Red Epic Mini-Mag System User manual

RED MINI-MAG SYSTEM |REDMAG 1.8" SSD SYSTEM
RED.COM
RED DSMC MEDIA
OPERATION GUIDE

COPYRIGHT © 2014 RED.COM, INC
RED DSMC MEDIA OPERATION GUIDE
955-0047, REV-E | 2
TABLE OF CONTENTS
Disclaimer 3
Copyright Notice 3
Trademark Disclaimer 3
Compliance Statements 3
Safety Instructions 5
Chapter 1: DSMC Media Overview 6
RED MINI-MAG System 6
REDMAG 1.8” SSD System 7
Mixing Carbon Fiber and Aluminum Components 8
Additional Resources 8
Chapter 2: RED MINI-MAG System 9
RED MINI-MAG 9
RED MINI-MAG Modules 10
RED STATION RED MINI-MAG 12
Chapter 3: REDMAG 1.8” SSD System 15
REDMAG 1.8” SSD 15
SSD Modules 16
RED STATIONS 22
Chapter 4: Install Media Modules 32
Install Side Media Modules 32
Install the REAR SSD MODULE 35
Eject Media from Camera (Unmount) 35
Chapter 5: Format Media 36
Overview 36
Format (Erase) Media In-Camera 36
Format (Erase) Media Via Computer 38
Clip Naming Conventions 40
Metadata 40
Media Capacity Remaining Status 41
Chapter 6: Offload Media 42
Connect RED MINI-MAGS to your Computer 42
Connect REDMAG 1.8” SSDS to Your Computer 43
Offload Data From Media to Your Computer 45
RED Watchdog 45
Chapter 7: Upgrade SSD Firmware 46
Verify Current SSD Firmware 46
Upgrade REDMAG 1.8” SSD (512GB) Firmware 47
Chapter 8: Troubleshoot Media 48
In-Camera Errors 48
Media Does Not Mount to Camera 48
Media Does Not Mount to Computer 49
LED Does Not Illuminate on RED Station 49
Cannot Format SSD on Computer 49
Identify SSD Type In-Camera 50
Appendix A: Technical Specifications 51
RED MINI-MAG 51
Carbon Fiber RED MINI-MAG Side SSD Module 51
RED MINI-MAG SIDE SSD MODULE 52
RED STATION RED MINI-MAG 52
REDMAG 1.8” SSD 53
DSMC 1.8” SSD SIDE MODULE 53
RED STATION REDMAG 1.8” 54
RED STATION REDMAG 2.5” 55
RED STATION BASE 55
Appendix B: REDCODE Options 56
RED MINI-MAG REDCODE Options 56
REDMAG 1.8” SSD REDCODE Options 61
SCARLET-X DRAGON REDCODE Options 77
SCARLET MYSTERIUM-X REDCODE Options 78

RED DSMC MEDIA OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC 955-0047, REV-E | 3
COMPLIANCE STATEMENTS
INDUSTRIAL CANADA EMISSION COMPLIANCE STATEMENTS
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
FEDERAL COMMUNICATIONS COMMISSION (FCC) STATE-
MENTS
This equipment has been tested and found to
comply with the limits for a Class B digital de-
vice, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reason-
able protection against harmful interference
in a residential installation. This equipment
generates, uses and can radiate radio fre-
quency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that inter-
ference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more
of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
NOTE: This device complies with Part 15 of the FCC Rules.
Operations subjected to the following two conditions (1) this device
may not cause harmful interference, and (2) this device must accept
any interference received, including that may cause undesirable in-
terference.
CAUTION: If the device is changed or modified
without permission from RED, the user may
void his or her authority to operate the equip-
ment.
AUSTRALIA AND NEW ZEALAND STATEMENTS
This device has been tested and found to comply with the limits for
a Class B digital device, pursuant to EN 55022:2006.
JAPAN STATEMENTS
This is a Class B product based on the
standard of the Voluntary Control Council
for Interference (VCCI) for information tech-
nology equipment. If this equipment is used
near a radio or television receiver in a do-
mestic environment, it may cause radio in-
terference. Install and use the equipment
according to the instruction manual.
EUROPEAN UNION COMPLIANCE STATEMENTS
RED declares that the
equipment described in this
document complies with the
requirements of the Europe-
an Council EMC Directive
2004/108/EC, Low Voltage
Directive 2006/95/EC, RoHS
Directive 2002/95/EC, and the WEEE Directive 2002/96/EC.
This declaration is based on compliance of the product to the fol-
lowing standards.
EN 55022, Information Technology Equipment - Radio Distur-
bance Characteristics
EN 55024, Information Technology Equipment - Immunity
Characteristics
EN 61000-3-2, Limits for harmonic current emissions
EN 61000-3-3, Limits for harmonic current emissions
EN 60950-1, Information Technology Equipment – Safety
DISCLAIMER
RED has made every effort to provide clear and accurate information
in these installation instructions, which are provided solely for the
user’s information. While thought to be accurate, the information in
this document is provided strictly “as is” and RED will not be held
responsible for issues arising from typographical errors or user’s
interpretation of the language used herein that is different from that
intended by RED. All safety and general information is subject to
change as a result of changes in local, federal or other applicable
laws.
RED reserves the right to revise this document and make changes
from time to time in the content hereof without obligation to notify
any person of such revisions or changes. In no event shall RED, its
employees or authorized agents be liable to you for any damages
or losses, direct or indirect, arising from the use of any technical or
operational information contained in this document.
For comments or questions about content in this Operation Guide,
please send a detailed e-mail to [email protected].
COPYRIGHT NOTICE
COPYRIGHT© 2014 RED.COM, INC.
All trademarks, trade names, logos, icons, images, written material,
code, and product names used in association with the accompa-
nying product are the copyrights, trademarks or other intellectual
property owned and controlled exclusively by RED.COM, INC.
TRADEMARK DISCLAIMER
All other company, brand and product names are trademarks or reg-
istered trademarks of their respective holders. RED has no affiliation
to, is not associated or sponsored with, and has no express rights
in third-party trademarks. SEARAY is a trademark of Samtec, Inc.

COPYRIGHT © 2014 RED.COM, INC
RED DSMC MEDIA OPERATION GUIDE
955-0047, REV-E | 4
INFORMATION
Products with the CE marking comply with the EMC Directive
(2004/108/EC) and the Low Voltage Directive (2006/95/EC) issued
by the Commission of the European Community. Compliance with
these directives implies conformity to the following European Prod-
uct Family Standards.
EN 55022 (CISPR 22) – Electromagnetic Interference
EN 55024-1 (CISPR 24) – Electromagnetic Immunity
EN 61000-3-2 (IEC610000-3-2) – Power Line Harmonics
EN 61000-3-3 (IEC610000) – Power Line Flicker
EN 60065 (IEC60065) – Product Safety
NORWAY
This subsection does not apply for the geographical area within a
radius of 20 km from the centre of Ny-Ålesund
Dette gjelder ikke for det geografiske området innenfor en radius av
20 km fra sentrum av Ny-Ålesund
The Waste Electrical and Electronic Equip-
ment (WEEE) mark applies only to countries
within the European Union (EU) and Norway.
This symbol on the product and accompany-
ing documents means that used electrical
and electronic products should not be mixed
with general household waste. For proper
treatment, recovery and recycling, please
take this product to designated collection
points where it will be accepted free of
charge. Alternatively, in some countries you
may be able to return your products to your
local retailer upon purchase of an equivalent
new product.
Disposing of this product correctly will help save valuable resources
and prevent any potential negative effects on human health and the
environment, which could otherwise arise from inappropriate waste
handling. Please contact your local authority for further details of
your nearest designated collection point. Penalties may be appli-
cable for incorrect disposal of this waste, in accordance with you
national legislation.
For business users in the European Union, if you wish to discard
electrical and electronic equipment, please contact your dealer or
supplier for further information.
RESPONSIBLE PARTY:
RED Digital Cinema
34 Parker
Irvine, CA 92618
USA

RED DSMC MEDIA OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC 955-0047, REV-E | 5
SAFETY INSTRUCTIONS
DO NOT use the media or media modules near water. Avoid
exposing your media or media modules to moisture. The units
are not waterproof, so contact with water could cause perma-
nent damage to the units as well as electric shock and serious
injury to the user. DO NOT use the media or media modules in
the rain or under other conditions with high moisture without
appropriate protection, and immediately remove power source
if the media or media modules are exposed to moisture.
WARNING: To reduce the risk of fire or elec-
tric shock, do not expose the media or
media modules to rain or moisture.
If fluids or foreign objects get inside any of the media modules
or RED STATIONS, disconnect the power source immediately
and file a support ticket on support.red.com.
DO NOT expose your media or media modules to excessive
vibration or impact (shock). Be careful not to drop your media
or media modules. Internal mechanisms may be damaged by
severe shock. Mechanical alignment of elements may be af-
fected by excessive vibration.
Avoid using the media or media modules in areas with high
humidity or dust.
DO NOT expose the media or media modules to strong elec-
tronic or magnetic fields.
Clean only using a dry cloth. When cleaning your media or
media modules, remember that it is not waterproof and mois-
ture can damage electronic circuitry. DO NOT rinse or immerse
any element of the media or media modules, keep them dry at
all times. DO NOT use soaps, detergents, ammonia, alkaline
cleaners, and abrasive cleaning compounds or solvents. These
substances may damage coatings and electronic circuitry.
The RED STATIONS operate best in an air-conditioned environ-
ment.
DO NOT operate or store near any heat sources such as radia-
tors, heat registers, stoves, or any other apparatus that pro-
duce heat. Store in a protected, level and ventilated place.
Avoid exposure to temperature extremes, damp, severe vibra-
tion, strong magnetic fields, direct sunlight or local heat sourc-
es during storage. Recommended storage and usage tempera-
tures for your media and media modules are:
‒Operating range: 0°C to 40°C (32°F to 104°F)
‒Storage range: -20°C to 50°C (-4°F to 122°F)
If there are any performance issues with your media or media
modules when operating within this temperature range, please
file a support ticket on support.red.com.
The REAR SSD MODULE, RED MINI-MAG SIDE SSD MODULE,
and DSMC 1.8" SSD SIDE MODULE are NOT HOT SWAPPA-
BLE – meaning you cannot remove or install them while the
camera is powered on. Before installing or removing any of
these modules, you MUST power down the camera. Failure
to do so may result in damage to the module and / or camera
brain that will not be covered under warranty.
Protect all power cords from being pinched, walked on or
driven over by a vehicle. Replace any power cords suspected
of sustaining damage due to crushing or other forms physical
damage. Use media and media modules only when they are in
good operating condition.
Always use the original packaging or similarly structured pack-
aging for transportation.
USE AT YOUR OWN RISK. RED is not responsible for lost data,
corrupted data, or damaged SSDs while using any of the SSD
media modules or RED STATIONS.
CAUTION: Refer all service and repair to
qualified RED service personnel. To reduce
the risk of electric shock, and damage to
the camera or accessories, DO NOT at-
tempt to perform any servicing other than
any procedures that are recommended in
the operating instructions.

COPYRIGHT © 2014 RED.COM, INC
RED DSMC MEDIA OPERATION GUIDE
955-0047, REV-E | 6
RED offers two (2) media systems for your RED Digital Still and Motion Camera (RED DSMC®):
RED MINI-MAGTM system
REDMAGTM 1.8" SSD system
RED MINI-MAG SYSTEM
This system centers around the RED MINI-MAG, which is the fastest, smallest, and most powerful media option
for your RED EPIC or SCARLET camera. RED MINI-MAGS use a faster read/write speed for capturing higher
frame rates and resolutions with less compression than previous DSMC media systems.
RED MINI-MAG SYSTEM COMPONENTS
The RED MINI-MAG system includes the following items, available at red.com (this table does not include any
of the RED MINI-MAG collections or packages, which are made up of the items below):
ITEM PART NUMBER
RED MINI-MAGTM (512GB) 750-0053
RED MINI-MAGTM SIDE SSD MODULE 720-0021
Carbon Fiber RED MINI-MAG TM Side SSD Module1NA
RED STATION®RED MINI-MAGTM 750-0055
RED MINI-MAGTM CASE (4-PACK) 790-0404
RED MINI-MAGTM CASE (12-PACK) 790-0405
1. The Carbon Fiber RED MINI-MAG Side SSD Module is only available with a carbon fiber DSMC BRAIN.
RED MINI-MAG
PACKAGE
01 DSMC MEDIA
OVERVIEW

RED DSMC MEDIA OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC 955-0047, REV-E | 7
REDMAG 1.8" SSD SYSTEM
This system centers around the REDMAG 1.8" SSD, which is a fast and reliable media option for your DSMC.
REDMAG 1.8" SSD SYSTEM COMPONENTS
The REDMAG 1.8" SSD system includes the following items, available at red.com (this table does not include
any of the REDMAG 1.8" SSD collections or packages, which are made up of the items below):
ITEM PART NUMBER
REDMAGTM 1.8" SSD (48GB) 750-0044
REDMAGTM 1.8" SSD (64GB) 750-0025
REDMAGTM 1.8" SSD (128GB) 750-0021
REDMAGTM 1.8" SSD (240GB)1750-0061
REDMAGTM 1.8" SSD (256GB) 750-0026
REDMAGTM 1.8" SSD (512GB)2750-0037
RED DSMC®SIDE 1.8" SSD MODULE 720-0013
RED DSMC®SIDE 1.8" SSD MODULE (DRAGON)3NA
RED DSMC®SIDE 1.8" SSD MODULE (CARBON FIBER DRAGON)4NA
REAR SSD MODULE 720-0009
RED STATION®REDMAGTM 1.8" 750-0006
RED STATION®REDMAGTM 1.8" (MINI)–ESATA 750-0035
RED STATION®REDMAGTM 1.8" (MINI)–USB 3.0 750-0036
RED STATION®REDMAGTM 2.5" 750-0007
RED STATION® BASE 750-0004
REDMAGTM CASE (4-PACK) 790-0204
REDMAGTM CASE (12-PACK) 790-0144
1. The REDMAG 1.8" SSD (240GB) requires that your DSMC is on firmware v5.1.44 or later.
2. The REDMAG 1.8" SSD (512GB) is no longer available for purchase at red.com, but is still supported by RED.
3. The DSMC 1.8" SSD SIDE MODULE (DRAGON) is only available with a DSMC with a RED DRAGON sensor.
4. The DSMC 1.8" SSD SIDE MODULE (CARBON FIBER DRAGON) is only available with a carbon fiber DSMC BRAIN.
DSMC MEDIA PACK

COPYRIGHT © 2014 RED.COM, INC
RED DSMC MEDIA OPERATION GUIDE
955-0047, REV-E | 8
MIXING CARBON FIBER AND ALUMINUM COMPONENTS
The structural mounting points for the carbon fiber media modules are optimized for the carbon fiber DSMC
BRAIN, whereas the structural mounting points for the standard aluminum side SSD modules are optimized for
use with the standard aluminum DSMC BRAIN.
Using a carbon fiber media module with an aluminum DSMC BRAIN or using an aluminum side SSD module with
a carbon fiber DSMC BRAIN may lead to an unstable connection between the BRAIN and the module, which
could affect data integrity.
WARNING: Damage to the DSMC BRAIN, side SSD module, or other components of the DSMC system caused
by mixing carbon fiber components with non-carbon-fiber components is not covered under warranty, and may
void the warranty for both the BRAIN and the side SSD module.
SUMMARY OF CARBON FIBER RESTRICTIONS
DO NOT attach any of the following side SSD modules to a carbon DSMC BRAIN:
RED MINI-MAG SIDE SSD MODULE
DSMC 1.8" SSD SIDE MODULE
DSMC 1.8" SSD SIDE MODULE (DRAGON)
DO NOT attach the following side SSD modules to a standard aluminum DSMC:
Carbon Fiber RED MINI-MAG Side SSD Module
DSMC 1.8" SSD SIDE MODULE (CARBON FIBER DRAGON)
ADDITIONAL RESOURCES
The following resources offer additional information about RED, the DSMC system, and the RED community:
RED.com: Check the official RED website for the latest information about RED products.
RED Learn Articles: RED offers in-depth technical articles about RED cameras, post-production, and digital
cinematography.
RED.com/downloads: Go to the RED Downloads page to download the latest firmware, operation guides,
and post-production software.
Support.red.com: Check the RED SUPPORT site for FAQs, or to file a support ticket.
Reduser.net: Discuss all things RED on the REDUSER third-party forum.

COPYRIGHT © 2014 RED.COM, INC
RED DSMC MEDIA OPERATION GUIDE
955-0047, REV-E | 9
02
RED MINI-MAG
The RED MINI-MAG is the fastest, smallest, and most powerful media option for your RED EPIC®or SCARLET®
camera. RED MINI-MAGS use a faster read/write speed for capturing higher frame rates and resolutions with
less compression than previous DSMC media systems.
The RED MINI-MAG is available in the following storage capacity: 512GB.
NOTE: The RED MINI-MAG system requires that your DSMC is on firmware v5.1.34 or later. If your DSMC is
on an earlier version, you can use the RED MINI-MAG to upgrade to v5.1.34 or later. While you can use a
RED MINI-MAG to downgrade to DSMC firmware versions earlier than v5.1.34, the DSMC will not be ful-
ly functional with the RED MINI-MAG SIDE SSD MODULE installed. You will need to either switch to a
DSMC 1.8" SSD SIDE MODULE or upgrade to v5.1.34 or later.
RED MINI-MAG INCLUDED COMPONENTS
The item listed in the table below ships with the RED MINI-MAG.
ITEM PART NUMBER
RED MINI-MAG (512GB) 750-0053
RED MINI-MAG
RED MINI-MAG
SYSTEM

COPYRIGHT © 2014 RED.COM, INC
RED DSMC MEDIA OPERATION GUIDE
955-0047, REV-E | 10
RED MINI-MAG MODULES
RED offers the following RED MINI-MAG modules:
RED MINI-MAG SIDE SSD MODULE: Mounts to any standard aluminum DSMC BRAIN.
Carbon Fiber RED MINI-MAG Side SSD Module: Mounts to any carbon fiber DSMC BRAIN, and is only available
with a carbon fiber DSMC BRAIN.
Each RED MINI-MAG module attaches to the DSMC so that you can mount a RED MINI-MAG to your camera.
Each RED MINI-MAG module has the same EVF/LCD LEMO connector, user keys, and REC button as the
DSMC 1.8" SSD SIDE MODULE.
WARNING: The RED MINI-MAG modules are NOT HOT SWAPPABLE, meaning you cannot remove or install the
modules while the camera is powered on. Before installing or removing the modules you MUST power down the
camera. Failure to do so may result in damage to the module or DSMC that will not be covered under warranty.
RED MINI-MAG SIDE SSD MODULE INCLUDED COMPONENTS
The item listed in the table below ships with the RED MINI-MAG SIDE SSD MODULE.
ITEM PART NUMBER
RED MINI-MAG SIDE SSD MODULE 720-0021
RED MINI-MAG SIDE SSD MODULE CONTROLS
This section describes the controls for all of the RED MINI-MAG modules.
CONTROL DESCRIPTION
User Key 1 Programmable key
User Key 1 + 2 Press: Eject Media
User Key 2 Programmable key
User Key 1 + 2 Press: Eject Media
REC button Programmable key
Full Press: Record Toggle
Half Press: AF Start
RED MINI-MAG
SIDE SSD MODULE

RED DSMC MEDIA OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC 955-0047, REV-E | 11
RED MINI-MAG SIDE SSD MODULE CONNECTORS
This section describes the connectors for all of the RED MINI-MAG modules.
Each RED MINI-MAG modules mounts to the left side of the DSMC BRAIN. The rear face of this module features
a slot for inserting a RED MINI-MAG.
WARNING: DO NOT attempt to insert any media type except for the RED MINI-MAG, or any foreign objects, into
the SSD slot, as that may damage the RED MINI-MAG module or DSMC system.
The EVF/LCD connector on the front face of the RED MINI-MAG module provides digital vid-
eo, communications, and power interconnection between the DSMC and a RED EVF or RED LCD.
Due to the requirement for absolute data integrity, the pinout of the EVF/LCD connector is not published.
CONNECTOR DESCRIPTION COMPATIBLE PARTS PART NUMBERS
EVF/LCD connector VIEWFINDER output LCD/EVF CABLE (RIGHT-TO-
RIGHT) 7" 790-0158
LCD/EVF CABLE (RIGHT-TO-
RIGHT) 12" 790-0162
LCD CABLE 6' 790-0055
LCD CABLE 10' 790-0056
RED MINI-MAG slot Slot for inserting a RED MINI-MAG RED MINI-MAG 750-0053
RED MINI-MAG SIDE SSD MODULE LEDS
This section describes the LED for all of the RED MINI-MAG modules.
LED COLOR/FLASHING DESCRIPTION
Media Indicator LED Off No media present
Green Ready to record
Red Recording
Red slow flashing Recording; 25% media left
Red fast flashing Recording; 5% media left
Yellow Finalizing
Yellow flashing Accessing media (for example,
when formatting)

COPYRIGHT © 2014 RED.COM, INC
RED DSMC MEDIA OPERATION GUIDE
955-0047, REV-E | 12
RED STATION RED MINI-MAG
The RED STATION RED MINI-MAG is designed exclusively for offloading data from RED MINI-MAGS, and connects
to your computer via Firewire 800, eSATA 6G, or USB 3.0. Its compact design takes up less space than the
traditional RED STATION REDMAG 1.8" and fits easier into cases for storage.
RED STATION RED MINI-MAG INCLUDED COMPONENTS
The items listed in the table below ship with the RED STATION RED MINI-MAG.
ITEM PART NUMBER
RED STATION RED MINI-MAG 750-0055
eSATA Data Cable (24") 790-0250
RED STATION USB 3.0 CABLE (24") 790-0314
RED STATION FW800 Cable (2") 790-0253
RED STATION FW800 Cable (24") 790-0251
RED STATION AC POWER ADAPTOR 790-0292
RED STATION USB TO DC POWER CABLE (24") 790-0316
RED STATION RED MINI-MAG

RED DSMC MEDIA OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC 955-0047, REV-E | 13
RED STATION RED MINI-MAG CONNECTORS AND CONTROLS
CONNECTOR DESCRIPTION COMPATIBLE PARTS PART NUMBERS
eSATA 6G connec-
tor1Connect to a computer via an eSATA connection eSATA Data Cable (24") 790-0250
FireWire 800 Connect to a computer or addi-
tional RED STATIONS via a FireWire
800 connection
RED STATION FW800 Cable (2") 790-0253
RED STATION FW800 Cable (24") 790-0251
USB 3.0 slot Connect to computer via USB 3.0
connection RED STATION USB 3.0 CABLE (24") 790-0314
On/Off Switch Turn on/off NA NA
+5 VDC IN +5 VDC power in RED STATION AC POWER ADAP-
TOR 790-0292
RED STATION USB TO DC POWER
CABLE (24") 790-0316
RED MINI-MAG slot
(front) Slot for inserting a RED MINI-MAG RED MINI-MAG 750-0053
1. Only Silicon Image or HighPoint SATA cards connect to the RED STATION RED MINI-MAG through eSATA.
RED STATION RED MINI-MAG
(Rear)

COPYRIGHT © 2014 RED.COM, INC
RED DSMC MEDIA OPERATION GUIDE
955-0047, REV-E | 14
RED STATION RED MINI-MAG LEDS
LED COLOR/FLASHING DESCRIPTION
Power Indicator LED Off Powered off and turned off
Red Powered on and turned on
Red fast flashing Accessing media
RED STATION RED MINI-MAG

COPYRIGHT © 2014 RED.COM, INC
RED DSMC MEDIA OPERATION GUIDE
955-0047, REV-E | 15
03
REDMAG 1.8" SSD
The REDMAG 1.8" SSD media works with the DSMC 1.8" SSD SIDE MODULE and REAR SSD MODULE to
provide a fast and reliable recording medium.
The REDMAG 1.8" SSD is available in the following storage capacities: 48GB, 64GB, 128GB, 256GB, and
512GB.
REDMAG 1.8" SSD INCLUDED COMPONENTS
Each REDMAG 1.8" SSD ships with one (1) of the following:
ITEM PART NUMBER
REDMAG 1.8" SSD (48GB) 750-0044
REDMAG 1.8" SSD (64GB) 750-0025
REDMAG 1.8" SSD (128GB) 750-0021
REDMAG 1.8" SSD (240GB)1750-0061
REDMAG 1.8" SSD (256GB) 750-0026
REDMAG 1.8" SSD (512GB)2750-0037
1. The REDMAG 1.8" SSD (240GB) requires that your DSMC is on firmware v5.1.44 or later.
2. The REDMAG 1.8" SSD (512GB) is no longer available for purchase at red.com, but is still supported by RED.
REDMAG 1.8" SSD
REDMAG 1.8" SSD
SYSTEM

COPYRIGHT © 2014 RED.COM, INC
RED DSMC MEDIA OPERATION GUIDE
955-0047, REV-E | 16
SSD MODULES
You can mount the REDMAG 1.8" SSD to the following modules:
DSMC 1.8" SSD SIDE MODULE
DSMC 1.8" SSD SIDE MODULE (DRAGON)
DSMC 1.8" SSD SIDE MODULE (CARBON FIBER DRAGON)
REAR SSD MODULE
DSMC 1.8" SSD SIDE MODULES
RED offers the following DSMC 1.8" SSD SIDE MODULES:
DSMC 1.8" SSD SIDE MODULE: Mounts to any standard aluminum DSMC BRAIN.
DSMC 1.8" SSD SIDE MODULE (DRAGON): Mounts to a DSMC with a RED DRAGON sensor, and is only avail-
able with a DSMC with a RED DRAGON sensor.
DSMC 1.8" SSD SIDE MODULE (CARBON FIBER DRAGON): Mounts to a carbon fiber DSMC BRAIN, and is only
available with a carbon fiber DSMC BRAIN.
Each DSMC 1.8" SSD SIDE MODULE attaches to the DSMC so that you can mount a REDMAG 1.8" SSD to
your camera.
Each DSMC 1.8" SSD SIDE MODULE has the same EVF/LCD LEMO connector, user keys, REC button, and
LED as the RED MINI-MAG SIDE SSD MODULE.
WARNING: The DSMC 1.8" SSD SIDE MODULE is NOT HOT SWAPPABLE, meaning you cannot remove or install
the module while the camera is powered on. Before installing or removing the module you MUST power down
the camera. Failure to do so may result in damage to the module or DSMC that will not be covered under war-
ranty.
DSMC 1.8" SSD SIDE MODULE
(Rear and Front)

RED DSMC MEDIA OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC 955-0047, REV-E | 17
DSMC 1.8" SSD SIDE MODULE INCLUDED COMPONENTS
The items listed in the table below ship with the DSMC 1.8" SSD SIDE MODULE.
ITEM PART NUMBER
DSMC 1.8" SSD SIDE MODULE 720-0013
Four (4) M3x0.5 x 6 mm Cap Screws NA
DSMC 1.8" SSD SIDE MODULE CONTROLS
This section describes the controls for all of the DSMC 1.8" SSD SIDE MODULES.
CONTROL DESCRIPTION
User Key 1 Programmable key
User Key 1 + 2 Press: Eject Media
User Key 2 Programmable key
User Key 1 + 2 Press: Eject Media
REC button Programmable key
Full Press: Record Toggle
Half Press: AF Start
DSMC 1.8" SSD SIDE MODULE
(Front)

COPYRIGHT © 2014 RED.COM, INC
RED DSMC MEDIA OPERATION GUIDE
955-0047, REV-E | 18
DSMC 1.8" SSD SIDE MODULE CONNECTORS
This section describes the connectors for all of the DSMC 1.8" SSD SIDE MODULES.
The DSMC 1.8" SSD SIDE MODULE mounts to the left side of the DSMC BRAIN. The rear face of this module
features a slot for inserting a REDMAG 1.8" SSD.
WARNING: DO NOT attempt to insert any media type except for the REDMAG 1.8" SSD, or any foreign objects,
into the SSD slot, as that may damage the DSMC 1.8" SSD SIDE MODULE or DSMC system.
The EVF/LCD connector on the front face of the DSMC 1.8" SSD SIDE MODULE provides digi-
tal video, communications, and power interconnection between the DSMC and a RED EVF or RED LCD.
Due to the requirement for absolute data integrity, the pinout of the EVF/LCD connector is not published.
CONNECTOR DESCRIPTION COMPATIBLE PARTS PART NUMBERS
EVF/LCD connector
(front) VIEWFINDER output LCD/EVF CABLE (RIGHT-TO- RIGHT) 7" 790-0158
LCD/EVF CABLE (RIGHT-TO-
RIGHT) 12" 790-0162
LCD CABLE 6' 790-0055
LCD CABLE 10' 790-0056
REDMAG 1.8" SSD
slot (rear) Slot for inserting a REDMAG 1.8" SSD REDMAG 1.8" SSD (48GB) 750-0044
REDMAG 1.8" SSD (64GB) 750-0025
REDMAG 1.8" SSD (128GB) 750-0021
REDMAG 1.8" SSD (256GB) 750-0026
REDMAG 1.8" SSD (512GB) 750-0037
WARNING: Damage to the DSMC, side SSD module, or other components of the DSMC system caused by mixing
carbon fiber components with non-carbon-fiber components is not covered under warranty, and may void the
warranty for both the BRAIN and the side SSD module. For more information, go to “Mixing Carbon Fiber and
Aluminum Components” on page 8.
DSMC 1.8" SSD SIDE MODULE
(Rear and Front)

RED DSMC MEDIA OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC 955-0047, REV-E | 19
DSMC 1.8" SSD SIDE MODULE LED
This section describes the LED for all of the DSMC 1.8" SSD SIDE MODULES.
LED COLOR/FLASHING DESCRIPTION
Media Indicator LED Off No media present
Green Ready to record
Red Recording
Red slow flashing Recording; 25% media left
Red fast flashing Recording; 5% media left
Yellow Finalizing
Yellow flashing Accessing media (for example, when
formatting)
DSMC 1.8" SSD SIDE MODULE
(Rear)

COPYRIGHT © 2014 RED.COM, INC
RED DSMC MEDIA OPERATION GUIDE
955-0047, REV-E | 20
REAR SSD MODULE
The REAR SSD MODULE secures onto the back of a MODULE ADAPTOR or a +1 ADAPTOR MODULE to serve
as a rear location for recording to a REDMAG 1.8" SSD. In the case that you are using cables or configurations
that make it difficult to access your DSMC 1.8" SSD SIDE MODULE, the REAR SSD MODULE is positioned to
make it easy to swap and record to a REDMAG 1.8" SSD.without interference.
The REAR SSD MODULE does not have any user keys or control buttons.
NOTE: The REAR SSD MODULE mounts only to a MODULE ADAPTOR or a +1 ADAPTOR MODULE.
REAR SSD MODULE INCLUDED COMPONENTS
The item listed in the table below ships with the REAR SSD MODULE.
ITEM PART NUMBER
REAR SSD MODULE 720-0009
REAR SSD MODULE
