Redback EV480D User manual
1
TABLE OF CONTENTS
•Symbols……………………........
•Safety Instructions and
General Power Tool Safety
Warnings…………
•Major Parts of the
Blower/Vacuum…………………
•Product Specifications…………
•Assembly and Operation………
•Battery Charger Function.……...
•Maintenance and Care………….
•Disposal…………………………..
•Guarantee/Warranty…………….
These instructions should be read in
conjunction with the instruction manual
for the battery pack and charger.
SYMBOLS
Before using this tool, read
the operations manual.
Read all safety warnings
and all instructions. Failure to follow the
warnings and instructions may result in
electric shock, fire and/or serious injury
General Safety Warning
1. Switch the unit off and remove the
battery under the following conditions: if
the unit is left unattended; before
checking, cleaning or performing other
work on the unit; if the unit starts
vibrating excessively.
2. Protect the battery contacts when
the battery is not being used. Loose
metal parts may short-circuit the
contacts - Explosion and fire hazard!
3. Render redundant garden tools
unusable: Main-operated tool handle by
removing the power cord, Battery-
operated tool by removing the battery.
Protective goggles/visor,
protective helmet & hearing
protection.
Wear non-slip, heavy-duty
protective gloves.
Do not expose to rain.
Do not throw batteries
and other electrical
products into the
household waste, fire, or water
Safety Instructions
User
This garden tool is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been
given supervision or instruction
concerning use of the machine by a
2
person responsible for their safety.
Never allow children or people
unfamiliar with these instructions to use
the garden tool. Supervise children. This
will ensure that children do not play with
the unit.
Intended Use
This garden tool is intended exclusively
- as a blower unit for blowing
leaves, grass, paper and the like in
the private sector
- according to the descriptions and
safety instructions indicated in this
operating manual.
Any other use is not as intended.
Improper use is not covered by the
warranty and the manufacturer will
reject any liability. The user is liable for
all injuries to third parties and damage
to their property.
Operate the unit only in the technical
condition as stipulated and delivered by
the manufacturer.
Arbitrary changes to the unit will exclude
the manufacturer from any liability for
resulting injury and/or damage.
General Power Tool
Safety Warnings
The term "power tool" in the warnings
refers to your main-operated (corded)
power tool or battery-operated
(cordless) power tool.
Work Area Safety
1. Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
2. Do not operate power tools in
explosive atmospheres, such as in the
presence of flammable liquids, gases, or
dust. Power tools create sparks which
may ignite the dust or fumes.
3. Keep children and bystanders away
while operating a power tool.
Distractions can cause you to lose
control.
Electrical Safety
1. Power tool plugs must match the
outlet. Never modify the plug in any way.
Do not use any adapter plugs with
earthed (grounded) power tools.
Unmodified plugs and matching outlets
will reduce the risk of electric shock.
2. Avoid body contact with earthed or
grounded surfaces, such as pipes,
radiators, ranges and refrigerators.
There is an increased risk of electric
shock if your body is earthed or
grounded.
3
3. Do not expose power tools to rain or
wet conditions. Water entering a power
tool will increase the risk of electric
shock.
4. Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep the cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase
the risk of electric shock.
5. When operating a power tool
outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable
for outdoor use reduces the risk of
electric shock.
6. If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected supply.
Use of an RCD reduces the risk of
electric shock.
Personal Safety
1. Stay alert, watch what you are doing
and use common sense when operating
a power tool. Do not use a power tool
while you are tired or under the
influence of drugs, alcohol, or
medication. A moment of inattention
while operating power tools may result
in serious personal injury.
2. Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing
protection used for appropriate
conditions will reduce the risk of injury.
3. Prevent unintentional starting.
Ensure the switch is in the off-position
before connecting to the power source
and/or battery pack, picking up, or
carrying the tool. Carrying power tools
with your finger on the switch or power
tools that have been turned on invites
accidents.
4. Remove any adjusting key or
wrench before turning the power tool on.
A wrench or a key left attached to a
rotating part of the power tool may
increase the risk of injury.
5. Do not overreach. Keep proper
footing and balance at all times. This
enables better control of the power tool
in unexpected situations.
6. Dress properly. Do not wear loose
clothing or jewelry. Keep your hair,
clothing and gloves away from moving
parts. Loose clothes, jewelry or long hair
can be caught by moving parts.
7. If devices are provided for the
connection of dust extraction and
collection facilities, ensure that these
are connected and properly used. Use
of dust collection can reduce dust-
related hazards.
Power Tool Use and
Care
4
1. Do not force the power tool. Use
the correct power tool for your
application. The correct power tool will
do the job better and safer at the rate for
which it is designed.
2. Do not use the power tool if it can’t
be turned on and off by its switch. Any
power tool that cannot be controlled with
the switch is dangerous and must be
repaired.
3. Disconnect the plug from the
power source and/or the battery pack
from the power tool before making any
adjustments, changing accessories, or
before storing the power tool. Such
preventive safety measure reduces the
risk of starting the power tool
accidentally.
4. Store idle power tools out of reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate it. Power tools
are dangerous in the hands of untrained
users.
5. Maintain the power tools. Check
for misalignment or binding of moving
parts, breakage of parts and any other
condition that may affect the power
tool’s operation. If damaged, have the
power tool repaired before use. Many
accidents are caused by poorly
maintained power tools.
6. Keep cutting tools sharp and
clean. Properly maintained cutting tools
with sharp cutting edges are less likely
to bind and are easier to control.
7. Use the power tool, accessories
and tool bits etc. in accordance with
these instructions, taking into account
the working conditions and the work to
be performed. Use of the power tool for
operations different from those intended
could result in a hazardous situation.
Battery Tool Use and Care
1. Recharge only with the charger
specified by the manufacturer. A charger
that is suitable for one type of battery
pack may create a risk of fire when used
with another battery pack.
2. Use power tools only with
specifically designated battery packs.
Use of any other battery packs may
create a risk of injury and fire.
3. When battery pack is not in use,
keep it away from other metal objects
like paper clips, coins, keys, nails,
screws, or other small metal objects that
can make a connection from one
terminal to another. Shorting the battery
terminals together may cause burns or
fire.
4. Under abusive conditions, liquid
may be ejected from the battery; avoid
contact. If you accidentally contact the
battery liquid, flush it with water. If the
battery liquid contacts the eyes, seek
medical help as soon as possible. Liquid
5
ejected from the battery may cause
irritation or burns.
Service
Have your power tool serviced by a
qualified repair person using only
identical replacement parts. This will
ensure that the safety of the power tool
is maintained.
Safety Instructions for The
Blower Unit
1. To ensure your safety and for the
safety of others, read this operating
manual and its safety instructions before
using the device. Please keep the
operating manual and its safety
instructions safe for subsequent use and
always have them ready to hand.
2. If the unit changes ownership,
hand over the operating manual with the
unit.
3. Persons who operate the unit
must not be under the influence of
intoxicants (e.g. alcohol, drugs or
medication).
4. Operate the unit only in the
technical condition stipulated and
delivered by the manufacturer.
Unauthorized changes to the unit
exclude liability of the manufacturer for
any resulting damage and/or injury.
5. Use the unit only in daylight or in
good artificial lighting.
6. Use the unit in dry conditions only.
Protect it from rain and moisture. The
ingress of water into the unit increases
the risk of an electric shock.
7. Switch the unit off and remove the
battery under the following conditions:
- if the unit is left unattended;
- before checking, cleaning or
performing other work on the unit;
- if the unit starts vibrating
excessively.
Before Starting the Unit
1. Before starting work, familiarize
yourself with the blower and its functions
as well as its controls.
2. Inspect the unit before switching it
on and check for signs of wear and
damage if it strikes an object.
3. Do not use a unit which has a
defective switch and can no longer be
switched on or off.
4. When working with or on the unit,
always wear sturdy footwear, long
trousers and the appropriate personal
protective equipment (goggles, hearing
protection, non-slip protective gloves,
etc.).
5. The wearing of personal protective
equipment reduces the risk of injuries.
6. Do not wear any jewelry or loose
clothing which could be caught by the
blower unit. Keep long hair away from
the intake openings.
6
7. Check the terrain on which the
unit will be used and remove any stones
and pieces of wire, which could be
picked up by the blower, to avoid
endangering people.
When Using the Unit
1. Do not switch on the unit if there
are persons (particularly children) or
animals in the immediate vicinity.
Ensure that children do not play with the
unit.
2. Interrupt blowing if you notice that
persons (particularly children) or pets
are nearby.
3. Do not blow any debris towards
people.
4. Avoid an abnormal body posture.
Ensure that you have a firm footing and
always keep your balance. You can then
better control the blower unit in
unexpected situations and particularly
on sloping areas.
5. Do not work with the blower in a
potentially explosive environment in
which there are flammable liquids,
gases or dust.
6. The blower may generate sparks
which could ignite the dust or the
vapors.
7. Do not use the blower unit near
open windows.
8. Be particularly careful when
walking backwards. There is a risk of
tripping!
9. Use the unit at walking pace only.
10. When interrupting work, never
leave the unit unattended and keep it in
a safe place.
Safety Instructions for The
Battery Charger
1. Keep the battery charger away from
rain or moisture. Penetration of
water in the battery charger
increases the risk of an electric
shock.
2. Keep the battery charger clean.
Contamination can lead to danger of
an electric shock.
3. Before each use, check the battery
charger, cable and plug. If damage
is detected, do not use the battery
charger. Never open the battery
charger yourself. Have repairs
performed only by a qualified
technician and only using original
spare parts. Damaged battery
chargers, cables and plugs increase
the risk of an electric shock.
4. Do not place any objects on the
battery charger and do not place the
battery charger on soft surfaces.
5. There is a risk of fire.
6. Always check that the mains voltage
matches the voltage indicated on
7
the rating plate of the battery
charger.
7. Never use the charger if cable, plug
or the unit itself has been damaged
by external influences. Take the
charger to the nearest service
center.
8. Never open the battery charger. If
the battery charger is defective, take it
to a service center.
Safety Instructions for Li-Ion
Batteries
1. Do not open the battery. There is
a risk of a short-circuit.
2. Protect the battery from heat, e.g.
from continuous exposure to sunlight,
fire, water and humidity.
3. There is a risk of explosion.
4. In case of damage and improper
use of the battery, vapors may be
emitted. Ventilate the area and seek
medical help in case of complaints. The
vapors can irritate the respiratory
system.
5. Under abusive conditions, liquid
may be ejected from the battery; avoid
contact. If contact accidentally occurs,
flush with water. If liquid contacts eyes,
additionally seek medical help.
6. Liquid ejected from the battery
may cause irritation or bums.
7. Use only original batteries with the
voltage indicated on the rating plate of
your electric power tool. If other
batteries are used, e.g. imitations,
reconditioned batteries or third-party
products, there is a risk of injuries as
well as damage caused by exploding
batteries.
8. The battery voltage must match
the battery charging voltage of the
battery charger. Otherwise, there is a
risk of fire and explosion.
9. Recharge only with the charger
specified by the manufacturer. A
charger that is suitable for one type of
battery pack may create a risk of fire
when used with another battery pack.
10. Pointed objects, such as nails or
screw-drivers, or external forces may
damage the battery. This may cause
internal short-circuit and the battery to
bum, smoke, explode or overheat.
8
MAJOR PARTS OF THE
BLOWER/VACUUM
1. Air Filter
2. Vacuum Pipe
3. Vacuum Tube
4. Wheels
5. Blow Tube
6. Blow Pipe
7. Vacuum/Collection Bag
8. Vacuum/Collection Discharge
9. Vacuum/Blower Switch
10. Top Grip Handle
11. Rear Handle
12. On/Off Trigger
13. Bayonet Catch/Release
9
PRODUCT SPECIFICATIONS
Tool
Blower/Vacuum
Model
EV480D
Rated Voltage
40V
Motor Type
Brushless
No-Load Speed
0-25,000 RPM
Blower
Air velocity
187 km/h
Air volume
4.4 m3/min
Vacuum
Air velocity
165 km/h
Air vacuum
9.8 m3min
Mulching Ratio
30:1
Weight
8.8 lbs
Battery
EP20
EP40
EP60
2.0Ah
4.0Ah
6.0Ah
50 mins
90 mins
117 mins
Tool Warranty
12 months
*You can extend the warranty by registering your
product online within 30 days of purchase
Battery Warranty
6 months
*You can extend the warranty by registering your
product online within 30 days of purchase
10
ASSEMBLY AND
OPERATION
GENERAL SAFETY
WARNING #1!
Before Initial Operation
Unpack the garden tool and accessories
and check that no parts are missing or
damaged.
NOTE: The batteries (optional;
depending on delivery scope) are not
fully charged on delivery. Prior to initial
operation, charge the batteries fully. See
user manual of the battery charger.
Assembly
Installing/Removing the
Blow Pipe
Tools are not required to install the
blower pipe.
1. Attach the blow pipe into the
connecting piece and secure by turning
it in clockwise direction (bayonet catch
engages).
2. The blower tube can be removed
for storage.
3. Just follow the reverse sequence
of the blow pipe installation to remove
the blow pipe.
Installing/Removing the
Vacuum Pipe
Tools are not required to install the
vacuum pipe.
1. Attach the vacuum pipe into the
connecting piece and secure by turning
it in clockwise direction (bayonet catch
engages).
2. The vacuum tube can be removed
for storage.
11
3. Just follow the reverse sequence
of the vacuum pipe installation to
remove the vacuum pipe.
Inserting/Replacing the
Battery
1. Charge the battery as described in
the user manual of the charger.
2. Press the charged battery into the
power tool until it clicks into place.
3. To remove, press the release
button (1) and pull out the battery (2).
GENERAL SAFETY
WARNING #2!
Switching On/Off the Power
Tool
Blower
Vacuum
12
Using the Blower
13
Using the Vacuum
14
Emptying the
Collection Bag
15
Battery Charger
Status Indicator Lights
The LED light indicates the operating
status and the state of charge of the
battery.
• LED steady red – The charger is ready
to charge but no battery is connected.
• LED flashes green - Battery is
charging.
LED steady green - The battery is fully
charged and can be removed.
• LED flashes red - Battery fault or
overheat
Charging the Battery
1. Plug the charger into an AC outlet
100-250V (normal household voltage).
2. Insert the battery into the slots of the
charger and slide
into place until the battery locks into
place
3. The LED will flash green while the
battery is charging.
- Once the battery is fully charged, the
LED indicator will show a steady green
light
- Remove the battery by pressing and
holding the latch button and sliding out
of the charger. Lithium Ion batteries
have no memory effect – a partial
charge will not damage your battery.
Battery State of Charge
Press the button to check the state of
charge at the state of charge indicator
LED.
The indicator goes out after 3 seconds.
If the LED lights red, the battery must be
recharged. If the LED doesn't light up
after the button is pressed, the battery is
faulty and must be replaced.
MAINTENANCE AND
CARE
GENERAL SAFETY
WARNING #1!
Cleaning
Do not use water or liquid detergents.
1. Remove dirt and dust from the
housing with a paintbrush and dry cloth.
16
2. Keep the ventilation slots clean and
free of dust.
Storage
1. Store the unit in a dry and frost-
free place (50-77 °C).
2. Store the battery and the unit
separately.
3. Charge the battery before storing
the unit in winter.
4. Keep the leaf blower, in particular
its plastic components, away from
flammable fluids, petroleum products,
penetrating oil, etc. They contain
chemical substances which may
damage, attack or destroy the plastic
components of the leaf blower.
5. Fertilisers and other garden
chemicals contain substances which
may have a highly corrosive effect on
the metal parts of the leaf blower.
17
Therefore do not store your leaf blower
near these substances.
Repair
Check the unit for damage. Repairs may
be earned out by an authorized customer
service centre only.
DISPOSAL
INFORMATION
GENERAL SAFETY
WARNING #3!
For EU countries only:
Do not throw electric power tools into the
household waste! In accordance with the
European Directive 2012/19/EC on
Waste Electrical and Electronic
Equipment and transposition into
national law, used electric power tools
must be collected separately and
recycled in an environmentally friendly
manner, samewith devices, accessories,
and packaging. Plastic parts are
identified for recycling according to
material type.
Do not open disused batteries.
Accumuiators/batteries should be
collected, recycled or disposed of in an
environmentally friendly manner, too.
For EU countries only:
In accordance with Directive
2006/66/EC defective or used batteries
must be recycled.
Please ask your dealer about the
disposal options!
18
GUARANTEE/
WARRANTY
This product has been manufactured to
the highest quality standards. When a
new product is purchased, it is
guaranteed a 12-month manufacturer’s
warranty which comes into force on the
date the product was purchased.
The guarantee covers only the defects
which can be attributed to a material
and/or production fault as well as non-
performance of warranted
characteristics. You can avail the 12-
month extension if you register this
product online within 30 days of
purchase.
When making a claim under the
guarantee, enclose the original sales
receipt with purchase date. Repairs
under the guarantee may be carried out
only by workshops or service centres
authorised by the manufacturer.
A claim may be made under the
guarantee only if the power tool has
been used as intended.
This warranty is invalid where defects
are caused by or result from:
- misuse, abuse or neglect;
- commercial use (industry, craft,
rental)
- repairs attempted by unauthorized
repair centers
- damage caused by external effects,
foreign objects, substances or
accidents.
Website: www.redbacktool.com
Email: support@redbacktool.com
Table of contents
Other Redback Blower manuals
