Red Hawk PowerSense BL-6000 Series User manual

Safely and efficiently provide
power over LAN Data cabling
for VoIP phones, Wireless
Networking access points
and other remote access
devices .
BL-6000 PowerSenseTM 24 Port
Modular Multiport InLine Power Hub
www.red-hawk.comTel: 408.945.1800 Fax: [phone] USA: 1.800.989.4295
The PowerSenseTM In-Line Power Hub from
Red Hawk provides a safe and efficient way
to provide power to VoIP Phones, Wireless
LAN Access Points, Web Cameras and
other LAN Devices without the use of an
external power supply for each device.
Power is supplied over the existing LAN
data cabling system. This greatly improves
the range of installation locations for such
devices, no longer requiring them to be
located near a power outlet. It also adds an
unprecedented level of safety and reliability
for powered LAN devices.
The PowerSenseTM Hub is a 24 port
rack-mount chassis powering up to 24
devices. Each 8 port module is
Hot-swappable so that modules may be
added to the chassis without powering
down the unit. If an individual power port is
damaged due to a lightning strike or power
surge, the module bank may be hot
swapped out without powering down the
chassis or disconnecting the other devices
attached to the other power ports in the
chassis.
When used with an uninterruptible power
supply, the PowerSenseTM Hub provides
non-stop power for up to 24 connected
devices. Continuous operation of powered
LAN devices is assured, while costly
downtime is avoided. The PowerSenseTM
Hub also eliminates the need for costly
uninterruptible power supplies to be
installed for each powered LAN device,
saving time and extra expense.
The PowerSenseTM Hub is tailored to
provide maximum value in VoIP network
applications. External power supplies
normally required for VoIP phones become
unnecessary. Power is now supplied by the
PowerSenseTM Hub System to the phones
directly over the existing LAN cabling
infrastructure. A device detection circuit
provides invaluable protection from
over-voltage damage if an incorrect device,
such as a laptop computer, is accidentally
attached to a powered network port.
PowerSense™ operates on Category 5, 5e
or 6 grade LAN Data Cable at standard
Ethernet distances. The BL-6000 series
supports powered devices requiring the
IEEE 802.3af Power over Ethernet Protocol.
Features/Benefits:
nHot swappable 8-port modules in the 19”
rackmount ready chassis support IEEE
802.3af powered devices
nEach module is current limited for short
circuit protection with power isolation of
1500 VRMS
nEach module auto-detects the power
requirement for safety and offers
transparent 10/100Mb and management
operations
nEach module has TWO diagnostic LED’s –
as shown above
nSupport for all compliant IEEE 802.3af
powered devices
nEach module supplies full 15.4 watts for up
to 8 devices as per the IEEE 802.3af
standard
*Supports the IEEE 802.2af standard for many manufacturers VoIP phones, Access Points, IP Cameras, etc.
Rackmount Chassis
Complete w/24 Ports
8 Port Module for
the 24 port chassis
Detect (blue)
Power (green)
Power / Data Out
Data In
Layer 3 Switch
Wireless
Access
Point
Laptop w/Wireless
IP Camera
VoIP Phone
Wireless Laptop/
PDA
Wireless
Access
Point
PowerSense BL-6000
MidSpan Hub
Powered Devices
IEEE802.3af Compatible
Example
using existing
Ethernet
Switch
BL-6500 Module

Interfaces
24 Female RJ-45 Data input ports
Shielded jacks for Category 5 UTP (two pair
wire) or 100-ohm STP (two pair wire).
Distance: 100 meters
24 Female RJ45 Data+Power over Ethernet
output ports
Physical / Mechanical
Chassis type: 19" Rackmount w/24 Ports
Chassis size: 17.5W X 16.25D X 1.75H
Module Type: Removable, hot swappable
Weight: 20lbs. (9kg)
Specifications - BL-6000 Power Hub
PowerSenseTM
In-Line
Power Hub
1405 S. Milpitas Blvd.
Milpitas, CA 95035
Copyright © 2003 Red Hawk. PowerSense is a trademark of Red Hawk.
While Red Hawk believes the foregoing information is accurate, Red Hawk has made no investigation
and does not make any representation or warranty as to its accuracy or completeness and reserves the
right to change specifications at any time without notice. Red Hawk will not be liable for any errors or
omissions in the foregoing, including any damages (whether incidental, consequential or actual)
resulting from the publication, distribution or use of, or reliance on, the foregoing information.
All corporate identities mentioned in this document are trademarked with their respective corporations.
www.red-hawk.comTel: 408.945.1800 Fax: [phone] USA: 1.800.989.4295
Electrical
AC Power Input
Voltage: 90-264V Autoranging (46Hz - 63Hz)
Connector: 3-pin with Ground
Chassis Grounding: Yes
Power Supply: Single
Power Cord: Removable w/IEC plug
DC Port Power Output
Power Enabling:
IEEE: IEEE 802.3af
Power pins: Unused pairs, pins 4,5(+), 7,8(-)
Max. Power/Port: 15.6W
Max Power-all ports active: 24*15.6W
Module to Module isolation: 1500V RMS
Overload protection: If Current reaches
400-450mA for 300-400 milliseconds, then
the port shuts down
LED Indicators / Module
Detect / Power Forwarding (blue)
Module Power (green)
Physical / Environmental
Operating Temperature
0˚ to 40˚ C ( 32˚ to 105˚ F)
Storage Temperature
-10˚ to 60˚ C ( 14˚ to 140˚ F)
Relative Humidity
10% to 90% non-condensing
Operating Altitude
-1,000 to 10,000 feet
Certifications
Safety: UL 1950 and cUL
Emissions: FCC Class A EN55022
Class A EN55024, CE Mark (CISPR 22 Class A)
Standards: P802.3af 802.3u
Integrated Network Products
BL-6000 Ordering Information
Chassis only - 19” Rackmount ready, holds up to
three 8 port modules
BL-6224 - 3 Slot PowerSense™ Chassis
Chassis - Complete w/ 8 port Modules, up to 3 modules
BL-6524 - 24 Power & Data Ports -IEEE 802.3af
BL-6516 - 16 Power & Data Ports -IEEE 802.3af
and 1 cover plate
BL-6508 - 8 Power & Data Ports - IEEE 802.3af
and 2 cover plates
Individual Spare Chassis Modules
BL-6500 - IEEE 802.3af - 8 Power & Data Ports
Chassis - Cover Plates for unused slots
BL-6201 - Single Slot cover plate
Rackmount Chassis
Complete w/24 Ports
