The model A2X90-VM 96x48 loop powered display is a universal local display
suitable for use with various transmitters. The transmitter must be fitted with an
analogue output and a terminal blocks.
The display is user programmable. Scaling, the position of the decimal point,
gate time and switch point may be set with two keys. The menu steps are output
to the LED display field.
6. Mechanical Data
The instrument is setted up for panel mounting.
It is fixed in place with the two clamps provided.
The maximum permitted panel thickness is 4mm.
Make all electrical connections with power supply off.
Take care to ensure electrical connections are correct.
Insert the clamps into the button-holes in the right and left sides of the
instrument and put them in tension turning the pin with a screw -driver (slot or
cross, 4 mm).
Make all electrical connections are correct as showed in the schemas below.

A2X90-VM
FT00536-0.00-0179FV A2X90-VM -page 5/12
7. Electrical Connection
Connect the plug-on display as shown in the wiring diagram.
Connector assignment
PIN 1 Switch out
PIN 2 GND
PIN 3 +VS
PIN 4 /
PIN 5 /
PIN 6 /
PIN 7 /
PIN 8 /
PIN 9 /
PIN 10 /
PIN 11 /
PIN 12 /

A2X90-VM
FT00536-0.00-0179FV A2X90-VM -page 6/12
Auxiliary power
The auxiliary power (typically 24 VDC) must be greater than the voltage drop
across the sensor, the voltage drop across the display (5 V) and any other
voltage losses (additional evaluation, cable losses).
Ub =Us + Ua + 5V (Us = other voltage losses)
Switching output
The operating voltage Ub at PIN 1is connected through via a PNP-transistor
when reaching the switching threshold. The max. current load constitutes 60
mA.
Connection exampleA2X90-VM

A2X90-VM
FT00536-0.00-0179FV A2X90-VM -page 7/12
8. Commissioning
8.1 Adjusting the Display
A èDownward and selection of menu items
B èUpward and selection menu items
A+B èEnter menu selection for adjustment or to exit acknowledge setting
8.2 Decimal Point
Press key B until: is displayed.
Press A+B to enter adjustment menu:
Press B or Afor up and down:
Press A+B to acknowledge setting and return to menu item “dP”
d
P
-
-
-
.
-
-
-
.
-
-

A2X90-VM
FT00536-0.00-0179FV A2X90-VM -page 8/12
8.3 Zero-Point (value to be displayed for 4 mA)
Press key B until: is displayed.
Press A+B to enter adjustment menu: for example: (0 bar)
Press B or Afor up and down
Press A+B to acknowledge setting and return to menu item “IS”
8.4 Span (value to be displayed for 20 mA)
Press key B until: is displayed.
Press A+B to enter adjustment menu:
Press B or Afor up and down: (for example: 60 bar)
Press A+B to acknowledge setting and return to menu item “FS”
8.5 Damping
Press key B until: is displayed.
Press A+B to enter adjustment menu:
(min. = 0.3 s; max. = 20.0 s)
Press B or Afor up and down: (for example: 1,5 sec)
Press A+B to acknowledge setting and return to menu item “Int”
8.6 Range Exceeded
(indication of less than 4 mA or greater than 20 mA)
Indicates “HI” if the upper limit or “LO” if the lower limit is exceeded
Press key B until: is displayed.
Press A+B to enter adjustment menu: message disabled
Press B or Afor up and down: message enabled
Press A+B to acknowledge setting and return to menu item “ISFS”
Indication: “HI” = Upper range exceeded, “LO” = Lower range exceeded
I
S
0.
0
0
F
S
0.
0
0
6
0.
0
0
I
n
t
0.
3
1.
5
I
S
F
S
O
F
F
o
n

A2X90-VM
FT00536-0.00-0179FV A2X90-VM -page 9/12
Attention: When the “HILO” indication is enabled,
error code “HI” or “LO” is displayed if the scale
range (-1999 (LO) to +9999 (HI)) is exceeded.
8.7 Switching Point
Press key B until: is displayed.
Press A+B to enter adjustment menu:
Press B or Afor up and down (20 bar)
Press A+B to acknowledge setting and return to menu item “SEt”
Attention: The standard hysteresis is the adjusted
switching point minus 3 digits (first digit resp.
first position right). On customer‘s request the
hysteresis can be factory-set.
8.8 Switching direction
Press key B until: is displayed.
Press A+B to enter adjustment menu:
(hysteresis via switching point, inverse)
Press B or Afor up and down
(hysteresis below switching point)
Press A+B to acknowledge setting and return to menu item “ALL”
8.9 Return to Measuring Mode
Depending on the selected menu point, press keyA or B fromone to eight
times.
9. Technical Information
9. Technical Information
S
E
t
2
0.
0
0
0.
0
0
A
L
L
H
I
L
O

A2X90-VM
FT00536-0.00-0179FV A2X90-VM -page 10/12
Display: 4-digit red LED display,
Digit height: 12,5 mm
Programmable decimal point setting
Indicating range: -1999 to +9999
Accuracy: 0.2% of span ± 1 digit
Electrical connection: To 2-wire transmitters with 4–20 mA output
12 pole terminal blocks
Sensor supply: not required, self-supply loop powered
Voltage drop: =5 V (acc. load: max. 250 )
Max. current load: max. 60 mA
Conversion rate: Three measurements/s,
Gate time: 0.3-20 s (adjustable)
Data back-up: Non-volatile FLASH MEMORY
Error message: HI: overrange
LO: underflow
Programming: With two keys, menu-assisted,
scaling of indication,
decimal point, gate time, error
message switch point
Protection: IP 54
Temperature influence
on display: 0.1% / 10 °C
Storage temperature: -30...+80 °C
Ambient temperature: 0...+60 °C
Case: panel mount 96 x 48 mm
Housing material: Noryl
Cut-out dimensions: 92 x 45 mm
Depth: 90 mm (terminal blocks included)
Weight: 140 g
