red lion DAS00PN1EE200000 User manual

DA_Dual Ethernet - A
Drawing No. LP1112
Effective 07 2020
DA Dual Ethernet Sled
Installation Guide
1
PACKAGE CHECKLIST
This product package should contain the items listed below. If
any items are missing or damaged, contact Red Lion immediately.
- DA Dual Ethernet Sled
- Installation Guide
SAFETY SUMMARY
All safety related regulations, local codes as well as instructions
that appear in this document or on equipment must be observed
to ensure personal safety and to prevent damage to either the
device or equipment connected to it.
Do not use these products to replace proper safety interlocking.
No software-based device (or any other solid-state device) should
ever be designed to be responsible for the maintenance of
personnel safety or consequential equipment not equipped with
safeguards. Red Lion disclaims any responsibility for damages,
either direct or consequential, that result from the use of this
equipment in a manner not consistent with these specifications.
SPECIFICATIONS
1. POWER REQUIREMENTS: Power is supplied by the DA host
controller.
Max Power: 2.1 W
2. INTERFACES:
Two 10/100 BaseTX RJ-45 Ports, auto MDI/ MDI-X.
Individual isolation from Ethernet network to controller:
1500 Vrms
3. ENVIRONMENTAL CONDITIONS:
Operating Temperature Range: -40 to 75 °C
Storage Temperature Range: -40 to 80 °C
Vibration to IEC 60068-2-6: Operational 5-500 Hz, 2 g
Shock to IEC 60068-2-27: Operational 15 g
Operating and Storage Humidity: 0 to 95% max. RH non-
condensing
Altitude: Up to 2000 meters
4. CERTIFICATIONS AND COMPLIANCES:
Refer to the controller manual for agency certifications.
CE Approved
EN 61326-1 Immunity to Industrial Locations
Emission CISPR 11 Class A
IEC/EN 61010-1
RoHS Compliant
5. INSTALLATION REQUIREMENTS: Sled must be installed
inside the unit case with the hardware provided. See
“Installing the Dual Ethernet Sled” for more details.
6. WEIGHT: 7.05 oz (200 g)
INSTALLING THE DUAL ETHERNET SLED
DA50 INSTALLATION
1. Prior to installing the Sled for your DA50 application, ensure
that the unit is not receiving power.
2. Disconnect and remove your DA50 from the DIN rail.
3. Remove the DA50 unit’s front cap by squeezing the sides and
pulling.
4. Slide out the sled holder.
5. Install the sled into the sled holder and hand tighten the
captive fasteners, or use a screwdriver.
6. Re-install the sled holder containing the sled into the
Converter. Make sure it is fully seated.
7. Replace the front cap.
CAUTION: Risk of Danger
Read complete instructions prior to installation and
operation of the unit.
ATTENTION : Risque de danger
Lire les instructions complètes avant l’installation et
l’utilisation de l’appareil.
CAUTION: Follow standard ESD precautionary
procedures.
ATTENTION: Suivez les procédures de précaution
standard de décharge électrostatique.
WARNING - Disconnect all power to the unit before
installing or removing sleds.
AVERTISSEMENT - Débranchez l’alimentation électrique
de l’appareil avant d’installer ou de retirer les tiroirs.
zDual 10/100TX Ethernet communication
zIndustrial rated for harsh environments
zWide operating temperature range
zSimplified deployment architecture
zField installable
zIndividually isolated ports
For use with DA50 and DA70 series covered in DEMKO 20 ATEX
2268X and IECEx UL 20.0007X certificates

2
Drawing No. LP1112 Effective 07 2020
DA70 INSTALLATION
1. Prior to installing the Sled(s) for your DA70 Controller
application, ensure that the Controller is not receiving power.
2. Remove the carriage from the Controller case by releasing the
two retaining latches and pulling straight out from Controller.
3. Remove blank panel from the carriage slot of the target sled
installation location.
4. Install sled by aligning the two sled mounting hole fasteners,
with the controller mounting posts. Be sure locating holes on
bottom side of sled align with the locating pins on the
carriage, and the sled sits flush against the carriage.
5. Hand tighten the sled captive fasteners, or use a screwdriver
if necessary.
6. Repeat the above steps for any additional sleds.
7. Carefully align the carriage with Controller base and press
carriage into the controller.
8. Close the retaining latches to ensure the carriage is fully
seated into the Controller case.
CONFIGURING THE DUAL ETHERNET SLED
DA50N CONFIGURATION
The Dual Ethernet Sled is configured using the web GUI. For
configuration and troubleshooting information, please refer to
the DA50N Software Manual for troubleshooting steps at
www.redlion.net/support/documentation.
DA50A or DA70A CONFIGURATION
The Dual Ethernet Sled is configured using the web GUI or
Crimson 3.2 (or later) software. Find additional information in the
Crimson 3.2 User Manual.
LEDs
STS LED
The STS LED provides status for the Dual Ethernet Sled. Refer
to the software user manual for more detailed information of
possible LED statuses.
LED COLOR(S) MEANING
YELLOW solid Link established.
YELLOW flashing Data being transferred.
GREEN (OFF) 10 BASE-T Communications
GREEN (ON) 100 BASE-TX Communications
RED LION CONTROLS TECHNICAL SUPPORT
If for any reason you have trouble operating, connecting, or
simply have questions concerning your new unit, contact Red
Lion’s technical support.
Support: support.redlion.net
Website: www.redlion.net
Inside US: [phone]
Outside US: [phone]
Red Lion Controls, Inc.
20 Willow Springs Circle York, PA 17406
ORDERING INFORMATION
PART NUMBER DESCRIPTION
DAS00PN1EE200000 Dual Ethernet Sled
COPYRIGHT
©2020 Red Lion Controls, Inc. All rights reserved. Red Lion
and the Red Lion logo are trademarks of Red Lion Controls,
Inc. All other company and product names are trademarks of
their respective owners.
CAUTION: Failure to properly align the carriage can
result in damage to the Sled connector pins.
ATTENTION: Si le chariot n’est pas correctement
aligné, les broches du connecteur du chariot
risquent d’être endommagées.
