Redback E522D User manual

40V LITHIUM-ION CORDLESS
HEDGE TRIMMER
Model: E522D
Operations Manual
www.redbacktool.com [e-mail]

1
TABLE OF CONTENTS
•Symbols……………………........1
•Safety Instructions………………2
•Major Parts of the
Hedge Trimmer………………….9
•Product Specifications…………10
•Assembly and Operation………11
•Battery Charger Function.……..12
•Exploded View and Part List...16
•Maintenance and Care….…….17
•Disposal………………………..18
•Guarantee/Warranty………….19
These instructions should be read in
conjunction with the instruction manual
for the battery pack and charger.
SYMBOLS
Before using this tool, read
the operations manual.
Read all safety warnings
and all instructions. Failure to follow the
warnings and instructions may result in
electric shock, fire and/or serious injury
General Safety Warning
1. To avoid accidental operation and
injury, the battery should always be
removed whenever you are not using
the tool, before checking, cleaning, or
performing other work on the unit, and if
the unit starts vibrating excessively.
2. This trimmer is equipped with a
dual switch safety feature. The saw will
not operate unless both the front handle
switch and the rear handle switch are
engaged. NEVER attempt to interfere
with this safety feature
3. Protect the battery contacts when
the battery is not being used. Loose
metal parts may short-circuit the
contacts - Explosion and fire hazard!
Protective goggles/visor,
protective helmet & hearing
protection.
Wear non-slip, heavy-duty
protective gloves.
Do not expose to rain.
Do not throw batteries
and other electrical
products into the
household waste, fire, or water

2
Safety Instructions
User
This garden tool is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been
given supervision or instruction
concerning use of the machine by a
person responsible for their safety.
Never allow children or people
unfamiliar with these instructions to use
the garden tool. Supervise children. This
will ensure that children do not play with
the unit.
Intended Use
This garden tool is
-intended for cutting and trimming
hedges and bushes which have a
maximum branch thickness of 22 mm;
designed for maintaining hedges and
bushes in the private sector,
- not suitable ifor work above
shoulder height,
- to use according to the
descriptions and safety
instructions indicated in this
operating manual.
Any other use is not as intended.
Improper use is not covered by the
warranty and the manufacturer will
reject any liability. The user is liable for
all injuries to third parties and damage
to their property.
Operate the unit only in the technical
condition as stipulated and delivered by
the manufacturer.
Arbitrary changes to the unit will exclude
the manufacturer from any liability for
resulting injury and/or damage.
General Power Tool
Safety Warnings
The term "power tool" in the warnings
refers to your battery-operated
(cordless) power tool.
Work Area Safety
1. Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
2. Do not operate power tools in
explosive atmospheres, such as in the
presence of flammable liquids, gases, or
dust. Power tools create sparks which
may ignite the dust or fumes.
3. Keep children and bystanders away
while operating a power tool.
Distractions can cause you to lose
control.
Electrical Safety
1. Power tool plugs must match the

3
outlet. Never modify the plug in any way.
Do not use any adapter plugs with
earthed (grounded) power tools.
Unmodified plugs and matching outlets
will reduce the risk of electric shock.
2. Avoid body contact with earthed or
grounded surfaces, such as pipes,
radiators, ranges and refrigerators.
There is an increased risk of electric
shock if your body is earthed or
grounded.
3. Do not expose power tools to rain or
wet conditions. Water entering a power
tool will increase the risk of electric
shock.
4. Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep the cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase
the risk of electric shock.
5. When operating a power tool
outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable
for outdoor use reduces the risk of
electric shock.
6. If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected supply.
Use of an RCD reduces the risk of
electric shock.
Personal Safety
1. Stay alert, watch what you are doing
and use common sense when operating
a power tool. Do not use a power tool
while you are tired or under the
influence of drugs, alcohol, or
medication. A moment of inattention
while operating power tools may result
in serious personal injury.
2. Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing
protection used for appropriate
conditions will reduce the risk of injury.
3. Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to the power source and/or
battery pack, picking up, or carrying the
tool. Carrying power tools with your
finger on the switch or power tools that
have been turned on invites accidents.
4. Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a
rotating part of the power tool may
increase the risk of injury.
5. Do not overreach. Keep proper
footing and balance at all times. This
enables better control of the power tool
in unexpected situations.
6. Dress properly. Do not wear loose
clothing or jewelry. Keep your hair,
clothing and gloves away from moving

4
parts. Loose clothes, jewelry or long hair
can be caught by moving parts.
7. If devices are provided for the
connection of dust extraction and
collection facilities, ensure that these
are connected and properly used. Use
of dust collection can reduce dust-
related hazards.
Power Tool Use and Care
1. Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job
better and safer at the rate for which it is
designed.
2. Do not use the power tool if it can’t be
turned on and off by its switch. Any
power tool that cannot be controlled with
the switch is dangerous and must be
repaired.
3. Disconnect the plug from the power
source and/or the battery pack from the
power tool before making any
adjustments, changing accessories, or
before storing the power tool. Such
preventive safety measure reduces the
risk of starting the power tool
accidentally.
4. Store idle power tools out of reach of
children and do not allow persons
unfamiliar with the power tool or these
instructions to operate it. Power tools
are dangerous in the hands of untrained
users.
5. Maintain the power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other
condition that may affect the power
tool’s operation. If damaged, have the
power tool repaired before use. Many
accidents are caused by poorly
maintained power tools.
6. Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to
bind and are easier to control.
7. Use the power tool, accessories and
tool bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to be
performed. Use of the power tool for
operations different from those intended
could result in a hazardous situation.
Battery Tool Use and Care
1. Recharge only with the charger
specified by the manufacturer. A charger
that is suitable for one type of battery
pack may create a risk of fire when used
with another battery pack.
2. Use power tools only with specifically
designated battery packs. Use of any
other battery packs may create a risk of
injury and fire.
3. When battery pack is not in use, keep
it away from other metal objects like
paper clips, coins, keys, nails, screws,

5
or other small metal objects that can
make a connection from one terminal to
another. Shorting the battery terminals
together may cause burns or fire.
4. Under abusive conditions, liquid may
be ejected from the battery; avoid
contact. If you accidentally contact the
battery liquid, flush it with water. If the
battery liquid contacts the eyes, seek
medical help as soon as possible. Liquid
ejected from the battery may cause
irritation or burns.
Safety Instructions for
Hedge Trimmers
1. Keep all body parts away from the
cutter. Never attempt to remove the
clippings while the blade is running or
hold material which is to be cut. Before
removing any jammed clippings, switch
off the unit
2. A moment of inattention when
using the hedge trimmer may result in
serious injuries.
3. Carry the hedge trimmer by the
handle when the blade has stopped.
When transporting or storing the hedge
trimmer, always remove the battery and
pull on the guard. Handle the unit
carefully to reduce the risk of injury from
the blade.
4. Hold the electric power tool by the
insulated handle surfaces only, as the
cutter may touch concealed power lines.
If the cutter comes into contact with a
live line, metallic parts of the unit may
become energized and cause an electric
shock.
Additional Safety
Instructions
1. This unit is not designed to be
used by persons (including children)
who have limited physical, sensory or
mental abilities or who have inadequate
experience and/or knowledge of the
unit, unless they are supervised by a
person responsible for their safety or
they have been instructed by the person
how to use the unit Children should be
supervised to ensure that they do not
play with the unit.
2. Switch the unit off and remove the
battery under the following conditions:
-if the unit is left unattended;
-before checking, cleaning or
performing other work on the unit;
-if the unit starts vibrating excessively.
3. While cutting, ensure that there
are no persons (particularly children) or
animals in the working area. Ensure that
children do not play with the unit.
4. Before switching on the hedge
trimmer, ensure that the working area is
free of stones and pieces of wire. Look
out for them while cutting and search
the hedge for concealed objects, such
as wire fences.

6
5. Use the unit only in daylight or in
good artificial lighting.
6. Use the unit in dry conditions only.
Protect it from rain and moisture.
7. Ensure that the cutter does not
touch the ground or other objects.
8. Wait until the electric power tool
has come to a standstill before putting it
down.
9. When interrupting work, never
leave the unit unattended and keep it in
a safe place.
10. Always switch the hedge trimmer off
before transporting it to other
workplaces.
11. Never grasp the blade of the hedge
trimmer.
12. Ensure that all guards and
handles are fitted before using the unit.
Never attempt to switch on an
incompletely assembled unit or a unit
which has unauthorized modifications.
13. Operate the unit only in the
technical condition stipulated and
delivered by the manufacturer.
Unauthorized changes to the unit
exclude liability of the manufacturer for
any resulting damage and/or injury.
14. Spare parts must conform to the
requirements specified by the
manufacturer. Therefore use original
spare parts only or spare parts
authorized by the manufacturer. When
replacing parts, please follow the
supplied installation instructions and
remove the battery beforehand.
15. Have repairs carried out
exclusively by a qualified technician or a
service center.
Safety Instructions for The
Battery Charger
1. Keep the battery charger away
from rain or moisture. Penetration of
water in the battery charger increases
the risk of an electric shock.
2. Keep the battery charger clean.
Contamination can lead to danger of an
electric shock.
3. Before each use, check the
battery charger, cable and plug. If
damage is detected, do not use the
battery charger. Never open the battery
charger yourself. Have repairs
performed only by a qualified technician
and only using original spare parts.
Damaged battery chargers, cables and
plugs increase the risk of an electric
shock.
4. Do not place any objects on the
battery charger and do not place the
battery charger on soft surfaces.
5. There is a risk of fire.
6. Always check that the mains
voltage matches the voltage indicated
on the rating plate of the battery
charger.

7
7. Never use the charger if cable,
plug or the unit itself has been damaged
by external influences. Take the charger
to the nearest service center.
8. Never open the battery charger. If
the battery charger is defective, take it
to a service center.
Safety Instructions for Li-
Ion Batteries
1. Do not open the battery. There is
a risk of a short-circuit.
2. Protect the battery from heat, e.g.,
from continuous exposure to sunlight,
fire, water and humidity.
3. There is a risk of explosion.
4. In case of damage and improper
use of the battery, vapors may be
emitted. Ventilate the area and seek
medical help in case of complaints. The
vapors can irritate the respiratory
system.
5. Under abusive conditions, liquid
may be ejected from the battery; avoid
contact. If contact accidentally occurs,
flush with water. If liquid contacts eyes,
additionally seek medical help.
6. Liquid ejected from the battery
may cause irritation or bums.
7. Use only original batteries with the
voltage indicated on the rating plate of
your electric power tool. If other
batteries are used, e.g. imitations,
reconditioned batteries or third-party
products, there is a risk of injuries as
well as damage caused by exploding
batteries.
8. The battery voltage must match
the battery charging voltage of the
battery charger. Otherwise, there is a
risk of fire and explosion.
9. Recharge only with the charger
specified by the manufacturer. A
charger that is suitable for one type of
battery pack may create a risk of fire
when used with another battery pack.
10. Pointed objects, such as nails or
screw-drivers, or external forces may
damage the battery. This may cause
internal short-circuit and the battery to
bum, smoke, explode or overheat.
Noise and Vibration
NOTE: Values for the A-weighted sound
pressure level and for the total vibration
values can be found in the "Product
Specifications" table. The indicated
measurements refer to new power tools.
Daily use causes the noise and vibration
values to change.
The vibration emission level given in this
information sheet has been measured in
accordance with a standardized test
given in EN 60745 and may be used to
compare one tool with another. It may
be used for a preliminary assessment of
exposure. The declared

8
vibration emission level represents the
main applications of the tool. However if
the tool is used for different applications,
with different accessories or poorly
maintained, the vibration emission may
differ. This may significantly increase
the exposure level over the total working
period. However if the tool is used for
different applications, with different
accessories or poorly maintained, the
vibration emission may differ. This may
significantly decrease the exposure level
over the total working period. Identify
additional safety measures to protect
the operator from the effects of vibration
such as: maintain the tool and the
accessories, keep the hands warm,
organization of work patterns.
Wear ear protection at a sound pressure
above 85 dB(A).
Service
Have your power tool serviced by a
qualified repair professional using only
the identical replacement parts. This
will ensure that the safety of the power
tool is maintained.

9
MAJOR PARTS OF THE
HEDGE TRIMMER
1. Battery pack
2. Rear Handle
3. Trigger Switch
4. Front Handle
5. Cutting blade
6. Protective guard
7. Front handle switch
8. Handle rotation lock button
9. Trigger lock button

10
PRODUCT SPECIFICATIONS
Tool
Hedge Trimmer
Model
E522D
Electrical Voltage
40 V
Cutting length
22”
Cutting diameter
0.71” (18mm)
No-Load Speed
1300 RPM
Motor Type
Brush
Teeth Pitch
0.86” (22mm)
Battery
EP20
EP40
EP60
2.0Ah
4.0Ah
6.0Ah
40 mins
95 mins
140 mins
Weight
7.1 lbs (3.2 kg)
Tool Warranty
12 months
*You can extend the warranty by registering your
product online within 30 days of purchase
Battery Warranty
6 months (limited)
*You can extend the warranty by registering your
product online within 30 days of purchase
Model
E522d
Rated Voltage
40V DC
Linear No Load Speed
1300rpm
Blade Length
22”
Weight (without EP40
battery pack)
7 lbs
Cutting Capacity
0.87”
Guaranteed Sound
Power Level
92 dB(A)
Vibration
Uncertainty K=
1.5m/s2
＜2.5m/s2
Battery Pack
Lithium Ion – EP20, EP40 or
EP60 (2.0, 4.0, or 6.0Ah)
Battery Charger
EC20 or EC50 (2.0A or
5.0A)
Model
E522d
Rated Voltage
40V DC
Linear No Load Speed
1300rpm
Blade Length
22”
Weight (without EP40
battery pack)
7 lbs
Cutting Capacity
0.87”
Guaranteed Sound
Power Level
92 dB(A)
Vibration
Uncertainty K=
1.5m/s2
＜2.5m/s2
Battery Pack
Lithium Ion – EP20, EP40 or
EP60 (2.0, 4.0, or 6.0Ah)
Battery Charger
EC20 or EC50 (2.0A or
5.0A)
Model
E522d

11
ASSEMBLY AND
OPERATION
GENERAL SAFETY
WARNING #1!
Before Initial Operation
Unpack the garden tool and accessories
and check that no parts are missing or
damaged.
NOTE: The batteries (optional;
depending on delivery scope) are not
fully charged on delivery. Prior to initial
operation, charge the batteries fully. See
user manual of the battery charger.
Inserting/Replacing the
Battery
•Charging the battery as described in
the user manual of the charger.
•Press the charged battery into the
power tool until it clicks into place.
•To remove, press the release button
(1) and pull out the battery (2).
GENERAL SAFETY
WARNING #3!
Adjusting the Rear Handle
Depending on the planned use the rear
handle can be rotated from the middle
position by 90° in either direction.
•Press the release button
downwards (1.) and simultaneously
rotate the rear handle to the left or right
(2.), until it clicks.
Rated Voltage
40V DC
Linear No Load Speed
1300rpm
Blade Length
22”
Weight (without EP40
battery pack)
7 lbs
Cutting Capacity
0.87”
Guaranteed Sound
Power Level
92 dB(A)
Vibration
Uncertainty K=
1.5m/s2
＜2.5m/s2
Battery Pack
Lithium Ion – EP20, EP40 or
EP60 (2.0, 4.0, or 6.0Ah)
Battery Charger
EC20 or EC50 (2.0A or
5.0A)

12
NOTE: The hedge trimmer will not turn
on when the rear handle is not securely
engaged in the respective end position.
Switching the Trimmer
On/Off
GENERAL SAFETY
WARNING #2!
NOTE: Two-hand safety circuit
The hedge trimmer is switched on and
operated with both hands. One hand
operates the switch on the rear handle,
the second hand the safety switch on
the handlebar, if you release either of
the two switches, the cutter bar
automatically stops.
Switching On
1. Hold the hedge trimmer firmly with
both hands and ensure that there are no
persons (particularly children) or
animals in the immediate vicinity.
2. Press and hold down the switch
interlock (1).
3. Press the switch (2) and the safety
switch (3). The hedge trimmer runs.
Switching Off
Release either of the two switches. The
cutter bar stops.
Battery Charger
Status Indicator
Lights
The LED light indicates the operating
status and the state of charge of the
battery.
• LED steady red – The charger is ready
to charge but no battery is connected.
• LED flashes green - Battery is
charging.
• LED steady green - The battery is fully
charged and can be removed.
• LED flashes red - Battery fault or
overheat

13
Charging the Battery
1. Plug the charger into an AC outlet
100-250V (normal household voltage).
2. Insert the battery into the slots of the
charger and slide
into place until the battery locks into
place
3. The LED will flash green while the
battery is charging.
- Once the battery is fully charged, the
LED indicator will show a steady green
light.
- Remove the battery by pressing and
holding the latch button and sliding out
of the charger. Lithium Ion batteries
have no memory effect – a partial
charge will not damage your battery.
Battery State of Charge
Press the button to check the state of
charge at the state of charge indicator
LED.
The indicator goes out after 3 seconds.
If the LED lights red, the battery must be
recharged. If the LED doesn't light up
after the button is pressed, the battery is
faulty and must be replaced.
Cleaning the Cutter Bar
(after each use)
•Remove the battery.
•Clean the cutter bar after each use.
Remove contamination, remains of
blades etc.
•Spray the cutter bar with
maintenance oil to ensure that the
hedge trimmer has a long service life.
Preferably use environmentally friendly
lubricants, e.g. service sprays.
CAUTION! Do not oil the hedge trimmer
while it is running.
Work Instructions
1. Check that all parts are firmly
attached and obviously undamaged.
2. Look over the working area and
remove any obstructions. Remove all
foreign objects from the hedge, such as
wire or other parts, as these may block
or damage the cutting mechanism.
3. Cut out thick branches beforehand
using pruning shears.
4. Pick up the power tool in both
hands as specified.
5. Always cut at full engine speed.
6. Start cutting only with the cutting
mechanism running.
7. The impact guard protects you
against unpleasant impacts, e.g. recoil
torque of the cutter, when striking a solid
object (wall, ground, etc.).

14
8. Never touch wire fences or the
ground with the running cutting
mechanism. If cutting hedges over a
prolonged period, interrupt your work
more frequently and oil the cutter bar.
9. Switch the engine off and remove
the battery:
-to remove blockages (jammed
clippings) from the cutting bar;
-if the unit behavior changes or it
vibrates unusually;
-if you have come into contact with
foreign objects or the ground;
-when taking breaks and leaving the
unit unattended.
NOTE: If the power tool is damaged or
vibrates unusually, it must be repaired by
a service center before it is used again.
10. After use, stop the motor and wait
until all rotating parts have come to a
standstill.
11. Place the protection hood on the
cutter bar.
Cutting Techniques
The hedge trimmer can be guided with
its double-sided cutters forwards and
backwards or in an oscillating
movement.
•Cut the sides of the hedge first and
then the top.
- When cutting sideways, hold the
handlebar sideways.
- When cutting low down, hold the
handlebar above.
•Cut the hedge from bottom to top.
•Hold the hedge trimmer at an angle of
5-10°to the hedge to ensure a
straight cut.
•Cut the hedge in a trapezoidal
shape. This prevents the lower part of
the hedge from losing its foliage due to
lack of light.

15
•Cut the upper edges of the hedge
slightly round.
•Cut in several stages if heavy
trimming is required.
•Peg out a string line if you want to cut
the hedge evenly.
•Trim the young hedge plants to the
required shape. The main shoot should
not be damaged until the hedge has
reached the required height. All other
shoots can be cut back to half their
height. Dispose of the clippings properly
and in an environmentally friendly
manner.
•Cutting times:
- Deciduous hedges-June and
October
- Evergreen hedges - April and
August
- Fast growing hedges (e.g.
conifers) - from May approx, every 6
weeks
NOTE: Beware of nesting birds in the
hedge. Do not cut the hedge until birds
have fledged or do not cut this part of
the hedge.
Operating the Hedge
Trimmer
1. Do not force the hedge trimmer
through heavy shrubbery. This can
cause the blades to bind and slow
down. If the blades slow down, reduce
the pace
2. Do not try to cut stems or twigs
that are larger than 15 mm thick, or
those
obviously
too large
to feed
into the
cutting
blade.
Use a hand saw or pruning cutters to
trim large stems.
3. An easy way to keep your hedge
level is to run a string line guide. Stretch
a piece of string along the hedge just
below your intended cutting line. Trim
the hedge just above this guide line.
4. Trim the side of a hedge so that it
tapers slightly towards the top (the
hedge will be slightly wider at the bottom
than at the top. This improves the

16
strength of the hedge and allows more
light to reach the leaves.
5. If the blades do become jammed,
release the trigger switch and allow the
blades to stop. Remove the battery pack
before attempting to remove the
obstruction.
6. Wear gloves when trimming
thorny or prickly growth.
7. When trimming new growth, use a
wide sweeping action, so that the stems
are fed directly into the cutting blade.
Older growth will have thicker stems and
will be trimmed easiest by using a
sawing movement.

17
EXPLODED VIEW AND
PARTS LIST
No.
Part No.
Description
QTY
No.
Part No.
Description
QTY
1
40V battery pack
1
33
20140110
center bracket
1
2
20920090
Left housing
1
34
60140120
Screw
2
3
21060230
Left handle
1
35
60200070
Washer
2
4
21060250
Right handle
1
36
70670270
Gear wheel
1
5
30030050
Micro switch
1
37
60010310
608 bearing
2
6
20470070
Rocker arm
1
38
70030600
Drive axle
1
7
60390170
Spring
1
39
60070160
Screw
2
8
60390160
Spring
3
40
60390150
Brake spring
1
9
60380380
Pressure spring
1
41
70670120
Gear wheel
1
10
20530070
Push button
1
42
60190150
Flat washer
1
11
20530120
Locking segment
1
43
60240050
Spring washer
1
12
30010150
PCB board
1
44
71260170
Cam disk
1
13
20800080
Plug pin
1
45
60200070
Washer
2
14
60140130
Screw
2
46
Cam bit
2
15
60170140
Tapping screw
2
47
Pressure board
1
16
60070130
Tapping screw
4
48
cylinder pin
2
17
20590050
Rubber washer
1
49
20140120
Bracket cover
1
18
20760030
Plug in seat
1
50
60090060
Screw
2
19
70630150
Plug in unit
4
51
60210040
Spring washer
2
20
20920100
Right housing
1
52
60190280
Blade washer
8
21
60170680
Self tapping screw
29
53
70150400
Washer
2
22
60190200
Flat washer
2
54
Screw
6
23
20920110
Protection guard
1
55
21140010
Blade sleeve
1
24
20260140
Right handle cover
1
56
20350060
Blade plug
1
25
20260130
Left handle cover
1
57
Aluminum support
bar
1
26
60070150
Screw
2
58
Iron support board
1
27
20260120
Rocker arm
1
59
Blade
2
28
20260110
Bracket
1
60
protection head
1
29
30020070
Start switch
1
61
Spacer
6
30
30010140
Motherboard
3
62
locking nut
6
31
30070040
Motor
1
32
70670260
Motor gear
1

18
MAINTENANCE AND
CARE
GENERAL SAFETY
WARNING #1!
For your own safety, perform
only the maintenance work
described here by yourself. All other
work, in particular motor
maintenance and repairs, must be
performed by a trained specialist,
improper work may damage the
power tool and also result in injuries.
Have this power tool inspected once
a year at a service center.
Cleaning
CAUTION! Do not use water or liquid
detergents. Clean the unit after every use.
Failure to dean the unit can damage the
materials and cause malfunctions.
1. After each use, clean the hedge
trimmer using a dry cloth or a brush if the
unit is very dirty.
2. Never spray the hedge trimmer with
water.
3. Keep the ventilation slits clean and
dust-free.
4. Clean the cutter bar after each use.
Remove contamination, remains of blades
etc.
5. Spray the cutter bar with maintenance
oil to ensure that the hedge trimmer has a
long service life. Preferably use
environmentally friendly lubricants, e.g.
service sprays.
6. Place the hedge trimmer on its side
and apply a thin film of oil to the cutter bar.
Blade Care
1. Lubricate the cutting blades after each
use.
2. Periodically inspect the blades for
damage and wear.
3. Always use the manufacturer's specified
replacement blades.
To Lubricate The Blade
1. For easier operation and longer blade
life, lubricate the hedge trimmer blade
before and after each use.
2. Before lubricating, remove the battery
pack and lay hedge trimmer on a flat
surface.
3. Apply light machine oil along the edge of
the top blade.
4. Always remove the battery pack before
lubricating the blades and never apply oil
to moving blades
Storage
1. Clean the hedge trimmer thoroughly
before storing. Store the hedge trimmer
with the battery removed in a dry, well-
ventilated place that is inaccessible to
children. Keep away from corrosive agents
such as garden chemicals and deicing
salts.

19
2. Always fit the blade cover over the
blades before storage. This will protect the
blades from damage and prevent injury on
the sharp blades.
3.Store and charge your batteries in a cool,
dry area (50-77 °F). Temperatures above
or below normal room temperature will
shorten battery pack life.
4. Never store the battery in a discharged
condition. Wait for the battery to cool and
recharge before storage.
Repair
Check the unit for damage. Repairs may be
earned out by an authorized customer
service center only.
DISPOSAL
INFORMATION
Render redundant garden tools
unusable:
- Main-operated tool by removing the
power cord,
- Battery-operated tool by removing the
battery.
For EU countries only:
Do not throw electric power tools into the
household waste! In accordance with the
European Directive 2012/19/EC on Waste
Electrical and Electronic Equipment and
transposition into national law, used electric
power tools must be collected separately
and recycled in an environmentally friendly
manner, same with devices, accessories,
and packaging. Plastic parts are identified
for recycling according to material type.
Do not open disused batteries.
Accumuiators/batteries should be
collected, recycled or disposed of in an
environmentally friendly manner, too.
For EU countries only:
In accordance with Directive 2006/66/EC
defective or used batteries must be
recycled.
Please ask your dealer about the disposal
options!
GUARANTEE/
WARRANTY
This product has been manufactured to the
highest quality standards. When a new
product is purchased, it is guaranteed a
12-month manufacturer’s warranty which
