Reid TC480 User manual

Ladies Classic eBike
Display Manual

PG 1
TC480 Display Manual (with setup instructions)
Appearance1.

PG 2
2. The main screen display content
3. Typical Operating Voltage: 24V-48V

PG 3
4. Display description
Display
Function
Description
Speed
Speed display unit
KM/H or MP/H.
ODO / TRIP
ODO for accumulative total
mileage. TRIP for single mileage.
Battery Indicator
Residual electricity display.
Cruise Identification
Display for cruise state.
Wheel Diameter Set
Manufacturer used to set up the
diameter of the wheel.
Throttle Fault
Displays when throttle is not
working.
Brake Instruction
Displays when brakes engaged.
If doesn't appear, there may be a
brake fault.
Light Instruction
Displays when light is on
Motor Fault
Displays when motor is not
working.
Controller Fault
Displays when controller is not
working.
Current Instruction
Points towards the current value
PAS Instruction
Displays speed PAS

PG 4
5. Operating instructions
Key
Operation
Display
Function
Description
Press Once
Briefly
ON
Press this button
briefly to turn on
the display.
Press Once
Briefly
ON/OFF
Headlamp
Press to turn on
and off the light.
Press Twice
Briefly
Trip Mileage
Reset
Press 2 times in a
row to reset the
trip mileage.
Hold
OFF
Press and hold
this button to
switch the
display off.
Press Once
Briefly
PAS Increase
Every click
reduces the
pedal assisted
speed gear. 5
levels available.
Press Twice
Briefly
ODO mileage
Press 2 times in a
row to display
ODO mileage.
Hold
ODO mileage
reset
Hold this button
for 2 seconds to
reset the ODO
mileage.
Press Once
Briefly
PAS reduce
Every click
reduces he pedal
assisted speed. 5
levels available.
Press Twice
Briefly
Trip Mileage
Press 2 times in a
row to see TRIP
mileage.
Hold
6KM/H
Hold to enter the
6KM/H
implement
mode.

PG 4
Press and hold
Wheel Diameter
Description below
Press and hold
Speed Limitation
Description below
Set the function 1 (wheel diameter setting)
Wheel diameter setting: Hold the up and down arrows for 5 seconds to enter wheel diameter settings, the default
speed display area will flash with the default factory settings. Release the two buttons and press '+' or '-' buttons to
adjust to the required wheel diameter value. Hold the up and down arrows for 5 seconds until the characters are
no longer flashing.
Speed Limitation Setting: Hold the two keys for 5 seconds to enter this setting. The default speed display area will
flash with the default factory speed limit characters. Release the two keys and then press the 'up' and 'down'
arrows to adjust to the required speed limit. The adjustable range is 12-40, when selected press the red circle for 5
seconds until the speed display character no longer flashes.
Press down the two keys circled in red for 5 seconds to change KMH to MPH and vice versa.
Work voltage: 24V; 36V; 48V
This display adapter carries high precision speed sensor
Closed system power
Adapter motor: the motor has speed output. Using this motor can accurately display speed.
Ordinary motor: Speed display is approximate.
Configuration Settings
Set the function 2 (speed limitation and changing KMH to MPH)

#
Error Code
Description
Action
1
101
The brake is not
reset when powered on.
Power cut break lever
needs replacing.
2
102
The handle is not
reset when powered on.
Check connection or
replace throttle
3
103
Throttle wire is not connected
properly or no longer works.
Check connection or
replace throttle
4
105
Speed sensor is not working.
Check connection or replace
Speed Sensor
5
24
Overcurrent controller
Check connection or replace
Controller
6
25
Undervoltage controller
Check connection or replace
Controller
7
26
Overvoltage controller
Check connection or replace
Controller
8
34
Motor stalling
Check connection or replace
Motor
9
35
Motor live wire
Check connection or replace
Motor
10
36
Commutator motor
Hall
Check connection or replace
Motor
11
52
The controller does
not support commands and needs
to be upgraded.
Check connection or replace
Controller
PG 5
Error Codes
We hope you’re happy and riding well, however, should an issue ever arise with your
eBike and you are shown an error code, you can refer to the below table for how to
troubleshoot and fix this. Should the problem not be fixed, please reach out to the
retailer you purchased from or Reid at www.reidbikes.com/contactus/ and we’ll do our
best to help.
For all warranty information on our eScooters, please visit our dedicated Warranty
Page www.reidbikes.com/warranty/.
