Redblock N1014-M User manual

INDUSTRIES LLP
REDBLOCK SHOWER NICHE
INSTALLATION MANUAL
N1014-M Shower Niche
N1028-M Shower Niche

TECHNICAL DRAWINGS
N1014-M
254mm
10”
19mm
3/4”
28mm
1 1/8”
13mm
1/2”
103mm
4”
15mm
5/8”
268mm
10 1/2”
356mm
14”
91°
437mm
17 3/16”
335mm
13 3/16”

N1028-M
254mm
10”
19mm
3/4”
28mm
1 1/8”
103mm
4”
15mm
5/8”
84mm
3 5/16”
280mm
11 1/16”
340mm
13 3/8”
710mm
28”
792mm
31 3/16”
335mm
13 3/16”
91°
13mm
1/2”
TECHNICAL DRAWINGS

A - Standard stud bay width
B - Rough-in height for niche install
N1014: 15 1/8"
N1028: 29 1/8"
1 2
INSTALLATION
34
x
x
x
x
x
x
Cutout: N1014-M: 10 1/8" x 14 1/8"
N1028-M: 10 1/8" x 28 1/8"
Note: Cutout should be 1 1/4" from stud
Stud center
line
center line (1/2" from stud face).

Over-tightening will distort the flange.
Tighten screws only until the flange
makes firm contact with backer board.
Apply secondary waterproofing around
the niche perimeter:
5
x
x
x
x
x
x
x
x
6
We recommend the application of Wedi Subliner Dry™ sheet waterproofing
membrane around the niche perimeter as a secondary waterproofing layer,
using Wedi Joint Sealant as an adhesive. Adhesion of Subliner Dry to the Redblock
Niche (with Wedi Sealant), has been verified via lab testing. Please be sure to
protect the tiling flange with masking tape before applying sealant.
™ Wedi and Wedi Subliner Dry are registered trademarks of Wedi GmbH
To protect the raised tiling flange
from damage, please cover it with
masking tape before proceeding.
If you're installing a liquid
membrane, please ignore steps 6-9.

x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
78
If a liquid waterproofing membrane is being applied instead of a sheet membrane, \RX
PXVWHQVXUHFRPSOHWHFRYHUDJH of the mounting flange and of the margin between
backer board and flange.
Please be sure to protect the tiling flange with masking tape before this application.

12
11
x
x
x
x
x
x
x
x
10
x
x
x
x
9
Use a groat float to press membrane
firmly into sealant and mortar.

CAUTION: PLEASE DO NOT USE ANY CLEANER THAT CONTAINS
CHLORINE BLEACH or any chlorinates.
Chlorine bleach can damage stainless steel and all other metal
surfaces over time.
If you insist on using a chlorine bleach containing cleaner in your
shower, try to avoid the niche and/ or shelf surfaces and promptly
remove any residue that may end up on these surfaces.
We recommend that you use only non-abrasive cleansers for
cleaning our products. The first cleaning step should always be
with warm water, a clean rag (or sponge), and a little bit of scrub-
bing. A mild liquid dish detergent can also be used (as long as it
does not contain chlorine bleach – see above). To reduce the
chance of scratching, take care to wipe in the direction of the
grain (direction of SS striations).
Another option would be *OxiClean powder dissolved in water. If
you would like more details on this or other cleaning options,
please visit our Stainless Steel Cleaning Page.
!
* OxiClean is a registered trademark of Church & Dwight Co., Inc.

INDUSTRIES LLP
2950 Newmarket St. #101-191 | Bellingham WA 98226 | T: 1-877-347-8148
[e-mail] | www.redblockindustries.com
