door if there is any water visible,
- Do not try to repair the machine by yourself. The machine may be damaged or more
troublesome repair work may be caused and even dangerous operation may take place
if it is repaired by any inexperienced or unqualified staff.
- If the plug (power cord) is damaged, it shall be replaced by the manufacturer or a service
agent to avoid any danger.
- Take care that power voltage and frequency shall be identical to those of washing machine.
- Do not use any socket with rated current less than that of washing machine. Never pull
out power plug with wet hand.
- To ensure your safety, power cord plug must be inserted into an earthed three-pole
socket. Check carefully and make sure that your socket is properly and reliably earthed.
- This machine shall be repaired only by an authorized service center and only authentic
accessories can be used.
- Do not dry articles that have been previously cleaned in, washed in, soaked in, or spotted
with gasoline, dry-cleaning solvents,or other flammable or explosive substances, as they
give off vapours that could ignite or explode.
- Do not use fabric softeners or products to eliminate static unless recommended by the
manufacturer of the fabric softener or product.
- Do not use heat to dry articles containing foam rubber or similarly textured rubber-like
materials. The interior of the appliance should be cleaned periodically by
qualified service personnel.
- Do not place items exposed to cooking oils in your dryer. Items contaminated with cooking
oils may contribute to a chemical reaction that could cause a load to catch fire.
- An appliance shall be clearly and permanently marked with a warning that the appliance is
intended for use only with fabrics that have been washed with water as a cleaning agent.
- To reduce the risk of fire, do not dry articles containing foam rubber or similarly textured
rubber like materials.
- If connected to a circuit protected by fuses, use time-delay fuses with this appliance.

P.05
SAFETY PRECAUTIONS
Before operating this machine
- Packing materials may be dangerous to the kids. Please keep all packing materials
(plastic bags, foams etc) far away from the kids.
- Washing machine shall not be installed in bath room or very wet rooms as well as in
the rooms with explosive or caustic gases.
- Make sure that the water and electrical devices must be connected by a qualified
technician in accordance with the manufacturer's instructions and local safety
regulations.
- Before operating this machine, all packages and transport bolts must be removed.
Otherwise,the washing machine may be seriously damaged while washing the clothes.
- Before washing the clothes at first time,the washing machine shall be operated in cotton
and hot water procedures without the clothes inside .
- This washing machine is for indoor use only.
Grounding instructions
- This appliance must be grounded . In the event of a malfunction or breakdown,
grounding will reduce the risk of electric shock by providing a path of least resistance
for the electric current. This appliance is equipped with a cord that has an equipment
-gurounding conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with all local
codes and ordinances.
WARNING-Improper connection of the equipment grounding conductor can result in
electric shock. Connect to individual branch Circuit. Check with a qualified electrician
or serviceman if you are in doubt as to whether the washer is properly grounded.
DO NOT modify the plug provided with the appliance if it will not fit the outlet . Please
have a proper outlet installed by a proper outlet installed by a qualified electrician.
Attention shall be paid to protecting the machine
- Do not climb up and sit on top cover of the machine.
- Do not lean against machine door.
- Please do not close the door with excessive forces. If it is found difficult to close the
door, please check if the excessive clothes are put in or distributed well.
Cautions during Handling Machine
- Transport bolts shall be reinstalled to the machine by a specialized person.
- The accumulated water shall be drained out of the machine.
- Handle the machine carefully. Never hold each protruded part on the machine while
lifting. Machine door can not be used as the handle during the conveyance.
Cautions When Washing Clothes
- Cold city water shall be used and hot water may be also connected according to the local
situations.
- Your washing machine is only for home use and is only designed for the textiles suitable
for machine washing.
- Flammable and explosive or toxic solvents are forbidden. Gasoline and alcohol etc.

P.06
shall not be used as detergents. Please only select the detergents suitable for machine
washing, especially for front loading .
- It is forbidden to wash carpets.
- Be careful of burning when washing machine drains hot washing water.
- Never refill the water by hand during washing.
- After the program is completed, please open the door after the bell or disconnect the
power supply to the machine.
- Please remember to disconnect water and power supply immediately after the clothes
are washed.
- Always follow the fabric care instructions recommended by the clothing manufacturer.
- Do not use the washing machine if it has a worn power cord or loose plug. Contact an
authorized service agent.
- Do not operate the washing machine if any guards, panels and /or fasteners except
transport fixing bolts have been removed. Check the fill hose connections on a regular
basis to ensure that they are tight and not leaking.
- Do not operate the washing machine if parts are missing or broken.
- Do not touch the door if washing at high temperatures.
Note;
- The Important Safeguards and Warnings indicated in this manual do not cover all
possible conditions which may occur. Common sense, caution and care must be
exercised when installing, maintaining or operating the washing machine.
- Always contact your dealer, distribute, service agent or the manufacturer about any
problems or conditions that you do not understand.
SAFETY PRECAUTIONS

P.07
Tools and Parts
Gather the required tools and parts before starting installation. The parts supplied are in
the washer drum.
INSTALLATION REQUIREMENTS
Transport Hole Plug
1/4 nut driver 3/8 socket with ratchet
3/8″ open end wrench
Adjustable wrench or 7/16″ socket with ratchet
Adjustable wrench or 9/16″ open-end wrench
Channel-lock adjustable pliers
Carpenter’s level
″ ″
-
Water Hoses(2)
Cable Tie
Warning!
Failure to comply with these warnings could result in serious
personal injuries.Note:Environmental Protection
- If you plan to dispose this machine, please comply with the local waste disposal
regulations. Cut off the power cord so that it will not be put into reuse.
Remove the door so that kids and animals will not be trapped in the machine.
- Do not use excessive detergents.
- Decontaminant and bleacher can be used to pre-treat the stains on the clothes only
when very necessary.
WARNING – Risk of Fire
Clothes dryer installation must be performed by a qualified installer.
Install the clothes dryer according to the manufacturer’s instructions and local codes.
These conditions will obstruct clothes dryer airflow and increase the risk of fire.
To reduce the risk of severe injury or death, follow all installation instructions.
Save these instructions.
1.This machine must be earthed properly. If there is any short circuit, earthing can reduce
the danger of electrical shock.
This machine is equipped with power cord, which includes plug, earthing wire at earthing
terminal.
2.Washing machine shall be operated in a circuit separate from other electrical appliances.
Otherwise, power protector may be tripped or fuse may be burned out.
！
WARNING

P.08
INSTALLATION REQUIREMENTS
Electrical Requirements
WARNING
2
2
Installation clearances
1.The location must be large enough to allow the washer door to be fully opened.
°
2. Additional spacing should be considered for ease of installation and servicing. The door
opens more than 90 ,and it is nor reversible.
3. Additional clearances might be required for wall ,door , and floor moldings.
4. Additional spacing of 25mm on all sides of the washer is recommended to reduce noise
transfer.
5. Companion appliance spacing should also be considered.
Location Requirements
Selecting the proper location for your washer improves performance and minimizes noise
and possible washer “walk.”Your washer can be installed under a custom counter,or in a
basement, laundry room, closet, or recessed area. See “Drain System.”Companion
appliance location requirements should also be considered. Proper installation is your
responsibility.
You will need
1. A water heater set to deliver 120°F (49°C) water to the washer.
2. A grounded electrical outlet located within 6 ft.(1.8 m) of where the power cord is
attached to the back of the washer.See “Electrical Requirements.”
3. Hot and cold water faucets located within 4 ft.(1.2 m)of the hot and cold water fill
valves,and water pressure of 20-100 psi (137.9-689.6 kPa).
4. A level floor with a maximum slope of 1" (25 mm)under entire washer.Installing the washer
on soft floor surfaces,such as carpets or surfaces with foam backing.is not recommended.
5. A sturdy and solid floor to support the washer with a total weight (water and load) of 200lbs.
6. Do not operate your washer in temperatures below 32°F (0°C).Some water can
remain in the washer and can cause damage in low temperatures.

P.09
Washer Dimensions
INSTALLATION REQUIREMENTS
23
"
(585 mm)
The dimensions shown are for the recommended spacing. Custom dercounter installation
23
"
( 595 mm)
1 "
(25 mm)
1 "
(25 mm)
2 " (50 mm)
" min.
(850 mm)
1/2
1/2
1/2
1/2
4
1"
(1035 mm)
23
"
(595 mm)
33
33
"
(850mm)
1.A120v.60Hz,AConly,15-or 20amp,fused electrical supply is required. A time-delay fuse
or circuit serving only this appliance be provided .
2.This washer is equipped with a power supply cord having a 3 prong grounding plug.
3.To minimize possible shock hazard ,the cord must be plugged into a mating,3 prong,
grounding type outlet ,grounded in accordance with accordance with local codes and
ordinances. If a mating outlet is not available ,it is the personal responsibility and
obligation of the customerto have the properly grounded outlet installed by a qualified
electrician.
4.If codes permit and a separate ground wire is used ,it is recommended that a qualified
electrician determine that the ground path is adequate.
5.Do not ground to a gas pipe .
6.Check with a qualified electrician if you are not sure the washer is properly grounded.
7.Do not have a fuse in the neutral or ground circuit.
Unpacking the washing machine
Unpack your washing machine and check if there is any damage during the transportation.
Also make sure that all the items (as shown in Page 5) in the attached bag arereceived.
If there is any damage to the washing machine during the transportation, or anyitem is
missing, please contact the local dealer immediately.

P.10
INSTALLATION INSTUCTIONS
Select the location
Before installing the washing machine, the location characterized as follows shall be
selected:
- Rigid, dry, and level surface (if not level, please make it level with reference to the
following figure “Adjust Leg”)
- Avoid direct sunlight
- Sufficient ventilation
- Room temperature is above 0 C
- Keep far away from the heat resources such as coal or gas.
Make sure that the washing machine will not stand on power cord.
Do not install the washing machine on the carpet floor.
Connect inlet pipe
Connect the inlet pipe as indicated in the figure.
For the model which has hot valve , please connect
the hot vale to hot water tap.
HC
Install inlet pipe
1.Connect the elbow to tap and fasten it
clockwise.
2.Connect the other end of inlet pipe to the inlet
valve at the backside of washing machine and
fasten the pipe tightly clockwise.
Dispose the packing materials
The packing materials of this machine may be dangerous to kids. Please dispose them
properly and avoid easy touch by kids. Please dispose the related packing materials
according to the relevant local regulations. Please do no throw the packing materials
away together with the other daily living rubbishes.
Remove transport bolts
Before using this washing machine, transport bolts
must be removed from the backside of
this machine. Please take the following steps to
remove the bolts:
1.Loosen all bolts with spanner and then remove them.
2.Cover the holes with transport hole plugs.
3.Keep the transport bolts properly for future use.

P.11
INSTALLATION INSTUCTIONS
A
Capacity can be no less than 17 gal.(64 L)per minute.
The top of the standpipe must be at least 60cm high and
no higher than 100cm from the bottom of the washer.
Floor drain system(view D).The floor drain system requires
a siphon break that may be purchased separately.
See“Tools and Parts”.The siphon break must be a minimum
of 28" (710 mm)from the bottom of the washer.
Additional hoses might be needed.
Min 60
Max 100
B
Laundry tub drain system (view C)
The laundry tub needs a minimum 20 gal. (76 L)
capacity. The top of the laundry tub must be
at least 60cm above the foor.
Min.60cm
Max.100cm
C
28 " min.
(710 mm)
D
Drain System Options
Standpipe drain system -wall or foor (views A & B)
The standpipe drain requires a minimum diameter
standpipe of 2"(50 mm).The minimum carry-away
Note: after connection, if there is any leakage with hose, then repeat the steps to connect inlet
pipe. The most common type of tap shall be used to supply water. If tap is square or too big,
then standard tap shall be changed.

P.12
INSTALLATION INSTUCTIONS
Electrical Connection
- As the maximum current through the unit is 12A when you are using its heating function,
please make sure the power supply system (current, power voltage and wire) at your
home can meet the normal loading requirements of the electrical appliances.
- Please connect the power to a socket which is correctly installed and properly earthed.
- Make sure the power voltage at your place is same to that in the machine's rating label.
- Power plug must match the socket and cabinet must be properly and effectively earthed.
- Do not use multi-purpose plug or socket as extension cord.
- Do not connect and pull out plug with wet hand.
- When connecting and pulling out the plug, hold the plug tightly and then pull it out. Do
not pull power cord forcibly.
- If power cord is damaged or has any sign of being broken, special power cord must be
selected or purchased from its manufacturer or service center for replacement.
5.Put a solid cylinder (e.g. pop cans) oppositely on the
top cover of the washing machine from in the left, right,
front and back directions. If the cylinder keeps stable, the washing machine is
positioned level. If it rolls, the washing machineis positioned unlevel.The rolling direction is
the direction of lower ground surface.Then the two legs in this direction shall be raised at the
same time until the washing machine is level.Steps 1~3 are repeated to make the bottom legs
closely against the ground and the nuts shall be locked tightly. .
3.Ensure the positioning status of washing machine.
Loosen the lock nut with spanner and turn the leg
with hand until it closely contacts with the floor. Press
the leg with one hand and fasten the nut closely to the
cabinet with the other hand.
4.After being locked properly, press four corners again to
make sure that they has been adjusted properly. If it is
still unstable, it has to repeat Steps 2 and 3
Level the washer
1.When positioning the washing machine, please
first check if the legs are closely attachedto the
cabinet. If not, please turn them to their original
positions with hand or spanner andtighten the
nuts with spanner.
2.After positioning the washing machine, press
four corners on top cover of washing machine
in sequence. If the washing machine is not
stable when being pressed, this leg shall be adjusted.

P.13
OPERATING INSTRUCTIONS
Checklist and Preparation before Washing Clothes
Please read this operation method carefully to avoid the troubles of washing machine and
damages of clothes.
Check if the first-washed clothes will bed decolorized.
After a white towel touched with liquid detergent is used to wash the invisible corners of the
clothes, check if the white towel is stained with
clothes' original color.
As for the scarves and those clothes that easily
get decolorized among imported clothes, please
wash them separately before washing.
As for the stains on sleeves, collars and pockets,
use the liquid detergent and wash it with brush
gently. Finally put them into the washing machine
to achieve more ideal washing effects.
As for temperature-sensitive clothes, they shall
be washed as required in the labels. Otherwise,
it may cause color change or distortion.
Keep in Mind:
Never put the clothes to be washed in washing machine for a long period of time.
Otherwise it may get moldy and cause spots. Therefore, please wash the clothes in time.
The clothes also may get color changed or distorted if they are not washed according to
the stated washing temperature.
Clothes that can not be washed by washing machine
The clothes that may get distorted if being immersed in water:
Ties, waistcoats, western-style clothes, outer garments etc. may have obvious shrinkage
if being immersed in water; the decolorized clothes such as blended spinning clothes of
artificial fiber etc.
WARNING – To reduce the risk of fire, electric shock, or injury to
persons, read the IMPORTANT SAFETY INSTRUCTIONS before
operating this appliance.

P.14
OPERATING INSTRUCTIONS
Wrinkle-style clothes, embossed clothes, resin clothes etc. may get distorted when being
immersed in water. Among cotton and wool materials, the clothes that get easily distorted
are wrinkle-style silk, fur products and fur decorations;
Clothes with decoration, long dress and traditional clothes etc are the products to get
decolorized easily.
Please do not wash the clothes without material labels and washing requirements.
Never wash the clothes stained with the chemicals such as gasoline, petroleum, benzene,
paint thinner and alcohol.
Please pay attention with regard to detergents
“Low bubble” detergent or washing powder or washing powder special for drum washing
machine shall be selected according to fiber types (cotton, synthetic fiber, soft products and
wool products), colors, washing temperatures, dirty degrees and types. Otherwise,
excessive bubbles may be generated and overflowed out of the drawer so that accidents
may take place.
Bleacher belongs to alkali type and can damage clothes, so it is suggested to use as little
as possible.
Powder detergents can easily leave the residues in the clothes so as to generate the bad
smell, so they shall be sufficiently rinsed.
Detergent can not easily get dissolved completely if there is too much detergent or water
temperature is rather low. It can remain in clothes, pipes and washing machines to
pollute the clothes.
Washing shall follow the weight of clothes, dirty degrees, local water hardness as well as
the recommendations from the detergent manufacturers. Please consult the water
company if you are not clear of water hardness.
Note:
Keep detergents and additives in safe and dry places out of touch by kids.
Please take out the items out of the pockets.
Please check the pockets of the clothes to be washed, empty the rigid items such as
decorations and coins, otherwise washing machine may be damaged or have abnormal
troubles.
For the clothes to be washed, they are classified according to the following
characteristics:
The symbol types of care labels: the clothes to be washed are classified into cotton, blended
fiber, synthetic fiber, silk, wool and artificial fiber.
Color: white and colorful colors shall be identified. All new colorful articles shall be washed
in a separate way.

P.15
OPERATING INSTRUCTIONS
Size: the articles of different sizes are washed together to increase the washing effects.
Sensitivity: soft articles shall be washed separately. As for new pure wool textiles, curtains
and silks, the soft washing procedure shall be selected. Check the labels in all washing
articles.
The clothes shall be sorted before being put into washing machine. As for the curtains with
hooks, the hooks shall be removed before being washed.
The decorations on the clothes may damage the washing machine. As for the clothes with
buttons or embroideries, they shall be turned over before being washed.
Clean up fasteners:
Zips shall be zipped close and buttons or hooks shall be fixed. The loose band or ribbon
shall be bound together.
It is suggested to put bras into the pillow slip
with zip or buttons sealed to prevent the steel
wire from popping out of bras into the drum and
damaging the machine.
Especially delicate textiles such as laced curtains,
straightjackets, small articles (tight socks,
handkerchiefs, ties etc.) shall be put into string
bag for washing.
When washing a single big and heavy dress such
as Turkish towels, jeans, wadded jackets etc.,
it may easily cause great eccentricity and give
alarm due to great unbalance. Therefore it is
suggested to add one or two more clothes to be
washed together so that draining can be done
smoothly.
Clean away dusts, stains and pet hairs from the clothes.
The clothes may be damaged and disturb washing effects during the friction between
dusts, stains and clothes.
To protect baby skin
Baby articles (baby clothes and towels) including napkins shall be washed separately.
If they are washed together with the adults' clothes, they may be infected. Rinsing times
shall be increased to ensure the thorough rinsing and cleaning without the detergent
residues.
It is suggested that the parts that are easily stained such as white sockets, collars
and sleeves etc. shall be hand washed before being put into washing machine to
achieve more ideal washing effects.
Please use powder or liquid detergents. The residues of the soap could remain in the
gaps of the clothes if soap is used.
！

P.16
OPERATING INSTRUCTIONS
Confirm the washing capacity:
Do not put excessive washings; otherwise it may affect the washing effects. Please confirm
the maximum affordable washing quantity according to the following table.
The clothes which easily get fuzzed shall be turned over for washing
The clothes which easily get fuzzed shall be washed separately; otherwise the other
articles can be stained with dust and thrum etc. Preferably, black clothes and cotton
clothes shall be washed separately because they can easily get stained with the thrums
of other colors when being washed together.
Please check before washing.
Washing machine shall not wash water-proof materials (ski suits, outside napkin
pads, curtains).
As for the fiber products that water can not get soaked easily into such as water-proof
cushions, and clothes, it is better not to wash. Otherwise there will be water bursting out
or abnormal vibration to cause danger while rinsing and draining so that the clothes also
may be damaged. (Such as outside napkin pads, raincoats, umbrella, ski suits, car covers,
sleeping sacks etc.)
Cautions during Draining
Draining of normal clothes:
Moistures of washings are drained through drain hole.
Draining of water-proof clothes and fiber products:
In the normal washing and draining status, moistures of water-proof clothes and fiber
products can not be drained while water is gathered in one direction so that the
eccentricity of washing machine is too great and vibration or moving is caused.
7.0kg
7.0kg
3.5kg
2.5kg

P.17
OPERATING INSTRUCTIONS
View of Control Panel
1. Power :Pressing [Power] to start the display. If the display is active, press to put the
washer into standby mode .If the washer is paused and the cycle is not restarted within
10 minutes,the current wash cycle will be cancelled.
2. Start/Pause :Press to start a wash cycle. If the washer is running, pressing it once will
pause the washer. Press again to restart the wash cycle.
NOTE:If the washer is paused and the cycle is not restarted within 10 minutes, the current
wash cycle will be cancelled.
3. Change Cycles and Options:Not all Options are available with all Cycles.
Cycles and Options can be changed anytime before Start/Pause is pressed.
4. To cancel a cycle.
a Press [Power] for 3 seconds to stop the cycle ,the door is unlock .Then change the cycle
b Press Start/Pause once and select the desired option.
5. To drain the washer manually.
a.Press Power for approximately 3 seconds.
b.Select Spin.
d.Press and hold START/PAUSE.
e.When the spin is complete, the door unlocks. Items can be removed from the washer.
6. Wash cycle.
Cotton/Normal: You can select this procedure to wash the daily washable clothes. The
washing period is quite long with quite strong washing intensive. It is recommended to
wash the daily cotton articles, for example: bed sheets, quilt covers, pillowcases, gowns,
underwear etc.
Bulky/Large:To increase the washing effects, main additional washing time is increased.
Except single quick, wash, drain and spin procedures, the other procedures can select
Cotton intensive function. It is recommended to wash the clothes for babies or worn by
the persons with allergic skin.
Sport: In this cycle, active enzyme can help wash the clothes which are not easily cleaned
in the way of 40℃ prewash and main wash.
Delicate: You can choose this procedure to wash silk clothes.
Hand Wash/Wool: You can select this procedure to wash the wool textiles labeled with
Start/
Pause
Hold 3 Sec.
Add Garment
Cotton/Normal
Baby Wear
Refresh
Sport
Delicate
Cotton/Normal
Bulky/Large
Hand Wash
/Wool
Rinse&Spin
Spin
Dry
Power
Speed Wash
Sanitary
∞
Drying
Extra Rinse
My Cycle
Pre-wash Temp. DelaySpin Speed Soil Level
Child Lock
F
Notes:
- The Control panel line chart is for reference only,Please refer to real product as standard.
- The Control panel could be changed without written notice. Please visit the website of
Washing Machine or call up the service line for consultation.

P.18
OPERATING INSTRUCTIONS
“Machine Wash”. Please select the proper washing temperature according to the label
on the articles to be washed. Furthermore, the proper detergent shall be selected for wool
textiles.
Baby Wear: You can choose this procedure to wash children's underwear.
Speed Wash: This procedure is suitable for washing few and not very dirty clothes quickly.
Sanitary: This cycle is specially set in this machine to clean the drum and tube. It will provide
an extra high temperature sterilization to make the clothes washing more green.
When proper amount of chlorine bleaching agent is put in, the barrel cleaning effect will be
better. The customer can use this procedure regularly according to the need.
NOTE: Do not use this cycle with clothes, and do not add detergent or fabrics softener.If you
use this cycle on a monthly basis, the wash drum will be kept clean.
Rinse ＆ Spin: Select this option to rinse and spin a load separately from a regular cycle.
This can be helpful in preventing fresh stains from setting in fabrics.
Refresh: During this cycle, there is only hot air rather than water ejecting from inside the
drum to wash the clothing. Also it can be used to dry clothes weighs less than 0.5kg.For
a shirt or a short.
Spin:Separate Spin Procedure.Soap water or rinse water shall be drained out before spinning.
Cotton/Normal Dry: This is a normal drying procedure. Moisture content of the clothes after
drying is -3%~3%.The load of drying is not more than 3.5kg.
NOTE: The drying time according to the weight.
OPTION BUTTONS
Drying: This option will add a drying cycle to the selected cycle.
Extra Rinse: This option will add an extra rinse cycle to the selected cycle.
My Cycle: When this button is pressed continuously, this cycle will be remembered.
You can quickly choose this cycle only by press this button at the washer next start.
Delay: The delay start light will flash to indicate the delay time.It will start the cycle
after【xx】hours.
Soil level: It’s divided into three levels. Choose the right soil level before the washer started
is necessary.
Spin speed: The washer drum spin at up to 1200RPM. This reduces drying time and saves
energy. Press the SPIN SPEED button until the indicator light for the desired setting is lit.
Some fabrics, such as delicates, require a slower spin speed.
Temp.: Press this button to select the temperature you need.And here are four temperature
can be selected.
Pre-wash: Select this option to add a prewash and spin cycle to the chosen cycle.
This is especially useful for heavily soiled items.
Note:
When choose the drying cycle, it can be achieved by cooling water.
Pre-wash Wash Rinse Spin Drying

P.19
OPERATING INSTRUCTIONS
Washing Clothes at first time
Before washing clothes at first time, the washing machine shall be operated in
one round of the whole procedures without clothes in as follows:
1.Connect power source and water.
2.Put a little detergent into the box and close it.
3.Press the button “Power”.
4.Press the button “Start/Pause”.
The drawer is separated as follows:
I: Pre-detergent or washing powder.
II: main detergent, softener, pre-dip,
bleaching or decontaminating products.
: washing additive, such as fabric softener or tackifier.
Put detergent into washing machine.
1.Pull out the drawer.
2.Fill pre-detergent into Case I (when necessary).
3.Fill detergent into Case II.
4.Fill softener into Case (when necessary).
Notes:
- As for the agglomerated or ropy detergent or additive, before they are poured into the detergent box,
it is suggested to use some water for dilution to prevent the inlet of detergent box from being blocked
and overflowing while filling water.
-
Do not use bleach. Hazardous fumes can form
Start up washing machine
Connect the power. Check if water pipes are connected properly. Open the tap completely.
Put in the clothes to be washed and fill in the detergent and tackifier. Then press the button
“Power”,Select the proper procedures and functions and press the button “Start/Pause”.
Select the procedure
The proper washing procedures shall be selected according to the types, quantities, and
dirtiness of the clothes to be washed in combination with the following washing
temperature table.
Please choose suitable type of detergent for the various washing temperature to get the best washing
effect with less water and energy consumption.
Ⅰ
Ⅱ
Extra Hot
Hot
Warm
Seriously besmirched, pure white cotton or flax (for example: coffee
table cloths, canteen table cloths, towels, bed sheets)
Moderately besmirched, colorful flax, cotton and synthetic articles
with certain decolorizing degree (for example: shirts, night pajamas;
Slightly besmirched, pure white flax (for example: underwear)
Normally besmirched articles (including synthetic and wool)

P.20
OPERATING INSTRUCTIONS
First, turn the rotary switch to select the corresponding procedures according to the types
of textiles.
Second, select the proper temperature according to the dirtiness. Generally, the higher
the temperature is, the more the power is consumed.
Last, select the proper revolution speed. The higher the revolution speed is, the drier the
textiles are spun, but higher the noises will also be increased.
The surfaces of delicate textiles will have wrinkles and the working life of washing
machine will be shortened.
Add garment
This operation can be executed during the washing procedure.
When the basket of the washing machine is still rolling and there is large amount of water with high
temperature in the basket, The state is unsafe; the door cannot be opened forcefully.
