USER MANUAL
Please read and keep these instrucons
OVER BED / CHAIR TABLE
RG624
Edion 1

redgumbrand.com.au
REDGUM Brand owns the copyright to the Over Bed / Chair Table user manual.
Any informaon contained in this user manual shall not be photocopied, reproduced or
translated into any other languages without the prior wrien consent of REDGUM Brand.
REDGUM Brand strives to provide the highest quality products possible.
Products are subject to change without noce.
© Copyright REDGUM Brand 2021
REDGUM Brand is part of FOR-DE Group Pty Ltd

redgumbrand.com.au
CONTENTS
1. INTRODUCTION - INTENDED USE
2. PRODUCT OVERVIEW - FEATURES / SPECIFICATIONS
3. ASSEMBLY - UNPACK and INSPECT SUPPLIED PARTS
4. ASSEMBLY - CASTOR INSTALLATION
5. ASSEMBLY - UPRIGHT INSTALLATION
6. ASSEMBLY - PLATFORM INSTALLATION
7. ASSEMBLY - LEVER INSTALLATION
8. OPERATION - PLATFORM HEIGHT ADJUSTMENT
9. OPERATION - LOCKING CASTORS
10. USAGE GUIDELINES - DO’s + DON’Ts
11. PRODUCT CARE - INSPECTIONS / CLEANING
12. WARRANTY

redgumbrand.com.au
INTRODUCTION
Thank you for purchasing this quality REDGUM Brand product.
If you have any issues or quesons about the Over Bed / Chair Table
please contact your supplier or REDGUM Brand direct:
T: [phone]
F: [phone]
E: [e-mail]
A: 1 Business Way, Malaga Western Australia 6090
INTENDED USE
This product has limitaons and should be used in accordance to these guidelines.
Failure to follow these guidelines may result in damage to the product and injury
to the user. It is the responsibility of the user to ensure the suitability of this product
for its intended use. The user should consult their appropriate healthcare
professional if unsure of the correct product usage for their unique circumstances.
Only use your Over Bed / Chair Table for the purpose for which it is intended, which
is as a plaorm that can be adjusted in height and posioned to suit the users
individual requirements.
IMPORTANT NOTE
This equipment MUST be assembled
by a competent person.
1.

redgumbrand.com.au
PRODUCT OVERVIEW
FEATURES
Stable working surface
Easy clean surface - vinyl wrapped
Height adjustable plaorm
Low clearance base to t under beds
Twin wheel locking castors
Epoxy powder coated metal frame
Chrome mild steel upright
Can be at packed for storage or transport
SPECIFICATIONS (All dimensions shown are nominal)
Dimensions:
Plaorm Width: 805mm
Plaorm Depth: 385mm
Plaorm Height: 715 - 1125mm
Base Frame Width (internal): 800mm
Base Frame Height: 90mm
Castors: Ø50mm plasc twin wheel locking castors
Product Weight: 11kg
Maximum Weight Loading: 12kg - evenly distributed
Please contact REDGUM Brand if you would like any further informaon
on your Over Bed / Chair Table.
2.

redgumbrand.com.au
ASSEMBLY- UNPACK and INSPECT SUPPLIED PARTS
Ensure you have been supplied with the following parts:
IMPORTANT NOTE
Check the product for any visible damage.
If you see any damage or suspect a fault,
DO NOT USE YOUR PRODUCT and contact
your supplier for support.
3.
1 x UPRIGHT
1 x BOLT 1
(Not to scale)
1 x PLATFORM
1 x BASE
4 x CASTOR
(Not to scale)
1 x SPANNER
(Not to scale)
1 x LEVER
(Not to scale)
2 x BOLT 2
(Not to scale)
2 x BOLT 3
(Not to scale) 1 x SCREW
(Not to scale) 1 x NUT
(Not to scale)
TOOLS REQUIRED
AND NOT SUPPLIED:
- PHILLIPS HEAD
SCREW DRIVER
- ADJUSTABLE SPANNER

redgumbrand.com.au
ASSEMBLY - CASTOR INSTALLATION
Please follow these steps to install the castors onto the base:
1. Lie the base down with the 4 holes on underside facing up.
2. Hand wind in castors (Ensure castors with brakes are ed to end of base frame).
3. Using the spanner provided - ghten castors.
4.
Hand wind castors into tapped holes
on underside of base
Tighten nut using
spanner provided
NOTE:
Ensure all castors are
suciently ghtened
Castor
Castor
Castor
Castor

redgumbrand.com.au
5.
ASSEMBLY- UPRIGHT INSTALLATION
Please follow these steps to install the upright onto the base:
1. Posion base on side as shown.
2. Line up holes in underside of upright with holes in base.
3. Hand wind in both bolts (Bolt 2 to be used).
4. Using the spanner supplied - ghten both bolts.
Upright
Base
Bolt 2
Tighten bolts using
spanner provided
NOTE:
Ensure both bolts are
suciently ghtened

redgumbrand.com.au
6.
OPERATION - PLATFORM INSTALLATION
Please follow these steps to
install plaorm to the upright:
1. Align plaorm with upright as shown.
2. Slide mount on underside of plaorm
into u plate on top of upright.
3. Line up holes in both mount plates.
4. Hand wind in both bolts
(Bolt 3 to be used).
5. Using the spanner
supplied - ghten
both bolts.
Tighten bolts using
spanner provided
Bolt 3

redgumbrand.com.au
ASSEMBLY - LEVER INSTALLATION
Please follow these steps to install
the lever onto the upright:
1. Line up the lever with the
curved back facing toward
plaorm.
2. Align hole in lever with
holes in upright mount.
3. Slide bolt 1 though
aligned holes.
4. Hand wind nut onto bolt.
5. Using spanner provided
and adjustable spanner
- ghten nut.
7.
Lever
Curved back on lever
to be facing up
Bolt 1
Nut
NOTE:
Ensure nut is suciently ghtened

redgumbrand.com.au
8.
IMPORTANT NOTE:
It is recommended that all items are
removed from the plaorm prior to
adjusng height.
Maximum load: 12kg (Evenly distributed)
OPERATION - PLATFORM HEIGHT ADJUSTMENT
IMPORTANT NOTE:
Prior to adjusng the plaorm height
the transport locking bolt needs
to be removed.
Using a phillips
head screw driver:
1. Remove the bolt
in upright.
2. Replace the bolt
with screw.
Please follow these steps
to adjust the height of
the plaorm:
1. Pull up on the lever.
2. With the lever pulled up
- adjust the plaorm to the required height.
(Pull up or push down)
3. Release the lever to set the
plaorm at the height.
Remove transport bolt
and replace with screw
Screw

redgumbrand.com.au
9.
OPERATION - LOCKING CASTORS
The Over Bed / Chair Table
has 4 locking swivel castors:
To LOCK the castor:
Using your foot - press DOWN on the brake pedal.
To UNLOCK the castor:
Using your foot - push UP on the brake pedal.
Push down
on pedal to
LOCK castor Push up
on pedal to
UNLOCK castor

redgumbrand.com.au
USAGE GUIDELINES - DO’s + DON’TS
Please follow these guidelines to get the
opmal benet from the Over Bed / Chair Table.
Failure to follow these guidelines
may result in damage to the
Over Bed / Chair Table and
put the user at risk.
The Over Bed / Chair Table is designed
to take 12kg Maximum Load (evenly distributed).
Do not overload the table!
Ensure any fasteners are
adequately ghtened aer
assembly and adjustment.
It is recommended that all items
are removed from the plaorm prior to adjusng height.
Do not use this product as a walking aid or as a sing / standing aid.
Ensure all castors are unlocked prior to moving table. Lock castors when appropriate.
This product is designed for INDOOR USE only.
Over Bed / Chair table can be pulled apart
for storage or transport if required and
reassembled for use.
10.

redgumbrand.com.au
11.
REDGUM Brand PRODUCT RANGE
INSPECTIONS
We suggest that you visually check the Over Bed / Chair Table periodically for signs of
damage or wear prior to use. Overall check that no components are loose or worn.
Please check all aspects paying parcular aenon to the following areas :
- Plaorm
- Frame
- Castors (Free wheeling - remove any built up material ie. hair / lint)
- Height adjustment lever
Withdraw the Over Bed / Chair Table immediately if you suspect damage
or any other fault. If in any doubt, please do not issue or use, but
immediately contact your supplier for service support.
IMPORTANT NOTE
Do not t any parts or accessories
to your Over Bed / Chair Table that
are manufactured by another company.
To do so will void your warranty and
may seriously compromise your safety.
CLEANING
Clean the Over Bed / Chair Table
using a non-abrasive cleaner or
mild detergent with a so cloth.
Abrasive cleaners or abrasive cleaning pads
could damage the Over Bed / Chair Table
and should not be used.
Inspect and remove any debris
(including hair / lint) from castors.

redgumbrand.com.au
12.
WARRANTY
The REDGUM Brand RG624 - OVER BED / CHAIR TABLE
is covered by a 12 Month Warranty from the date of purchase.
If the product has any manufacturing faults during this period contact the place of
purchase for assessment. Failures as a result of ACCIDENTAL MISUSE, MODIFICATION
OR WEAR AND TEAR ARE NOT COVERED BY THIS WARRANTY.
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entled to a replacement part for a major failure and for
compensaon for any other reasonably foreseeable loss or damage. You are entled
to have the goods repaired or replaced if the goods fail to be of acceptable quality
and failure does not amount to major failure.
If you have any issues or quesons
about your Over Bed / Chair Table
please contact your supplier or
REDGUM Brand direct on:
T: [phone]
F: [phone]
E: [e-mail]
A: 1 Business Way, Malaga
Western Australia 6090
Please keep this User Manual
in a safe place for future reference.

redgumbrand.com.au
DISTRIBUTOR:
Proudly Australian Owned and Operated
