Peak Scientific NG2000 User manual

NG 2000-5000
User Manual
2014 © Peak Scientific - Rev. 6 – 10/01/14

NG Range User Manual
Page 2 2014 © Peak Scientific - Rev. 6 – 10/01/14
Contents
Change History 3
How to Use This Manual 3
Introduction 4
Warranties and Liabilities 5
Safety Notices 6
Symbols 6
Safety Notice to Users 6
Declaration of Conformity 7
Environmental Declaration 8
Technical Specification 9
Environment 9
Inlet Conditions 9
Generator Outlets 9
Electrical Requirements 9
General 9
Unpacking 10
Removing the generator from the crate 11
Installation 12
Generator Environment 12
General Dimensions 12
Wall Mounting 13
Electrical Connection 14
Fuse 14
External Connections 14
Start-up Procedure 15
IMPORTANT DOCUMENT S 16
Normal Operation 17
Principal of Operation 17
Unusual Operation 17
Service Requirements 18
Service Schedule 18
Service Plans 18
Cleaning 18

NG Range User Manual
Page 3 2014 © Peak Scientific - Rev. 6 – 10/01/14
Change History
Rev. Comment Name Date
1 Initial release S.G.M. 27/11/98
2 System diagrams updated H.D. 03/04/03
3 USA technical support number added F.A.D. 11/11/04
4 New style front added F.A.D. 08/04/05
5 Updated to new format L.C. 01/10/13
6 Unpacking and Wall Mounting Instructions L.C. 10/01/14
7
How to Use This Manual
This manual is intended for end users and has been written so that it can either
be read as a step by step guide to installation and usage or as a reference
document where you can skip to the relevant information.
Users of a hard copy version can refer to the contents page to find the relevant
information. Users of the soft copy version can use the hyperlinks from the
contents page as well as the hyperlinks between sections.
Please review each of the following sections carefully.
Thank you for selecting Peak Scientific to meet your Gas Generation needs, and
should you require any further assistance or support please do not hesitate to
contact Peak Scientific or the Peak Partner from which you purchased your
Generator.

NG Range User Manual
Page 4 2014 © Peak Scientific - Rev. 6 – 10/01/14
Introduction
Welcome to the User Manual for the Peak Scientific high purity Nitrogen gas
generator. Enclosed in this manual you will find the information required to
ensure that your generator is operated and serviced according to our
recommended guidelines, which will prepare you for long and trouble free
Nitrogen generation.
The Peak Scientific High Purity Nitrogen Generator is designed specifically for
use with laboratory analytical Instruments as a source of carrier gas. The
generator has been designed to operate from an existing source of dry, oil free,
compressed air, and an electrical supply. To deliver high volume, clean, dry
Nitrogen.

NG Range User Manual
Page 5 2014 © Peak Scientific - Rev. 6 – 10/01/14
Warranties and Liabilities
1. The Company warrants that it has title to the Goods.
2. Subject to the provisions of this clause the Company warrants that the
Goods shall comply in all material respects with any specification
referred to in the Order Confirmation (as the same may be amended)
and shall, subject thereto, be free from defects in material and
workmanship for the lesser of a period of twelve months from the date
of delivery or thirteen months from the date of dispatch from the
factory.
3. Save as provided in this clause and except where the Goods are sold to a
person dealing as a consumer (within the meaning of the Unfair Contract
Terms Act 1977) all warranties, conditions or other terms implied by
statute or common law are hereby expressly excluded save to the extent
they may not be lawfully excluded. When the Goods are sold to a
consumer within the meaning of the Unfair Contract Terms Act 1977 their
statutory rights are not affected by the provisions of this clause.
4. In the event of the Customer making a claim in respect of any defect in
terms of clause 2 hereof the Customer must.
1. Reasonably satisfy the Company that the Goods have been
properly installed, commissioned, stored, serviced and used and
without prejudice to the generality of the foregoing that any
defect is not the direct or indirect result of lack of repair and/or
servicing, incorrect repair and/or servicing, use of wrong
materials and/or incorrect spare parts
2. Allow the company to inspect the Goods and/or any installation
and any relevant packaging as and when reasonably required by
the Company.
5. Subject to the Company being notified of any defect as is referred to in
sub-clause 2 hereof within a reasonable time of it becoming apparent
and subject always to the terms of sub-clause 4 hereof, the Company
shall, in its option, replace or repair the defective Goods or refund a
proportionate part of the Price. The Company shall have no further
liability to the Customer (save as mentioned in sub-clause 6 hereof).
6. The Company shall be liable to indemnify the Customer in respect of any
claim for death or personal injury to any person in so far as such is
attributable to the negligence or breach of duty of the Company or any
failure by the Company to comply with the provisions of sub-clause 2
hereof.
7. Save as provided in sub-clause 2 hereof the Company shall not be liable
in respect of any claim by the Customer for costs, damages, loss or
expenses (whether direct, indirect, consequential or otherwise) or
indemnity in any respect howsoever arising including, but not by way of
limitation, liability arising in negligence (other than pursuant to clause 6
above) that may be suffered by the Customer or any third party.

NG Range User Manual
Page 6 2014 © Peak Scientific - Rev. 6 – 10/01/14
Safety Notices
Symbols
This manual uses the following symbols to highlight specific areas important to
the safe and proper use of the Generator
Safety Notice to Users
These instructions must be read thoroughly and understood
before installation and operation of your Peak Generator. Use
of the Generator in a manner not specified by Peak Scientific
MAY impair the SAFETY provided by the equipment.
When handling, operating or carrying out any maintenance,
personnel must employ safe engineering practices and
observe all relevant local health and safety requirements and
regulations. The attention of UK users is drawn to the Health
and Safety at Work Act 1974, and the Institute of Electrical
Engineers regulations.
A WARNING notice denotes a hazard. It calls attention to an operating procedure,
process or similar, which if not correctly performed or adhered to, could cause personal
injury or in the worst case death. Do not proceed beyond a WARNING notice until the
indicated conditions are fully understood or met.
A CAUTION notice denotes a hazard. It calls attention to an operating procedure,
process or similar, which if not correctly performed or adhered to, could cause damage
to the Generator or the Application. Do not proceed beyond a CAUTION notice until the
indicated conditions are fully understood or met.
Caution, risk of electric shock. Ensure power to the Generator has been removed before
proceeding.

NG Range User Manual
Page 7 2014 © Peak Scientific - Rev. 6 – 10/01/14
Declaration of Conformity
We Peak Scientific Instruments Ltd.
Of Fountain Crescent, Inchinnan, Renfrewshire, PA4 9RE
Declare that:
Equipment: Nitrogen Gas Generator
Model: NG*000(A) Series * Denotes any numeric value.
(A) Denotes compressor based model.
LVD Certificate No: 3818TC1
EMC Certificate No: 3781TC2
Date: 03 / 02 / 2014
To which this declaration relates, is in conformity with the applicable EC
directives, harmonized standards, and other normative requirements.
•
Low Voltage Directive 2006/95/EC
EN 61010-1: 2010 Electrical Equipment for measurement, control and
laboratory use.
•
Electromagnetic Compatibility Directive 2004/108/EC
EN 61326-1: 2006 Electrical Equipment for measurement, control
and laboratory use.
All evaluation, testing and certification issued by:
York EMC Services Ltd
Donibristle Industrial Park
Dunfermline, Fife
KY11 9HZ
Signed: Name: Chris Pugh
Date: 3rd February 2014 Position: Engineering Director

NG Range User Manual
Page 8 2014 © Peak Scientific - Rev. 6 – 10/01/14
Environmental Declaration
We Peak Scientific Instruments Ltd.
Of Fountain Crescent, Inchinnan, Renfrewshire, PA4 9RE
Declare that:
Equipment: Nitrogen Gas Generator
Model: NG*000(A) Series * Denotes any numeric value.
(A) Denotes compressor based model.
Is fully compliant with the following Directives
•2002/96/EC WEEE (Waste of Electrical and Electronic
Equipment)
•2002/95/EC RoHS (Restriction of Hazardous
Substance)
Peak Scientific Instruments Ltd fully complies with its obligations towards the
European WEEE (Waste of Electrical and Electronic Equipment) Directive
2002/96/EC. These obligations are being met within the B2B compliance
group.
Peak Scientific Instrument Ltd have developed all reasonable ‘due dilligence’
controls to ensure that our products comply with the principles and
requirements of the European RoHS (Restriction of Hazardous Substances)
Directive 2002/95/EC. Similar directives in the United States and China, for
example, have also been captured within this program.
Where a specific certificate of compliance is required, this can be requested, on
a product serial number basis, directly from Peak Scientific Instruments Ltd, by
contacting us through our website on www.peakscientific.com
Signed: Name: Chris Pugh
Date: 3rd February 2014 Position: Engineering Director

NG Range User Manual
Page 9 2014 © Peak Scientific - Rev. 6 – 10/01/14
Technical Specification
Environment
Minimum Operating Ambient
Temperature
5°C / 41°F
Maximum Operating Ambient
Temperature
25°C / 75°F
Maximum Altitude
2000 meters
Maximum Relative Humidity
70%
Minimum Storage Temperature 10°C / 50°F
Maximum Storage Temperature
25°C / 75°F
Inlet Conditions
Minimum Air Pressure 120 psi (8.2 bar)
Maximum Air Pressure
130 psi (8.8 bar)
Generator Outlets
NG2000
NG3000
NG4000
NG5000
Max Flow Rate (cc/min @ 80 psi (5.5 Bar))
2000
3000
4000
5000
Particles
<0.01
μ
m
Phthalates None
Suspended Liquids
None
Gas Outlets
1
Start-Up Time For Purity 8 hours
Electrical Requirements
Voltage
110/230v
Frequency 50/60 Hz
Current 230v (110v)
0.5 (1.2) A
Pollution Degree
2
Installation Category II
General
Generator Dimensions cm (“)
43 (16.9) x 41 (16.1) x 124 (48.8)
Generator Weight kg (lbs) 57 (126) 77 (170) 88 (176) 88 (176)
Shipping Crate Dimensions cm (“)
64 (25.1) x 60 (23.6) x 146 (57.4)
Shipping Weight
87 (192)
107 (236)
110 (242)
110 (242)

NG Range User Manual
Page 10 2014 © Peak Scientific - Rev. 6 – 10/01/14
Unpacking
Although Peak Scientific takes every precaution with safe transit and
packaging, it is advisable to fully inspect the unit for any sign of transit
damage.
Check ‘SHOCKWATCH’ label for signs of rough handling prior to un-packing –
Any damage should be reported immediately to the carrier and Peak
Scientific or the Peak Partner from where the unit was purchased.
Follow the unpacking instructions posted on the side of the crate. It will require
two people to remove the unit from the shipping crate and to manoeuvre the
Generator onto the floor.
Please save the product packaging for storage or future shipment of the
Generator.
Note: Included with the Generator is a “Fittings Kit” containing a mains
power lead for UK, EU or US and all the required fittings. Be careful not to
discard these with the packaging.

NG Range User Manual
Page 11 2014 © Peak Scientific - Rev. 6 – 10/01/14
Removing the generator from the crate
The generator weighs over
57kg
and as such should be unpacked by two
people using the following method.
All the screws encircled in
RED
should first be removed from the shipping
crate, there are approximately 16 screws, and the front door should then be
removed.
Now, with someone positioned at either side of the shipping crate, the top half
of the crate can be slid backwards and away from the rest of the crate. With
the top of the crate removed the foam insert of top of the generator should
also be taken off.
The generator can now be lifted out of the crate base and onto the floor. This
should be done again with someone positioned at either side. There is a gap in
the foam base for hand access, one hand should be positioned here underneath
the generator and the other at the back supporting the weight. The generator
should then be tilted back slightly and then up and out of the foam base and
onto the floor.

NG Range User Manual
Page 12 2014 © Peak Scientific - Rev. 6 – 10/01/14
Installation
Generator Environment
The Generator is designed for indoor use only. It should be
installed adjacent to the application it is supplying. If this is
not convenient then the unit can be sited elsewhere, however,
consideration should be made of the lengths of pipe runs as
pressure drops can result from extended runs of pipe. Please
see the Tubing lengths section for further details.
Performance of the Generator (like all sophisticated
equipment) is affected by ambient conditions. Note should
also be taken to the proximity of Air Conditioning outlets.
These can sometimes give rise to “pockets” of air with high
relative humidity. Operation of the unit within such a pocket
could adversely affect its performance. Consideration should
also be given to the air flow around the unit. It is
recommended that an air gap of 75mm (3”) should be
maintained down both sides, at the rear and across the top of
the unit. Please refer to the drawing below for the general
dimensions of the unit.
Maximum Ambient Conditions: 25°C (dry bulb) 70%RH (Max) Non-Condensing
General Dimensions
NG2000-5000
1240

NG Range User Manual
Page 13 2014 © Peak Scientific - Rev. 6 – 10/01/14
Wall Mounting
The NG range generator is designed to be mounted against a wall for safety
reasons.
Supplied in the generator fittings kit are all the fittings required to wall mount
the generator. Detailed below are the necessary steps to mount the unit to a
wall.
Locate the screw in the top rear corner of the unit, beside the yellow warning
label. Remove the screw from the generator this should be repeated for the
other side of the unit, and retain.
Next, using the screw which was removed, fit the bracket and washers
provided to the generator. Again this should be repeated for the other side.
The bracket is adjustable to accommodate varying kickboard widths.
Finally, using the dimensions provided, fix the wall plugs to the wall, ensuring
wall plug is suitable for the type of wall. If not, use the correct type. Secure the
generator to the wall with the screws from the fittings kit.

NG Range User Manual
Page 14 2014 © Peak Scientific - Rev. 6 – 10/01/14
Electrical Connection
Connect the Generator to an appropriate 110/230 volt single-phase supply,
refer to the generator serial plate for input specification and ensure your supply
matches the requirements
If the appropriate power cord is not supplied: a new plug, rated to at least 10
amps, can be fitted by a qualified electrician.
This unit is classified as SAFETY CLASS 1. THIS UNIT MUST
BE EARTHED. Before connecting the unit to the mains supply,
please check the information on the serial plate. The mains
supply must be of the stated AC voltage and frequency.
EARTH/GROUND (E):- Green & Yellow or Green
LIVE (L):- Brown or Black
Neutral (N):- Blue or White
Our electrical requirements are 110/230 VAC nominal +/- 10% depending on
chosen model. Extended periods at these extremes can have a detrimental
effect on the operation and life of the Generator.
Fuse
The generator protection fuse, in the pull out drawer of the mains inlet IEC
connector located adjacent to the off/on switch. The replacement fuse must be
rated T10AH250V
External Connections
The Nitrogen Generator should be connected to a clean, dry source of
compressed air. A minimum pressure of 120 psi is required. Any doubts as to
the suitability of the compressed air supply should be referred to the factory
for advice.
The generator has two ¼” BSPT bulkhead connections to the left side of the
unit. The upper port is the Compressed Air inlet and the lower is the Nitrogen
outlet. A ⅛” Swagelok fitting is supplied for connection to the application.
There is no drain on this machine. Any moisture liberated by the filter separator
is discharged through the high capacity exhaust system, where sudden
reduction in pressure causes instant evaporation. The water vapour is safely
removed from the unit by the ventilation system.
Air Inlet
Nitrogen Outlet
Power Switch
Power Inlet/Fuse Drawer

NG Range User Manual
Page 15 2014 © Peak Scientific - Rev. 6 – 10/01/14
Start-up Procedure
With the generator installed as described earlier, connect power to the unit and
turn it on. Disconnect the Nitrogen outlet connection to allow the generator to
vent to atmosphere until the unit is stabilised. At Switch-on the exhaust valve
will open and the generator will commence its venting cycle. This is to allow
venting of any residual pressure in the system. The vent cycle may last up to 90
seconds. At the end of the vent cycle, the inlet valve will open and the normal
operating cycle will begin. Pressure should begin to build on the gauge on the
front panel, reaching 80 psi after approximately 10 minutes.
The generator has been pre-set in the factory to give the specified output flow
rate and pressure. Once the pressure in the Nitrogen receiver exceeds that
setting the generator will stabilise and produce pure Nitrogen. Maximum purity
will be achieved after around 8 hours. After this time the generator can be
reconnected to the application.
The design of the generator is such that it will deliver up to the rated output
flow of Nitrogen at 80 psi. Should the demand for Nitrogen be less than the
rated output flow, or indeed should the demand stop, the generator will
continue to operate without any problems. The generator is protected from
over-pressure and its normal operating cycle ensures frequent venting.

NG Range User Manual
Page 16 2014 © Peak Scientific - Rev. 6 – 10/01/14
IMPORTANT
DOCUMENT S
Warranty Entitlement
To register your generator for your warranty entitlement, send the completed
form to Peak Scientific by:
•
Email
[e-mail]
•
Online
http://www.peakscientific.com/service-and-support/warranty_registration
•
•
Phone
F ax
[phone]
[phone]
PRODUCT WARRANTY REGISTRATION
COMPANY: CONTACT NAME:
ADDRESS:
EMAIL ADDRESS:
CITY/TOWN: GENERATOR SERIAL NUMBER:
POSTCODE:
COUNTRY: MODEL TYPE:
TELEPHONE: INSTALLATION DATE (DD/MM/YYYY):
Important Please Note:
You have 1 month to register your Peak Scientific product from the date of shipment.
If you wish to defer installation of your generator you must notify Peak Scientific within
1 month of the shipment date. This can be done by emailing
[e-mail] Once registered the warranty will be honoured for a
period of 12 months after the installation date.
For any generators that remain unregistered the warranty will begin from date of
shipment.
Thank you on behalf of Peak Scientific.

NG Range User Manual
Page 17 2014 © Peak Scientific - Rev. 6 – 10/01/14
Normal Operation
Principal of Operation
The High Purity Nitrogen Generator utilizes a ‘Pressure Swing Adsorption’
(PSA) method to extract pure Nitrogen from air. This is where un-wanted
gasses can be selectively adsorbed from compressed air into a porous carbon
molecular sieve material (CMS). The Peak Scientific Instruments LTD. Generator
utilizes a unique single column system where the column is alternately
pressurised and vented under a finely tuned timing cycle. The rates of
pressurisation and venting are accurately set which guarantees high purity
better than can be achieved with a similarly sized traditional 2-column system.
Unusual Operation
If at any time the Generator begins to emit excessive noise or vibration, then it
should be switched off and you should contact Peak Scientific or the Peak
Partner from which the Generator has been purchased.

NG Range User Manual
Page 18 2014 © Peak Scientific - Rev. 6 – 10/01/14
Service Requirements
Service Schedule
Service Interval
Component
Part No.
Qty.
12 months
Separator filter element
02-4335
1
Exhaust silencer element
02-4336
1
Silencer filter
02-1016
1
Table 1: Service schedule
As an alternative to purchasing the 12 month service items individually an
Annual Service Kit is available as one part number. This contains all the filters
required for this Generator and offers a costs saving over buying the
components separately.
Purchase Interval
Component
Part No.
Qty.
12 months
Service Kit NG250-5000
08-4723
1
Service Plans
Peak Scientific offer two service plans. The Complete Service Plan, specifically
designed for Generators operated in critical environments, also includes full
breakdown cover, guaranteed response times and Generator upgrades if
available. Our Standard Service Plan, covering the basic needs of our
Generators, features special deals on spare parts and breakdowns.
If you want to know more about our Service Plan options and how we ensure
that your instrument can run with the maximum uptime and performance,
please contact us at [e-mail]
Cleaning
Clean the outside of the Generator only using warm soapy water and a clean
damp cloth. Ensure the cloth is thoroughly rung out to remove excess fluid
prior to use.
Cleaning should only be undertaken with the power switched
off and the power cord removed from the rear of the
Generator.
Under no circumstances should any solvents or abrasive
cleaning solutions be used as these can contain fumes that
could be harmful to the Generator.

2014 © Peak Scientific - Rev. 6 – 10/01/14
Peak Scientific UK
Fountain Crescent
Inchinnan Business Park
Inchinnan
PA4 9RE
Scotland, UK
Peak Scientific North America
19 Sterling Road
Suite #1
Billerica, MA 01862
USA
Peak Scientific India
202, Amsri Shamira
Old Lancer Line
Opp. St. Mary’s Degree College
S.D. Road Secunderabad
500 025, India
Peak Scientific Africa
PO Box 478
Somerset Mall
7137
South Africa
Tel: [phone]
Fax:
[phone]
Tel: [phone]
Fax:
[phone]
Tel: [phone]
Fax:
[phone]
Tel: [phone]
Fax:
[phone]
Peak Scientific Germany
Herriotstrasse 1
60528 Frankfurt
Germany
Peak Scientific China
Room 606 Building 1
Lane 2277 Zuchongzhi Road
Pudong New Area
Shanghai
201203, China
Peak Scientific Mexico
Solon 352
Col. Los Morales Polanco
11530 Mexico, D.F.
Mexico
Peak Scientific Australia
PO Box 65
Belmont
Victoria 3216
Australia
Tel: [phone]
Fax:
[phone]
Tel: [phone]
Fax:
[phone]
Tel: [phone]
Fax:
[phone]
Tel: [phone]
Peak Scientific Taiwan
4F.-6, No.736
Zhongzheng Rd.
Zhonghe Dist.
New Taipei City
Tel:
[phone]
Fax:
[phone]
Peak Scientific Brazil
Peak Scientific Brasil
Av. Quieroz Filho
1700 – torre Sunny-Conj. 602
São Paulo SP Brasil
Tel:
[phone]
Peak Scientific Japan K.K.
2-7-56, 2F Fuji Building 28
Kita Aoyama, Minato-Ku
Tokyo, Japan
107-0061
Tel:
[phone]
Peak Scientific Singapore
3 Science Park Drive
#03-14 The Franklin
Science Park Drive 1
Singapore, 118223
Tel:
[phone]
Fax:
[phone]
