RED-RING Selectronic Premier User manual

Warmer
Cooler
Start/Stop
Temperature
Temperature
Lock
Selectronic
Premier
IMPORTANT
This booklet should be given to the customer
after installation and demonstration
Selectronic
Premier
Thermostatic Instantaneous Electronic Shower
Handbook
IMPORTANT!
PLEASE REMOVE THE
“USER INFORMATION” LABEL
FROM FRONT COVER IF THIS
IS A CARE INSTALLATION

2
Selectronic Premier
(with 1.25m Hose)
THIS APPLIANCE CAN BE USED BY CHILDREN AGED FROM 3 YEARS AND ABOVE AND
PERSONS WITH REDUCED PHYSICAL, SENSORY OR MENTAL CAPABILITIES, OR LACK
OF EXPERIENCE AND KNOWLEDGE IF THEY HAVE BEEN GIVEN SUPERVISION OR
INSTRUCTION CONCERNING USE OF THE APPLIANCE IN A SAFE WAY AND
UNDERSTAND THE HAZARDS INVOLVED. CHILDREN SHALL NOT PLAY WITH THE
APPLIANCE. CLEANING AND USER MAINTENANCE SHALL NOT BE MADE BY CHILDREN
Warmer
Cooler
Start/Stop
Temperature
Temperature
Lock
Selectronic
Premier
Selectronic Premier Plus
(with 2m Hose)
1050 mm
Warmer
Cooler
Start/Stop
Temperature
Temperature
Lock
Selectronic
Premier
264 mm
364 mm
610 mm

Installation Instructions
ALL WIRING AND INSTALLATION MUST BE
SUPERVISED BY A SUITABLY QUALIFIED
PERSON.
We recommend that the installation be done in
the following sequence: -
a) Fix the shower to the wall
b) Plumbing
c) Electrical connections
d) Commissioning
Warning! Do Not Install The Shower In A
Room Where It May Be Subject To Freezing
a) Fix The Shower To The Wall
When deciding where to place the unit a few
things need to be taken into consideration: -
1) The unit MUST NOT be mounted directly
in the path of the spray from the handset
2) The handset could be used over a sink for
hair washing.
3) The handset does not come into contact
with the used water in the cubicle, bath or
basin.
A hose retainer is supplied with the
Accessories (See Diagrams 27 & 28).
4) The unit can be mounted at a lower level for
less able users combined with optional
extended hose and riser rail.
The installation must comply with BS 8300:
2018.(Design of buildings and their
approaches to meet the needs of disabled
people. Code of practice).Remembering to
Adhere to point 1.
5) Choose a flat piece of wall to avoid the
possibility of distorting the backplate and
making the front cover a poor fit.
3
Mains cold water supply
(either top, bottom
or rear entry)
Height of spray head
and shower to suit
user’s requirements
A TYPICAL INSTANTANEOUS ELECTRIC SHOWER INSTALLATION
User Information
Product Dimensions
How To Use Your Shower
How Your Shower Works
Handset Operation
Routine Maintenance
Periodical Maintenance
Trouble Shooting (User)
BEAB Care Wash Scheme
Installation Summary
Guarantee
Contents
Installer Information;-
Product Dimensions
Installation Instructions
Plumbing Connections
Electrical Connections
Changing The Operation Mode
Templock/Normal
Changing ‘DIP Switch’ Default Setting
Commissioning
Trouble Shooting (Installer)
BEAB Care Wash Scheme
Spares
Page Page
2
3
5
7
9
9
11
19
20
21
2
12
16
18
18
19
19
20
21
24

4
Remove the four cover screws and lift the
cover off.
Remove the four inlet cover screws and remove
inlet cover - also the two side access trimplate
section screws and remove complete with seal
(See diagram 1).
Hold the shower vertically against the wall and
mark the top hole first.
Drill the hole to take the rawl plug provided
(taking care to keep dust away from the
shower).
Put the top screw in first leaving it proud by
5mm approximately. The shower can now be
hung on this screw.
Position the shower so that it is vertical then
mark and drill the other two holes. Then fix the
Shower to the wall.
Assemble the accessories as shown in
Diagrams 27 and 28. Fix the riser rail with
screws provided. The fixing holes are revealed
by removing the plastic fronts.
Note: Care must be taken to ensure the notch
in the riser rail is fully engaged into the
corresponding lug in the wall bracket. This has
been made a firm fit to aid stability and stop
rotation.
Having determined the direction of the inlet
water mains supply and cable approach for
the installation (Top, Bottom, or Rear or any
combination) - it is necessary to remove the
appropriate section inserts. See Plumbing
Connections and Electrical Installation
sections (Pages 5 and 7) for detailed guidance.
480
1000
Handset Height Adjustment
Drop-down rail on side wall
Alarm Pull Cord
Back
Rest
Elevation
650
1500x1500 Wheelchair Turning Space
Towel / Grab Rail
Floor
Drain
Tip Up Seat
Shower Curtain
1200
1200
500
350
Drop-down
Rail
850 300
2000
Shower Riser
Rail
Fall of Floor
Plan
Shower
Unit
All measurements shown are in millimetres. Drawing sizes are
not to scale. Shower model shown is a Selectronic Premier Plus.
Typical guideline dimensions used for
less- abled bathroom installations

5
Plumbing Connections
Plumbing to be carried out before wiring
DO NOT use jointing compounds on any pipe
fittings for the installation.
DO NOT solder fittings near the shower unit
as heat can travel along pipework and
damage components.
Compression fittings MUST be used to
connect to the inlet of the shower.
Note: We recommended that a WRAS (Water
Regulations Advisory Scheme) listed isolating
valve be fitted between the rising main and
the unit. This will allow the unit to be serviced
without having to turn off the house water at
the stop valve.
The unit can be connected to the mains
COLD water supply. This must have a
minimum running pressure of 0.07 MPa
(0.7bar / 10 p.s.i.) and a maximum pressure
of 1MPa (10bar / 145 p.s.i.).
This unit can be fed from a header tank
provided this has a minimum head of 7 metres
(23ft).
IMPORTANT: Before completing the
connection of the water supply to the inlet of the
shower, flush out the pipework to remove all
swarf and system debris. This can be achieved
by connecting a hose to the pipework and
turning on the mains water supply long enough
to clear the debris to waste.
A blockage in the waterways (particularly the spray
plate of the handset and solenoid valve) will prevent
the unit from working correctly.
The shower is designed to have an open outlet and
should ONLY be used with the fittings recommended
by the manufacturer.
Installation Procedure
Turn off the water supply either at the mains
stopvalve or the isolating stopvalve.
For ease of access to the inlet fitting the right hand
side of the shower has a removable inlet cover. See
Diagram 1. Also remove the backplate side access
trimplate shown in Diagram 1.
Diagram 2
A
B
C
D
Diagram 1

6
Connect the mains water supply to the Inlet of the shower via 15mm copper, stainless steel or plastic
pipe using a 15mm compression fitting. See (Diagram 4) for advice on Rear Entry fitting.
The Inlet fitting is designed to rotate through 180° to allow for either Top or Bottom/Rear entry fitting
(See Diagrams 3).
Installation Note: The inlet fitting is designed to enter a compression fitting only. DO NOT use push
Fit connectors as full engagement cannot be guaranteed. DO NOT use excessive force when making
these connections.
Installation Note: If installing a water feed pipe from the back, the use of a soldered Elbow
Connector is recommended. It should be positioned approximately 87mm from the inlet connector
centre. The centre of the inlet connector to the wall surface is 21mm.
IMPORTANT: The inlet
fitting MUST be used in the
Bottom fitting position for
Rear fitting. Under NO
circumstances must the
Inlet be rotated 90° and the
pipe fitted directly.
The shower has not been
designed for this method
of connection.
BOTTOM ENTRY REAR ENTRY
DISCARD
THIS
PART
REFIT THIS
SECTION
DISCARD
THIS
PART
REFIT THIS
SECTION
TOP ENTRY
Diagrams 3

7
87 mm
21 mm
Diagram 4
If you are replacing an earlier model of the
Redring Selectronic you will need to remove
the appropriate backplate section subject to
whether the mains water plumbing approach
is either top or bottom entry. See Diagram 2
- Options ‘A’ or ‘B’.
For surface mounted Top entry for plumbing
remove and discard section ‘C’ and for the
Bottom entry option do likewise with section
‘D’.
Make sure the backplate is square on the wall
and tighten the retaining screws which hold it
to the wall.
Turn ON the mains water supply and check for
leaks in the pipework connection to the
shower.
Note: At this stage no water can flow through
the unit.
IMPORTANT: Using a suitable sealant,
always seal around the incoming pipework
through the wall to prevent water entering
the wall.
WARNING! The outlet of the shower
acts as a vent and MUST NOT be
connected to anything other than the
Hose and Showerhead supplied or
approved by the manufacturer
Electrical Connections
The electrical installation must be in accord-
ance with the current BS7671 (I.E.T. wiring
regulations) and “Part P” of the Building
Regulations and/or local regulations.
The unit is designed for a single phase 50 Hz
a.c. electrical supply.
Please check the rating plate on the unit to
see what details apply to your unit.
A means for disconnection in all poles must
be incorporated in the fixed wiring in accord-
ance with the wiring rules. We recommend
ceiling switches.
The cable size required is determined by the
kW rating of the shower and the distance
between the shower and the consumer unit.
The table on Page 8 is for guidance only in
choosing the correct cable for your installation.
I
If on installation it is the intention to use YT2
conduit trunking to conceal the surface
electrical cable to either the Top or Bottom
TRIAC
COOLER
FLOW
TRANSDUCER
INLET
THERMISTOR
STEPPER
MOTOR
L
E
N
SOLENOID
TRIAC PCB
UMBILICAL
STEP FLOW
TRIAC IN OUT
TEMPS
POWER
OUTLET
THERMISTOR
HEAT EXCHANGER
Wiring Diagram

Diagram 5
E
F
G
Installed in an
insulated wall
In conduit
trunking
Clipped direct
or buried in a
non-insulated
wall
6 mm
32A
10 mm
43A
16 mm
57A
I
I
2
2
2
6 mm
38A
10 mm
52A
16 mm
69A
I
I
2
2
2
6 mm
46A
10 mm
63A
16 mm
85A
I
I
2
2
2
Twin and earth PVC insulated cable
Current carrying capacity
8.5kW
9.5kW
10.8kW
I
I
40A
40/45A
45A
I
I
45A
45A
45A
I
I
Unit
Rating
MCB Cartridge
Fuse
CIRCUIT PROTECTION
Note: Cable selection is dependent on derating
factors
8
entry points then the following backplate
component will need to be discarded allowing
for the conduit to fit into the backplate. See
Diagram 5 - Option ‘E’ or ‘F’.
If the installation requires the use of 10mm²
cable up through the Bottom Entry option, then
you will need to remove the appropriate
backplate section ‘G’ shown in Diagram 5.
(*See limitations on 16mm² on Page 9).
Rear cable entry is permissible within the
service channel area “H” shown in diagram 5.
The position will be dependent on the chosen
water entry.
The cable connected to the appliance must be
fixed wiring, and should be stripped back as
shown in Diagram 7
Connect the cable to the terminal block.
Ensure that all the retaining screws are VERY
tight and that no cable insulation is trapped
under the screws.
Warning! Failure To Comply With
These Instructions Could Result In
A Failure Of The Terminal Block.
Warning! This Appliance Must Be
Earthed
Replace the
trimplate section complete with seal.
inlet cover and side access
Diagram 6
H
*
**

Changing ‘DIP Switch’ Default Setting
On the PCB in the upper right corner there is a set of 6 ‘DIP Switches’ (See
NOT TO BE CHANGED they are used for the shower software configuration.
Diagram 9) The top 3 are
WARNING! Switch OFF the electricity at the isolating switch before removing the cover.
9
10mm
55mm
EARTH
LIVE
NEUTRAL
FIT EARTHING SLEEVE
Diagram 7
IMPORTANT Connect flying lead from PCB
to rear of the front cover - see
Remember to select mode and configure
before, replacing the front cover and fastening
in position with four screws.
Diagram 6.
Changing The Operating Mode
Templock/Normal
On the extreme right hand side of the PCB
mid way up is the ‘4 Way Temp Limit Slider
Switch’ (See Diagram 8).
PLEASE NOTE! The Selectronic Premier is
factory set with the ‘Temp Limit Slider Switch’
set at ‘Locked Position 1’.
After the unit is commissioned, you have the
option of choosing from any of three different
lockable temperature settings plus normal
operation position from left to right.
Remove the front cover taking care not to strain
the flying lead.
Change the switch to the desired temperature
control position.
WARNING! Switch OFF the electricity
at the isolating switch before removing
the cover.
Replace and refasten the front cover.
Switch on electricity. Check that the unit operates correctly.
PLEASE NOTE! The Temperature Lock light on the front cover of the shower will not illuminate if
Normal Position 4 has been selected.
Locked Position 1
(Extreme Left)
Unlocked Position 4
(Extreme Right)
Temperature
Adjustment Range
34-40 C Nominal°25-46 C°Nominal
Locked Position 2
(First ‘Click’ from
the Extreme Left)
Locked Position 3
(Second ‘Click’ from
the Extreme Left)
34-41 C°Nominal 34-43 C°Nominal
Diagram 8
LOCKED
POSITION
’1’
LOCKED
POSITION
’2’
LOCKED
POSITION
’3’
UNLOCKED
POSITION
’4’
(For Top and Bottom entry : If 16mm² is
required, then use 10mm² just for the last link
from the Local isolator to the Shower).
Note : Ref 16mm² cable: 16mm² cable can only be installed via rear entry method.
*

10
The lower 3 are ‘Shower Control Feature Setting Options’ and can be set to suit the requirements of
the user. The function and options for each ‘DIP Switch’ are shown below:-
PLEASE NOTE! The Selectronic Premier is
factory set with the ‘DIP Switch’ set as follows:-
4 at ‘0’ (Fixed Flow)
5 at ‘0’ (Preset Start-Up)
6 at ‘0’ (Flow Limited to 6 l/m Max).
DIP 4:- This is used to select “Eco Power
Save”.
Fixed Flow =
With the ‘DIP Switch’ pushed to the
left the shower will save power. As the
temperature is reduced, the shower
will use less power (Eco Power ON).
Maximise Flow =
When the ‘DIP Switch’ is pushed to the
right the shower will use maximum
power at all temperature settings (Eco
Power OFF).
DIP 5:- Preset Start-up =
With the ‘DIP Switch’ pushed to the
left the shower will start up at a preset
temperature every time it is used.
The start up temperature depends on
The setting of the ‘Temp Lock Switch’.
a) When set to 1the start up = 40°C Nominal (Digit 5 on front cover display)
b) When set to 2the start up = 41°C Nominal (Digit 6 on front cover display)
c) When set to 3the start up = 43°C Nominal (Digit 8 on front cover display)
d) When set to 4the start up = 41°C Nominal (Digit 6 on front cover display)
Previous Setting =
With the ‘DIP Switch’ is pushed to the right the shower will start up at the same temperature
as the last time the shower was used. E.g. If the shower was set to Digit 4 (39°C) when it was
switched off, then it will start up at Digit 4 the next time it is used.
DIP 6:- This is used to select “Eco Water Save”
Flow Limited to 6 l/m (Litres / Minute) max =
When the ‘DIP Switch’ is pushed to the left the shower will prevent high water flow rates.
The shower will not supply water at a flow rate greater than 6 l/m (Eco Water Save ON)
Temperature unaffected. This selection meets the ‘Sustainable Home’ water consumption
requirement per person for showering.
Flow Limited to 9 l/m (Litres / Minute) max =
When the ‘DIP Switch’ is pushed to the right the shower does not restrict the flow rate.
The shower is capable of supplying water at a flow rate greater than 6 l/m ‘DIP Switch’ (Eco
Water Save OFF).
I
I
I
Position ‘0’
(Switch to the Left)
Position ‘1’
(Switch to the Right)
DIP 4: Flow Optimiser Switch
DIP 5: Start-Up Temperature Setting
DIP 6: Maximum Flow Limiter Flow Limited to 6 l/m max Flow Limited to 9 l/m max
Fixed Flow
Preset Start-Up
Maximise Flow
Previous Setting
Diagram 9
ON
456
123
X

11
Diagram 10
Diagram 11
Diagram 12
Commissioning
Ensure the water and electricity are switched
on to the unit.
Press and hold the Cooler button until
confirmed with one audible short bleep.
See Diagram 10
The digital display will illuminate with a capital
“C”. See Diagram 11
If the button does not respond, ensure that the
flying lead from the PCB has been connected
to the front cover. See Diagram 6
Allow the unit to fill and wait for the water to
come out of the handset then press the
Stop/Start button turning the shower OFF
(Confirm with three audible short bleeps).
See Diagram 12
Re-start - Press Start /Stop Button in the
centre. (Confirmed with a single bleep)See
Diagram 13
Check that the outlet temperature increases to
a comfortable temperature.
Check for leaks.
Press START/STOP button to switch the unit
OFF (Confirm with three audible short
bleeps).See Diagram 12
This completes the commissioning.
1
Audible Short
Bleep
Audible Short
Bleep
1
Audible Short
Bleeps
3
IMPORTANT! This appliance is not intended for use by persons (including
children and the infirm) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their
safety.
Children should be supervised to ensure that they do not play with the appliance.
I
Warning! Do Not Switch The Shower On If You Suspect It Of Being Frozen,
Wait Until You Are Sure That It Has Been Completely Thawed Out.
IMPORTANT NOTE! Always use the
Start/Stop button to switch the shower
OFF.
If the ceiling isolator is used to stop the
shower running, without first pressing the
Stop button, then the shower may go into
Over Temperature Shutdown the next time it
is used.
I

How To Use Your Shower
Warmer
Cooler
Start/Stop
Temperature
Temperature
Lock
Selectronic
Premier
Temperature
Lock Light
Warmer
Cooler
Start / Stop
To Switch The Shower On :
Switch On Electricity at ceiling / isolating switch.
Press the Start / Stop button. (Confirmed with a single bleep). (See Diagram 13).
The shower will start and display the target running temperature for about two
seconds. An internal motor will also adjust to give the optimal flow rate.
Note The target start up temperature is set by the installer. (See Installer section).
This is normally 40°C (Digit 5), with adjustment being 34°C to 40°C (Digit 1 to 5).
After two seconds the Display will change to show the actual temperature (usually “L”).
The digit will flash and increase until the Display reaches the target running temp.
When the shower has reached the target temperature it stops flashing.
A double bleep will sound, indicating the shower is ready to use.
(The shower will only double bleep once per shower session).
To Change The Shower Temperature :
Press the Warmer Button to increase
the temperature. (See Diagram 14).
(Confirmation with a Single Bleep).
Audible Short
Bleep
1
Diagram 13
12
Diagram 14
Audible Short
Bleep
1

Diagram 15
Audible Short
Bleep
1
13
Always wait for afew seconds for the temperature to change to the new setting.
Press the Cooler Button to decrease the
temperature. (See Diagram 15).
(Confirmed with a Single bleep).
Pressing the Warmer Button when the
temperature is at Maximum will not
increase the temperature.
Four rapid Bleeps will sound.
(See Diagram 16).
Diagram 16
Audible Short
Bleep
4
Diagram 17
Audible Short
Bleep
4
Pressing the Cooler Button when the
temperature is at Minimum will not
decrease the temperature.
Four rapid Bleeps will sound.
(See Diagram 17).
Please Note!
The temperature adjustment range is set by the installer. (See Installer section).
When there is a limit to the adjustment, the “Temperature Lock” light is ON.
In the “Unlocked” setting there are eleven temperature options:-
L-1-2-3-4-5-6-7-8-9-H (Where L is about 25°C and H is about 46°C).

14
Diagram 19
Diagram 18
Audible Short
Bleeps
3
To Switch the Shower Off :
To switch the shower off, press the
Start /Stop button. (Confirmed with 3
short bleeps).
(See Diagram 18).
IMPORTANT NOTE! Always use the
Start/Stop button to switch the shower
OFF.
The water will continue to run for a few
seconds to cool down for the next
shower.
The display will scroll round (see
Diagram 19). The shower will then
switch off automatically.
Switch Off at ceiling / isolating switch.
IMPORTANT NOTE! Always use the Start / Stop button to switch the
shower OFF.
If the ceiling isolator is used to stop the shower running, without first pressing the
Stop button, then the shower may go into Over Temperature Shutdown the next
time it is used.
Over Temperature Shutdown
If an abnormal condition occurs which causes the water to get too hot.
Diagram 20
Audible Short Bleeps
8
The unit will automatically shutdown
straight away and the water will
stop flowing. This is to prevent any
hot water coming out of the handset.
This is indicated by 8 short bleeps
and the display flashing a lowercase
“o” and then “t” (see Diagram 20).
This will continue until the water is at a
safe temperature. The unit will then
switch off automatically and will need
to be restarted in the normal way (see
“normal operation” section).

Diagram 22
Diagram 21
Audible Short
Bleeps
3
It can take a long time for the unit to reach a safe temperature. To speed this
temperature reduction up, the hot water can be purged from the unit.
Purging
While the unit is in “O” (Over) “t”
(Temperature) shutdown mode. Press the
cooler button for more than 3 seconds.
(See Diagram 21)
This will switch the water on ONLY while
the button is pressed.
Caution!!
Water Will Be Hot stand clear of the spray
from the handset.
Keep pressing the button the unit will then
switch off automatically with 3 short bleeps
when a safe water temperature has been
reached.
Temperature Lock Operation
This mode is selected on installation to
prevent the temperature being set too Hot
or too Cold. See section in ‘Changing the
Operating Mode’ Page 9.
All the controls are the same as previously
described.
However, the Warmer and Cooler
adjustment is Locked to the digit range
(Shown in table on Page 9) and the
temperature lock light will come on (See
Diagram 22).
Automatic Switch Off
With temperature lock selected, the
shower will automatically switch off after
30 minutes.
Near the end of the 30 minutes the shower
will bleep several times and the display will
change to “t” (See Diagram 23).
In order to stop the shower automatically
switching off, press either the warmer or
cooler button.
Diagram 23
15

16
Diagram 24
Temperature Lock Override
Note: For Care Wash installations the
Temperature Lock Switch MUST be set to
ON (Templock Position 1 or 2) and must
not be overridden.
The temperature lock feature can be
overridden, while the shower is running,
by pressing the warmer and cooler
buttons together for more than three
seconds (See Diagram 24).
The shower will revert back to normal
operation (Unlocked).
However, it will return to temperature lock
mode the next time it is used.
START/STOP
BUTTON
DIGITAL
TEMPERATURE
RANGE
DISPLAY
TEMPERATURE
LOCK
INDICATOR
TEMPERATURE
CONTROL
BUTTONS
Warmer
Cooler
Start/Stop
Temperature
Temperature
Lock
Selectronic
Premier
How Your Shower Works
1. Water is heated instantaneously
as it flows over the heaters in the
heat exchanger assembly.
2. The thermostatic shower auto-
matically adjusts the power to the
heating elements and flow of
water to achieve the selected
water temperature. The electron-
ics senses the incoming water
temperature and the flow of water
through the heat exchanger.
It then works out how many
heaters to switch on so that the
shower temperature matches the
temperature selected by the
buttons.
3. The amount of hot water available
at the selected temperature is
limited by the total power of the
heater. The ideal flow rate is
calculated and adjusted
automatically.
4. The water is turned on and off by
the solenoid valve built into the
Shower.

17
5. A stabiliser is built into the flow
valve to automatically compensate
for small fluctuations in water
pressure that frequently occur in
households.
There are three further controls to
cater for exceptional reductions in
water pressure to prevent the
shower from getting too hot.
a) If the flow of water is less than
1.0 l/min the power to the
elements is switched off, but the
solenoid valve remains open
allowing water to flow through
the shower.
b) If the outlet temperature sensor
senses an excessive
temperature the flow of water
and the heating elements will
automatically switch off. The
electronics will signal over
Temperature condition (see
“over temperature shutdown”
section).
c) A two stage mechanical thermal
cut-out is mounted on the top of
the heat exchanger independent
of the electronics.
Stage one switches the power
off to the elements if it senses
an excessive temperature.
The switch operates with an
audible click and will reset if
cold water is run through the
shower.
Stage two only operates if an
extreme temperature is sensed.
The cut out will permanently
switch off and it will then have
to be replaced.
Manufacturer
Glen Dimplex
Product
RSELP85S
RSELP85P
RSELP85WPC
RSELP95S
RSELP95P
RSELP95WPC
RSELP108S
RSELP108P
Load profile
XS
XS
XS
Efficiency Class
A
A
A
Efficiency %
37
37
37
Consumption
(kWh \ annum)
495
488
489
Thermostat
Setting (°C)
40
40
40
Sound (dB)
15
15
15
Precautions
Follow all product installation, care and maintenance
instructions as listed in this “instruction / installation”
manual
This information shows how our products pass the relevant european union energy
directives (ErP).
ENERGY RELATED PRODUCT DIRECTIVE (ErP)
ENSURE POWER IS OFF BEFORE REMOVING COVER.
REPLACE THIS COVER PRIOR TO FITTING THE FRONT COVER.
WARNING
WARNING
THIS
PRODUCT
MUST BE
EARTHED
TERMINAL
BLOCK
TEMPLOCK
SWITCH
SOLENOID
VALVE
INLET
COVER
POWER
PCB
BRASS
COOLER
MOTOR
FLOW
TRANSDUCER
FLOW
VALVE
OUTLET
TEMP
SENSOR
OUTLET
HEAT
EXCHANGER
LOGIC
PCB
DIP
SWITCH
THERMAL
CUTOUT

18
Routine Maintenance
Handset:-
In Order To Maintain The Performance Of Your Shower You Must
Clean The Shower Head Regularly.
All water contains particles of lime-scale, which build up in the
showerhead and unit reducing the performance.
It is therefore important to clean the showerhead by simply rubbing the
rubber nozzles or soaking in proprietary lime-scale remover and rinsing
thoroughly before use.
The frequency of this will vary from weekly to quarterly depending on the
water hardness and experience.
In some winter conditions, when the incoming mains water is particularly
cold it may be necessary to select the inner or outer spray pattern only;
this will ensure correct operation of the shower with a slightly lower water
flow rate.
After use it is normal for some water to drip from the spray head for a few
moments. This helps prevent scale build up over prolonged use.
Shower Accessories :-
It is recommend that as well as checking the showerhead as detailed
above, the shower unit, riser rail, hose etc. be cleaned using a soft cloth
and that the use of abrasive or solvent based cleaning fluid be avoided,
especially on any plated finishes.
We recommend that before any cleaning, the isolating switch be turned off,
thus avoiding accidentally switching on the shower.
You Must Regularly Inspect The Shower Hose For Wear And Damage.
Replace If Necessary, Or Every Two Years, With Our Approved Part.
Diagram 25
THE SHOWER IS DESIGNED AND
APPROVED TO EN-60335 WITH THE
HANDSET PROVIDED.
UNDER NO CIRCUMSTANCES MUST ANY
HANDSET THAT IS NOT APPROVED BY
THE MANUFACTURER BE USED WITH
THIS PRODUCT.
Periodical Maintenance
If scale deposits are
stubborn, soak the shower
head in proprietary
limescale remover and rinse
thoroughly before use.
Daily Cleaning
To break away scale on a
daily bases, rub your thumb
over the surface whilst the
shower is running.
Handset Operation
There are five defined spray plate setting modes (patterns) adjustable by rotating the spray plate
(see Diagram 25).
These modes (patterns) have a positive click to identify them.
The spray plate rotates through a limited travel and changes spray pattern with every click.
So you can choose your favourite setting to enhance your shower experience.

19
Periodical Maintenance
Cleaning the Filter
It is recommended that the filter is periodically
cleaned in order to maintain the performance
of the shower. It is essential that this operation
is carried out by a competent person.
The inlet filter is situated inside the water inlet
fitting (See Diagram 26).
To gain access to the filter remove the cover
and right hand trim plate. When removing the
cover be careful that you DO NOT tug the
flying lead from the PCB which is attached to
the cover. Disconnect the flying lead from
the reverse of the front cover.
Holding the filter body with a spanner across
the flats, unscrew the top cap on the water
inlet fitting using another spanner.
Inspect the ‘O’ rings on the filter body for any
damage when removed from the inlet assembly.
When cleaning the filter, DO NOT use a sharp
object, as it will cause damage. It is preferable
to use an old toothbrush or similar
Do not remove the filter mesh from the body
and clean whilst still in position.
Refit the filter making sure it is screwed fully
home. Do not over tighten the filter cap on
reassembly.
WARNING! Switch OFF the electricity at
the isolating switch and the water supply
at the mains before removing the cover.
Diagram 26
Troubleshooting
If the performance of the shower deteriorates in service, follow the checks in the “Self Help” table
below before calling out the contractor.
Any one of the simple adjustments could restore the performance.
If these fail to restore the performance you should seek professional help.
The person who installed the shower is probably the best one to repair it and is certainly the person
to contact if you have a problem in the guarantee period.
I
I
SELF HELP CHECK LIST
a) Water too HOT
b) Water too COLD
c) Spray pattern poor
I
I
Press the cooler button.
Clean spray plate holes on showerhead.
Press the warmer button (See Page 9 For allowed
adjustment range) .
Clean spray plate. Select Outer/Inner only.
I
I

20
d) Display behaves erratically.
e) Water does not flow when START/STOP
button is pressed.
Lights ON.
“o” and “t” flashing in display.
No lights.
f) Warmer/Cooler buttons do not function.
g) Unit makes a whirring noise, especially
at the start of the shower session.
I
I
I
I
I
I
I
Switch OFF electricity at ceiling/wall isolating switch,
wait a few seconds, switch on again.
(Note: The shower should be switched OFF each
time after use at the ceiling/wall isolating switch.
Note: If there is no water flowing then the shower will
automatically switch OFF after about 5 seconds.
Check the water supply is turned ON.
Unit in over temperature mode see section on “purging”.
Check ceiling/wall isolating switch is ON.
Check power is ON.
Temperature range may be limited by Temp/Lock setting
(See Page 9)
This is normal.
There is a motor inside the shower used to adjust the
flow and this always operates at the start of each shower.
I
I
I
I
I
I
PROFESSIONAL SERVICE CHECK LIST
This additional checklist is provided for the benefit of the qualified service representative.
WARNING! Switch Off The Electricity At The Isolator Before Removing The Front Cover To
Make Checks.
a) Poor temperature control.
b) Water too COLD
c) Poor or no control over water flow.
d) No water when START/STOP button is
pressed.
e) Unit has been switched OFF using
START/STOP button but can be heard
heating the water.
I
I
I
I
I
Check inlet/outlet thermistors to see if they are in circuit.
Check for blockage in the inlet filter.
Check circuit through thermal cut-out.
Check circuit through all heating elements.
Test should be done using a low voltage resistance
meter whilst the power is switched OFF at the isolating
switch.
Check working voltage.
Replace inlet valve assembly.
Check water supply. Check circuit through solenoid coil.
If OK replace logic PCB.
Replace triac PCB.
I
I
I
I
I
f ) Temperature buttons have a limited
adjustment range.
g) Shower runs for about 5 seconds and
then switches OFF by itself.
I
I
Unit is in Temp/Lock mode. Remove cover and change
position of templock switch to ‘4’ (see Diagram 8 for
location) or explain feature to user.
Note: For Care Wash installations the Temperature Lock
Switch MUST be set to 1 or 2.
Flow transducer fault.
Check that internal blade “spins” when the water flows:
If not, replace transducer.
I
I
BEAB Care Wash Scheme
Note: For Care Wash Installations the Temperature Lock Switch
MUST be set to either 1or 2.
I
I
For those installations where the BEAB Care Wash Scheme is required please refer to separate
handbook “Commissioning, In Service Testing and Maintenance of the Selectronic Shower for
BEAB Care Wash Schemes.
