Realm Ready Davis AeroCone Rain Collector User manual
1
2
Table of Contents
1 Terms and Conditions ........................................................................... 3
1.1 Safety............................................................................................................... 3
1.2 Batteries........................................................................................................... 3
1.3 Maintenance .................................................................................................... 3
1.4 Compliance...................................................................................................... 3
2 Installation ............................................................................................ 4
2.1 Gather InstallationTools................................................................................... 4
2.2 ConrmGatewayInstallation.......................................................................... 4
2.3 Install Rainbucket............................................................................................. 4
2.4 Cut Zip Tie ....................................................................................................... 4
2.5 Observe LED.................................................................................................... 4
2.6 Replace Cone................................................................................................... 4
2.7 Flag Location ................................................................................................... 5
3 Support................................................................................................. 5
3.1 Support Contact .............................................................................................. 5
3.2 Part Numbers .................................................................................................. 5
3
1 Terms and Conditions
You agree to follow RealmFive Terms and Conditions by
using RealmFive devices and material.
Read and follow all the instructions for installing Realm-
Five-Ready Davis AeroCone Rain Collector so it will func-
tion and perform properly. A best practice is to test the
Data Gateway and rain collector before going out to the
eld to ensure that everything operates correctly.
Site selection of the rain collector can impact the validity
of the data that is collected.
Follow the site selection and mounting recommendations
and guidelines provided by the rain collector manufacturer.
Disclaimer: RealmFive is not responsible for poor site
selection and installation of rain collector and is not held
responsible for management decisions based on data
collected.
RealmFive-Ready Davis AeroCone Rain Collector is splash
resistant but not waterproof.
RealmFive-Ready Davis AeroCone Rain Collector must be
installed in an approved mounting orientation to decrease
the probability of water entering the enclosure.
RealmFive-Ready Davis AeroCone Rain Collector should
not be immersed in liquid or buried. Improper installation,
product misuse, and unsuitable protection may cause
damage to the rain collector and void the warranty.
1.1 Safety
Use proper safety practices to reduce risk to users, their
property, and equipment. RealmFive will not be held
responsible for any personal injury and damage to equip-
ment and property. RealmFive will also not be held re-
sponsible for the spread of any pests due to not following
sanitary and quarantine practices; improper footwear, tool,
or equipment cleaning; or any other negligent practices.
Below is a list of recommended practices (but certainly not
an all-inclusive list):
• Avoid injuries by practicing good ergonomics such as
• Not carrying too heavy of a load like all the equip-
ment into the eld at once
• Avoid awkward positions and/or overextending your
body or muscles.
• All equipment and footwear should be cleaned after
use taking care to remove all soil residue in the instal-
lation eld. Store equipment in dry, enclosed place.
• Read and follow all manufacturer’s safety instruc
• tions and guidelines for rain collector and installation
tool and equipment
• Use hand protection such as suitable gloves to pro-
tect your hands during installation
• Use suitable eye protection
• Wear proper protective clothing.
1.2 Batteries
Do not mix batteries together such as type, chemistry, or age.
Battery life estimates are not guaranteed because of environ-
mental conditions of operation and initial battery conditions.
Do not heat above 85 degrees C (185 degrees F), burn, or
recharge the batteries. Extreme heat or cold may cause the
batteries to explode and damage or destroy the rain collector.
Do not expose battery contents to water.
Dispose of batteries and weather mote circuit according
to local regulations. Do not dispose of the rain collector or
batteries in re.
1.3 Maintenance
RealmFive-Ready Davis AeroCone Rain Collector is de-
signed for outdoor use, but it is important to periodically
check rain collector and weather mote for (but certainly
not an all-inclusive list)
• Rain Collector
• Read and follow all manufacturer’s maintenance
instructions and guidelines for rain collector.
• Weather Mote
• Dry the rain collector off before opening if there is
any water or condensation on the enclosure.
• Inspect the case to ensure it is free of any damage or
cracks.
• Look at telephone wire and terminal plug to ensure
that they are not damaged and properly plugged in.
• Replace batteries as necessary.
• When replacing batteries, inspect the battery holders
to verify they are free of corrosion and clean. Proper
close and seal the mote lid ensuring an interior seal
has happened.
• Ensure the rain collector lid is properly replaced and
shut.
1.4 Compliance
Changes or modications not expressly approved by the
manufacturer could void the user’s authority to operate this
equipment.
This product meets the applicable FCC Part 15 rules. Op-
eration is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must
accept any interference, including interference that may
cause undesired operation of the device.
Le présent materiel est conforme aux CNRexempts de li-
4
cence d’Industrie Canada. Son fonctionnement est soumis
aux deux conditions suivantes: (1) cet appareil ne peut pas
provoquer d’interférences, et (2) cet appareil doit accepter
toute interférence, y compris celles susceptibles de provo-
quer le fonctionnement du dispositive.
To limit RF exposure, please ensure 4 inches (10 cm) of
separation from the transmitter antennas at all times.
Interference may occur even after proper installation. Cor-
rect the interference by
• Make sure all VFD motors in the area have the prop-
er ltering.
• Make sure all other electrical equipment and RF
communications in the area is FCC approved and
not preventing use of the 900 MHz ISM band.
2 Installation
2.1 Gather InstallationTools
Gather tools needed for installation:
• Flags (if installing in the eld)
• Appropriate safety gear per manufacturer’s instruc-
tions
• Tools needed for rain collector installation per the
manufacturer’s instructions
2.2 ConrmGatewayInstallation
The rain collector needs the Data Gateway to send in its
data packets. Data Gateway must be installed before the
rain collector. See Data Gateway Installation manual to set
up the Data Gateway.
2.3 Install Rainbucket
Install the rain collector per the manufacturer’s instruc-
tions. Wait to cut the zip tie as per the manufacturer’s
instructions until step 2.7.
2.4 Cut Zip Tie
Cut the zip tie that is holding the tipping mechanism in
place. Pull the tab from the weather mote.
2.5 Observe LED
The device LED will repeatedly blink red-yellow-green-yel-
low as it boots. It will then blink cyan while it acquires time
and location via GPS.
While the device acquires GPS, it will also occasionally
ash magenta-green or magenta-red, indicating it is send-
ing radio packets.
Magenta-green means it received an acknowledge from
Data Gateway.
Magenta-red means no acknowledge was received. This
may occasionally happen if other devices are sending
packets at the same time or if there is short interference
with the signal. If every single packet is magenta-red, the
device needs to be mounted higher or closer to Data
Gateway.
5
2.6 Replace Cone
Put the rain collector cone back on the base and lock it
back into place.
The rain collector cone will only t back on the base if the logo
is facing outward and away from the mounting mechanism.
2.7 Flag Location
Add a ag at the end of the row and in the end rows near
the ditch to mark its location if you installed the rain col-
lector in the eld. This will help you nd the rain collector
easier if it needs to be replaced or serviced.
3 Support
3.1 Support Contact
Contact customer support with issues by reaching us at
E-mail: support@realmve.com
Phone: 402-318-3583
Slack: Company specic channel provided to you after
purchasing the rain collector.
3.2 Part Numbers
Product Part Number
Realm-Ready
Davis
150-00425
AeroCone Rain
Collector
