Remaco BKT Series User manual

B K T S e r i e s - V i d e o Wa l l M o u n t T V B r a c k e t
www.remacotech.com Email : [email protected] Tel : [phone] Fax : [phone]
Features
- Post-Installation Adjustments Leveling, tilt and in-out adjustment knobs make it easier that ever to flush and level
the flat-panels for a seamless video wall
- Locking Safety Screws
- Spring lock to lock or unlock the mount from the closed position.
- Cable/Electrical Access
- Complied to VESA : 200mm x 200mm, 400mm x 600mm
BKT-529 Specifications
Product Dimension
+/- (Y)
+/- (x)
+/- (Z)
+/- (Z)
+/- (Y)
LOCK
M
I.1
L
12
3 4
Solid Concrete Mounting Wood Stud Mounting
I.2
L
12
3
Suitable LCD / TV
Load Capacity
Depth (Kept Position)
Depth (Popped Out)
Wall Mount Plate
Depth to wall
Colour
Complied to VESA
:
:
:
:
:
:
:
:
46” to 70”
70kg
113mm (+/- 10mm with Micro-adjustment)
300mm (+/- 10mm with Micro-adjustment)
505 x 545mm
120 to 260mm
Black
400 x 400mm, 400 x 600

B K T S e r i e s - V i d e o Wa l l M o u n t T V B r a c k e t
www.remacotech.com Email : [email protected] Tel : [phone] Fax : [phone]
Attaching Brackets to Screen
Opon Padlock
Features 1pc per bracket
(Not Included)
Post-Installaon Adjustments
adjustments +/-Z
adjustments +/-Z
adjustments +/-Y
X
Z
Y
screen
Raise Slightly the boom
of screen before adjust
adjustments +/-X
These registers must align prior to
installaon. They are factory set.
Check to determine proper
alignment.
