red roo HLS Operating instructions

OPERATING INSTRUCTIONS FOR HLS USER
Familiarise yourself with the hydraulic log splitter and its
controls.
Wear safety glasses, or helmet visor combination, loose
tting gloves, hearing protection and safety work boots.
PPE (Personal Protection
Equipment) is mandatory
before operating this machine.
ALWAYS make certain that all control levers are in the
disengage position prior to starting the engine.
Disconnect the retaining pin from the headstock and lower
the lifting table onto the lifting frame.
DO NOT allow by-standers near the hydraulic
logsplitter while in operation. OPERATING THIS
MACHINE IS A SINGLE PERSON OPERATION.
It is the responsibility of the operator to keep
bystanders and animals a minimum of 6 metres (18 feet)
away from the hydraulic log splitter while in operation.
Open fuel shut off valve, if engine is equipped.
Move choke control to CHOKE or START position.
Note: Choke must be fully closed. Move throttle
control to RUN or FAST position. If engine is equipped
with rocker style stop switch, push RUN or I (I = Ignition)
before starting. Rewind Starter: Grasp rope handle and
pull slowly until resistance is felt to prevent kickback. Then
pull cord rapidly to overcome
compression and start engine.
Repeat if necessary with choke
off and throttle control in FAST
position. Operate engine in fast
position.
Place or roll log / wood onto lifting table (DO NOT EXCEED
250KGS/550LBS).
Lift the log / wood and roll the log / wood between the head
stock and the splitting head. NEVER have your hands or
ngers between the log / wood and the splitting head or
head stock.
NEVER place your hands or ngers
between the end of the log / wood and the
headstock. (See inside reference photo).
NEVER place your hands or ngers between the end of the
log / wood and the splitting head.
NEVER position the log by placing your hands or ngers at
the ends of the log / wood.
Position the log by placing a hand on the top of the log /
wood as close to the centre of the log / wood as possible.
NEVER have your hands or ngers close to the headstock
or splitting head while the machine is in operation.
REMEMBER OPERATING THIS MACHINE IS A SINGLE
PERSON OPERATION. Keep all bystanders a minimum of
6 metres (18 feet) away.
ALWAYS position the log / wood to split with the grain of the
log / wood.
When splitting wood always operate the hydraulic logsplitter
in front of the axle on the hydraulic valve side of the main
beam only. Use caution whilst standing in this position as
certain logs / wood can spring back under tension, and exit
from the hydraulic logsplitter with force.
Engage the splitting head control lever until it comes in
contact with the log / wood. Slowly ease the splitting head
into the log / wood. Do not try to force the split. Once the
log / wood is secured between the splitting head and head
stock remove your hand from the top centre of the log / wood
and proceed to split. NEVER PLACE YOUR HANDS OR
FINGERS AT THE END OF THE LOG / WOOD.
SPLIT WOOD IN THE DIRECTION OF THE GRAIN ONLY.
Log / Wood to be split should be cut as squarely as possible.
NEVER attempt to load the hydraulic log splitter when the
ram is in motion.
NEVER straddle or climb over the hydraulic log
splitter while in use.
NEVER insert hands or ngers into the cracks
of the log / wood during the splitting procedure.
Once the log / wood has been split return the
splitting head clear all debris and repeat the procedure
STOP ENGINE: Do not move choke control to Choke
position to stop engine. Backre or engine damage may
occur. Move throttle control to SLOW
position, then push rocker switch to O
(STOP), or turn key to off if equipped.
AFTER USE
Turn fuel tap to “OFF” position
Allow machine to cool down (minimum 5 minutes)
Clean with warm soapy water. Ensure no water
enters the carburettor.
SAFETYPRECAUTIONS
AND OPERATING
INSTRUCTIONS
™
GT5
GARDEN
TILLER
OPERATION OF GT622
1) Remove the garden tiller
from its trailer/carrier/ute. Use caution.
2) Familiarize yourself with the machine and its
controls.
5) Ensure the tyne engagement control lever is in
the neutral position. The tyne engagement
control lever is located
machine below handle bar. The neutral position
on the left hand side of the
of the lever is achieved by simply releasing the
tyne engagement control lever.
4)
3) Adjust wheels if required, using the handle wheel
adjustment lever.
Adjust depth shoe if required, using the depth
control adjustment lever.
6) Open fuel shut-off valve. Set choke
control to Choke or Start position.
Set throttle control to Run or Fast
position. Set engine
stop switch to On or
Run position. Pull
starter cord rapidly.
Repeat (if necessary)
with choke off.
pull up on the tyne engagement control lever.
The tynes will begin to turn. Release the tyne
7) Wheninposition to begingarden tilling,
engagement control lever to stop the tynes turning.
Tyne speed is governed by engine throttle setting.
WARNING! –KEEPHANDSAND
FEET CLEAR OF TYNES AT ALL
TIMES!
8) Do not hurry the job. Proceed slowly and allow
the machine time to do the job. When ground
is extremely hard, reduce engine speed. Consider
watering the surface and reducing engine speed.
Adjust wheels and depth shoe accordingly while
tilling
WARNING! –IN CASE OF DIFFICULTY,
RELEASE THE TYNE ENGAGEMENT
CONTROL LEVER. ALL TILLING ACTION
STOPS.Turn the engine "STOP" switch
to off located on the engine.
9) Stop Engine: Release the tyne engagement
control lever. Move throttle to Slow position.
Set engine stop switch to Stop or Off position.
DO NOT move choke
position to stop engine.
Backfire or engine
damage may occur.
AFTER USE
1) Turn fuelshut off valve to the "OFF"
position.
2) Allow machine to cool down.
3) Wash mud and dirt off of the garden tiller.
Ensure no water enters the carburettor.
4) Removeanyweeds,wire,rope or other
material thatmayhavewrappedaround the
tynes and rotor assembly.
5) Returnwheels and depth control handle to
transport position.
© Copyright 2012, Red Roo Sales & Service Company Pty. Ltd. 1301-0069-A
Commer
“The Right Way to Rent” cial Outdoor Power Equipment
control to Choke or Start
You alone know the operational demands and
special conditions affecting the equipment in
your situation and therefore assume the
responsibility for developing, carrying out, and
enforcing the safety concepts which apply to your
own operation to effect the greatest safety for
yourself andthe people around you.
SAFETYPRECAUTIONS
AND OPERATING
INSTRUCTIONS
™
GT622
GARDEN
TILLER
OPERATION
1) Remove the garden tiller
from its trailer/carrier. Use caution.
2) Familiarize yourself with the machine and its
controls.
3) Ensure the safety clutch control lever is in the
disengagedposition. The safety clutch
control lever is located on the left handle bar.
The disengaged position of the lever is down.
4) Remove the shaft locking pin located behind
the wheel axle. Store pin in hole provided on
left hand side of handle bar.
5) The wheel axle will now pivot. Lift up on the
handle to allowwheelaxle to pivot. For
transport, keep the wheel axle forward. When
cultivating, keep the wheel axle rearward for
added stability and control.
DO NOT transport the tillerwith the wheel
axle in the rear position.
6) Adjust depth shoe(ifequipped) by removing
shaft locking collarand slidingdepth shoe to
desired position. Replace shaft locking collar.
7) Open fuel shut-off valve. Set choke
control to Choke or Start position.
Set throttle control to Run or Fast
position. Set engine
stop switch to On or
Run position. Pull
starter cord rapidly.
Repeat (if necessary)
with choke off.
8) Wheninposition to begingarden tilling,
engage the safety clutch controllever. The
tyneswillbeginrotating. Wheel axle must be in
the rearpositionwhile tilling.Release the
safety clutch controllever to stop the tynes
rotating. Tynespeed is governed by engine
throttle setting.
WARNING! –KEEPHANDSAND
FEET CLEAR OF TYNES AT ALL
TIMES!
9) Do not hurry the job. Proceed slowly and allow
the machine time to do the job. When ground
is extremely hard, reduce engine speed.
WARNING! –IN CASE OF DIFFICULTY,
DISENGAGE THE SAFETY CLUTCH
CONTROL LEVER. ALL TILLING ACTION
STOPS.Press the engine"STOP"button
located on the engine.
10) Stop Engine: Release the safety clutch control
lever.Move throttle to Slowposition. Set engine
stop switch to Stop or Offposition.DO NOT move
choke control to Choke
or Start position to stop
engine.Backfire or
enginedamagemay
occur.
AFTER USE
1) Turn fuelshut off valve to the "OFF"
position.
2) Allow machine to cool down.
3) Wash mud and dirt off of the garden tiller.
Ensure no water enters the carburettor.
4) Removeanyweeds,wire,rope or other
material thatmayhavewrappedaround the
tynes and rotor assembly.
5) Returnwheelaxle to forwardposition for
transport. Replace shaft locking collar.
6) Returndepth shoe(ifequipped) to full Up
position.
© Copyright 2001, Red Roo Sales & Service Company Pty. Ltd. 1301-0018
Commercial Environmental Equipment
SAFETYPRECAUTIONS
AND OPERATING
INSTRUCTIONS
™
GT622
GARDEN
TILLER
OPERATION
1) Remove the garden tiller
from its trailer/carrier. Use caution.
2) Familiarize yourself with the machine and its
controls.
3) Ensure the safety clutch control lever is in the
disengagedposition. The safety clutch
control lever is located on the left handle bar.
The disengaged position of the lever is down.
4) Remove the shaft locking pin located behind
the wheel axle. Store pin in hole provided on
left hand side of handle bar.
5) The wheel axle will now pivot. Lift up on the
handle to allowwheelaxle to pivot. For
transport, keep the wheel axle forward. When
cultivating, keep the wheel axle rearward for
added stability and control.
DO NOT transport the tillerwith the wheel
axle in the rear position.
6) Adjust depth shoe(ifequipped) by removing
shaft locking collarand slidingdepth shoe to
desired position. Replace shaft locking collar.
7) Open fuel shut-off valve. Set choke
control to Choke or Start position.
Set throttle control to Run or Fast
position. Set engine
stop switch to On or
Run position. Pull
starter cord rapidly.
Repeat (if necessary)
with choke off.
8) Wheninposition to begingarden tilling,
engage the safety clutch controllever. The
tyneswillbeginrotating. Wheel axle must be in
the rearpositionwhile tilling.Release the
safety clutch controllever to stop the tynes
rotating. Tynespeed is governed by engine
throttle setting.
WARNING! –KEEPHANDSAND
FEET CLEAR OF TYNES AT ALL
TIMES!
9) Do not hurry the job. Proceed slowly and allow
the machine time to do the job. When ground
is extremely hard, reduce engine speed.
WARNING! –IN CASE OF DIFFICULTY,
DISENGAGE THE SAFETY CLUTCH
CONTROL LEVER. ALL TILLING ACTION
STOPS.Press the engine"STOP"button
located on the engine.
10) Stop Engine: Release the safety clutch control
lever.Move throttle to Slowposition. Set engine
stop switch to Stop or Offposition.DO NOT move
choke control to Choke
or Start position to stop
engine.Backfire or
enginedamagemay
occur.
AFTER USE
1) Turn fuelshut off valve to the "OFF"
position.
2) Allow machine to cool down.
3) Wash mud and dirt off of the garden tiller.
Ensure no water enters the carburettor.
4) Removeanyweeds,wire,rope or other
material thatmayhavewrappedaround the
tynes and rotor assembly.
5) Returnwheelaxle to forwardposition for
transport. Replace shaft locking collar.
6) Returndepth shoe(ifequipped) to full Up
position.
© Copyright 2001, Red Roo Sales & Service Company Pty. Ltd. 1301-0018
Commercial Environmental Equipment
SAFETYPRECAUTIONS
AND OPERATING
INSTRUCTIONS
™
GT622
GARDEN
TILLER
OPERATION
1) Remove the garden tiller
from its trailer/carrier. Use caution.
2) Familiarize yourself with the machine and its
controls.
3) Ensure the safety clutch control lever is in the
disengagedposition. The safety clutch
control lever is located on the left handle bar.
The disengaged position of the lever is down.
4) Remove the shaft locking pin located behind
the wheel axle. Store pin in hole provided on
left hand side of handle bar.
5) The wheel axle will now pivot. Lift up on the
handle to allowwheelaxle to pivot. For
transport, keep the wheel axle forward. When
cultivating, keep the wheel axle rearward for
added stability and control.
DO NOT transport the tillerwith the wheel
axle in the rear position.
6) Adjust depth shoe(ifequipped) by removing
shaft locking collarand slidingdepth shoe to
desired position. Replace shaft locking collar.
7) Open fuel shut-off valve. Set choke
control to Choke or Start position.
Set throttle control to Run or Fast
position. Set engine
stop switch to On or
Run position. Pull
starter cord rapidly.
Repeat (if necessary)
with choke off.
8) Wheninposition to begingarden tilling,
engage the safety clutch controllever. The
tyneswillbeginrotating. Wheel axle must be in
the rearpositionwhile tilling.Release the
safety clutch controllever to stop the tynes
rotating. Tynespeed is governed by engine
throttle setting.
WARNING! –KEEPHANDSAND
FEET CLEAR OF TYNES AT ALL
TIMES!
9) Do not hurry the job. Proceed slowly and allow
the machine time to do the job. When ground
is extremely hard, reduce engine speed.
WARNING! –IN CASE OF DIFFICULTY,
DISENGAGE THE SAFETY CLUTCH
CONTROL LEVER. ALL TILLING ACTION
STOPS.Press the engine"STOP"button
located on the engine.
10) Stop Engine: Release the safety clutch control
lever.Move throttle to Slowposition. Set engine
stop switch to Stop or Offposition.DO NOT move
choke control to Choke
or Start position to stop
engine.Backfire or
enginedamagemay
occur.
AFTER USE
1) Turn fuelshut off valve to the "OFF"
position.
2) Allow machine to cool down.
3) Wash mud and dirt off of the garden tiller.
Ensure no water enters the carburettor.
4) Removeanyweeds,wire,rope or other
material thatmayhavewrappedaround the
tynes and rotor assembly.
5) Returnwheelaxle to forwardposition for
transport. Replace shaft locking collar.
6) Returndepth shoe(ifequipped) to full Up
position.
© Copyright 2001, Red Roo Sales & Service Company Pty. Ltd. 1301-0018
Commercial Environmental Equipment
HLS
HYDRAULIC
LOG SPLITTER
SAFETY INSTRUCTIONS FOR RH918 USERS
OPERATING
INSTRUCTIONS
USE COMMON SENSE
AND PLENTY OF IT
TRANSPORT
BEFORE USE
1) DO NOT allow any person operate the
rotary hoe without first reading and
understanding the safety instructions and
operating instructions.
2) NEVER allow children to operate the rotary hoe.
8) ALWAYS make certain the Tyne Control Lever is
set at neutral while loading and unloading the
rotary hoe, or moving to and away from working area.
9) NEVER run the machine in reverse while the tynes
are rotating. Always move the tyne control lever to
“OFF” before reversing the wheels.
11) DO NOT leave the machine unattended while the
engine is running.
12) DO NOT overspeed the engine or alter the governor
settings. Excessive speed is dangerous and will
shorten engine life.
13) NEVER operate the rotary hoe in an
enclosed area. Engine exhaust contains
carbon monoxide, an odourless and
tasteless poison.
14) STOP the engine and disconnect the
spark plug lead(s) and allow engine to
cool before inspecting or performing
maintenance on the rotary hoe.
15)
1)
REFUELLING
* Shut off the engine. DO NOT REFUEL
AN ENGINE WHILE OPERATING!
* Allow engine to cool. Minimum 5 minutes
* USE UNLEADED FUEL ONLY.
Use clean, fresh unleaded fuel.
* Do not mix oil with unleaded fuel.
* Do not over-fill fuel tank. Allow space
for fuel expansion.
10) NEVER operate the unit without the safety
guards in place and in working order. Keep
the unit well maintained and in good
working order.
4) ALWAYS use the rotary
hoe in a well lighted area.
7) NEVER operate the rotary hoe when fatigued.
ALWAYS BE ALERT! If you get tired while
operating the rotary hoe, take a break. If you have
any type of physical or mental condition that may
be aggravated by strenuous work, consult with
your physician before you operate this equipment.
NEVER operate the rotary hoe under the influence
of medication, alcohol or drugs.
6) DO NOT allow other persons near the
rotary hoe. It is up to the operator to keep
bystanders and animals a minimum of 6
5) ALWAYS operate the rotary
hoe on level ground only.
Police the area before rotary
hoeing. Remove any foreign objects in the digging
area - bricks, rocks, wire and sticks. Locate and mark
any sprinkler heads, water pipes, gas lines,
electrical and telephone cables or any other hazard
either below or above ground.
3) ALWAYS wear protective clothing when operating
the rotary hoe. This includes, but is not limited to;
safety glasses, loose fitting gloves, steel capped
boots and hearing protection. NEVER wear loose
fitting clothing or jewellery when operating the
rotary hoe. Keep all clothing away from moving
parts. Items could become caught in the machine,
resulting in injury.
KNOW THE CONTROLS AND HOW TO STOP
THE ROTARY HOE QUICKLY IN AN EMERGENCY.
metres (20’) away from the machine while in
operation.
ALWAYS KEEP YOUR HANDS,
FEET AND BODY AWAY FROM
THE DIGGING ZONE WHILE
ENGINE IS RUNNING.
* Do not smoke.
* Allow no naked flame or hot material in refuelling area.
* Use only approved fuel containers and funnels.
Remember, fuel is a potential hazard .
Be sure Tyne Control Lever is set to “Neutral”
while loading and unloading the rotary hoe
and when moving to or from jobsite.
Ensure that all grass and weeds have been cut
as low as possible.
2) If the rotary hoe is to be used in clay or hard
ground conditions, it is recommended to water
the area thoroughly and allow sufficient time
for earth to soften.
3) Police the area. Remove any
foreign objects from the area.
4) Identify and mark the location of sprinkler heads,
gas pipes, telephone cables etc.
“The Right Way to Rent”
You alone know the operational demands and
special conditions affecting the equipment in
your situation and therefore assume the
responsibility for developing, carrying out, and
enforcing the safety concepts which apply to your
own operation to effect the greatest safety for
yourself andthe people around you.
3)
a. Move the fuel valve
lever to ON
position. a. Put Wheel Drive Lever in neutral.
c. Have engine at full throttle (forward).
d. Hold Digging Chain Control Lever in On position.
e. Squeeze the safety Clutch Lever/Operator Presence Control.
f. Slowly lower the digging boom until the desired trench
depth is achieved using the Digging Boom Control Lever.
g. Put Wheel Drive Control Lever in reverse. Start at low speed.
h.
a.
Adjust the wheel speed until a workable speed is reached
Use a very slow speed for trenching and adjust for soil
conditions as necessary. If objects such as rocks or roots
jam in the chain, release the Safety Clutch Lever/Operator
Presence Control, then reverse the chain to dislodge the
debris. If necessary move the trencher forward a few
inches and trench the area again.
Shut off switch on
console should be
used, not shut off
switch on engine.
b. Turn the engine switch
to the OFF position.
c. Turn the fuel
valve lever to the
OFF position
1) Allow machine to cool down. Wash mud and dirt off of
the hydraulic trencher. Ensure no water enters the
carburettor
2) Remove any objects that may have wrapped around
the trencher chain or assembly.
b. Be sure both hubs are engaged (turn hub lock handle
clockwise). (See Free Wheel Hub Feature)
b. To start a cold
engine, move the
choke lever or choke
rod (applicable
types) to the
CLOSED
position.
To restart a
warm engine,
leave the choke lever or choke rod in the OPEN position.
c. Move the
throttle lever
away from the
MIN position,
about 1/3 of the
way toward the
MAX position.
d. Turning the engine switch
to the ON position.
RECOIL STARTER
Pull the starter grip lightly
until you feel resistance,
then pull briskly.
Return the starter
grip gently.
STARTING THE ENGINE: 5) TRENCHING PROCEDURE:
6) STOPPING THE ENGINE:
WARNING - KEEP HANDS AND FEET CLEAR
OF TRENCHING CHAIN AND OTHER MOVING
PARTS AT ALL TIMES!
WARNING! - In case of difficulty, release the
Safety Clutch Lever/Operator Presence Control
All trenching action stops. Turn the Engine
Stop button to STOP located either side on the
main control console or the engine.
4)
a. Start and warm up engine.
b. Put Wheel Drive Control Lever in neutral.
c. One wheel hub may be disengaged (free wheeling)
for easier steering before driving machine to work
loccation. (See Wheel Hub Feature)
d. Squeeze the safety Clutch Lever/Operator Presence
Control and change the Wheel Direction Control to
desired speed and direction.
e. Adjust the wheel speed and navigate the trencher to the
starting position. The trencher is designed to dig toward
the operator (with the Wheel drive Control Lever in
reverse). With this in mind, position the machine to
start the trench. Note: When initially engagaing the
rotating chain into the ground, be aware that in the hard or
rocky ground the rotating trencher chain may
aggressively dig in and lurch forward. For this reason
make sure that theres is sufficient clearance from
structures, objects or people in front of the machine.
AFTER USE
Make sure that there is sufficient clearance from
structures, objects or people in front of the machine
© Copyright 2013, Red Roo Sales & Service Company Pty. Ltd. 1301-0066-A
Move the throttle lever
to the MIN position.
Some engine applications use a
remote-mounted throttle control
rather than the engine-
mounted lever shown here
SAFETYPRECAUTIONS
AND OPERATING
INSTRUCTIONS
™
GT5
GARDEN
TILLER
OPERATION OF GT622
1) Remove the garden tiller
from its trailer/carrier/ute. Use caution.
2) Familiarize yourself with the machine and its
controls.
5) Ensure the tyne engagement control lever is in
the neutral position. The tyne engagement
control lever is located
machine below handle bar. The neutral position
on the left hand side of the
of the lever is achieved by simply releasing the
tyne engagement control lever.
4)
3) Adjust wheels if required, using the handle wheel
adjustment lever.
Adjust depth shoe if required, using the depth
control adjustment lever.
6) Open fuel shut-off valve. Set choke
control to Choke or Start position.
Set throttle control to Run or Fast
position. Set engine
stop switch to On or
Run position. Pull
starter cord rapidly.
Repeat (if necessary)
with choke off.
pull up on the tyne engagement control lever.
The tynes will begin to turn. Release the tyne
7) Wheninposition to begingarden tilling,
engagement control lever to stop the tynes turning.
Tyne speed is governed by engine throttle setting.
WARNING! –KEEPHANDSAND
FEET CLEAR OF TYNES AT ALL
TIMES!
8) Do not hurry the job. Proceed slowly and allow
the machine time to do the job. When ground
is extremely hard, reduce engine speed. Consider
watering the surface and reducing engine speed.
Adjust wheels and depth shoe accordingly while
tilling
WARNING! –IN CASE OF DIFFICULTY,
RELEASE THE TYNE ENGAGEMENT
CONTROL LEVER. ALL TILLING ACTION
STOPS.Turn the engine "STOP" switch
to off located on the engine.
9) Stop Engine: Release the tyne engagement
control lever. Move throttle to Slow position.
Set engine stop switch to Stop or Off position.
DO NOT move choke
position to stop engine.
Backfire or engine
damage may occur.
AFTER USE
1) Turn fuelshut off valve to the "OFF"
position.
2) Allow machine to cool down.
3) Wash mud and dirt off of the garden tiller.
Ensure no water enters the carburettor.
4) Removeanyweeds,wire,rope or other
material thatmayhavewrappedaround the
tynes and rotor assembly.
5) Returnwheels and depth control handle to
transport position.
© Copyright 2012, Red Roo Sales & Service Company Pty. Ltd. 1301-0069-A
Commer
“The Right Way to Rent” cial Outdoor Power Equipment
control to Choke or Start
You alone know the operational demands and
special conditions affecting the equipment in
your situation and therefore assume the
responsibility for developing, carrying out, and
enforcing the safety concepts which apply to your
own operation to effect the greatest safety for
yourself andthe people around you.
SAFETY INSTRUCTIONS FOR RH918 USERS
OPERATING
INSTRUCTIONS
USE COMMON SENSE
AND PLENTY OF IT
TRANSPORT
BEFORE USE
1) DO NOT allow any person operate the
rotary hoe without first reading and
understanding the safety instructions and
operating instructions.
2) NEVER allow children to operate the rotary hoe.
8) ALWAYS make certain the Tyne Control Lever is
set at neutral while loading and unloading the
rotary hoe, or moving to and away from working area.
9) NEVER run the machine in reverse while the tynes
are rotating. Always move the tyne control lever to
“OFF” before reversing the wheels.
11) DO NOT leave the machine unattended while the
engine is running.
12) DO NOT overspeed the engine or alter the governor
settings. Excessive speed is dangerous and will
shorten engine life.
13) NEVER operate the rotary hoe in an
enclosed area. Engine exhaust contains
carbon monoxide, an odourless and
tasteless poison.
14) STOP the engine and disconnect the
spark plug lead(s) and allow engine to
cool before inspecting or performing
maintenance on the rotary hoe.
15)
1)
REFUELLING
* Shut off the engine. DO NOT REFUEL
AN ENGINE WHILE OPERATING!
* Allow engine to cool. Minimum 5 minutes
* USE UNLEADED FUEL ONLY.
Use clean, fresh unleaded fuel.
* Do not mix oil with unleaded fuel.
* Do not over-fill fuel tank. Allow space
for fuel expansion.
10) NEVER operate the unit without the safety
guards in place and in working order. Keep
the unit well maintained and in good
working order.
4) ALWAYS use the rotary
hoe in a well lighted area.
7) NEVER operate the rotary hoe when fatigued.
ALWAYS BE ALERT! If you get tired while
operating the rotary hoe, take a break. If you have
any type of physical or mental condition that may
be aggravated by strenuous work, consult with
your physician before you operate this equipment.
NEVER operate the rotary hoe under the influence
of medication, alcohol or drugs.
6) DO NOT allow other persons near the
rotary hoe. It is up to the operator to keep
bystanders and animals a minimum of 6
5) ALWAYS operate the rotary
hoe on level ground only.
Police the area before rotary
hoeing. Remove any foreign objects in the digging
area - bricks, rocks, wire and sticks. Locate and mark
any sprinkler heads, water pipes, gas lines,
electrical and telephone cables or any other hazard
either below or above ground.
3) ALWAYS wear protective clothing when operating
the rotary hoe. This includes, but is not limited to;
safety glasses, loose fitting gloves, steel capped
boots and hearing protection. NEVER wear loose
fitting clothing or jewellery when operating the
rotary hoe. Keep all clothing away from moving
parts. Items could become caught in the machine,
resulting in injury.
KNOW THE CONTROLS AND HOW TO STOP
THE ROTARY HOE QUICKLY IN AN EMERGENCY.
metres (20’) away from the machine while in
operation.
ALWAYS KEEP YOUR HANDS,
FEET AND BODY AWAY FROM
THE DIGGING ZONE WHILE
ENGINE IS RUNNING.
* Do not smoke.
* Allow no naked flame or hot material in refuelling area.
* Use only approved fuel containers and funnels.
Remember, fuel is a potential hazard .
Be sure Tyne Control Lever is set to “Neutral”
while loading and unloading the rotary hoe
and when moving to or from jobsite.
Ensure that all grass and weeds have been cut
as low as possible.
2) If the rotary hoe is to be used in clay or hard
ground conditions, it is recommended to water
the area thoroughly and allow sufficient time
for earth to soften.
3) Police the area. Remove any
foreign objects from the area.
4) Identify and mark the location of sprinkler heads,
gas pipes, telephone cables etc.
“The Right Way to Rent”
You alone know the operational demands and
special conditions affecting the equipment in
your situation and therefore assume the
responsibility for developing, carrying out, and
enforcing the safety concepts which apply to your
own operation to effect the greatest safety for
yourself andthe people around you.
Online Demonstration Available at:
www.redroo.com/products/logsplitter

1) DO NOT allow any person to operate the
hydraulic log splitter without rst reading
and understanding the owners manual.
Also read and understand the engine
manual. Know the operating controls and how to stop
the machine quickly in an emergency.
2) NEVER allow children or untrained adults to
operate the hydraulic log splitter
3) ALWAYS wear
protective clothing when
operating the hydraulic
logsplitter. This includes, but is not limited to; safety
glasses, loose tting gloves, steel capped boots and
hearing protection. Never wear loose tting clothes
or jewellery when operating the hydraulic logsplitter.
Keep all clothing away from moving parts.
Items could become caught in the machine,
resulting in injury.
4) ALWAYS operate the hydraulic logsplitter in a
well-lighted area
5) NEVER operate the hydraulic
logsplitter on a slippery, wet, muddy, or
icy surfaces. ALWAYS keep your work
area clear of debris.
6) allow bystanders near the hydraulic
logsplitter. OPERATING THIS MACHINE
IS A SINGLE PERSON OPERATION. It
is the operator’s responsibility to keep
bystanders and animals at a minimum of
6 metres (18 feet) away from the hydraulic logsplitter
while in operation.
7) NEVER operate the hydraulic logsplitter when
fatigued. ALWAYS BE ALERT! If you get tired while
operating the hydraulic logspllitter take a break. If
you have any type of physical or mental condition
that may be aggravated by strenuous work, check
with your physician before you operate this machine.
NEVER operate the hydraulic logsplitter under the
inuence of medication, alcohol or drugs.
8) NEVER step over the hydraulic log splitter
when it is operation – walk around the
hydraulic logsplitter to get around to the
other side
9) place your hands or ngers
between the end of the log / wood
and the headstock
place your hands or ngers
between the end of the log / wood and the splitting head
position the log by placing your hands or ngers at the
end of the log / wood.
Position the log by placing a hand on the top of the log /
wood as close to the centre of the log / wood as possible.
NEVER have your hands or ngers close to the headstock
or splitting head while the machine is in operation. Remove
hand completely from the log / wood once the splitting head
engages the log / wood.
10) NEVER overspeed the engine or alter the governor
settings. Excessive speed is dangerous and will shorten
engine life
11) NEVER operate the hydraulic logsplitter in
an enclosed area. Engine exhaust contains
carbon monoxide, an odourless and tasteless
poison that can kill.
12) NEVER leave this machine unattended while the
engine is running.
13) ALWAYS STOP the engine immediately if a
hydraulic leak occurs. NEVER operate this
machine with frayed, kinked, cracked or
damaged hoses, ttings, or tubing.
14) ALWAYS STOP the engine and disconnect the
spark plug lead(s) and allow the engine to cool
down (Minimum 5 minutes)
15) ALWAYS
• Turn Off Engine: • Allow Engine To Cool
• Minimum 5 Minutes
• USE UNLEADED FUEL ONLY
• Use Clean, fresh unleaded fuel
• Do-Not over-ll fuel tank
• Allow space for fuel expansion
• Allow no naked ame or hot material in
refuelling area
• Do not smoke near the log splitter
• Use only approved fuel containers and
funnels. Remember, fuel is a potential hazard
• Refer to engine owners manual for
full details
SAFETY INSTRUCTIONS FOR HLS USERS
HLS HYDRAULIC LOG
SPLITTER OPERATING
INSTRUCTIONS
USE COMMON SENSE
AND PLENTY OF IT
TRANSPORT
WARNING make sure that the hydraulic lifting platform
is in the highest position (inside the mudguard) and
secured with retaining pin to the headstock before
towing. DO NOT ATTEMPT TO TOW THIS MACHINE
WITHOUT THE LIFTING TABLE BEING SECURED TO
THE HEADSTOCK IN THE UPRIGHT
POSITION.
DO NOT exceed 80kms (50mph) per hour
when towing this machine. Make sure that
the trailer coupling is secure and lights are operating
properly.
IT IS THE RESPONSIBILITY OF THE INDIVIDUAL TOWING
THIS LOGSPLITTER TO MAKE SURE THEY HAVE
SECURED THE MACHINE PROPERLY TO THE TOW
VEHICLE.
BEFORE USE
Perform a thorough and complete visual inspection of the
hydraulic log splitter.
Always keep your work area clear and free of debris.
safety
IS EVERYBODY’S BUSINESS
...now
safety
IS EVERYBODY’S BUSINESS
...now
safety
IS EVERYBODY’S BUSINESS
...now
safety
IS EVERYBODY’S BUSINESS
...now
SAFETY INSTRUCTIONS FOR RH918 USERS
OPERATING
INSTRUCTIONS
USE COMMON SENSE
AND PLENTY OF IT
TRANSPORT
BEFORE USE
1) DO NOT allow any person operate the
rotary hoe without first reading and
understanding the safety instructions and
operating instructions.
2) NEVER allow children to operate the rotary hoe.
8) ALWAYS make certain the Tyne Control Lever is
set at neutral while loading and unloading the
rotary hoe, or moving to and away from working area.
9) NEVER run the machine in reverse while the tynes
are rotating. Always move the tyne control lever to
“OFF” before reversing the wheels.
11) DO NOT leave the machine unattended while the
engine is running.
12) DO NOT overspeed the engine or alter the governor
settings. Excessive speed is dangerous and will
shorten engine life.
13) NEVER operate the rotary hoe in an
enclosed area. Engine exhaust contains
carbon monoxide, an odourless and
tasteless poison.
14) STOP the engine and disconnect the
spark plug lead(s) and allow engine to
cool before inspecting or performing
maintenance on the rotary hoe.
15)
1)
REFUELLING
* Shut off the engine. DO NOT REFUEL
AN ENGINE WHILE OPERATING!
* Allow engine to cool. Minimum 5 minutes
* USE UNLEADED FUEL ONLY.
Use clean, fresh unleaded fuel.
* Do not mix oil with unleaded fuel.
* Do not over-fill fuel tank. Allow space
for fuel expansion.
10) NEVER operate the unit without the safety
guards in place and in working order. Keep
the unit well maintained and in good
working order.
4) ALWAYS use the rotary
hoe in a well lighted area.
7) NEVER operate the rotary hoe when fatigued.
ALWAYS BE ALERT! If you get tired while
operating the rotary hoe, take a break. If you have
any type of physical or mental condition that may
be aggravated by strenuous work, consult with
your physician before you operate this equipment.
NEVER operate the rotary hoe under the influence
of medication, alcohol or drugs.
6) DO NOT allow other persons near the
rotary hoe. It is up to the operator to keep
bystanders and animals a minimum of 6
5) ALWAYS operate the rotary
hoe on level ground only.
Police the area before rotary
hoeing. Remove any foreign objects in the digging
area - bricks, rocks, wire and sticks. Locate and mark
any sprinkler heads, water pipes, gas lines,
electrical and telephone cables or any other hazard
either below or above ground.
3) ALWAYS wear protective clothing when operating
the rotary hoe. This includes, but is not limited to;
safety glasses, loose fitting gloves, steel capped
boots and hearing protection. NEVER wear loose
fitting clothing or jewellery when operating the
rotary hoe. Keep all clothing away from moving
parts. Items could become caught in the machine,
resulting in injury.
KNOW THE CONTROLS AND HOW TO STOP
THE ROTARY HOE QUICKLY IN AN EMERGENCY.
metres (20’) away from the machine while in
operation.
ALWAYS KEEP YOUR HANDS,
FEET AND BODY AWAY FROM
THE DIGGING ZONE WHILE
ENGINE IS RUNNING.
* Do not smoke.
* Allow no naked flame or hot material in refuelling area.
* Use only approved fuel containers and funnels.
Remember, fuel is a potential hazard .
Be sure Tyne Control Lever is set to “Neutral”
while loading and unloading the rotary hoe
and when moving to or from jobsite.
Ensure that all grass and weeds have been cut
as low as possible.
2) If the rotary hoe is to be used in clay or hard
ground conditions, it is recommended to water
the area thoroughly and allow sufficient time
for earth to soften.
3) Police the area. Remove any
foreign objects from the area.
4) Identify and mark the location of sprinkler heads,
gas pipes, telephone cables etc.
“The Right Way to Rent”
You alone know the operational demands and
special conditions affecting the equipment in
your situation and therefore assume the
responsibility for developing, carrying out, and
enforcing the safety concepts which apply to your
own operation to effect the greatest safety for
yourself andthe people around you.
SAFETY INSTRUCTIONS FOR RH918 USERS
OPERATING
INSTRUCTIONS
USE COMMON SENSE
AND PLENTY OF IT
TRANSPORT
BEFORE USE
1) DO NOT allow any person operate the
rotary hoe without first reading and
understanding the safety instructions and
operating instructions.
2) NEVER allow children to operate the rotary hoe.
8) ALWAYS make certain the Tyne Control Lever is
set at neutral while loading and unloading the
rotary hoe, or moving to and away from working area.
9) NEVER run the machine in reverse while the tynes
are rotating. Always move the tyne control lever to
“OFF” before reversing the wheels.
11) DO NOT leave the machine unattended while the
engine is running.
12) DO NOT overspeed the engine or alter the governor
settings. Excessive speed is dangerous and will
shorten engine life.
13) NEVER operate the rotary hoe in an
enclosed area. Engine exhaust contains
carbon monoxide, an odourless and
tasteless poison.
14) STOP the engine and disconnect the
spark plug lead(s) and allow engine to
cool before inspecting or performing
maintenance on the rotary hoe.
15)
1)
REFUELLING
* Shut off the engine. DO NOT REFUEL
AN ENGINE WHILE OPERATING!
* Allow engine to cool. Minimum 5 minutes
* USE UNLEADED FUEL ONLY.
Use clean, fresh unleaded fuel.
* Do not mix oil with unleaded fuel.
* Do not over-fill fuel tank. Allow space
for fuel expansion.
10) NEVER operate the unit without the safety
guards in place and in working order. Keep
the unit well maintained and in good
working order.
4) ALWAYS use the rotary
hoe in a well lighted area.
7) NEVER operate the rotary hoe when fatigued.
ALWAYS BE ALERT! If you get tired while
operating the rotary hoe, take a break. If you have
any type of physical or mental condition that may
be aggravated by strenuous work, consult with
your physician before you operate this equipment.
NEVER operate the rotary hoe under the influence
of medication, alcohol or drugs.
6) DO NOT allow other persons near the
rotary hoe. It is up to the operator to keep
bystanders and animals a minimum of 6
5) ALWAYS operate the rotary
hoe on level ground only.
Police the area before rotary
hoeing. Remove any foreign objects in the digging
area - bricks, rocks, wire and sticks. Locate and mark
any sprinkler heads, water pipes, gas lines,
electrical and telephone cables or any other hazard
either below or above ground.
3) ALWAYS wear protective clothing when operating
the rotary hoe. This includes, but is not limited to;
safety glasses, loose fitting gloves, steel capped
boots and hearing protection. NEVER wear loose
fitting clothing or jewellery when operating the
rotary hoe. Keep all clothing away from moving
parts. Items could become caught in the machine,
resulting in injury.
KNOW THE CONTROLS AND HOW TO STOP
THE ROTARY HOE QUICKLY IN AN EMERGENCY.
metres (20’) away from the machine while in
operation.
ALWAYS KEEP YOUR HANDS,
FEET AND BODY AWAY FROM
THE DIGGING ZONE WHILE
ENGINE IS RUNNING.
* Do not smoke.
* Allow no naked flame or hot material in refuelling area.
* Use only approved fuel containers and funnels.
Remember, fuel is a potential hazard .
Be sure Tyne Control Lever is set to “Neutral”
while loading and unloading the rotary hoe
and when moving to or from jobsite.
Ensure that all grass and weeds have been cut
as low as possible.
2) If the rotary hoe is to be used in clay or hard
ground conditions, it is recommended to water
the area thoroughly and allow sufficient time
for earth to soften.
3) Police the area. Remove any
foreign objects from the area.
4) Identify and mark the location of sprinkler heads,
gas pipes, telephone cables etc.
“The Right Way to Rent”
You alone know the operational demands and
special conditions affecting the equipment in
your situation and therefore assume the
responsibility for developing, carrying out, and
enforcing the safety concepts which apply to your
own operation to effect the greatest safety for
yourself andthe people around you.
MAXIMUM ANGLE
OF OPERATION
DO NOT EXCEED
15º ANGLE
USE COMMON SENSE
AND PLENTY OF IT
SAFETY INSTRUCTIONS FOR HT912USERS
INSTRUCTIONS
DO NOT allow any person to operate the
hydraulic trencher without first reading and
understanding the safety instructions and
NEVER allow children to operate the hydraulic trencher.
ALWAYS use hydraulic trencher in a well lighted area.
ALWAYS make certain that all control clutches are in
the “disengaged” position prior to starting the engine.
The safety clutch lever/Operator Presence Control on
the left handlebar is for operator protection. DO NOT
tape down or otherwise bypass this Safety Device.
NEVER wear loose fitting clothing or jewellery when
operating the hydraulic trencher. Keep all clothing
away from moving parts. Item could become
caught in the machine, resulting in injury.
ALWAYS wear protective
clothing when operating
the hydraulic trencher.
This includes, but is not limited to, safety glasses, hard hat
loose fitting gloves, steel capped boots and hearing protection.
operating instructions. KNOW THE CONTROLS AND
HOW TO STOP THE HYDRAULIC TRENCHER QUICKLY
IN AN EMERGENCY.
1)
2)
3)
4)
Police the area before trenching. Remove any foreign
objects in the digging area eg bricks, rocks, wire and
sticks. Locate and mark any sprinkler heads, water
pipes, gas lines, electrical and telephone cables or any
other hazard either below or above ground.
5)
DO NOT leave the machine unattended while the engine
is running. DO NOT park on incline or park
perpendicular to slope. DO NOT freewheel down incline.
7)
DO NOT overspeed the engine or alter the governor
settings. Excessive speed is dangerous and will
shorten engine life
8)
NEVER operate the hydraulic trencher when fatigued.
ALWAYS BE ALERT! If you get tired while operating
the hydraulic trencher, take a break. If you have any
type of physical or mental condition that may be
aggravated by strenuous work, consult with your
physician before you operate this equipment. NEVER
operate the hydraulic trencher under the influence of
medication, alcohol or drugs.
9)
NEVER operate the unit without the safety
guards in place and in working order. Keep
the unit well maintained and in good working order
Remove the hydraulic trencher from its
trailer. Use caution.
Police the area. Remove any
foreign objects from the area.
Identify and mark the location of sprinkler heads,
gas pipes, telephone cables, etc.
IGNITION: Must be in “ON” position to start. “OFF”
to stop.
ENGINE: Throttle cable controls engine speed.
Operate at full throttle (all the way forward).
WHEEL DRIVE CONTROL LEVER: Controls wheel
speed forward or reverse after clutch lever is engaged.
DIGGING BOOM CONTROL LEVER: Raises and lowers
the digging boom.
DIGGING CHAIN CONTROL LEVER: must be in “ON”
position BEFORE clutch lever is depressed in order
to start chain in motion. Chain moves in a forward
direction after clutch lever is engaged.
SAFETY CLUTCH LEVER/OPERATOR PRESENCE
CONTROL: (At left handle grip) Activates WHEEL
DRIVE and DIGGING CHAIN controls when depressed.
Stops all motion when released.
FORWARD/REVERSE DIGGING CHAIN CONTROL
LEVER: Allows manual operation of chain in forward
or reverse rotation to dislodge objects or dig difficult
terrain. (This control can be used with the clutch lever
released.) To reverse chain, DIGGING CHAIN control
must be in “OFF” position.
Familiarize yourself with the hydraulic
trencher and its controls.
10)
1)
1)
2)
1)
Free Wheel Hub Feature - Operation:
Pull one free wheeling pin slightly, using the split
ring. Rotate the pin until the 3mm (1/8”) diameter roll
pin aligns with the slot in the mounting plate. Allow
the pin to slide through the slot. Repeat for the other
wheel. Roll the trencher until each pin drops into a
hole in the hub. The wheel hubs are now locked.
Reverse the procedure to unlock the wheels.
2)
DO NOT allow other persons near the hydraulic
trencher. It is up to the operator to keep
bystanders and animals a minimum of 6 metres
(20ft) away from the machine while in operation.
12)
NEVER operate the hydraulic trencher in an
enclosed area. Engine exhaust contains carbon
monoxide, an odourless and tasteless poison.
13)
WARNING: Hydraulic oil is under extreme
pressure and can get under skin and burn
or poison. Check for leaks with cardboard.
14)
STOP the engine and disconnect the spark
plug lead(s) and allow engine to cool before
inspecting or performing maintenance on
the hydraulic trencher.
15)
REFUELLING
* Shut off engine. DO NOT REFUEL AN ENGINE
WHILE OPERATING!
* Allow engine to cool. Minimum 5 minutes
* Do not smoke. *Allow no naked flame
or hot material in refuelling area.
* Use only approved fuel containers and funnels.
Remember, fuel is a potential hazard.
* Do not over-fill fuel tank. Allow space for
fuel expansion.
* USE UNLEADED FUEL ONLY. Use clean,
fresh unleaded fuel.
* Do not mix oil with unleaded fuel.
16)
ALWAYS KEEP YOUR HANDS, FEET AND BODY
AWAY FROM THE DIGGING CHAIN AND OTHER
MOVING PARTS WHILE ENGINE IS RUNNING.
11)
ALWAYS operate
hydraulic trencher
on level ground only.
6) MAXIMUM
ANGLE OF
OPERATION
DO NOT EXCEED 15ºANGLE
BEFORE USE
OPERATION
TRANSPORT
80
KPH
50
MPH
SAFETY INSTRUCTIONS FOR RH918 USERS
OPERATING
INSTRUCTIONS
USE COMMON SENSE
AND PLENTY OF IT
TRANSPORT
BEFORE USE
1) DO NOT allow any person operate the
rotary hoe without first reading and
understanding the safety instructions and
operating instructions.
2) NEVER allow children to operate the rotary hoe.
8) ALWAYS make certain the Tyne Control Lever is
set at neutral while loading and unloading the
rotary hoe, or moving to and away from working area.
9) NEVER run the machine in reverse while the tynes
are rotating. Always move the tyne control lever to
“OFF” before reversing the wheels.
11) DO NOT leave the machine unattended while the
engine is running.
12) DO NOT overspeed the engine or alter the governor
settings. Excessive speed is dangerous and will
shorten engine life.
13) NEVER operate the rotary hoe in an
enclosed area. Engine exhaust contains
carbon monoxide, an odourless and
tasteless poison.
14) STOP the engine and disconnect the
spark plug lead(s) and allow engine to
cool before inspecting or performing
maintenance on the rotary hoe.
15)
1)
REFUELLING
* Shut off the engine. DO NOT REFUEL
AN ENGINE WHILE OPERATING!
* Allow engine to cool. Minimum 5 minutes
* USE UNLEADED FUEL ONLY.
Use clean, fresh unleaded fuel.
* Do not mix oil with unleaded fuel.
* Do not over-fill fuel tank. Allow space
for fuel expansion.
10) NEVER operate the unit without the safety
guards in place and in working order. Keep
the unit well maintained and in good
working order.
4) ALWAYS use the rotary
hoe in a well lighted area.
7) NEVER operate the rotary hoe when fatigued.
ALWAYS BE ALERT! If you get tired while
operating the rotary hoe, take a break. If you have
any type of physical or mental condition that may
be aggravated by strenuous work, consult with
your physician before you operate this equipment.
NEVER operate the rotary hoe under the influence
of medication, alcohol or drugs.
6) DO NOT allow other persons near the
rotary hoe. It is up to the operator to keep
bystanders and animals a minimum of 6
5) ALWAYS operate the rotary
hoe on level ground only.
Police the area before rotary
hoeing. Remove any foreign objects in the digging
area - bricks, rocks, wire and sticks. Locate and mark
any sprinkler heads, water pipes, gas lines,
electrical and telephone cables or any other hazard
either below or above ground.
3) ALWAYS wear protective clothing when operating
the rotary hoe. This includes, but is not limited to;
safety glasses, loose fitting gloves, steel capped
boots and hearing protection. NEVER wear loose
fitting clothing or jewellery when operating the
rotary hoe. Keep all clothing away from moving
parts. Items could become caught in the machine,
resulting in injury.
KNOW THE CONTROLS AND HOW TO STOP
THE ROTARY HOE QUICKLY IN AN EMERGENCY.
metres (20’) away from the machine while in
operation.
ALWAYS KEEP YOUR HANDS,
FEET AND BODY AWAY FROM
THE DIGGING ZONE WHILE
ENGINE IS RUNNING.
* Do not smoke.
* Allow no naked flame or hot material in refuelling area.
* Use only approved fuel containers and funnels.
Remember, fuel is a potential hazard .
Be sure Tyne Control Lever is set to “Neutral”
while loading and unloading the rotary hoe
and when moving to or from jobsite.
Ensure that all grass and weeds have been cut
as low as possible.
2) If the rotary hoe is to be used in clay or hard
ground conditions, it is recommended to water
the area thoroughly and allow sufficient time
for earth to soften.
3) Police the area. Remove any
foreign objects from the area.
4) Identify and mark the location of sprinkler heads,
gas pipes, telephone cables etc.
“The Right Way to Rent”
You alone know the operational demands and
special conditions affecting the equipment in
your situation and therefore assume the
responsibility for developing, carrying out, and
enforcing the safety concepts which apply to your
own operation to effect the greatest safety for
yourself andthe people around you.
3)
a. Move the fuel valve
lever to ON
position. a. Put Wheel Drive Lever in neutral.
c. Have engine at full throttle (forward).
d. Hold Digging Chain Control Lever in On position.
e. Squeeze the safety Clutch Lever/Operator Presence Control.
f. Slowly lower the digging boom until the desired trench
depth is achieved using the Digging Boom Control Lever.
g. Put Wheel Drive Control Lever in reverse. Start at low speed.
h.
a.
Adjust the wheel speed until a workable speed is reached
Use a very slow speed for trenching and adjust for soil
conditions as necessary. If objects such as rocks or roots
jam in the chain, release the Safety Clutch Lever/Operator
Presence Control, then reverse the chain to dislodge the
debris. If necessary move the trencher forward a few
inches and trench the area again.
Shut off switch on
console should be
used, not shut off
switch on engine.
b. Turn the engine switch
to the OFF position.
c. Turn the fuel
valve lever to the
OFF position
1) Allow machine to cool down. Wash mud and dirt off of
the hydraulic trencher. Ensure no water enters the
carburettor
2) Remove any objects that may have wrapped around
the trencher chain or assembly.
b. Be sure both hubs are engaged (turn hub lock handle
clockwise). (See Free Wheel Hub Feature)
b. To start a cold
engine, move the
choke lever or choke
rod (applicable
types) to the
CLOSED
position.
To restart a
warm engine,
leave the choke lever or choke rod in the OPEN position.
c. Move the
throttle lever
away from the
MIN position,
about 1/3 of the
way toward the
MAX position.
d. Turning the engine switch
to the ON position.
RECOIL STARTER
Pull the starter grip lightly
until you feel resistance,
then pull briskly.
Return the starter
grip gently.
STARTING THE ENGINE: 5) TRENCHING PROCEDURE:
6) STOPPING THE ENGINE:
WARNING - KEEP HANDS AND FEET CLEAR
OF TRENCHING CHAIN AND OTHER MOVING
PARTS AT ALL TIMES!
WARNING! - In case of difficulty, release the
Safety Clutch Lever/Operator Presence Control
All trenching action stops. Turn the Engine
Stop button to STOP located either side on the
main control console or the engine.
4)
a. Start and warm up engine.
b. Put Wheel Drive Control Lever in neutral.
c. One wheel hub may be disengaged (free wheeling)
for easier steering before driving machine to work
loccation. (See Wheel Hub Feature)
d. Squeeze the safety Clutch Lever/Operator Presence
Control and change the Wheel Direction Control to
desired speed and direction.
e. Adjust the wheel speed and navigate the trencher to the
starting position. The trencher is designed to dig toward
the operator (with the Wheel drive Control Lever in
reverse). With this in mind, position the machine to
start the trench. Note: When initially engagaing the
rotating chain into the ground, be aware that in the hard or
rocky ground the rotating trencher chain may
aggressively dig in and lurch forward. For this reason
make sure that theres is sufficient clearance from
structures, objects or people in front of the machine.
AFTER USE
Make sure that there is sufficient clearance from
structures, objects or people in front of the machine
© Copyright 2013, Red Roo Sales & Service Company Pty. Ltd. P/N 1301-0066-A
Move the throttle lever
to the MIN position.
Some engine applications use a
remote-mounted throttle control
rather than the engine-
mounted lever shown here
SAFETYPRECAUTIONS
AND OPERATING
INSTRUCTIONS
™
GT5
GARDEN
TILLER
OPERATION OF GT622
1) Remove the garden tiller
from its trailer/carrier/ute. Use caution.
2) Familiarize yourself with the machine and its
controls.
5) Ensure the tyne engagement control lever is in
the neutral position. The tyne engagement
control lever is located
machine below handle bar. The neutral position
on the left hand side of the
of the lever is achieved by simply releasing the
tyne engagement control lever.
4)
3) Adjust wheels if required, using the handle wheel
adjustment lever.
Adjust depth shoe if required, using the depth
control adjustment lever.
6) Open fuel shut-off valve. Set choke
control to Choke or Start position.
Set throttle control to Run or Fast
position. Set engine
stop switch to On or
Run position. Pull
starter cord rapidly.
Repeat (if necessary)
with choke off.
pull up on the tyne engagement control lever.
The tynes will begin to turn. Release the tyne
7) Wheninposition to begingarden tilling,
engagement control lever to stop the tynes turning.
Tyne speed is governed by engine throttle setting.
WARNING! –KEEPHANDSAND
FEET CLEAR OF TYNES AT ALL
TIMES!
8) Do not hurry the job. Proceed slowly and allow
the machine time to do the job. When ground
is extremely hard, reduce engine speed. Consider
watering the surface and reducing engine speed.
Adjust wheels and depth shoe accordingly while
tilling
WARNING! –IN CASE OF DIFFICULTY,
RELEASE THE TYNE ENGAGEMENT
CONTROL LEVER. ALL TILLING ACTION
STOPS.Turn the engine "STOP" switch
to off located on the engine.
9) Stop Engine: Release the tyne engagement
control lever. Move throttle to Slow position.
Set engine stop switch to Stop or Off position.
DO NOT move choke
position to stop engine.
Backfire or engine
damage may occur.
AFTER USE
1) Turn fuelshut off valve to the "OFF"
position.
2) Allow machine to cool down.
3) Wash mud and dirt off of the garden tiller.
Ensure no water enters the carburettor.
4) Removeanyweeds,wire,rope or other
material thatmayhavewrappedaround the
tynes and rotor assembly.
5) Returnwheels and depth control handle to
transport position.
© Copyright 2012, Red Roo Sales & Service Company Pty. Ltd. 1301-0069-A
Commer
“The Right Way to Rent” cial Outdoor Power Equipment
control to Choke or Start
You alone know the operational demands and
special conditions affecting the equipment in
your situation and therefore assume the
responsibility for developing, carrying out, and
enforcing the safety concepts which apply to your
own operation to effect the greatest safety for
yourself andthe people around you.
USE COMMON SENSE
AND PLENTY OF IT
SAFETY INSTRUCTIONS FOR HT912USERS
INSTRUCTIONS
DO NOT allow any person to operate the
hydraulic trencher without first reading and
understanding the safety instructions and
NEVER allow children to operate the hydraulic trencher.
ALWAYS use hydraulic trencher in a well lighted area.
ALWAYS make certain that all control clutches are in
the “disengaged” position prior to starting the engine.
The safety clutch lever/Operator Presence Control on
the left handlebar is for operator protection. DO NOT
tape down or otherwise bypass this Safety Device.
NEVER wear loose fitting clothing or jewellery when
operating the hydraulic trencher. Keep all clothing
away from moving parts. Item could become
caught in the machine, resulting in injury.
ALWAYS wear protective
clothing when operating
the hydraulic trencher.
This includes, but is not limited to, safety glasses, hard hat
loose fitting gloves, steel capped boots and hearing protection.
operating instructions. KNOW THE CONTROLS AND
HOW TO STOP THE HYDRAULIC TRENCHER QUICKLY
IN AN EMERGENCY.
1)
2)
3)
4)
Police the area before trenching. Remove any foreign
objects in the digging area eg bricks, rocks, wire and
sticks. Locate and mark any sprinkler heads, water
pipes, gas lines, electrical and telephone cables or any
other hazard either below or above ground.
5)
DO NOT leave the machine unattended while the engine
is running. DO NOT park on incline or park
perpendicular to slope. DO NOT freewheel down incline.
7)
DO NOT overspeed the engine or alter the governor
settings. Excessive speed is dangerous and will
shorten engine life
8)
NEVER operate the hydraulic trencher when fatigued.
ALWAYS BE ALERT! If you get tired while operating
the hydraulic trencher, take a break. If you have any
type of physical or mental condition that may be
aggravated by strenuous work, consult with your
physician before you operate this equipment. NEVER
operate the hydraulic trencher under the influence of
medication, alcohol or drugs.
9)
NEVER operate the unit without the safety
guards in place and in working order. Keep
the unit well maintained and in good working order
Remove the hydraulic trencher from its
trailer. Use caution.
Police the area. Remove any
foreign objects from the area.
Identify and mark the location of sprinkler heads,
gas pipes, telephone cables, etc.
IGNITION: Must be in “ON” position to start. “OFF”
to stop.
ENGINE: Throttle cable controls engine speed.
Operate at full throttle (all the way forward).
WHEEL DRIVE CONTROL LEVER: Controls wheel
speed forward or reverse after clutch lever is engaged.
DIGGING BOOM CONTROL LEVER: Raises and lowers
the digging boom.
DIGGING CHAIN CONTROL LEVER: must be in “ON”
position BEFORE clutch lever is depressed in order
to start chain in motion. Chain moves in a forward
direction after clutch lever is engaged.
SAFETY CLUTCH LEVER/OPERATOR PRESENCE
CONTROL: (At left handle grip) Activates WHEEL
DRIVE and DIGGING CHAIN controls when depressed.
Stops all motion when released.
FORWARD/REVERSE DIGGING CHAIN CONTROL
LEVER: Allows manual operation of chain in forward
or reverse rotation to dislodge objects or dig difficult
terrain. (This control can be used with the clutch lever
released.) To reverse chain, DIGGING CHAIN control
must be in “OFF” position.
Familiarize yourself with the hydraulic
trencher and its controls.
10)
1)
1)
2)
1)
Free Wheel Hub Feature - Operation:
Pull one free wheeling pin slightly, using the split
ring. Rotate the pin until the 3mm (1/8”) diameter roll
pin aligns with the slot in the mounting plate. Allow
the pin to slide through the slot. Repeat for the other
wheel. Roll the trencher until each pin drops into a
hole in the hub. The wheel hubs are now locked.
Reverse the procedure to unlock the wheels.
2)
DO NOT allow other persons near the hydraulic
trencher. It is up to the operator to keep
bystanders and animals a minimum of 6 metres
(20ft) away from the machine while in operation.
12)
NEVER operate the hydraulic trencher in an
enclosed area. Engine exhaust contains carbon
monoxide, an odourless and tasteless poison.
13)
WARNING: Hydraulic oil is under extreme
pressure and can get under skin and burn
or poison. Check for leaks with cardboard.
14)
STOP the engine and disconnect the spark
plug lead(s) and allow engine to cool before
inspecting or performing maintenance on
the hydraulic trencher.
15)
REFUELLING
* Shut off engine. DO NOT REFUEL AN ENGINE
WHILE OPERATING!
* Allow engine to cool. Minimum 5 minutes
* Do not smoke. *Allow no naked flame
or hot material in refuelling area.
* Use only approved fuel containers and funnels.
Remember, fuel is a potential hazard.
* Do not over-fill fuel tank. Allow space for
fuel expansion.
* USE UNLEADED FUEL ONLY. Use clean,
fresh unleaded fuel.
* Do not mix oil with unleaded fuel.
16)
ALWAYS KEEP YOUR HANDS, FEET AND BODY
AWAY FROM THE DIGGING CHAIN AND OTHER
MOVING PARTS WHILE ENGINE IS RUNNING.
11)
ALWAYS operate
hydraulic trencher
on level ground only.
6) MAXIMUM
ANGLE OF
OPERATION
DO NOT EXCEED 15ºANGLE
BEFORE USE
OPERATION
TRANSPORT
USE COMMON SENSE
AND PLENTY OF IT
SAFETY INSTRUCTIONS FOR HT912USERS
INSTRUCTIONS
DO NOT allow any person to operate the
hydraulic trencher without first reading and
understanding the safety instructions and
NEVER allow children to operate the hydraulic trencher.
ALWAYS use hydraulic trencher in a well lighted area.
ALWAYS make certain that all control clutches are in
the “disengaged” position prior to starting the engine.
The safety clutch lever/Operator Presence Control on
the left handlebar is for operator protection. DO NOT
tape down or otherwise bypass this Safety Device.
NEVER wear loose fitting clothing or jewellery when
operating the hydraulic trencher. Keep all clothing
away from moving parts. Item could become
caught in the machine, resulting in injury.
ALWAYS wear protective
clothing when operating
the hydraulic trencher.
This includes, but is not limited to, safety glasses, hard hat
loose fitting gloves, steel capped boots and hearing protection.
operating instructions. KNOW THE CONTROLS AND
HOW TO STOP THE HYDRAULIC TRENCHER QUICKLY
IN AN EMERGENCY.
1)
2)
3)
4)
Police the area before trenching. Remove any foreign
objects in the digging area eg bricks, rocks, wire and
sticks. Locate and mark any sprinkler heads, water
pipes, gas lines, electrical and telephone cables or any
other hazard either below or above ground.
5)
DO NOT leave the machine unattended while the engine
is running. DO NOT park on incline or park
perpendicular to slope. DO NOT freewheel down incline.
7)
DO NOT overspeed the engine or alter the governor
settings. Excessive speed is dangerous and will
shorten engine life
8)
NEVER operate the hydraulic trencher when fatigued.
ALWAYS BE ALERT! If you get tired while operating
the hydraulic trencher, take a break. If you have any
type of physical or mental condition that may be
aggravated by strenuous work, consult with your
physician before you operate this equipment. NEVER
operate the hydraulic trencher under the influence of
medication, alcohol or drugs.
9)
NEVER operate the unit without the safety
guards in place and in working order. Keep
the unit well maintained and in good working order
Remove the hydraulic trencher from its
trailer. Use caution.
Police the area. Remove any
foreign objects from the area.
Identify and mark the location of sprinkler heads,
gas pipes, telephone cables, etc.
IGNITION: Must be in “ON” position to start. “OFF”
to stop.
ENGINE: Throttle cable controls engine speed.
Operate at full throttle (all the way forward).
WHEEL DRIVE CONTROL LEVER: Controls wheel
speed forward or reverse after clutch lever is engaged.
DIGGING BOOM CONTROL LEVER: Raises and lowers
the digging boom.
DIGGING CHAIN CONTROL LEVER: must be in “ON”
position BEFORE clutch lever is depressed in order
to start chain in motion. Chain moves in a forward
direction after clutch lever is engaged.
SAFETY CLUTCH LEVER/OPERATOR PRESENCE
CONTROL: (At left handle grip) Activates WHEEL
DRIVE and DIGGING CHAIN controls when depressed.
Stops all motion when released.
FORWARD/REVERSE DIGGING CHAIN CONTROL
LEVER: Allows manual operation of chain in forward
or reverse rotation to dislodge objects or dig difficult
terrain. (This control can be used with the clutch lever
released.) To reverse chain, DIGGING CHAIN control
must be in “OFF” position.
Familiarize yourself with the hydraulic
trencher and its controls.
10)
1)
1)
2)
1)
Free Wheel Hub Feature - Operation:
Pull one free wheeling pin slightly, using the split
ring. Rotate the pin until the 3mm (1/8”) diameter roll
pin aligns with the slot in the mounting plate. Allow
the pin to slide through the slot. Repeat for the other
wheel. Roll the trencher until each pin drops into a
hole in the hub. The wheel hubs are now locked.
Reverse the procedure to unlock the wheels.
2)
DO NOT allow other persons near the hydraulic
trencher. It is up to the operator to keep
bystanders and animals a minimum of 6 metres
(20ft) away from the machine while in operation.
12)
NEVER operate the hydraulic trencher in an
enclosed area. Engine exhaust contains carbon
monoxide, an odourless and tasteless poison.
13)
WARNING: Hydraulic oil is under extreme
pressure and can get under skin and burn
or poison. Check for leaks with cardboard.
14)
STOP the engine and disconnect the spark
plug lead(s) and allow engine to cool before
inspecting or performing maintenance on
the hydraulic trencher.
15)
REFUELLING
* Shut off engine. DO NOT REFUEL AN ENGINE
WHILE OPERATING!
* Allow engine to cool. Minimum 5 minutes
* Do not smoke. *Allow no naked flame
or hot material in refuelling area.
* Use only approved fuel containers and funnels.
Remember, fuel is a potential hazard.
* Do not over-fill fuel tank. Allow space for
fuel expansion.
* USE UNLEADED FUEL ONLY. Use clean,
fresh unleaded fuel.
* Do not mix oil with unleaded fuel.
16)
ALWAYS KEEP YOUR HANDS, FEET AND BODY
AWAY FROM THE DIGGING CHAIN AND OTHER
MOVING PARTS WHILE ENGINE IS RUNNING.
11)
ALWAYS operate
hydraulic trencher
on level ground only.
6) MAXIMUM
ANGLE OF
OPERATION
DO NOT EXCEED 15ºANGLE
BEFORE USE
OPERATION
TRANSPORT
Engine
Operating Controls
Head Stock
Splitting Head
Hydraulic Lifting
Platform Control Lever
Log Cradle
Splitting Head
Control Lever
Safety Tow Chain
Jockey
Wheel
Hydraulic Log/Wood
Lifting Platform
OPERATOR
ZONE
Throttle
Control
To w Coupling
Locking Pin
Engine
Exhaust
