RDC GSM-ICE3 User manual

Interactive
Ecosystem
Communication
3
The GSM-ICE Gateway connects almost any alarm
panel with the communication ecosystem. This allows
for alarm signal reporting to the control room, control
of the alarm system with the smart phone app and the
addition of IP cameras using the same app. Smart
home/business IoT functions will be available in the
near future.
Alarm panel
POS
NEG IP1 RX
IP2 AC TX CID
IceCube
Control
Web app version
https://icecube.secure.direct

Key switch arming via the mobile application
can be achieved using a plug-in relay
expander module.
Key switch arming
See panel specific programming and wiring
instructions to follow.
Your Dealer Admin User should input the
3
following into the ICE Admin portal prior to
installation.
BEFORE INSTALLATION
https://iceadmin.secure.direct
2. Add the g .ateway serial number
The serial number can be scanned from
the outer packaging prior to installation or
from the unit on-site and send to your
Dealer Admin User for input. A Panel ID is
generated automatically and linked in the
system by the unit serial number.
1. Create an account.
3. Select a service plan, correct panel type
and activate the account.
3
4. Add main and sub users for the ICE
Control mobile app.
5. Input all other relevant customer
information.
6. Select/confirm the correct panel type.
Should the technician discover that a
different panel is used on-site, the Dealer
Admin User should be informed and the
3
correct panel type input into ICE Admin
portal. This input overrides selection in
point 3 if different.
Maximum recommended wire length is 5m.
INSTALLATION
Antenna and unit mounting position
NB: Do not mount units with an internal
antenna inside a metal enclosure.
Mount the gateway in its final position only
when the optimal signal position has been
determined - see LED indications.
When using a magnetic external antenna,
mount either on top or underneath the
control panel with a vertical orientation. Do
not mount on the side with a horizontal
orientation.
12 Volt power connection
2
Always use a minimum of 0.5mm stranded
wire for the 12V source. Four-core wire is
definitely NOT recommended.
POS
NEG IP1 RX
IP2 AC TX CID
POS
NEG IP1 RX
IP2 AC TX CID
WARNING
Do not open enclosure
sensitive antenna inside
IC S
725231000104
ICS
725231000104 Installation instructions inside
Please refer to warnings
ICS
www. ice3.co.za - 24hr Technical standby [phone]

Gateway connections & reporting
POS
NEG IP1 RX
IP2 AC TX CID
Input 2 / AC (select J1)
DC ( )
+
TX
DC (-) / RING
TIP
RX
Input 1
Input 2 jumper
With jumper
- AC monitoring
Without jumper
- Input 2
To panel serial
Green Amber Red
GSM activity
Input 1 (IP1) - fixed function
J1 jumper off - IP2 function selected
- Wireless panic button receiver
External resistor - not required
Default trigger - positive pulse
- Electric fence relay output
- Fixed panic button
Additional hardwired inputs x2
Input 2 (IP2/AC) - dual function
- Alarm panel PGM
Input delay - 100ms fixed
AC delay - 10 minutes - fixed
J1 jumper on - AC function selected
AC function monitors mains fail/restore.
Connect TIP and DC(-) as per individual
panel diagram for Contact ID reporting.
Dialler capture/Contact ID
AMBER - GSM
LED Indications
Off No GSM link
Blip Server request (1x/3sec)
Fast flashing Negotiating (5x/sec)
Slow flashing Connected to server (1x/sec)
GREEN - General
RED - Server
Off Restarting connectivity
Fast flashing Searching for network
Variable timing RSSI signal strength
- on longer = stronger
- on shorter = weaker
Slow flashing GSM link active
Solid GSM network established
Off No server connection
Battery monitoring and reporting
Reports battery low/battery restore.
Battery low - below 10.8V.
Battery restored - above 12.5V.
Connection - none required
Central station software generates alert on
polling communication failure.
Connection - none required
Polling/auto test
Patented “always-on” network supervision.
No auto-test/self-test reporting needed.

System acc. code [3][1][0] 1234*66
st
1 coms. options [3][8][0] 1 = on
Installer mode [*][8]
Installer code [5][5][5][5]
Programming mode [*][8][5][5][5][5]
Telephone no. [3][0][1] 1234*6666…
Partition acc. code [3][1][1] 1234
Note: If partitions 2-8 exist, programme
sections 312-318 as 1234 as well.
PowerSeries 1864PC
Coms. format [3][1][0] 0300
Op/Cl coms. [3][6][7] 1 = on
- call direction 5 = on
Communicator programming
Tel1 = 03 Tel2 = 00
Note: Call directions option locations 351-374,
1 = on or Partition1. If the system has
more partitions, 2-8 should also be on.
nd
2 coms. options [3][8][1] 4 = on
Start Zone1 prog. [0][0][1]
Scroll to Zone7 [<][>] Zone7 = 22
(Momentary K/S arm)
Scroll to Zone8 [<][>] Zone8 = 01 (Entry exit)
Entry2 delay 030 secs
Exit delay 003 secs
(for quicker arming)
Away and stay arm/disarm using Relay1&2
Note: Key switch arm/disarm is global for all
activated partitions.
Entry1 delay 030 secs
Delays [0][0][5]
Go to Partition1 [0][1]
Zones 7-8 used as example.
Keypad Bus Zones & PGMs
T-1
R-1 TIP RING
GRN YEL BLK RED - Bell + Bell - AUX
+ AUX
AC AC
Zone 8 COM Zone 7
DEOL Connection SEOL Connection
Zone resistor
Tamper resistor
DSC PC1864
Relay 1Relay 1Relay 2
RELAY EXPANDER
GSM GATEWAY
Away/stay mode arm [0][2][3] 8 = off
[2][0][2] 7 = on
8 = on
Exit and save [#][#]

Programming mode [*][8][5][5][5][5]
NEO
Communicator programming
Panel coms. path [3][0][0]
Partition1 acc. code [0][0][1] 1234#
Scroll [<][>] Closing confirm = Y
Part.1 call direction [3][1][1]
Scroll [<][>] Comms enable = Y
RC#1 format [0][0][1] CID = auto
st
001–003 to report to receiver1 - 1 Tel no.
Com. options 1 [3][8][0]
Phone line [0][1]
System acc. code [0][0[0] 1234
Com. format [3][5][0]
Phone numbers [#][3][0][1]
Receiver1 [0][0][1]
Phone number1 [0][0][1] 1234 *66#
Account codes [3][1][0]
Note: Programme 002-008 as 1234 if
partitions 2-8 are present.
Note: Program 312-318 as 1234 if partitions
2-8 are present.
Com. options 2 [3][8][0] Install Zone7 resistor to Relay1 on the unit.
Away and stay arm/disarm using Relay1&2
Exit and save [#][#][#]
System times [0][0][5] 001
Momentary arm [0][6][6]
Partition1 timers [2][0][1] Zones 7/8 =Y
[0][0][8][*]
Section 001- Zone7 [0][0][7][*]
Install Zone8 resistor to Relay2 on the unit.
Section 022 - option 10 Zone8 [*= No][#]
Zone8 as entry/exit [0][0][1]
To arm system in AWAY or STAY mode.
Zone 7-8 used as example - [<][>] to scroll
Keypad Bus Zones & PGMs
T-1
R-1 TIP RING
Relay 1Relay 1Relay 2
GRN YEL BLK RED - Bell + Bell - AUX
+ AUX
AC AC
Zone 8 COM Zone 7
RELAY EXPANDER
GSM GATEWAY
DSC NEO
DEOL Connection SEOL Connection
Zone resistor
Tamper resistor

Programming mode [*][9][9][9][9 (default)
Communicator programming
st
1 Telephone number
st
1 digit [4][3][*][1][*]
nd
2 digit [4][4][*][2][*]
st
1 digit [4][8][*][1][*]
th
4 digit [5][1][*][4][*]
Account code
Communicator format
th
4 digit [4][6][*][4][*]
nd
2 digit [4][9][*][2][*]
Contact ID protocol [4][7][*][6][*]
rd
3 digit [4][5][*][3][*]
rd
3 digit [5][0][*][3][*] .
Go into programming
Exit and save [#][#][#]
Away arm/disarm using Relay1
Zone8 used as example.
Select Zone8 [8][*]
Note that the exit delay need not be
programmed as this will instantly arm the
system in away mode.
Zone option K/S arm/disarm [5][*]
AC AC - GND - GND + TX
Siren 12V K/P Zone 7 COM Zone 8 1 2 3 4 5
Phone Phone Line Earth Line
IDS 805
18V AC
Zones
Dialer board
Relay 1Relay 1Relay 2
RELAY EXPANDER GSM GATEWAY
DEOL Connection
Zone resistor
Tamper resistor
SEOL Connection
NOTE:
Stay mode key switch arm/disarm via the
app is not supported on this panel.
Stay arm/disarm can be done via the keypad.
Although not functional, the away arm
function is still shown in the mobile app.

Telephone number [4][1]
Programming mode [9][9][9][9][*]
Zone7 used as example.
Installer code [0][0][0][0][0][0]
IDS
Partition1 [6][1]
Select Zone7 [7][*]
Panel programming
Programming mode [0] hold down
Installer mode [5][5][5][5]
Communicator programming
Contact ID [5][*]
Telephone number [5][1] 1234
Account code [1][2][3][4]
Note: Programme 62-68 as 1234 if partitions
2-8 are present.
Programming zone arming and disarming
Access Zones1-7 [1][*]
Key switch arm/disarm [5][*]
Exit and save [#][#]
The keypad expects a 4-digit section number
Enable tel. reporting [3][0][3][6] 3 = on
Communicator acc. no [3][0][6][1] 1234
Note: Program 3062-3068 as 1234 if partitions
2-8 are present.
Telephone no. 1 [3][0][7][1] 1234
Auto-trouble report codes [4][0][3][7]
Auto-zone report codes [4][0][3][2]
Contact ID format [3][0][7][0] 5555
Away arm/disarm using Relay1
Zone7 used as example.
Key switch prog. type [0][5][0][3]
8-dig. panel serial no.
3-dig. zone input no.
used e.g. 007
Key switch prog. [0][6][0][3]
Exit programming [CLEAR]
Momentary K/S pulse [1]
Assigned Partition1 [1]
Force arming [1]
K/S arming delay [3][1][3][0] 001 = 1 sec
0 sec will not work
Instant arming (AWAY) [8]
X
Protective your future
Zone resistor
Tamper resistor
DEOL Connection SEOL Connection
AC AC + TX
- TX
+ - Siren BUS Zone 7 COM Zone 8 Panic Phone -
IDS X64
18V AC
ZonesLine
Relay 1Relay 1Relay 2
RELAY EXPANDER GSM GATEWAY
Stay mode key switch arm/disarm via the
app is not supported on this panel.
Stay arm/disarm can be done via the keypad.
Although not functional, the away arm
function is still shown in the mobile app.
NOTE:

1 - TLM trouble on
6 - force dial on
MG5050
[8][1][1] 1234
Communicator programming
The keypad expects a 3-digit section number.
2 - TLM reporting on
Default code [0][0][0][0]
Contact ID [8][1][0]
Telephone no.1 [8][1][5] 1234
Partition1 [4][4]
Programming options [8][0][0]
5 - Tone dial on
Partition2 [8][1][2] 1234
Away arming
Momentary key switch [2][6]
Exit delay Partition1 [7][4][5] 000
Zone5 [0][0][5]
Zones 4-5 used as example.
Away and stay arm/disarm using Relay1&2
Install Zone5 resistor to Relay1 on the unit.
Partition assignment [1][Enter]
None of the zone options should be selected.
Panel will instantly arm when key switch is
activated.
Stay arming
Zone4 [0][0][4]
Panel will instantly arm when key switch is
activated.
Select no.6 zone option [Enter]
Install Zone4 resistor to Relay2 on the unit.
Momentary key switch [2][6]
Partition assignment [1]
Exit delay Partition1 [7][4][5] 000
Exit programming [CLEAR]
Exit and save [Menu][Yes]
AC Bell PGMs + AUX - AUX BUS COM Zone 4 Zone 5 GND R-1 T-I
RING TIP
PARADOX MG5050
Zones
GSM GATEWAY
Relay 1Relay 1Relay 2
RELAY EXPANDER
Zone resistor
Tamper resistor
DEOL Connection SEOL Connection

Contact ID format [3][0][7][0] 5555
Telephone no.1 [3][0][7][1] 1234
Communicator acc. no. [3][0][6][1] 1234
EVO192
Default code [0][0][0][0]
Communicator programming
The keypad expects a 4-digit section number.
Enable tel. reporting [3][0][3][6] 3 = on
Note: Program 3062-3068 as 1234 if more
than one partition is present.
Trouble reporting codes [4][0][3][7]
Zone reporting codes [4][0][3][2]
Zone7 used as example.
Key switch arming delay [3][1][3][0]
Key switch programming [0][5][0][3]
8-Digit panel serial no. [0][1][2][x] [x][x][B][C]
Away arm/disarm using Relay1
Key switch programming [0][6][0][3]
Assigned Partition1 [1]
Momentary key switch [1]
Zone input number [0][0][7]
Force arming [7]
Instant arming (AWAY) [8]
1 Second waiting time [0][0][1]
Note: 0 Sec does not work, value must be 001.
PARADOX EVO
AC Bell PGMs Relay + AUX
- AUX
BUS Zone 7 Zone 8 COM GND R-1 T-I
RING TIP
Zones
Relay 1Relay 1Relay 2
RELAY EXPANDER GSM GATEWAY
Zone resistor
Tamper resistor
DEOL Connection SEOL Connection
Stay mode key switch arm/disarm via the
app is not supported on this panel.
NOTE:
Stay arm/disarm can be done via the keypad.
Although not functional, the away arm
function is still shown in the mobile app.

Programming mode [1][2][3][4] Menu 9
Communicator programming
Save [Yes/Arm]
UDL and DIGI options [7][0]
Reporting protocol [2]
2 Dial in DTMF on
5 Auto test on
Reporting event [5]
Account code [1] 1234 [Yes/Arm]
Telephone no. [0] 1234 [Yes/Arm]
As default all options are already selected
Dialling attempts [3] Default value
Reporting partitions [4]
832/412
Save [Yes/Arm]
ARC no.1 settings [7][1]
Ensure the relevant partitions in use are
displaying on the keypad. If it's not displaying,
press 1,2,3,4 and switch them on.
Select protocol options [8][2]
1 Enable comms on
Save [Yes/Arm]
Contact ID [4]
8 Blind dial on
Away arming
Force arming [1][4] on (all Zones)
Set on for all Zones, this option default is off.
Select Zone8 [0][8]
Zones7-8 used as example.
Away and stay arm/disarm using Relay1&2
Go into programming [1][1]
Key switch arm/disarm [1][6]
Set the zone attributes [1][5]
Select Zone8 [0][8]
Confirm [Yes/arm]
Return to main location [Menu]
Note: Exit delay need not to be programmed.
Stay arming
Go into programming [1][1]
Return to main location [Menu]
Miscellaneous 1 [4][Yes
Any zo]ne eg Zone7 [0][7] [1][6][n][g]
Ensure 4=off to report stay arm/disarm.
Force arming [1][4] on (all Zones)
Set on for all Zones, this option default is off.
Zone attributes [1][5]
Select Zone7 [0][7]
Instant stay on Zone7 [4]
Confirm [Yes/arm]
Note: Exit delay need not to be programmed.
Return to main location [Menu]
Exit and save [9]
Relay 1Relay 1Relay 2
+
-
RELAY EXPANDER GSM GATEWAY
AC Bell DATA
+ AUX
- AUX Zone 7 COM Zone 8 Input Siren OUT
Zones R-1
T-1
R
T
GND
TEXECOM 412/832
Zone resistor
Tamper resistor
DEOL Connection SEOL Connection

Primary tel. no. [NO] 1234
Programming mode [1][2][3][4]
Note: [NO] enables editing
Go to UDL/Digi options
Go to program Digi
Communicator programming
Select arc 1 protocol [NO]
Select Contact ID [YES]
Report areas [NO]
Reporting partition [1][YES]
Note: COM300 or COM2400 module required
for Contact ID.
Confirm no. [YES]
8168
Repeat for partitions being used, e.g.1,2,3,4
Return - main screen [MENU]
Confirm no. [YES]
Digi options [NO][1][YES]
Return - main screen [MENU]
Account no. [NO] 1234
Away arming
Install Zone7 resistor to Relay1 on the unit.
Away and stay arm/disarm using Relay1&2
Zones7-8 used as example.
Zone setup [YES]
Zone7 [NO]
Stay arming
Moment key [YES]
Attributes 1 [NO]
Exit and save [MENU][YES]
Zone8 [NO]
Part 1 omit [NO][YES]
Install Zone8 resistor to Relay2 on the unit.
Zone setup [YES]
Moment key [YES]
Attributes 1 [NO]
Instant arm [NO][YES]
NET 1 NET 2 + AUX + AUX - AUX
- AUX
A
- T
- A
- T
-
TEXECOM 8168
Zone 7Zone 8 12V
GND
T
R
T-1
R-1
Relay 1Relay 1Relay 2
+
-
RELAY EXPANDER GSM GATEWAY
Zone resistor
Tamper resistor
DEOL Connection SEOL Connection

Select programming [OK]
Go MS [OK]
Select PSTN only [OK]
Communicator programming
Set seconds [0][0] [OK]
Go to parameters [OK]
Programming mode [1][1][1][1] [OK]
Select com. option [OK]
Select method [OK]
Select PSTN [OK]
Select timers [OK]
Select PSTN lost [OK]
Set minutes [0][0] [OK]
Select wait dial tone [OK]
Press the page/back button
Select dial method [OK]
Select DTMF [OK]
Press the page/back button
Select MS1 [OK]
Select voice [OK]
Press the page/back button
Go to accounts [OK]
Select MS1 [OK]
Insert the acc. no. [0][0][1][2][3][4] [OK]
Press the page/back button
Insert tel no. [1][2][3][4] [OK]
Save and exit [0] [OK]
Press the page/back button twice
Go to com. format [OK]
Select Contact ID [OK] Set zone for K/S arm [1][9] [OK]
Save and exit [0] [OK]
Away arm/disarm using Relay1
Zone7 used as example.
Insert installer code [1][1][1][1] [OK]
Select programming [OK]
Select parameters [OK]
Select individually [OK]
Select zone options [OK]
[0][7] [OK]
Relay 1Relay 1Relay 2
+
-
RELAY EXPANDER
GSM GATEWAY
AC BUS Zone 7 COM Zone 8 + AUX
- COM + Bell - Bell Tip
OU1 Ou2 + -
Zones
Phone
LINE
LINE
SET
SET
2k2 resistor between
the 12VDC and a
line connection
Risco LightSys
Zone resistor
Tamper resistor
DEOL Connection SEOL Connection
Stay mode key switch arm/disarm via the
app is not supported on this panel.
Stay arm/disarm can be done via the keypad.
Although not functional, the away arm
function is still shown in the mobile app.
NOTE:

st
Select 1 1 tel. [#]
Input account code [0][0][1][2][3][4][#]
Go 3 comm format [#]
Select 1 MS tel.1 [#]
Programming mode [*][7][0][1][2][8][#]
Select 1 link-up [#]
Select 1 MS #1 link-up [#]
Go to 5 dialer [#]
Select 1 PSTN/voice [#]
Insert tel. no. [1][2][3][4][#][*][*]
Select 1 MS link-up [#]
Communicator programming
Go to no. 2 accounts [#]
Select 1 Partition1 [#]
Select N (No) [#][*][*]
- to not apply settings to all partitions.
Select 5 control [#]
Input format [0][4][2][0][#][*]
Exit and save [*][*]
Go to 6 parameters [#]
Select 6 dial method [#]
Select 1 MS enable [Y][#]
Select 1 DTMF [#]
Relay 1Relay 1Relay 2
+
-
RELAY EXPANDER
GSM GATEWAY
AC BUS Zone 7 COM Zone 8 + AUX - COM + Bell - Bell Tip
OU1 Ou2 GND AUX -
Zones
Phone
LINE
LINE
SET
SET
Risco ProSys V7
Zone resistor
Tamper resistor
DEOL Connection SEOL Connection
NOTE:
Stay mode key switch arm/disarm via the
app is not supported on this panel.
Stay arm/disarm can be done via the keypad.
Although not functional, the away arm
function is still shown in the mobile app.

Step 2 - Location 1
Communicator programming
Segment 3 2
Input phone number
NX8 V2
Segment 2 1
Segment 4 3
Step 1 - Location 0
Programming mode [*][8][9][7][1]3][0][#]
Segment 1 15
Segment 5 4
Segment 14 A
Enter 1234 into segments 1234 respectively
Step 3 - Location 2
Step 4 - Location 5
Enable Partition1 to report to phone no.1
Step 5 - Location 23
Enter a 1 for Ademco Contact ID
Enter 1234 into segments 1234 respectively for
the account code in partition 1
Segment 3 enable 1&2 for opening and closing
and zone bypass reporting
Step 6 - Location 88
Away arm/disarm using Relay1
Zone7 used as example.
Location 25 (zone programming 1-8)
Select segment 7 (Zone7) [1][1]
Exit and save [#][#]
This will set Zone7 as a key switch zone
Programming mode [*][8][9][7][1]3][0][#]
T-1
T R R-1
Zone 1 COM Zone 2 Zone 3 COM Zone 4 + AUX
- AUX
DATA
AUX 2 Smoke COM Siren AUX 1 GND AC AC
CADDX NX8 V2
Relay 1Relay 1Relay 2
RELAY EXPANDER
GSM GATEWAY
Zone resistor
Tamper resistor
DEOL Connection SEOL Connection
Stay arm/disarm can be done via the keypad.
NOTE:
Stay mode key switch arm/disarm via the
app is not supported on this panel.
Although not functional, the away arm
function is still shown in the mobile app.

Hunter-Pro
832, 896, 8144
Panel programming
Communication [1][3][ENTER]
Access MS1 options [ENTER]
Ensure that the MS1 protocol options display 0
and 230 and T=1.
Modify MS1 reporting [ENTER]
Prog. test/interval time [ENTER]
ID account 000000 [ENTER]
Phone no. [1][2][3][4]
[END]
Configure account no. [NEXT] [ENTER]
Add MS1 phone no. [1][2][3][4]
Programming mode [1][2][3][4]
Set radio test interval [ENTER]
Radio no. [1][2][3][4] [ENTER]
Set dials [3]
Check other options required to be activated as
per installation requirements.
Tone dial +
No dial tone check +
Enable comm methods PSTN primary +
all others –
Exit programming [END] repeat
Set rings [1]
Modify coms. option [#] for + to -
Connect T-Line +
Add MS2 and MS3 phone no.s if used.
External line leave as is [ENTER]
ACK wait time leave as is
Away arm/disarm using Relay1
On-board panel key switch zone is used for
arm/disarming. Connect Relay1 as per the
diagram. No resistor required.
Zone 1 Zone 7 Zone 8 - + KEY SIREN RELAY BUS ALARM
PIMA HUNTER-PRO
12V
SET
LINE
LINE
Relay 1Relay 1Relay 2
+
-
RELAY EXPANDER
GSM GATEWAY
Zone resistor
Tamper resistor
DEOL Connection SEOL Connection
Stay mode key switch arm/disarm via the
app is not supported on this panel.
NOTE:
Stay arm/disarm can be done via the keypad.
Although not functional, the away arm
function is still shown in the mobile app.

Copyright © 2019
Radio Data Communications (PTY) Ltd.
WARNINGS
In addition to these warnings, please also
read the Warnings and General Trading
Terms & Conditions (including an indemnity)
in the Combined Agreement including its
schedules and addendums as updated from
time to time at www.radiodata.co.za.
INSTALLATIONS MUST BE CARRIED OUT BY
QUALIFIED SERVICE PERSONNEL ONLY.
Socket outlet must be installed near the control
panel and be easily accessible.
Telephone plugs and connectors must be
installed inside the metal enclosure of the
control panel. Interconnecting cables must be
placed in conduit.
Install the gateway in a location where no
person is less than 200mm from the antenna at
any time.
Only install the gateway in accordance with this
manual for proper operation.
Comply with all applicable standards which
require regular servicing by qualified licensed
technicians as well as regular testing.
The unit must only be operated with a supplied
and approved antenna.
24hr Standby 082 444 7176 - www.radiodata.co.za
