Reflex IQ-LOGGER User manual

IQ-LOGGER™
This easy-to-use core logging solution provides
fast, accurate structural measurements
Q U I C K R E F E R E N C E G U I D E
REFLEX IQ-LOGGER™ Software v1.2
Inside
1. Installation
2. Set Up
3. Initialisation
4. Logging
5. Verification
Compatible
The information contained in this document is believed to be accurate at the time of printing; however, Imdex Limited, its subsidiaries, agents, distributors or resellers assume no responsibility
or liability for the accuracy or completeness of, or consequences arising from, such information and the use of such information. Changes, typos, and technical inaccuracies will be corrected in
subsequent publications. This publication is subject to change without notice.
Determination of the suitability of any information or product for use contemplated by any user, and the manner of that use is the sole responsibility of the user.
Copyright © 2017 Imdex Limited.

Charge Battery Pair REFLEXIQ-
LOGGER™ to computer
Plug in the supplied micro USB cable.
Orange light on: Battery charging.
Orange light turns off: Battery fully charged.
Turn on the device by squeezing both
side buttons until the blue and green
lights illuminate; enable Bluetooth on
the computer.
Launch REFLEXIQ-LOGGER™ software
Double-click desktop icon to launch the REFLEXIQ-LOGGERapp. The Projects screen displays.
Press the Sync button to transfer data between HUBand the REFLEX™ REFLEX IQ-LOGGER™
software.
Add Project (in the app)
IQ-LOGGER™ S E T U P
2

Add Drillhole (in the app)
Configure Drillhole (in the app)
Custom Structural Feature lists can be created in IMDEXHUB-IQ™ and synced to the app using the
Sync button.
IQ-LOGGER™ S E T U P
3

Turn on REFLEX
IQ-LOGGER™ Stabilise gyroscopes
Press and hold both side buttons until
the green and blue lights turn on. The
red light should start to flash.
While the red light is flashing, wave the device in a
figure-eight pattern 5 times, then sit it on a flat
surface until the red light extinguishes and the laser
illuminates.
A flashing green light indicates that battery charge is less than 20%. If the battery charge is <5% the
device will not turn on and shows a red LED. Charge the device for at least an hour.
Align device
Place the device on the drillhole orientation line, ensure it is pointing downhole then press either side
button to align.
IQ-LOGGER™ I N I T I A L I S E
4

Set depth and structure type
To record a lineation, you must first record the planar feature it lies on.
Move device downhole
Roll the REFLEXIQ-LOGGER™ device down the core along the orientation line (check that the depth
increases in the software interface).
Align with first structure
Stop rolling the device when the front wheel alignment marker is inline with the first structure to
measure.
IQ-LOGGER™ L O G G I N G
5

Measure first structure
Lift the REFLEXIQ-LOGGER™ device to align the laser with the structure, click the front button on top
of the device to record the measurement.
Move to second structure
Slide the device back on the core with the front wheel alignment marker inline with the first structure,
then slide downhole to the next structure; ensure it is aligned with the drillcore orientation line, click
either side button.
Select structure type
Change the structure type setting on the device by scrolling through the list using the Back button on
top of the device.
IQ-LOGGER™ L O G G I N G
6

Measure next structure
Lift the REFLEXIQ-LOGGER™ device to align the laser with the structure, click the front button on the
top of the device to record the measurement.
If the structure is a linear feature, first measure the
angle of the plane it lies on, then measure the linear
structure by aligning the laser with the line on the
plane surface.
Press the front button on the top of the device twice (quickly) to set the QAFlag for
that reading.
Take measurements for all structures of interest
Repeat steps 5 to 7 to take measurements for all structures of interest.
to upload to Hub
Turn off device
Press and hold both side buttons until the
green and blue lights extinguish. The
REFLEXIQ-LOGGER™is now turned
off.
IQ-LOGGER™ L O G G I N G
7

Verify Data
The red star indicates the drillhole position.
The legend describes the feature for each shape and colour.
Set the depth filter to display only readings of interest.
Check the recorded data. You can edit the following details:
lDelete bad recording: select the recording and right click, then select Delete
lSet structural features: click the field and select the new feature from the dropdown list (note that
you cannot change linear readings to planar and vice versa)
lIf custom lists have been synced from IMDEXHUB-IQ™, select additional meta data attributes in
structural lists 2 and 3
lEdit the Depth: type a new depth into the field
lSet Movement: On lineation-type readings, select the Movement from the dropdown list
lSet QAflag: Set to on or off for any reading
lEdit Logger Name: Edit as required
lEnter Notes: Add notes by typing into the field
IQ-LOGGER™ V E R I F I C A T I O N
