RED DSMC POWER
OPERATION GUIDE

COPYRIGHT © 2014 RED.COM, INC
RED DSMC POWER OPERATION GUIDE
955-0038, REV-F |2
TABLE OF CONTENTS
Disclaimer 3
Copyright Notice 3
Trademark Disclaimer 3
Compliance Statements 3
Safety Instructions 5
Battery Storage and Handling 6
Shipping Disclaimer 6
Chapter 1: DSMC Power Introduction 7
Read Before You Shoot 7
Power Operations 8
Basic Battery Operations 10
Additional Resources 10
Chapter 2: DSMC Power Components 11
DSMC Power Modules 12
RED Batteries 13
RED Chargers 14
Power Adaptors, Cables, and Accessories 15
Chapter 3: DSMC Power Modules 16
DSMC Side Handle 17
DSMC Adaptor Modules 18
DSMC Adaptor Operations 21
DSMC Power Module Operations 23
Pro Battery Module (Dual) 25
Pro Battery Module (Quad) 26
REDVOLT XL Module 27
Quickplate Module 33
Backpack Quickplate (Short) 34
Chapter 4: RED Batteries 37
REDVOLT and REDVOLT XL 38
RED BRICK 39
Chapter 5: RED Chargers 41
REDVOLT Travel Charger 42
REDVOLT Charger (Quad) 43
RED BRICK Charger 44
Chapter 6: Power Adaptors, Cables, and Accessories 47
Power Adaptors and Accessories 47
RED Cables 50
Chapter 7: Troubleshoot DSMC Power 52
RED Batteries and Chargers 52
Appendix A: Technical Specifications 53
DSMC Modules 53
RED Batteries 56
RED Chargers 58
Appendix B: DSMC Module Compatibility 59
DSMC Module Types and Priority 59
Module Restrictions 60
Maximum Supported Modules 60
DSMC Module Compatibility Matrix 61

RED DSMC POWER OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC 955-0038, REV-F |3
COMPLIANCE STATEMENTS
INDUSTRIAL CANADA EMISSION COMPLIANCE STATEMENTS
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
FEDERAL COMMUNICATIONS COMMISSION (FCC) STATE-
MENTS
This equipment has been tested and found to
comply with the limits for a Class B digital de-
vice, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reason-
able protection against harmful interference
in a residential installation. This equipment
generates, uses and can radiate radio fre-
quency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that inter-
ference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more
of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
In order to maintain compliance with FCC regulations, shielded
cables must be used with this equipment. Operation with non-ap-
proved equipment or unshielded cables is likely to result in interfer-
ence to radio and TV reception. The user is cautioned that changes
and modifications made to the equipment without the approval of
the manufacturer could void the users authority to operate this
equipment.
NOTE: This device complies with Part 15 of the FCC Rules.
Operations subjected to the following two conditions (1) this device
may not cause harmful interference, and (2) this device must accept
any interference received, including that may cause undesirable in-
terference.
CAUTION: If the device is changed or modified
without permission from RED, the user may
void his or her authority to operate the equip-
ment.
AUSTRALIA AND NEW ZEALAND STATEMENTS
RED declares that the radio equipment described in this document
comply with the following international standards.
IEC 60065 - Product Safety
RED declares digital devices described in this document comply
with the following Australian and New Zealand standards.
AS/NZS CISPR 22 – Electromagnetic Interference
AS/NZS CISPR 24 – Electromagnetic Immunity
AS/NZS 61000.3.2 – Power Line Harmonics
AS/NZS 61000.3.3 – Power Line Flicker
JAPAN STATEMENTS
This is a Class B product based on the
standard of the Voluntary Control Council
for Interference (VCCI) for information tech-
nology equipment. If this equipment is used
near a radio or television receiver in a do-
mestic environment, it may cause radio in-
terference. Install and use the equipment
according to the instruction manual.
EUROPEAN UNIONCOMPLIANCE STATEMENTS
Information
RED declares that products
with the CE marking com-
ply with the EMC Directive
(2004/108/EC) and the Low
Voltage Directive (2006/95/
EC) issued by the Commis-
sion of the European Community. Compliance with these directives
DISCLAIMER
RED®has made every effort to provide clear and accurate informa-
tion in this operation guide, which is provided solely for the user’s
information. While thought to be accurate, the information in this
document is provided strictly “as is” and RED will not be held re-
sponsible for issues arising from typographical errors or user’s in-
terpretation of the language used herein that is different from that
intended by RED. All safety and general information is subject to
change as a result of changes in local, federal or other applicable
laws.
RED reserves the right to revise this document and make changes
from time to time in the content hereof without obligation to notify
any person of such revisions or changes. In no event shall RED, its
employees or authorized agents be liable to you for any damages
or losses, direct or indirect, arising from the use of any technical or
operational information contained in this document.
For comments or questions about content in this Operation Guide,
please send a detailed e-mail to [email protected].
COPYRIGHT NOTICE
COPYRIGHT© 2014 RED.COM, INC.
All trademarks, trade names, logos, icons, images, written material,
code, and product names used in association with the accompa-
nying product are the copyrights, trademarks or other intellectual
property owned and controlled exclusively by RED.COM, INC.
TRADEMARK DISCLAIMER
All other company, brand and product names are trademarks or reg-
istered trademarks of their respective holders. RED has no affiliation
to, is not associated or sponsored with, and has no express rights
in third-party trademarks.

COPYRIGHT © 2014 RED.COM, INC
RED DSMC POWER OPERATION GUIDE
955-0038, REV-F |4
implies conformity to the following European Product Family Stan-
dards.
EN 55022 (CISPR 22) – Electromagnetic Interference
EN 55024-1 (CISPR 24) – Electromagnetic Immunity
EN6100-3-2 (IEC610000-3-2) – Power Line Harmonics
EN6100-3-2 (IEC610000) – Power Line Flicker
EN 60065 (IEC60065) – Product Safety
Products with the ROHS marking comply with the Restriction of
Hazardous Substances Directive (2011/65/EU) issued by the Com-
mission of the European Community.
INFORMATION
Products with the CE marking comply with the EMC Directive
(2004/108/EC) and the Low Voltage Directive (2006/95/EC) issued
by the Commission of the European Community. Compliance with
these directives implies conformity to the following European Prod-
uct Family Standards.
EN 55022 (CISPR 22) – Electromagnetic Interference
EN 55024-1 (CISPR 24) – Electromagnetic Immunity
EN 61000-3-2 (IEC610000-3-2) – Power Line Harmonics
EN 61000-3-3 (IEC610000) – Power Line Flicker
EN 60065 (IEC60065) – Product Safety
USAGE RESTRICTIONS FOR PRODUCTS THAT INCORPORATE
REDLINK
Products that fall into this category are denoted
by inclusion of the Class 2 identifier symbol (ex-
clamation mark in a circle) accompanying the CE
Mark on the products regulatory label, example
to the left.
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE)
The Waste Electrical and Electronic Equip-
ment (WEEE) mark applies only to countries
within the European Union (EU) and Norway.
This symbol on the product and accompany-
ing documents means that used electrical
and electronic products should not be mixed
with general household waste. For proper
treatment, recovery and recycling, please
take this product to designated collection
points where it will be accepted free of
charge. Alternatively, in some countries you
may be able to return your products to your
local retailer upon purchase of an equivalent
new product.
Disposing of this product correctly will help save valuable resources
and prevent any potential negative effects on human health and the
environment, which could otherwise arise from inappropriate waste
handling. Please contact your local authority for further details of
your nearest designated collection point. Penalties may be appli-
cable for incorrect disposal of this waste, in accordance with you
national legislation.
For business users in the European Union, if you wish to discard
electrical and electronic equipment, please contact your dealer or
supplier for further information.
FRANCE
Usage Restrictions - Geographic Area Where Restriction Applies :
France
For mainland France:
2.400 - 2.4835 GHz (Channels 1-16) authorized for indoor use
2.400 - 2.454 GHz (Channels 1-10) authorized for outdoor use
Restrictions d’utilisation - Zone géographique où les restrictions
s’appliquent : France
Pour la France métropolitaine
2.400 - 2.4835 GHz (Canaux 1 à 16) autorisé en usage intérieur
2.400 - 2.454 GHz (Canaux 1 à 10) autorisé en usage extérieur
NORWAY
This subsection does not apply for the geographical area within a
radius of 20 km from the centre of Ny-Ålesund.
Dette gjelder ikke for det geografiske området innenfor en radius av
20 km fra sentrum av Ny-Ålesund.
RESPONSIBLE PARTY:
RED Digital Cinema
34 Parker
Irvine, CA 92618
USA

RED DSMC POWER OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC 955-0038, REV-F |5
SAFETY INSTRUCTIONS
DO NOT use near water. Avoid exposing to moisture. The unit
is not waterproof, so contact with water could cause perma-
nent damage to the unit as well as electric shock and serious
injury to the user. DO NOT use in the rain or under other condi-
tions with high moisture without appropriate protection, and
immediately remove power source if exposed to moisture.
WARNING: To reduce the risk of fire or
electric shock, do not expose to rain or
moisture.
DO NOT expose to excessive vibration or impact (shock). Be
careful not to drop. Internal mechanisms may be damaged by
severe shock.
Clean only using a dry cloth. When cleaning, remember that it
is not waterproof and moisture can damage electronic circuitry.
DO NOT rinse or immerse, keep dry at all times. DO NOT use
soaps, detergents, ammonia, alkaline cleaners, and abrasive
cleaning compounds or solvents. These substances may dam-
age lens coatings and electronic circuitry.
CAUTION: Proper ventilation requires a
minimum 1/2" (1,25 cm) clearance be-
tween ventilation openings and exter-
nal surfaces. Verify that objects that can
block the fan intake and exhaust ports do
not impede airflow. Failure to permit ad-
equate airflow may result in overheating
of the camera, degraded operation and in
extreme situations, damage to the cam-
era.
DO NOT operate or store near any heat sources such as radia-
tors, heat registers, stoves, or any other apparatus that pro-
duce heat. Store in a protected, level and ventilated place.
Avoid exposure to temperature extremes, damp, severe vi-
bration, strong magnetic fields, direct sunlight or local heat
sources during storage. Remove any batteries from the camera
before storage. Recommended storage and usage tempera-
tures are:
‒Operating range: 0°C to 40°C (32°F to 104°F)
‒Storage range: –20°C to 50°C (–4°F to 122°F)
If there are any performance issues when operating within this
temperature range, please file a support ticket at https://sup-
port.red.com.
The Rear Modules are NOT HOT SWAPPABLE, meaning you
cannot remove or install them while the camera is turned on.
Before installing or removing any of these accessories, you
MUST turn off the camera. Failure to do so may result in dam-
age to the accessory and/or camera BRAIN that will not be
covered under warranty.
Do not bypass the third prong of the grounding-type plug on
the power cord of the AC Power Adaptor. A grounding-type
plug has two blades and a third “grounding” prong. The third
prong is provided for your safety. A grounding-type plug shall
be connected to an outlet with a protective earthen connec-
tion. If the grounding-type plug does not fit into your outlet,
do not attempt to modify the plug or outlet, consult a qualified
electrician.
Protect all power cords from being pinched, walked on or driv-
en over by a vehicle. Replace any power cords suspected of
sustaining damage due to crushing or other forms of damage.
Products marked with this symbol are
class 2 devices. These devices are not
provided with a grounding type plug.
CAUTION: The power cord plug for the AC
Power Adaptor is used as the power dis-
connect. To disconnect all power from the
AC Power Adaptor, unplug the power cord
plug from the wall outlet. During use, the
power cord plug should remain easily ac-
cessible at all times.
Lithium-ion batteries may be subject to special handling re-
quirements pursuant to federal and local laws. Please refer to
specific shipping instructions included with your battery re-
garding proper transport of your battery. Do not handle your
battery if it is damaged or leaking. Disposal of batteries must
be in accordance with local environmental regulations. For
example, California law requires that all rechargeable batter-
ies must be recycled by an authorized recycle center. Storing
batteries fully charged or in high temperature conditions may
permanently reduce the life of the battery. Available battery
capacity may also be temporarily lessened after storage in low
temperature conditions.
WARNING: Do not expose the battery to
excessive heat.
WARNING: Danger of explosion if an in-
correct battery is charged or used to pow-
er the camera and accessories. Replace
only with the same or equivalent type bat-
tery.
CAUTION: Refer all service and repair to
qualified RED service personnel. To reduce
the risk of electric shock, and damage to
the camera or accessories, DO NOT at-
tempt to perform any servicing other than
any procedures that are recommended in
the operating instructions.
INDOOR USE ONLY: Products marked with
this symbol are designed for use indoors
only.

COPYRIGHT © 2014 RED.COM, INC
RED DSMC POWER OPERATION GUIDE
955-0038, REV-F |6
BATTERY STORAGE AND HANDLING
WARNING: Failure to read, understand, and
follow these instructions may result in over-
heating, chemical leakage, smoke emission,
fire, or other potentially harmful results.
Always follow proper battery handling and storage practices. Im-
proper handling and/or failure to abide by proper storage instruc-
tions may cause permanent damage to batteries, or degrade battery
charge holding capacity. Improper handling practices or failure to
comply with instructions may also put you at risk.
Lithium-Ion batteries, like the REDVOLT®, REDVOLT XL, and RED
BRICK®, self-discharge over time. When storing for long periods
of time, store batteries separately from the camera or charger and
remember to charge batteries to a capacity level of 50% to 80%. If
batteries will be stored for long periods of time, RED recommends
that you check the charge level at least once every six (6) months,
and recharge batteries to a capacity level of 50% to 80%.
When not in use, remove the battery from the camera or charger and
store the battery in a cool, dry place. Avoid extreme hot tempera-
tures (such as inside a hot car), corrosive gas, and direct sunlight.
The optimal storage temperature for batteries is between –20°C to
20°C (–4°F to 68°F).
WARNING: Batteries stored in a discharged
state for long periods of time may self-dis-
charge and lose the ability to hold a charge.
WARNING: If recharging operation fails to
complete even when a specified recharging
time has elapsed, immediately stop further re-
charging.
DO NOT store batteries in a fully charged state for extended
periods of time.
DO NOT store batteries in a fully discharged state for extended
periods of time.
DO NOT store batteries in the camera, in a camera module, or
in a charger for extended periods of time.
DO NOT use batteries for purposes other than their intended
use.
DO NOT store batteries in extreme hot or cold temperatures.
DO NOT store batteries in direct sunlight.
DO NOT use third-party chargers with your RED batteries.
DO NOT disassemble or modify the battery.
DO NOT overcharge batteries. Overcharging may increase in-
ternal temperature beyond the recommended limits and cause
permanent damage to the battery.
DO NOT connect the positive (+) and negative (–) terminals to
a metal object such as a wire.
DO NOT transport or store the battery together with metal ob-
jects such as jewelry, hairpins, etc. as they may generate heat
if they come into contact with the battery.
DO NOT discard the battery into fire or heat.
DO NOT store, use, or recharge the battery near a heat source
such as a fire or a heater.
DO NOT allow the battery to get wet.
DO NOT pierce the battery with pointed or other sharp objects.
DO NOT step on, throw, or strike the battery with a hammer.
DO NOT use a battery that appears to be deformed or dam-
aged.
DO NOT directly solder the battery.
DO NOT put the battery into a microwave oven or a pressur-
ized container.
DO NOT use or subject the battery to intense sunlight or hot
temperatures such as in a car in hot weather.
DO NOT use it in a location where static electricity may be
present.
DO NOT exceed the recharging temperature range of 0˚C to
40˚C (32˚F to 104˚F).
RED recommends that you only use RED chargers to recharge
RED batteries.
Store the battery in a location where children cannot reach it.
If the battery leaks or gives off a bad odor, discontinue use
immediately.
If the battery gives off an odor, generates heat, becomes dis-
colored or deformed, or in any way appears abnormal dur-
ing use, recharging or storage, immediately remove it from the
equipment or battery charger and discontinue use.
If electrolyte begins leaking from the battery and comes into
contact with your skin or clothing, immediately wash it away
with running water. Failure to do this may result in skin inflam-
mation.
If the battery leaks and the electrolyte reaches the eyes, do
not rub them. Instead, rinse the eyes with clean running water
and immediately seek medical attention. Failure to do this may
result in eye injury.
If you find discoloration, a bad odor due to leakage, overheat-
ing and/or other irregularities when using the battery for the
first time, contact your Bomb Squad representative immedi-
ately.
NOTE: For more information regarding RED
battery charging and instructions for care,
please refer to our Terms and Conditions.
SHIPPING DISCLAIMER
Unless you have been certified to ship dangerous goods, you must
work with a Dangerous Goods, Class 9-certified shipper to assist
you with a shipment that includes a RED BRICK (or other regulated
lithium ion batteries). Please note that applicable laws prohibit the
shipping of batteries that are physically damaged. We urge you to
look into the formal rules and regulations of shipping Class 9 Dan-
gerous Goods prior to preparing your shipment. For more informa-
tion on these regulations, please visit www.iata.org and www.dot.
gov.

COPYRIGHT © 2014 RED.COM, INC
RED DSMC POWER OPERATION GUIDE
955-0038, REV-F |7
The RED®Digital Still and Motion Camera (DSMC®) system delivers high performance digital imaging over a
wide range of frame rates and optical formats. The DSMC system is supported by an expansive arsenal of
power modules, batteries, and chargers that provide adaptable configuration solutions to meet your needs.
READ BEFORE YOU SHOOT
Read this operation guide carefully and in its entirety before assembling or operating your DSMC or other RED
accessories. In addition to this document, RED offers the following operation guides for the DSMC system.
DSMC Operation Guide
DSMC Media Operation Guide
To download RED operation guides, visit the RED downloads page at www.red.com/downloads.
REDVOLTs and
REDVOLT Travel Charger
01 DSMC POWER
INTRODUCTION

COPYRIGHT © 2014 RED.COM, INC
RED DSMC POWER OPERATION GUIDE
955-0038, REV-F |8
POWER OPERATIONS
This section describes the basic power operations of the DSMC system.
For more information, see the DSMC Operation Guide, available at www.red.com/downloads.
WARNING: Modules, displays, and accessories are NOT HOT SWAPPABLE, meaning that you cannot remove or
install the item while the camera is turned on. Before installing or removing a module, display, or accessory,
you MUST turn off the camera. Failure to do so may result in damage to the item or DSMC that is not covered
under warranty.
POWER INPUTS
1
2
There are two (2) primary power inputs that provide power to the DSMC BRAIN:
#DSMC POWER INPUT DESCRIPTION
1SEARAY power connector Provides power to the BRAIN from attached DSMC modules
2DC IN connector Provides power to the BRAIN using a AC Power Adaptor (DSMC) or
certain battery modules, such as the Backpack Quickplate (Short)
NOTE: Additionally, one (1) REDVOLT®battery may be used in conjunction with the DSMC Side Handle to provide
short term power and support hot-swapping of other power sources.
POWER PRIORITY
When multiple power sources are connected to the BRAIN, power consumption is prioritized in this sequence:
1. DC power supply (DC IN connector)
2. Attached RED BRICK®(Lowest state of charge first)
3. Battery module batteries (SEARAY connector; lowest state of charge first)
4. REDVOLT battery in an attached DSMC Side Handle
SEARAY Connector (top) and
DC IN Connector (bottom)

RED DSMC POWER OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC 955-0038, REV-F |9
POWER CONSUMPTION
The BRAIN draws approximately 60 W when recording in 5K resolution, at 24 FPS.
Under typical conditions batteries provide the following operating time:
REDVOLT: Powers the BRAIN and accessories for approximately 30 minutes.
REDVOLT XL: Powers the BRAIN and accessories for approximately 90 minutes.
RED BRICK: Powers the BRAIN and accessories for approximately 120 minutes.
POWER STATUS
The power status of the current primary power source displays in the Lower Status Row of the DSMC graphical
user interface (GUI). Navigate to the Power In menu at Menu > Power > Power In for the status of all connected
power sources.
APPROVED EXTERNAL DC POWER
The DSMC accepts input voltages of 11.5 V to 17 V DC, and can draw a maximum current of 12 A. The BRAIN
can be powered continuously by connecting one (1) of the following to the DC IN port on the BRAIN:
AC Power Adaptor (DSMC)
RED BRICK Charger: Requires a 2B-to-1B Power Adaptor Cable.
RED BRICK: Requires a Backpack Quickplate or Battery Belt Clip (DSMC). Also supported by a RED Quick-
plate or RED Cradle using a 2B-to-1B Power Adaptor Cable.
XLR DC power source: Requires an XLR Power Cable.
TURN ON THE BRAIN
1. Attach a power source to the BRAIN.
The Power Status LED illuminates red, indicating that an appropriate power source is connected
2. Press and release the PWR/REC button on the right side of the BRAIN.
The Power Status LED turns off, and within five (5) seconds illuminates yellow as the BRAIN turns on.
The Power Status LED then illuminates green to confirm that the BRAIN is turned on and ready to use.
NOTE: Once turned on, the DSMC Power Status LED flashes red when there is less than five (5) minutes of op-
erating time remaining.
TURN OFF THE BRAIN
Use one (1) of the following methods to turn off the BRAIN:
Go to Menu > Power and select Shutdown.
Press and hold PWR/REC until the Shutting Down... notification shows on the display.
NOTE: The DSMC turns off automatically if the supply voltage drops to 11.5 V.

COPYRIGHT © 2014 RED.COM, INC
RED DSMC POWER OPERATION GUIDE
955-0038, REV-F |10
BASIC BATTERY OPERATIONS
This section describes the basic battery operations of REDVOLT, REDVOLT XL, and RED BRICK batteries.
BATTERY DISCHARGE PROTECTION
REDVOLT, REDVOLT XL, and RED BRICK batteries are equipped with discharge protection and shut off when
output voltage falls below 10 V. Lithium-ion batteries self-discharge over time. Charging the battery restores
lost capacity. For more information, go to “Battery Storage and Handling” on page 6.
PERFORM A FULL CHARGE
RED recommends that you perform a full charge, also known as a deep charge, at least once every 10 battery
charge cycles. A full charge consists of discharging a battery completely, and then recharging it to maximum
capacity. Performing a full charge helps maintain maximum battery capacity and calibrates sensors to provide
accurate capacity readout information.
To perform a full charge, follow the instructions below:
1. Completely discharge the battery.
2. Connect the appropriate RED charger to a standard wall outlet or other sufficient power source.
3. Insert the discharged battery into the charger.
4. Charge the battery until the LED indicator turns green, signalling a fully charged battery.
5. Remove the battery from the charger. DO NOT overcharge for extended periods of time.
BATTERY STORAGE
When not in use, remove the battery from the camera or charger and store the battery in a cool, dry place.
Avoid storage areas with fluctuating temperatures, extreme hot or cold temperatures, corrosive gas, and direct
sunlight. The optimal storage temperature for batteries is between –20°C to 20°C (–4°F to 68°F). For more
information, go to “Battery Storage and Handling” on page 6.
Lithium-Ion batteries, like the REDVOLT, REDVOLT XL, and RED BRICK, self-discharge over time. Prior to stor-
ing for long periods of time, charge batteries to a capacity level of 50% to 80%. Use the LED indicator array on
REDVOLT and RED BRICK batteries to ensure the level of charge is between 50% and 80%. Press the battery
status button next to the LEDs to display the battery charge level. Verify that two (2) LEDs are illuminated on
the REDVOLT, or three (3) to four (4) LEDs are illuminated on a RED BRICK.
For long term storage over six (6) months, RED recommends that you check the charge level at least once every
six (6) months, and recharge batteries to a capacity level of 50% to 80%.
ADDITIONAL RESOURCES
The following resources offer additional information about RED, the DSMC system, and the RED community:
RED.com: Check the official RED website for latest information about RED products.
RED Learn Articles:RED offers in-depth technical articles about RED cameras, post-production, and digital
cinematography.
RED.com/downloads: Go to the RED Downloads page to download the latest firmware, operation guides,
and post-production software.
DSMC Toolkit: Go to the RED Downloads page to find the DSMC Toolkit that offers a number of helpful tools
and resources to customize and improve your DSMC workflow and operation.
Support.red.com: Check the RED SUPPORT site for FAQs, or to file a support ticket.
Bomb Squad Support: For more information, contact your Bomb Squad representative.
In-camera Help: Select the Help button on an in-camera screen to open up the help for that screen.
Reduser.net: Discuss all things RED on the REDUSER third-party forum.

COPYRIGHT © 2014 RED.COM, INC
RED DSMC POWER OPERATION GUIDE
955-0038, REV-F |11
This chapter provides an overview of the DSMC Power components, including:
“DSMC Power Modules” on page 12
“RED Batteries” on page 13
“RED Chargers” on page 14
“Power Adaptors, Cables, and Accessories” on page 15
WARNING: Modules, displays, and accessories are NOT HOT SWAPPABLE, meaning that you cannot remove or
install the item while the camera is turned on. Before installing or removing a module, display, or accessory,
you must turn off the camera. Failure to do so may result in damage to the item or DSMC that is not covered
under warranty.
NOTE: Availability of components is subject to change at any time.
REDVOLT XL
Power Pack
02 DSMC POWER
COMPONENTS

COPYRIGHT © 2014 RED.COM, INC
RED DSMC POWER OPERATION GUIDE
955-0038, REV-F |12
DSMC POWER MODULES
This section describes DSMC power modules.
RED DSMC modules enable you to configure your camera BRAIN for your exact shooting requirements and
are designed to support REDVOLT®, REDVOLT XL, and RED BRICK®batteries. Most DSMC modules require an
adaptor module to attach to the BRAIN. Specific module attachment requirements may vary.
For more information, go to “DSMC Power Modules” on page 16.
RED DSMC power module options include:
ITEM PART NUMBER
DSMC Side Handle 720-0012
Module Adaptor 720-0008
+1 Adaptor Module 720-0018
Pro Battery Module (Dual) 720-0005
Pro Battery Module (Quad) 720-0006
REDVOLT XL Module 740-0031
Quickplate Module 790-0343
Backpack Quickplate (Short) 790-0342
Backpack Base Plate 790-0384
Backpack Quickplate (Short) Collection COL-0119
WARNING: DO NOT use more than one (1) DSMC battery module at a time. Using multiple battery modules may
damage the camera BRAIN and is not covered under warranty.
NOTE: DSMC adaptor modules provide advanced support and compatibility with other modules; however, there
are restrictions and incompatibilities. For more information, go to “DSMC Module Compatibility” on page 59.
REDVOLT XL Module

RED DSMC POWER OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC 955-0038, REV-F |13
RED BATTERIES
This section describes RED lithium-ion batteries.
The REDVOLT, REDVOLT XL, and RED BRICK are lightweight, rechargeable lithium-ion batteries designed to
provide sustained power to the DSMC BRAIN. These batteries provide long-term mobile power and attach to
the DSMC BRAIN via a DSMC power module or other RED accessory.
For more information, go to “RED Batteries” on page 37.
RED offers the following batteries:
ITEM PART NUMBER
REDVOLT (37 Wh) 740-0020
REDVOLT XL (89 Wh) 740-0021
RED BRICK (153 Wh) 740-0002
WARNING: DO NOT overcharge batteries. Overcharging may increase internal temperature beyond the recom-
mended limits and cause permanent damage to the battery.
WARNING: DO NOT store batteries in a fully charged or fully discharged state for extended periods of time.
WARNING: DO NOT store batteries in the camera, in a camera module, or in a charger for extended periods of
time.
REDVOLT XL (left) and
REDVOLT (right)

COPYRIGHT © 2014 RED.COM, INC
RED DSMC POWER OPERATION GUIDE
955-0038, REV-F |14
RED CHARGERS
This section describes RED chargers used to recharge RED lithium-ion batteries.
RED chargers are used to REDVOLT, REDVOLT XL, and RED BRICK lithium-ion batteries.
For more information, go to “RED Chargers” on page 41.
RED battery charger options include:
ITEM PART NUMBER
REDVOLT Travel Charger 790-0134
REDVOLT Charger (Quad) 740-0015
RED BRICK Charger 740-0006
WARNING: DO NOT overcharge batteries. Overcharging may increase internal temperature beyond the recom-
mended limits and cause permanent damage to the battery.
REDVOLT Travel
Charger

RED DSMC POWER OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC 955-0038, REV-F |15
POWER ADAPTORS, CABLES, AND ACCESSORIES
This section describes DSMC power adaptors, cables, and other accessories.
RED power adaptors, cables, and accessories are hand-made and expertly crafted to the highest standards.
RED performance cables feature robust industry-standard LEMO connectors, and are available in a variety of
connector sizes and lengths to support displays, modules, and other camera accessories.
For more information, go to “Power Adaptors, Cables, and Accessories” on page 47.
RED cables, adaptors, and accessories include:
ITEM PART NUMBER
AC Power Adaptor (DSMC) 740-0025
RED Cradle 790-0007
RED Quickplate 790-0008
Battery Belt Clip (DSMC) 790-0291
EVF/LCD Cables For a full list, go to “EVF/LCD Cables” on page 50
4-pin to 2-pin Adaptor Cable 790-0334
2-Pin 1B LEMO-to-Flying Lead Cable 790-0366
2B-to-1B Adaptor Cable 790-0138
Pro I/O Aux Power Out + GPIO Cable (6') 790-0209
XLR Power Cable (10') 790-0164
XLR Power Cable (30") 790-0165
AC Power Adaptor
(DSMC)

COPYRIGHT © 2014 RED.COM, INC
RED DSMC POWER OPERATION GUIDE
955-0038, REV-F |16
DSMC®power modules and adaptor modules provide battery power and other options for the DSMC BRAIN®.
This chapter describes installation and operation information for the following DSMC power modules:
“DSMC Side Handle” on page 17
“Module Adaptor” on page 18
“+1 Adaptor Module” on page 18
“Pro Battery Module (Dual)” on page 25
“Pro Battery Module (Quad)” on page 26
“REDVOLT XL Module” on page 27
“Quickplate Module” on page 33
“Backpack Quickplate (Short)” on page 34
For more information on DSMC power modules, see the RED Store at www.red.com/store.
WARNING: Modules, displays, and accessories are NOT HOT SWAPPABLE, meaning that you cannot remove or
install the item while the camera is turned on. Before installing or removing a module, display, or accessory,
you must turn off the camera. Failure to do so may result in damage to the item or DSMC and is not covered
under warranty.
03 DSMC POWER
MODULES

RED DSMC POWER OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC 955-0038, REV-F |17
DSMC SIDE HANDLE
The DSMC Side Handle provides programmable menu controls and a battery compartment that supports one
(1) REDVOLT battery. The backlit LCD displays camera parameter values and illuminates for operation in the
dark. Insert a REDVOLT in the DSMC Side Handle to power the DSMC, modules, and attached accessories.
Inserting a REDVOLT in the DSMC Side Handle also enables you to hot swap batteries and power sources con-
nected to the SEARAY and DC IN power connectors on the BRAIN.
For more information, see the DSMC Operation Guide, available at www.red.com/downloads.
NOTE: Upgrading your DSMC to v5.3 also upgrades the DSMC Side Handle. During the upgrade, you will be in-
structed to shut down the DSMC twice so that the firmware upgrades successfully. Any DSMC Side Handle that
is upgraded to v5.3 can only be used with DSMCs running v5.2 or later. In order to use a DSMC Side Handle
with v5.1 after you’ve upgraded it to v5.3, first downgrade to v5.2, and then downgrade to v5.1.
INSERT A REDVOLT
1. Press the battery door release button on the top of the DSMC Side Handle to open the battery door.
2. Press up on the red retainer and insert a REDVOLT battery until it is fully seated.
3. Close the DSMC Side Handle battery door.
REMOVE A REDVOLT
1. Press the battery door release button on the top of the DSMC Side Handle to open the battery door.
2. Press up on the red retainer.
3. Continue to apply pressure to the red retainer and remove the REDVOLT battery.
DSMC Side Handle Front
(left), DSMC Side Handle
Rear (right)

COPYRIGHT © 2014 RED.COM, INC
RED DSMC POWER OPERATION GUIDE
955-0038, REV-F |18
DSMC ADAPTOR MODULES
This section describes the DSMC adaptor modules.
MODULE ADAPTOR
The Module Adaptor mounts to the back of the BRAIN and provides power and support for connected mod-
ules. The Module Adaptor includes 1/4-20 mounting holes for customized configuration support. Most DSMC
modules require the use of an adaptor module.
WARNING: The Module Adaptor is NOT compatible with the +1 Adaptor Module.
+1 ADAPTOR MODULE
The +1 Adaptor Module mounts to the back of the BRAIN, providing power and support for connected modules.
The +1 Adaptor Module also offers a 4-pin 0B LEMO auxiliary power (DC) port for camera accessories, and an
EVF/LCD port for the use of an additional viewfinder or display.
WARNING: The +1 Adaptor Module IS NOT compatible with the Module Adaptor.
WARNING: DO NOT use the EVF/LCD port on the +1 Adaptor Module if a Pro I/O Module is connected to the
DSMC BRAIN. The Pro I/O Module overrides the EVF/LCD and AUX power out ports when connected.
NOTE: The +1 Adaptor Module requires DSMC firmware v4.0.8 or later.
NOTE: Use a 4-Pin to 2-Pin Adaptor Cable to support 2-pin camera accessories.
+1 Adaptor Module

RED DSMC POWER OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC 955-0038, REV-F |19
+1 ADAPTOR MODULE CONNECTIONS
1
4
2
5
3
#CONNECTOR CONNECTOR TYPE CONNECTOR FUNCTION
1Mounting 1/4-20 mounting Supports bolt-on auxiliary equipment
2EVF/LCD1N/A Custom digital video and power interconnection between the
BRAIN and RED EVF or LCD; Pinout not published
3Auxiliary power
out (PWR) 4-pin 0B LEMO Supplies unregulated (+) 11.5 to 17 V battery pass-through; Connect to 2-pin LEMO accessories with RED 4-Pin to 2-Pin
Adaptor Cable; Max sustained current is 2 A
4REDMOTE®dock
connector 8-point POGO connector Power and support for the REDMOTE
5Dock connector SEARAY connector Supports power and communication with modules
1. DO NOT use the EVF/LCD port on the +1 Adaptor Module if a Pro I/O Module is connected to the DSMC BRAIN. The Pro I/O Module
overrides the EVF/LCD and AUX power out ports when connected.
NOTE: The default auxiliary power output setting is on. Use the on-screen menu to toggle this setting ON/OFF.
In the menu screen, go to: Power > Power Out > +1 PWR. After a DSMC firmware upgrade or factory reset, the
default auxiliary power output setting is turned on. Thereafter, the last power output setting is restored.
+1 Adaptor Module

COPYRIGHT © 2014 RED.COM, INC
RED DSMC POWER OPERATION GUIDE
955-0038, REV-F |20
AUXILIARY POWER OUT (PWR)
The auxiliary power output supplies unregulated +11.5 to +17 V battery pass-through power. The maximum
sustained current draw is 2.0 A.
1
2
4
3
4-PIN 0B LEMO PWR CONNECTOR1
PIN SIGNAL
1Ground
2Not used
3Not used
4+11.5 to 17 V unregulated battery pass-through power
1. Mating connector: ENG.0B.304.CLL
COMPATIBLE CABLES
790-0334: 4-Pin to 2-Pin Adaptor Cable
Auxiliary Power
(PWR) Out
