Casambi Lithernet User guide

Lithernet - Casambi Gateway v1.71
System Manual
Stand: 13.04.2021

2
Inhaltsangabe
1. Hardware ...............................................................................................................................................5
1.1. LED-Display ..................................................................................................................................6
1.2. Hardware Revision .......................................................................................................................7
1.3. Watchdog ......................................................................................................................................8
1.4. Conformity ....................................................................................................................................9
1.5. Bluetooth Module .......................................................................................................................10
1.6. Device Labeling ..........................................................................................................................12
2. Areas of application .............................................................................................................................13
2.1. Gateway to the Eutrac Netcomposer .........................................................................................14
2.2. Gateway to the Helvar Router System (HelvarNet) ...................................................................15
2.3. Gateway to a system via UDP / TCP commands ......................................................................17
2.4. Bridge between individual Casambi systems .............................................................................18
2.5. Coupling to an existing BMS / visualization ...............................................................................20
2.6. ArtNet Gateway ..........................................................................................................................22
2.7. BacNet/IP Gateway ....................................................................................................................23
3. Settings in the gateway .......................................................................................................................24
3.1. General Setting ..........................................................................................................................25
3.1.1. Network ..............................................................................................................................26
3.1.1.1. IP settings .................................................................................................................27
3.1.1.2. NTP-Client ................................................................................................................28
3.1.1.3. Restart Gateway .......................................................................................................29
3.1.2. User and Time ...................................................................................................................30
3.1.2.1. User Management ....................................................................................................31
3.1.2.2. Date and Time ..........................................................................................................32
3.1.3. Configuration .....................................................................................................................33
3.1.3.1. Control System Wizard ............................................................................................34
3.1.3.1.1. Netcomposer System ......................................................................................36
3.1.3.1.2. Art-Net .............................................................................................................37
3.1.3.1.3. Free commands over UDP .............................................................................38
3.1.3.1.4. HelvarNet (TCP) ..............................................................................................39
3.1.3.1.5. Free commands over TCP ..............................................................................40
3.1.3.1.6. UDP Casambi Command ................................................................................41
3.1.3.1.7. UDP Casambi Bridge ......................................................................................42
3.1.3.1.8. BacNet/IP .........................................................................................................43
3.1.3.2. LED Settings ............................................................................................................44
3.1.3.3. Update Firmware ......................................................................................................45
3.1.3.4. Import / Export ..........................................................................................................46
3.1.3.5. System Memory .......................................................................................................47
3.2. To Casambi ................................................................................................................................48
3.2.1. Commands ........................................................................................................................49
3.2.1.1. Select storage space ................................................................................................50
3.2.1.2. Trigger .......................................................................................................................51
3.2.1.2.1. Netcomposer Command Builder .....................................................................52
3.2.1.2.1.1. Device Level ...........................................................................................53
3.2.1.2.1.2. Scene ....................................................................................................54
3.2.1.2.1.3. Group with Scene ...................................................................................55
3.2.1.2.1.4. Group with Level ....................................................................................56
3.2.1.2.1.5. Sequence ................................................................................................57
3.2.1.2.2. HelvarNet Command Builder ...........................................................................58
3.2.1.2.2.1. Recall Scene (Group) .............................................................................59

3
3.2.1.2.2.2. Recall Scene (Device) ............................................................................60
3.2.1.2.2.3. Direct Level (Group) ...............................................................................61
3.2.1.2.2.4. Direct Level (Device) ..............................................................................62
3.2.1.3. Action ........................................................................................................................63
3.2.1.3.1. Ping ..................................................................................................................64
3.2.1.3.2. Set Level .........................................................................................................65
3.2.1.3.3. Push Button Pressed ......................................................................................66
3.2.1.3.4. Push Button Released ....................................................................................67
3.2.1.3.5. Set Presence ...................................................................................................68
3.2.1.3.6. Set Scene Level ..............................................................................................69
3.2.1.3.7. Set Group Level ..............................................................................................70
3.2.1.3.8. Set Push Button Level ....................................................................................71
3.2.1.3.9. Set Lux Sensor ................................................................................................72
3.2.2. Sensors ..............................................................................................................................73
3.2.2.1. HelvarNet ..................................................................................................................74
3.2.2.2. Netcomposer ............................................................................................................75
3.2.2.3. BacNet/IP ..................................................................................................................76
3.2.2.3.1. Lightsensor ......................................................................................................78
3.2.2.3.2. Presence ..........................................................................................................79
3.3. From Casambi ............................................................................................................................80
3.3.1. Select storage space .........................................................................................................82
3.3.2. Trigger ................................................................................................................................83
3.3.3. Action .................................................................................................................................85
3.3.3.1. Netcomposer Command Builder ..............................................................................86
3.3.3.2. HelvarNet Command Builder ...................................................................................87
3.3.3.3. Bridge Mode Command Builder ...............................................................................88
3.4. Console .......................................................................................................................................89
3.4.1. Console ..............................................................................................................................92
3.4.2. Parameter ..........................................................................................................................93
4. Settings in the Casambi app ...............................................................................................................94
4.1. Behavior as a lamp ....................................................................................................................95
4.2. Settings as a lamp .....................................................................................................................96
4.3. Settings as a button ...................................................................................................................98
4.4. Settings as a PIR sensor ...........................................................................................................99
4.5. Settings as lux sensor ..............................................................................................................100
5. Command structure in UDP Casambi Command mode ...................................................................101
5.1. General structure of the commands ........................................................................................102
5.2. Commands from the Casambi system .....................................................................................103
5.2.1. 0x28 - Receive time from the Casambi network .............................................................104
5.2.2. 0x0D - Scene called ........................................................................................................105
5.2.3. 0x39 - Node Status .........................................................................................................106
5.2.4. 0x3A - Notify Node removed ..........................................................................................107
5.3. Commands to the Casambi system .........................................................................................108
5.3.1. 0x10 - Push Button Pressed ...........................................................................................109
5.3.2. 0x11 - Push Button Released .........................................................................................110
5.3.3. 0x1E - Set the level of a scene ......................................................................................111
5.3.4. 0x1F - Set the level of a group .......................................................................................112
5.3.5. 0x20 - Set level of all devices .........................................................................................113
5.3.6. 0x21 - Set the level of the target of a button ..................................................................114
5.3.7. 0x28 - Request time from the Casambi network ............................................................115
5.3.8. 0x28 - Set time in the Casambi network ........................................................................116
5.3.9. 0x2B - Set presence sensor ...........................................................................................117

4
5.3.10. 0x2C - Set light sensor .................................................................................................118
5.3.11. 0x39 - Node Status .......................................................................................................119
5.4. Demo programs ........................................................................................................................120
6. Command structure in BacNet / IP mode .........................................................................................121
6.1. To Casambi ..............................................................................................................................123
6.2. From Casambi ..........................................................................................................................124
6.3. Sensor Value To Casambi ........................................................................................................125
7. Changelog Firmware .........................................................................................................................126
7.1. Firmwareversion 1.00 ...............................................................................................................127
7.2. Firmwareversion 1.10 ...............................................................................................................128
7.3. Firmwareversion 1.15 ...............................................................................................................129
7.4. Firmwareversion 1.16 ...............................................................................................................130
7.5. Firmwareversion 1.25 ...............................................................................................................131
7.6. Firmwareversion 1.50 ...............................................................................................................132
7.7. Firmwareversion 1.51 ...............................................................................................................133
7.8. Firmwareversion 1.55 ...............................................................................................................134
7.9. Firmwareversion 1.5.7 ..............................................................................................................135
7.10. Firmwareversion 1.65 .............................................................................................................136
7.11. Firmwareversion 1.69 .............................................................................................................137
7.12. Firmwareversion 1.70 beta .....................................................................................................138
7.13. Firmwareversion 1.71 .............................................................................................................139
8. End ....................................................................................................................................................140

5
1. Hardware
The device has only one connection for network (RJ45). The supply takes place via POE.
The gateway uses one address in the Casambi network.
On the front there are 4 LEDs for status display.

6
1.1. LED-Display
The module has 4 LEDs on the front. From bottom to top:
1) Operating LED - flashes green regularly (1 second)
2) Network status - lights up yellow when network is plugged in
3) UDP LED - Lights up red when there is no UDP connection, green when one is established
4) TCP / IP LED - Lights up red when there is no TCP / IP connection, green when one has been opened
The LEDs can also be switched off in the software.
When the device is set to identify mode via the surface, the LEDs 2-4 start to flash in ascending and descending
order for 10 seconds.
The LEDs with the numbers 3 and 4 can take up to 60s to display the status after a restart.

7
1.2. Hardware Revision
Hardware Revision 1:
Development Device for early testing of the functions
Hardware Revision 2:
Final layout with final housing.

8
1.3. Watchdog
A watchdog runs in the gateway with a set time of 90s so that the device can be restarted automatically if
necessary.

9
1.4. Conformity
EC declaration of conformity
Lichtmanufaktur Berlin GmbH hereby declares that the radio system type "Lithernet - Casambi Gateway"
complies with Directive 2014/53 / EU.
The full text of the EU declaration of conformity is available at the following Internet address: https://
archiv.intelligent-lighting.de/index.php/s/XoR27GRkiMWLyeD

10
1.5. Bluetooth Module
Attention!
All information on this page relates only to the radio module used. Not the entire product.
The CBM-002A module from Casambi Oy is used as the Bluetooth module
The declaration of conformity for the radio module can be found at the following Internet address: https://
casambi.com/static/datasheets/CBM-002-DoC.pdf
-------------------------------------------------------------------------------------------------------------------------------------------------------------------
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Contains FCC ID: 2ALA3-CBM002A
-------------------------------------------------------------------------------------------------------------------------------------------------------------------
This device complies with Industry Canada’s licenseexempt RSSs. Operation is subject to the following two
conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including
interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d’Industrie
Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions
suivantes:
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
Contains IC: 22496-CBM002A
-------------------------------------------------------------------------------------------------------------------------------------------------------------------

11

12
1.6. Device Labeling
There are 2 labels on the back of the device.
Here you can see in the barcode:
01: Litehrnet - Casambi Gateway
41/2020: week and year of manufacture in this case week 41 in 2020
00000001: serial number of the device
The second label contains the information that must be available for the built-in CBM-002 module:

13
2. Areas of application
The Ethernet gateway can be used in different ways.
3.1 Gateway to the Eutrac Netcomposer
3.2 Gateway to the Helvar Router System (HelvarNet)
3.3 Gateway to a system via UDP / TCP commands
3.4 Bridge between individual Casambi systems
3.5 Coupling to an existing BMS / visualization
3.6 ArtNet Gateway

14
2.1. Gateway to the Eutrac Netcomposer
In this operating mode it is possible to establish a link to a system with the Eutrac netcomposers.
It is possible to communicate bidirectionally between the two systems. A total of 32 triggers can be set in each
direction for each gateway.
The programming uses a wizard that simplifies the creation of commands.
The operating mode to be selected here would be "Netcomposer".
Video: https://youtu.be/fxEkgmIicBc

15
2.2. Gateway to the Helvar Router System (HelvarNet)
In this operating mode it is possible to establish a link to a system with the Helvar router system.

16
It is possible to communicate bidirectionally between the two systems. A total of 32 triggers can be set in each
direction for each gateway.
The programming uses a wizard that simplifies the creation of commands.
An IP address of a router must be specified as the destination of the connection.
The operating mode to be selected here would be "HelvarNet (TCP)".
Video: https://youtu.be/Uu9n5WTbBqI

17
2.3. Gateway to a system via UDP / TCP commands
In this operating mode it is possible to link to a system not defined in advance using UDP / TCP ASCII
commands.
This could e.g. Media controls (Crestron, ...) or KNX systems with which this integration via the network is
possible.
It is possible to communicate bidirectionally between the two systems. A total of 32 triggers can be set in each
direction for each gateway.
The operating mode to be selected here would be "UDP Free Messages" or "TCP Free Messages".
Video - Crestron: https://youtu.be/gpAQnBhzsz8
Video - KNX / Loxone: https://youtu.be/04bY2onxfj4

18
2.4. Bridge between individual Casambi systems
In this operating mode it is possible to connect several self-sufficient Casambi networks via the gateway.
It is possible to communicate bidirectionally between the two systems. A total of 32 triggers can be set in each
direction for each gateway.
Of course, several gateways can react to the same commands.

19
The gateways communicate with each other via UDP broadcast commands on a freely adjustable port.
The operating mode to be selected here would be "UDP Casambi Bridge".

20
2.5. Coupling to an existing BMS / visualization
In this operating mode it is possible to use a gateway directly. Each gateway receives a BridgeID which makes it
identifiable in the commands.
It is possible to communicate bidirectionally between the two systems. A total of 32 triggers can be set in each
direction for each gateway.
Of course, several gateways can react to the same commands.
The gateways communicate with each other via UDP broadcast commands on a freely adjustable port.
The operating mode to be selected here would be "UDP Casambi Command".
