1. Product Overview
Product name: ACTIVE MOBILE GATEWAY WITH COMM (AMG-C)
Model No.: CV90-JE103
Brand: OMNITRACS
The AMG-C system components include:
•Power I/O cable
•AMG-C hardware and fasteners

80-JE177-1 Rev. B
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
3
2. Product Feature Introduction
Network:
•EVDO / CDMA / UMTS / LTE / GPS / GLONASS
Body:
•Dimensions: 165 x 95 x 32.5 mm
•Weight: 375g
•SIM Card: Non-Removable Dual SIM card slot (AT&T, Sprint)
Platform:
•Android 7.1 Nougat

80-JE177-1 Rev. B
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
4
Comms:
•WLAN: 2.4 GHz / 5GHz dual band IEEE802.11 a/b/g/n/ac Wave2 WLAN
(Build in APP will be used for Wi-Fi feature set up and link up)

80-JE177-1 Rev. B
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
5
•Bluetooth: 4.2 BR/EDR/LE
Battery:
•710 mAh polymer Li-ion backup battery (Not used as main power supply source)

80-JE177-1 Rev. B
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
6
3. Interface Description
Front View
•USB OTG Connector: This connector can be used for charging USB powered device
and is able to transfer logging data.
•Driver Notification LED: This RGB LED is used to provide notifications to drivers if there
are any activity happens to the unit.
•ELD LED: This RGB LED is used to provide notifications to drivers if there are any
activity happens to the data logging.

80-JE177-1 Rev. B
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
7
Rear View
•Main Power Connector: This connector is used to connect the power cable from vehicle
battery power supply.
•Expansion I/O Connector: This connector is used to connect the optional I/O expansion
cable. The I/O expansion cable consist of a protected external 5V power supply,
protected external vehicle battery power supply, Driver Notification & ELD LED
expansion control ports and a general purpose RS232 serial connection (Tx/Rx).
•USB Host Connector: This connector can be used for charging USB powered device
and is able to transfer logging data.

80-JE177-1 Rev. B
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
8
4. Installation Instructions
Before starting the installation, inspect the vehicle to determine an installation location.
DO locate the display where it:
•Has a flat mounting surface that is strong enough to support the mounting hardware
•Is clear of dash controls and gauges
•Is not mounted in constant, direct sunlight
DO NOT locate the display where it:
•Obstructs the driver's field of vision
•Distracts the driver from the driving task
•Interferes with the driver's operation of controls or shifting
•Obstructs the area swept by the windshield wipers
•Blocks the deployment of an airbag
•Limits a passenger's leg room or blocks access to any other compartments
•Interferes with anyone entering or exiting the vehicle cab
•Could likely impact the driver or passenger in case of an accident or collision
Additional information for selecting an installation location:
Installations should not obstruct the driver’s field of vision while operating the vehicle and
should comply with all applicable federal and state laws and regulations regarding appropriate
installation locations (including restrictions against the mounting of objects on a vehicle's
windshield) and driver distraction.

80-JE177-1 Rev. B
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
9
Warning statement:
Class A Device
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a commercial installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will
be required to correct the interference at their own expense.
15.21 statement
CAUTION:
Any changes or modifications not expressly approved by the grantee of this device could void
the user's authority to operate the equipment.
15.19 statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
2.1091 statement
RF Exposure warning
This equipment must be installed and operated in accordance with provided instructions and
the antenna(s) used for this transmitter must be installed to provide a separation distance of at
least 20 cm from all persons and must not be co-located or operating in conjunction with any
other antenna or transmitter. End-users and installers must be provided with antenna
installation instructions and transmitter operating conditions for satisfying RF exposure
compliance.
SLAVE EQUIPMENT
This device is slave equipment, the device is not radar detection and not ad-hoc operation in
the DFS band.

80-JE177-1 Rev. B
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
10
IC Statement:
ICES-003 statement
CAN ICES-3 (A)/NMB-3 (A)
RSS-Gen statement
Canada, Industry Canada (IC) Notices
This device complies with Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Canada, avis d'Industry Canada (IC)
Cet appareil est conforme avec Industrie Canada exemptes de licence RSS standard(s).
Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas
causer d'interférence et (2) cet appareil doit accepter toute interférence, notamment les
interférences qui peuvent affecter son fonctionnement.
RSS-102 statement
Radio Frequency (RF) Exposure Information
The radiated output power of the Wireless Device is below the Industry Canada (IC) radio
frequency exposure limits. The Wireless Device should be used in such a manner such that the
potential for human contact during normal operation is minimized.
This device has also been evaluated and shown compliant with the IC RF Exposure limits under
mobile exposure conditions. (antennas are greater than 20cm from a person's body).
Informations concernant l'exposition aux fréquences radio (RF)
La puissance de sortie émise par l’appareil de sans fil est inférieure à la limite d'exposition aux
fréquences radio d'Industry Canada (IC). Utilisez l’appareil de sans fil de façon à minimiser les
contacts humains lors du fonctionnement normal.
Ce périphérique a également été évalué et démontré conforme aux limites d'exposition aux RF
d'IC dans des conditions d'exposition à des appareils mobiles (antennes sont supérieures à 20
cm à partir du corps d'une personne).
