Rem Cambox SCALA Installation guide

Camera Adapter PTX-150
Connections
1 RS422 + Tally
2 Ethernet
3 Audio In/Out
4 Reference Out
5 S I ‘M’ Input (to Control Unit)
6 C Out to PTZ
7 S I Input (to Control Unit)
8 S I from Control Unit
9 12G input to Control Unit
10 12G Active Loop Out
11 Lemo Hybrid Connector
PTZ
SCALA – Quick Manual – FULL Version
Fiber Solutions PTZ HYBRID / Fiber INTERFACE
CCU
Only one Camera Adapter show
Cambox SCALA
REM Via Sorrento 20153 Milan Italy (H24): [e-mail]
11
De ices:
PTX-150 Cambox Camera Adapter
PTY-150 Cambox Control Unit
Control Unit PTY-150
Commands / LE s
1 CCU PTY-150 Powered
2 Power Enable (CCA1)
3 Power Enable (CCA2)
4 Phantom Enable (CCA1)
5 Phantom Enable (CCA2)
6 Status (CCA1)
7 Status (CCA2)
Status LE s:
Power CCA = PTX-150 Powered
Fiber Link = Fiber Active
Eth Data = ata present in Ethernet
422 Data = Serial ata present
Tally = Tally Activated
1Control Unit PTY-150
PTX-150 with PTY-150
Note: Energy is not supplied to hybrid cable until camera adapter fully connected and handshaked.
To avoid unwanted spikes it is recommended to disable power to PTY-150 before disconnecting it
Safety Notes
o not open units
angerous voltage inside.
Check Ground connection
o not change fuse value
ON
Led
6,7 4,52,3
16
Control Unit PTY-150
Connections
1 Ethernet (CCA1)
2 RS422 & Tally/GPI (CCA1)
3 S I ‘M’ Output (from CCA1)
4 S I Input (to CCA1)
5 S I Output (from CCA1)
6 S I-12G (from CCA1)
7 S I-12G (from CCA1)
8 Ethernet (CCA2)
9 RS422 & Tally/GPII (CCA1)
10 S I ‘M’ Output (from CCA2)
11 S I Input (to PT 2)
12 S I Output (from CCA1)
13 S I-12G (from CCA2)
14 S I-12G (from CCA2)
15 Reference Input (BB or MS)
16 Audio In/Out (4+4)
17 Lemo Connector (CCA1)
18 Lemo Connector (CCA1)
19 Main 90-250 Vac (Fuse 2AT)
19 15 1
8
2
917 18
1043 56
712 13
14
75
109
8
34
2
111
6
3G SDI 2
RS422 / 232
12G SDI
Tally / GPI
Microphone
Ethernet 1G
3G SDI 1
Audio / TC
Genlock
3G SDI Ret
POWER
LINE Audio

Camera Adapter Inputs Signals
Video Signals: 1 - S I 3G, 6G, 12G [BNC]
2 - S I S , H ,3G [BNC]
1 - Reference [BNC]
Audio Signals: 1 - Balanced Analog (Line Level) [ B9]
1 - Balanced Microphone Input [ B9]
ata Signals: 1 - Serial ata (RS422) [RJ45]
1 - Ethernet 1GB [ RJ45]
2 - GPI In [RJ45] (1)
Camera Adapter Outputs Signals
Video Signals: 1 - S I S , H , 3G
Audio Signals: 1 - Unbalanced Analog Audio [ B9]
ata Signals: 1 - Serial ata (RS422) [RJ45]
1 - Ethernet 1GB (with opt. POE++) [RJ45](*)
1 - Tally Out (open collector) [RJ45]
Power : 1 - POE++ on Ethernet [RJ45] Option
1 - 12V Out [M8] (*)
Control Unit Inputs Signals per each Camera Adapter Channel
Video Signals: 1 - S I S , H , 3G [BNC]
1 - Reference (BB, Composite) [BNC]
Audio Signals: 2 - Unbalanced Analog (Line Level) [ B9]
ata Signals: 1 - Serial ata (RS422) [RJ45]
1 - Ethernet 1GB [ RJ45]
1 - Tally In [RJ45]
2 - GPI Out [RJ45]
Control Unit Outputs Signals per each Camera Adapter Channel
Video Signals: 1 - S I 3G, 6G, 12G [BNC]
2 - S I S , H ,3G [BNC]
Audio Signals: 1 - Balanced Line Output [ B25]
1 - Balanced Microphone Line Output [ B25]
ata Signals: 1 - Serial ata (RS422) [RJ45]
1 - Ethernet 1GB [RJ45]
2 - GPI Out (open collector) [RJ45]
Power : 1 - Main 90-240 Vac [V E with Fuse]
Hybrid Connection:
L: SMPTE LEMO 3K
N: Neutrik OpticalCon UO
Fiber Pair Version:
N: Neutrik uo Lite
P: LC/LC
[ No Power to CCA ]
Power Consumption: 20 W per channel without camera load
MAX Camera Load: 12 Volts-60W (default) or 40W on POE++
(*) only one option allowed
CCA Mechanical: imension: W x H x (182, 40, 219 mm)
Weight (1,9 Kg)
CCU Mechanical: imension: 1RU, epth 300mm
Weight: (1Ch 3,1 Kg) (2Ch 3,9 Kg)
2021 Subject to chan e
Note: Multiple Version Available. Contact us for details or visit our website
Camera Adapter
Audio Pinout ( B9)
1 Output Line A Audio +
2 Output Line B Audio +
3 Ground
4 Input Mic + (30db)
5 Input Line Audio +
6 Output Line A Audio -
7 Output Line B Audio -
8 Input Mic - (30db)
9 Input Line Audio -
Control Unit
Audio Pinout ( B25)
1 Output Mic 1+
2 Ground
3 Output Line 1-
4 Input Line A+
5 Ground
6 Input Line 1 B-
7 Output Mic 2+
8 Ground
9 Output Line 2 -
10 Input Line 2 A+
11 Ground
12 Input Line 2 B-
13 Ground
14 Output Mic 1-
15 Output Line 1+
16 Ground
17 Input Line A-
18 Input Line 1 B+
19 Ground
20 Output Mic 2-
21 Output Line 2+
22 Ground
23 Input Line 2 A-
24 Input Line 2 B+
25 Ground
Camera Adapter
C Out Pinout <5>
1 Out +12V
2 Out +12V
3 Ground
4 Ground
5 Out +12V
[Use supplied XLR4P adapter]
CCA Camera Mechanical Installation (e. .: AW-UE-150)
Fix Camera Mount Braket on top using 4 screw supplied or 4MA-10mm max
then follow the PTZ camera Installation manual
¼” holes available on bottom for Tripod or similar fixing
o not obstruct the flow of air, do not cover Fan gate and front holes
CCA & CCU
RS422 Pinout (RJ45)
1 TX-
2 TX+
3 Ground
4 RX-
5 RX+
6 Tally [→ CCA]
7 GPI 1 [→ CCU]
8 GPI 2 [→ CCU]
Camera Adapter Status LED
Powered
Camera Adapter Controls
No Controls
Control Unit Status LEDs
CCA Powered [CCA connected, Power supplied to camera]
Fiber Link Active [Fiber connection established]
Eth ata [Ethernet active (flashin )]
422 ata [Data present on RS422 bus (flashin )]
Tally [ Tally line activated]
Control Unit Controls
CCA Power Enables [Power savin ]
Microphone Phantom Enables [Channel 1 / Channel 2]
Fiber Solutions
ETH
AW-UE150 Connections Example
422
Control Unit (CCU) Back
Return Video
S I 3G from CCU
Microphone In
Phantom (On/Off)
Notes:
Various PTZ cameras
adapters, plates, cables
and tripod mount available.
Contact us for informations
V1.1 Subject to chan e
Camera Adapter
XLR-4P Cable
Adapter Pinout
1 Ground
2 Unused
3 Unused
4 Out +12V
