Remlinger 3500 Operating instructions
Rolling Finisher
Model 3500
Owner’s Manual
Installation and Parts Manual
OurTraditionisQualityDrivenandFieldProven
Manual # MAN-RF-NA-001
Table of Contents
OPERATING TIPS.................................................................................................................................4
SAFETY..................................................................................................................................................5
PRE-ASSEMBLY INSTRUCTIONS.......................................................................................................5
RECOMMENDED TORQUE SPECIFICATIONS...................................................................................5
ROLLING FINISHER - MAINTAINING..................................................................................................6
ADJUSTING THE CLEVIS HEIGHT..............................................................................................................................6
ADJUSTING THE HITCH LENGTH...............................................................................................................................6
LUBRICATION ........................................................................................................................................................6
SINGLE BAR HARROW - MAINTAINING ............................................................................................7
ADJUSTING HARROW HEIGHT .................................................................................................................................7
ADJUSTING SPRING TENSION..................................................................................................................................7
PINNING THE HARROW UP......................................................................................................................................7
DOUBLE ROLLER HARROW - MAINTAINING....................................................................................8
ADJUSTING THE ROLLER HEIGHT.............................................................................................................................8
ADJUSTING ROLLER AGGRESSION...........................................................................................................................8
ADJUSTING THE SPRING DOWN PRESSURE ..............................................................................................................8
LUBRICATION ........................................................................................................................................................8
ROLLING FINISHER - ASSEMBLY ......................................................................................................9
BASE /AXLE INSTRUCTIONS (DIAGRAM PAGE 15)......................................................................................................9
BASE /A-FRAME INSTRUCTIONS (DIAGRAM PAGE 17) .............................................................................................10
WING INSTRUCTIONS (DIAGRAM PAGE 19) .............................................................................................................10
OPTIONAL GAGE WHEEL INSTRUCTIONS (DIAGRAM PAGE 21).................................................................................11
HOSE KIT LAYOUT -SEE APPENDIX PAGE 43..........................................................................................................11
SINGLE BAR HARROW - MOUNTING...............................................................................................12
1BAR HARROW INSTRUCTIONS (DIAGRAM PAGE 23)...............................................................................................12
DOUBLE ROLLER HARROW - MOUNTING......................................................................................13
DOUBLE ROLLER HARROW INSTRUCTIONS (DIAGRAM PAGE 25)...............................................................................13
PARTS DESCRIPTION – BASE / AXLE.............................................................................................14
PARTS DIAGRAM – BASE / AXLE ....................................................................................................15
PARTS DESCRIPTION – BASE / A-FRAME......................................................................................16
PARTS DIAGRAM – BASE / A-FRAME .............................................................................................17
PARTS DESCRIPTION – WING..........................................................................................................18
PARTS DIAGRAM – WING .................................................................................................................19
PARTS DESCRIPTION – WING EXTENSION / GAGE WHEEL........................................................20
PARTS DIAGRAM – WING EXTENSION / GAGE WHEEL................................................................21
PARTS DESCRIPTION – SINGLE BAR HARROW............................................................................22
PARTS DIAGRAM – SINGLE BAR HARROW...................................................................................23
PARTS DESCRIPTION – DOUBLE ROLLER HARROW...................................................................24
PARTS DIAGRAM – DOUBLE ROLLER HARROW ..........................................................................25
LAYOUT – 12’ BASE (STANDARD)...................................................................................................26
11’9” HARROW ON A 12’ BASE..............................................................................................................................26
LAYOUT – 12’ BASE...........................................................................................................................27
13’3” HARROW ON A 12’ BASE..............................................................................................................................27
LAYOUT – 14’ BASE (STANDARD)...................................................................................................28
14’0” HARROW ON A 14’ BASE..............................................................................................................................28
2
LAYOUT – 16’ BASE (STANDARD)...................................................................................................29
16’4” HARROW ON A 16’ BASE..............................................................................................................................29
LAYOUT – 16’ BASE...........................................................................................................................30
17’10” HARROW ON A 16’ BASE............................................................................................................................30
LAYOUT – 3’ WING.............................................................................................................................31
19’8” HARROW ON A 12’ BASE..............................................................................................................................31
21’11” HARROW ON A 14’ BASE............................................................................................................................31
24’2” HARROW ON A 16’ BASE..............................................................................................................................31
LAYOUT – 4’ WING.............................................................................................................................32
21’2” HARROW ON A 12’ BASE..............................................................................................................................32
23’5” HARROW ON A 14’ BASE..............................................................................................................................32
25’8” HARROW ON A 16’ BASE..............................................................................................................................32
LAYOUT – 5’ WING.............................................................................................................................33
22’8” HARROW ON A 12’ BASE..............................................................................................................................33
24’11” HARROW ON A 14’ BASE............................................................................................................................33
27’2” HARROW ON A 16’ BASE..............................................................................................................................33
LAYOUT – 6’ WING.............................................................................................................................34
24’2” HARROW ON A 12’ BASE..............................................................................................................................34
26’5” HARROW ON A 14’ BASE..............................................................................................................................34
28’8” HARROW ON A 16’ BASE..............................................................................................................................34
LAYOUT – 6’ WING.............................................................................................................................35
25’8” HARROW ON A 12’ BASE..............................................................................................................................35
27’11” HARROW ON A 14’ BASE............................................................................................................................35
30’2” HARROW ON A 16’ BASE..............................................................................................................................35
LAYOUT – 3’ WING WITH 4’ STUB....................................................................................................36
27’2” HARROW ON A 12’ BASE..............................................................................................................................36
29’5” HARROW ON A 14’ BASE..............................................................................................................................36
31’9” HARROW ON A 16’ BASE..............................................................................................................................36
LAYOUT – 4’ WING WITH 4’ STUB....................................................................................................37
30’11” HARROW ON A 14’ BASE............................................................................................................................37
33’3” HARROW ON A 16’ BASE..............................................................................................................................37
LAYOUT – 4’ WING WITH 4’6” STUB................................................................................................38
32’5” HARROW ON A 14’ BASE..............................................................................................................................38
34’9” HARROW ON A 16’ BASE..............................................................................................................................38
LAYOUT – 5’ WING WITH 4’6” STUB................................................................................................39
33’11” HARROW ON A 14’ BASE............................................................................................................................39
36’3” HARROW ON A 16’ BASE..............................................................................................................................39
LAYOUT – 5’ WING WITH 5’ STUB....................................................................................................40
35’5” HARROW ON A 14’ BASE..............................................................................................................................40
37’9” HARROW ON A 16’ BASE..............................................................................................................................40
LAYOUT – 6’ WING WITH 5’ STUB....................................................................................................41
39’3” HARROW ON A 16’ BASE..............................................................................................................................41
LAYOUT – 6’ WING WITH 5’ STUB....................................................................................................42
40’9” HARROW ON A 16’ BASE..............................................................................................................................42
APPENDIX ...........................................................................................................................................43
HOSE DIAGRAMS.................................................................................................................................................43
REGISTRATION INFORMATION........................................................................................................53
WARRANTY POLICY..........................................................................................................................53
REGISTRATION FORM.......................................................................................................................55
3
Operating Tips
•Read and understand this manual before operating your Rolling Finisher
(RF), please call with any questions before operating. Damage may occur if
cart is improperly used or operated.
•Always place the front roller in the aggressive mode (position A). The rear
roller can be set in either aggressive or passive mode. See page 8 for more
information.
•We recommend raising your RF cart before turning on each end. Turning
with the rollers on the ground creates side stresses and could cause damage
to the rollers, bearings, and / or frames.
•Always look over your RF cart before each operation. Look for loose bolts,
frayed hoses, damaged parts, or flat tires.
•Always place all transport locks in place when transporting or storing your
Rolling Finisher. This machine is equipped with locks for all lift cylinders.
•Unfolding the machine: for field operation, keep the transport locks on all lift
cylinders (including gage wheels). Unfold the wings and then remove the
transport locks. If the transport locks are removed, the base will drop to the
ground first. The rollers on the wings will be forced into the ground and could
cause damage to the rollers, bearings, and / or frames.
•Folding the machine: for transport, the transport locks do not have to be in
place to fold the wings. The cart will first raise and than the wings will fold. It
is recommended that the transport locks be in place before transporting.
•Caution: Remember to rotate the rear jack stand into transport position after
attaching the RF cart to your implement. Damage to the jack or mounting
hardware can result.
•Make sure hitch pin with keeper, hose connections, and safety lighting
(optional) plugs are all connected properly before operating.
4
Safety
1. Never attempt to operate or adjust the harrow without reading this manual.
2. Never allow anyone to ride on the harrow or other attachments.
3. Drive slowly over rough ground.
4. Always slow down when turning.
5. Always support the Rolling Finisher when mounting or working on the cart or
other attachments.
6. Never attempt to adjust the harrow while it is in motion.
7. Periodically check bolts and replace worn ones.
8. Be careful around teeth, tines, sweeps, and blades; they get sharper with
wear.
9. Periodically check tires for wear and proper inflation.
a. 7.60-15 8 ply 52 psi max
b. 9.5L-15 8 ply 44 psi max
10.Hydraulics:
a. When installing hydraulic hose, make sure all connections are tight and
cylinders are full of hydraulic oil.
b. Relieve pressure in hydraulic lines before uncoupling hoses from
source.
c. Check for and correct all points of abrasion of hydraulic hose. Do not
us a partially damaged hose.
Pre-Assembly Instructions
1. All references to right hand and left-hand sides are determined by facing the
implement from the rear.
2. Check your packing lists and report any missing parts within 30 days.
3. Lubricate all moving parts and bearings as recommended.
4. Follow assembly instructions in the order shown.
5. This setup & owners manual should be given to the owner for their reference.
Recommended Torque Specifications
THREAD SIZE FT -LBS N-M
1/4”-20 9 -11 12 -15
3/8”-16 35 -42 48 -57
7/16”-14 54 -64 73 -87
1/2”-13 80 -96 109 -130
5/8”-11 150 -180 203 -244
3/4”-10 270 -324 366 -439
1”-8 580 -696 787 -944
The above specifications apply to SAE Grade 5 Fasteners.
5
Rolling Finisher - Maintaining
Adjusting the Clevis Height
Major – Remove the two 3/4”-10 x 6” hex cap bolts and pull the
telescoping hitch out and rotate 180°. Replace the 3/4” bolts and
tighten. The clevis will also have to be rotated.
Minor – Remove the two 3/4” hitch bolts and move the clevis up or down.
Replace the bolts.
Adjusting the Hitch Length
Loosen the two 3/4”-10 x 7” hex cap bolts and slide the telescoping hitch
in or out to the desired length. Replace the 3/4” bolts and tighten. (The
proper hitch length is 1/2 of the leading implement width.)
Lubrication
Use SAE Multi Purpose Grease
1. Transport axle (2 locations) - Every 15 hours
Zerk located inside the upper part of the wheel arm at the
pivot pin.
2. Gage wheel axle - optional (2 locations) - Every 15 hours
Zerk located inside the upper part of the wheel arm at the
pivot pin.
3. Front and Rear Wing Hinge (4 locations) - Every 15hours
Zerk located on the wing side of the hinge.
4. Transport & gage wheel bearings - Once a year or 50 hours
Raise the tires off the ground and check for end play. To
eliminate, remove dust cap and cotter pin. Tighten slotted
nuts until there is noticeable resistance and back off one
slot. Replace cotter pin and dust cap.
5. Harrow attachments - refer to the proper section of this
manual.
6
Single Bar Harrow - Maintaining
Adjusting Harrow Height
The harrow mounting arm height is fixed. The harrow can be angled back
to adjust the depth the teeth penetrate the soil.
Adjusting Spring Tension
Use the 5/16” snap pear link to adjust the chain to the desired length
(remove any twist in the chain). Refer to the photo below.
Pinning the Harrow Up
Remove the 1/2” x 5” clevis pin from behind the top part of the mounting
arm and place the chain in the last link. Pull the harrow up and place the
pin in the front hole. This will hold the harrow up and off the ground in the
field. Refer to the photo below.
1/2” x 5” Clevis Pin
Pin up Hole
5/16” Snap Pear Link
Refer to this photo for harrow adjustments. Angled Tooth Harrow shown.
7
Double Roller Harrow - Maintaining
Adjusting the Roller Height
Front Roller – The front roller has three height adjustments. This will
change the height relationship between the two rollers. Loosen the two
5/8”-11 x 4 1/2”, remove the front bolt. Adjust to desired height and
replace the bolt. Tighten both bolts.
Rear Roller – The rear roller is fixed and is not adjustable.
Adjusting Roller Aggression
Position A- Aggressive Mode produces maximum soil shattering.
Position B- Passive Mode provides a soil firming action.
The front roller should always be placed in the Position A.
Adjusting the Spring Down Pressure
The spring has no adjustment, the weight of the cart preloads the springs.
Lubrication
Use #2 multi purpose lithium grease on bearings at least once a season
or every 150 hours. Pump grease in slowly until old grease and dirt are
forced out around seals. It is best to lubricate bearings just prior to
prolonged storage.
Upper Fixed Spring
Front Roller Height
Adjustment
Lower Fixed Spring
Refer to this photo for roller adjustments.
8
Rolling Finisher - Assembly
Base / Axle Instructions (Diagram page 15)
1. The first step is to identify the proper parts to assemble this section of
the cart. Set the base on saw horses or similar supports.
Note: The axle ears face the front of the cart.
2. Attach the axle assembly to the base. Use the (2) axle hinge pins, 1”-14
slotted hex nuts, and 3/16” x 2” cotter pins to secure the axle to the
base. Secure the axle pins to the hinge ears with a 3/8”-16 x 1 1/4” hex
cap bolt with locknut.
Note: The ears on the lower wheel arms should be pointed to the front.
3. Pin the 3” x 8” cylinders onto the cart. Use the standard pins and clips
supplied with the cylinder. Open hydraulic ports on cylinders to relieve
pressure. Extend the cylinders out, pin to the ear and place the cylinder
locks over the cylinder rods. Use the 1/2” x 2 1/2” clevis pin and bow-tie
keeper clip to secure locks in place.
Note: The hydraulic ports on cylinders must face out.
4. Place the (4) hub and spindle assemblies on the wheel arms. Use the
1/2”-13 x 3” hex cap bolt with locknut to secure the spindle into the
spindle tube. Attach the four tire assemblies to the hubs using 6 hub
bolts.
5. Bolt the jack stand mount to the base. Use the (2) 5/8”-11 x 3 1/2” hex
cap bolt, (4) 1/2”-13 x 3 1/2” hex cap bolt, (2) back plates, lock washers
and nuts to secure assembly to the base. Bolt the 5000# jack stand to
the jack stand riser. Use a 5/8”-11 x 3 1/2” hex cap bolt and lock nut to
secure the jack stand to the riser. Use the 5/8” pin supplied with the jack
stand to pin the jack stand riser to the jack stand mount. Use the 1/4”-20
x 1 1/4” bolt, nut, lock washer, and flat washer to attach the chain to the
jack stand riser.
Note: Mount jack stand assembly right of center on base.
6. Flat Fold - Place the (2) wing stand mounts on the base. Use (1) 1/2”-
13 x 3 1/2” hex cap bolt, lock washer, and nut. The stands should be
placed so that they catch the ends of the wings.
Stack Fold - Place the short wing stand mount on the LH side of the
base. Use (1) 1/2”-13 x 3 1/2” hex cap bolt, lock washer, and nut. This
stand should be placed so that it catches the end of the LH wing. The
longer of the stands is for the RH stack fold wing. Bolt the stand to the
hole closed to the center of the “RF” Cart. Use (1) 3/4”-10 x 3 1/2” hex
cap bolt, locknut. Bolt the (2) supports to the stand and base using (2)
3/4”-10 x 3 1/2” hex cap bolts, locknuts.
Note: The wing stands on the stack-fold machines are not adjustable.
9
Base / A-Frame Instructions (Diagram page 17)
7. Next, the “A” frame can be attached to the base. Use (12) 5/8”-11 x 1
3/4” hex cap bolts, lock washers, and nuts to attach the “A” frame to the
base. The “A” frame matches up to plates on the base. The short brace
on the rear of the A-frame will be located the bottom when mounted
properly.
8. Slide the hitch assembly into the “A” frame assembly. Use (2) 3/4”-10 x
7” hex cap bolts and lock nuts to secure the hitch in the “A” frame. The
hitch length is measured from the hitch pin to the front of the transport
tires.
Note 1: The proper hitch length is equal to 1/2 of the implement width.
Note 2: The plates on the front of the hitch should be offset down. If
more hitch height is needed the hitch can be rotated 180°.
9. Bolt the clevis hitch assembly in to the hitch. Use (2) 3/4””-10 x 6” hex
cap bolts and lock nuts. Bolt the hose holder on with 5/8”-11 x 2” hex
cap bolt, flat washer and locknut. Slide the large ring of the safety chain
over the threaded bushing on the hitch plate. Use the cap, 3/4”-10 x 1
1/2” hex cap bolt and lock washer to secure.
Wing Instructions (Diagram page 19)
10.Attach the wing assembly to the base. Use the (2) wing hinge pins, 1”-
14 slotted hex nuts, and 3/16” x 2” cotter pins to secure the wing to the
base. Secure the wing pins to the hinge ears with a 3/8”-16 x 1 1/4” hex
cap bolt with locknut.
11.Attach the 4” or 4 1/2” x 16” cylinders to the ears on the base frame ear.
Use the standard cylinder pin and clip supplied with each cylinder. The
cylinder with plastic stop is for the RH side and is only used with stack
fold wings.
12.Rotate the (2) linkage straps, (2) 1” UHMW plastic washers and place
them on the wing frame ear as shown in diagram. Use a 1” pin with (2)
machine bushings and 1/4” x 2” cotter pins to hold in place.
Note: The (2) 1” UHMW plastic washers should be placed between the
linkage straps and the wing frame ear.
13.Open hydraulic ports on cylinders to relieve pressure. Extend cylinder
rod out far enough to pin cylinder clevis to upper wing lever hole. Use
the standard pins and clips supplied with cylinder.
Note: The wings will be self supporting.
10
Optional Gage Wheel Instructions (Diagram page 21)
14.Next, bolt the gauge wheel mount assembly and back plate assembly to
wing extension. Use (4) 5/8”-11 x 3 1/2” hex cap bolts, lock washers and
nuts. Location for gauge wheel mounting varies from cart to cart. The
following are maximum distances from the center of the wing hinge pin.
12’ Base - 66” 14’ Base - 89” 16’ Base - 112”
15.Attach the gauge wheel arm assembly to the gauge wheel mount. Use
the axle hinge pins, 1”-14 slotted hex nut, and 3/16” x 2” cotter pin to
secure the arm to the mount assembly. Secure the axle pins to the
hinge ears with a 3/8”-16 x 1 1/4” hex cap bolt with locknut.
Note: The ears on the gauge wheel arms should be pointed to the front.
16.Pin the 3” x 8” cylinders onto the cart. Use the standard pins and clips
supplied with the cylinder. Open hydraulic ports on cylinders to relieve
pressure. Extend the cylinders out, pin to the ear and place the cylinder
locks over the cylinder rods. Use the 1/2” x 2 1/2” clevis pin and bow-tie
keeper clip to secure locks in place.
Note: The hydraulic ports on cylinders must face out.
17.Place the hub and spindle assemblies on the wheel arms. Use the 1/2”-
13 x 3” hex cap bolt with locknut to secure the spindle into the spindle
tube. Attach the tire assemblies to the hubs using 6 hub bolts.
Torque all bolts to specifications, refer to page 5. Periodically check for
loose or worn bolts. Replace as necessary.
Hose Kit Layout - See Appendix page 43
18.The majority of the cart should be assembled. Locate and separate all
hoses and fittings from kit. Follow the proper hose kit diagram that
describes the base size and fold option on your cart. The 3” x 8”
hydraulic cylinders are used for the lift system. The 4” or 4 1/2” x 16”
hydraulic cylinders are used for the wing fold system. Run the pressure
and return lines through the L.H. “A” frame tube. After hoses are placed
on the cart and tightened to the correct cylinders, bolt hose holder
clamps to hose holder bases. Use a 3/8”-16 x 1 1/4” hex cap bolt to
secure clamp to base.
11
Single Bar Harrow - Mounting
1 Bar Harrow Instructions (Diagram page 23)
1. Refer to the harrow layout section of this manual for proper location.
2. Place the zinc coated bushings in the harrow arms and attach the arms in
the proper holes on the frame. Use a 5/8”-11 x 4 1/2” hex cap bolt and
lock nut to secure the arm in place.
Note: If there are wing extensions on your cart, the bolts for these areas
need to be a 1/2” longer.
3. Place the tension spring eyelet in proper mounting hole location. Use a
5/8”-11 x 4 1/2” hex cap bolt and lock nut to secure spring in place. Next
attach the chain of the tension spring to the slot in the harrow arm (remove
any twist in the chain). Use a 5/16” snap pear link to secure the chain in
the slot.
4. Next, lay the harrow sections under the harrow arm. The sections are
tagged for proper location. Refer to the harrow layout section of this
manual for proper harrow section location.
5. Angled Tooth Harrow - Attach the harrow section to harrow mounting
arms. Use (2) 1/2-13” x 4” x 3” u-bolts, flat washers, lock washers and
nuts to hold (formed channel) harrow to arms.
Note: Replace one of the end teeth at the center of the cart with the Y-
tooth that was packed separate. Use the original bolts.
Straight Tooth Harrow - Attach the harrow section to harrow mounting
arms. Use (2) 5/8-11” x 1 1/4” hex cap bolts, flat washers, lock washers
and nuts to hold (angle iron) harrow to arms.
Coil Tine Harrow - Center the tine bars on the harrow mounting arms.
Use (2) 3/8-16” x 1 1/2” x 2 1/14” u-bolts, lock washers and nuts to hold
tine bar to arms. Slide the tine clamp onto the coil tine. Place the coil tine
and clamp assembly onto the tine bars. Use (1) 3/8”-16 x 3 1/2” hex cap
bolt, tine retainer washer, lock washer, & nut. Center the tine finger of the
first coil tine and clamp assembly 2 1/2” from the end of the tine bar.
Place the rest of the tines on 9” centers.
6. Refer to the harrow layout section of this manual for proper harrow
location of bolts and u-bolts. Start with base sections first, and centered
them under the cart. Tighten to secure harrow.
Torque all bolts to specifications, refer to page 5. Periodically check for
loose or worn bolts. Replace as necessary.
12
Double Roller Harrow - Mounting
Double Roller Harrow Instructions (Diagram page 25)
Roller harrows are not recommended in rocky conditions!
1. The roller harrow sections have the bearings factory installed. Refer to
the harrow layout section of this manual for proper harrow section
location.
2. The Double Roller Arms have been pre-assembled at the factory.
3. Place a zinc coated bushing in the roller mounting and mount to the rear
of the cart. Use a 5/8”-11 x 4 1/2” hex cap bolt and lock nut. Attach the
spring assembly to the rear of the cart. Use a 5/8”-11 x 4 1/2” hex cap bolt
and lock nut.
Note: If there are wing extensions on your cart, the bolts for these areas
are a 1/2” longer.
4. Attach the roller frame to the roller sections. Use the 1”-8 x 3 3/4” hex cap
bolt with bearing spacer, lock washer, and nut.
Note: Place the 1” flat washer in the “Gap” between the bearing and the
frame spacer block as needed. Refer to page 25.
5. Lay the roller sections out behind the harrow cart. Attach the roller
sections to the roller mounting arms and the side plate assemblies. Use
the 1/2”-13 x 2” x 3” u-bolt with lock washer and nut. Refer to the harrow
layout section of this manual for proper harrow section location.
Note 1: Refer to page 7 for roller aggression.
Note 2: The front roller should always be placed in the Position A.
6. Bolt SMV sign and owner’s manual canister to bracket using (3) 1/4”-20 x
1 1/4” hex cap bolts, lock washers and nuts. U-bolt SMV bracket to roller
frame on rear of cart. Use a 1/2” x 2” x 3” u-bolt, lock washers and nuts to
secure bracket to the roller frame.
Note: S.M.V sign must be in center or left-of-center on the “RF” Cart.
7. Place all product and warning decals in proper locations on roller cart.
Torque all bolts to specifications, refer to page 5. Periodically check for
loose or worn bolts. Replace as necessary.
13
DescriptionPart NumberItem
Base Axle AssemblyRF-10031
Jackstand Mount WeldmentRF-10392
Jackstand Riser WeldmentRF-10403
Flat Fold Wing Stand
Wing Stand Weldment (12ft & 14ft Base)
Stack Fold Wing Stand (16ft Base)
RF-1054
RF-1050
RF-1051
4
Axle Hinge Pin Assembly w/
1"-14 Hex Slotted Nut & Cotter Pin
RF-1013-AS
5
3 x 8 Cylinder
RF-01086
Wing Stand Support PlateRF-0118
7
1/2"-13 UNC x 3 1/2" Gr.5 Bolt w/ Lock Washer & Nut
8
STD Spindle Seal
RF-00379
Inner Tapered Roller Bearing
RF-003810
Stack-Fold Hydraulic Valve
RF-012711
Outer Tapered Roller Bearing
RF-003912
STD Spindle Washer
RF-004013
STD Spindle Cotter Pin
RF-004114
STD Spindle Nut
RF-004215
3/8-16 UNC x 1 1/4" Gr.5 Bolt
16
7.60L-15 Tire
15-6 6 on 6 Rim
RF-0029
RF-0035
17
Jackstand Back PlateRF-009218
Cylinder Transport LockRF-010019
6 Bolt Spindle
RF-003120
5/8-11 UNC x 3 1/2" Gr.5 Bolt w/Lockwasher & Nut
21
1/2"-20 x 1 1/4" Hub Bolt
22
Transport Lock PinRF-011523
Bow Tie Keeper PinRF-011324
1/2-13 UNC x 3" Gr.5 Bolt w/ Locknut
25
STD Dust Cap
RF-004326
5000# Top Crank Jack Stand - Square Mnt
RF-010927
1/4-20 UNC x 2 3/4" Gr.5 Bolt w/ Lockwasher & Nut
29
STD 6-Bolt HubRF-003030
3/8-16 UNC x 3" Gr.5 Bolt w/ Lockwasher & Nut
31
3/4-10 UNC x 3 1/2" Gr.5 Bolt w/ Locknut
32
1/2-13 UNC x 2 1/2" Gr.5 Carriage Bolt
33
Valve Plate WeldmentRF-107434
Parts Description - Base / Axle
14
Parts Description - Base / Axle
1
2
3
4
5
6
7
20
9
10
30
12
13
15
14
26
22
17
23
19
24
25
1.00
See Lower LH Corner
21
27
4
34
31
29
11
8
16
1
33
32
18
Reflector
2 x 9 Yellow
Front Side Only
Decal- "FEMA"
Both Ends
Remove Pin & Chain
From Jackstand Attach
to Jackstand Mount
21
8
Reflector
2 x 9 Red
Backside Only
Decal- "Caution"
Transport Lock
Serial #
Location
15
DescriptionPart NumberItem
12ft Base Weldment
14ft Base Weldment
16ft Base Weldment
RF-1085
RF-1088
RF-1090
1
12ft A-Frame Weldment
14ft & 16ft A-Frame Weldment
RF-1086
RF-1089
2
12ft Base HD Telescoping Hitch Weldment
14ft & 16ft Base HD Telescoping Hitch Weldment
RF-1091
RF-1087
3
Hose Holder Rod Assembly
w/ 3/16" x 2" Cotter Pin
RF-1041-AS
4
CAT III Cast Hitch Assy
Bolt on Cast Clevis
Cast Base Hitch
3/4-10 UNC x 5" Gr.8 Bolt w/ Locknut
PUR-10001
PUR-00003
PUR-00004
5
3/4-10 UNC x 6" Gr.5 Bolt w/ Locknut
6
3/4-10 UNC x 7" Gr.5 Bolt w/ Locknut
7
Large Hose HolderPUR-000058
5/8-11 UNC x 2" GR. 5 Bolt w/ Washer & Locknut
9
1/4-20 UNC x 4.5" Gr.5 Bolt w/ Lockwasher & Nut
10
Stack-Fold Hydraulic Valve
RF-012711
R.H. Light Bracket
L.H. Light Bracket
RF-0168
RF-0169
12
1/4-20 UNC x 1" Gr.5 Bolt w/ Lockwasher & Nut
13
R.H. Dual Light Box w/ Brake
L.H. Dual Light Box w/ Brake
EL-0004
EL-0005
14
Hose Holder Clamp
RF-009715
3/8-16 UNC x 1 1/4" Gr.5 Bolt
16
SMV BracketRF-012117
Owner's Manual Canister
RF-014218
1/2-13 X 2" X 3 1/2" U-Bolt w/ Lockwasher & NutRB-0025-AS
19
1/4-20 UNC x 1.25" Gr.5 Bolt w/ Lockwasher & Nut
20
S.M.V. Sign
RF-016721
Parts Description - Base / Axle
16
Parts Description - Base / A-Frame
2
7
34
8
9
6
5
11
10
16 15
1
Light Kit
12
13
14
Use Existing Roller
Arm Bolts to Mount
Red Lens Outside Rear
19
17
18
20
21
SMV Sign
Decal- "3500 Rolling Finisher"
Both Sides
Reflector- 2 x 9 Yellow
Both Sides
Decal- "Caution Transport Hazard"
Both Sides
Reflector 2 x 9 Yellow
Both Sides
17
Parts Description – Wing
Item No. Part No. Part Name / Description
1 RF-1004
RF-1017
RF-1031
RF-1032
RF-1033
RF-1034
RF-1035
RF-1036
LH 6ft Wing Assembly
RH 6ft Wing Assembly
RH 5ft Wing Assembly
LH 5ft Wing Assembly
RH 4ft Wing Assembly
LH 4ft Wing Assembly
RH 3ft Wing Assembly
LH 3ft Win
g
Assembl
y
(
shown
)
2 RF-0048 Win
g
Pivot Leve
r
3 RF-0044 Linka
g
e Strap
4A RF-0110
RF-0134 4” x 16” Cylinder w/ Pins & Clips
4 1/2” x 16” C
y
linder w/ Pins & Clips
4B RF-1067
RF-1068
4” x 16” Cylinder w/ Pins, Clips,
& Plastic Stop (stack fold only)
4 1/2” x 16” Cylinder w/ Pins, Clips,
& Plastic Stop
(
stack fold onl
y
)
5 RF-0049 1” UHMW Plastic Washe
r
6 RF-0050 1 1/4” UHMW Plastic Washe
r
7 RF-0065-AS 1 1/4” Pivot Pin
w/
(
2
)
Flat washers & Cotter Pins
8 RF-0066-AS 1” Pivot Pin
w/
(
2
)
Machine Bushin
g
& Cotter Pins
9 RF-1012-AS Wing Hinge Pin Assembly
w/ 1”-14 Hex Slotted Nut & Cotter Pin
10 3/8”-16 x 1 1/4” Gr. 5 Bolt w/ Locknut
11 5/8”-11 x 2” Gr. 5 Bolt w/ Jamb Nut
(
stack fold onl
y
)
18
19
Parts Description – Wing Extension / Gage Wheel
Item No. Part No. Part Name / Description
1 Win
g
Assembl
y
2 RF-1042
RF-1043
RF-1044
RF-1045
RF-1046
RF-1047
LH 4ft Wing Extension Assembly (shown)
LH 4.5ft Wing Extension Assembly
LH 5ft Wing Extension Assembly
RH 4ft Wing Extension Assembly
RH 4.5ft Wing Extension Assembly
RH 5ft Win
g
Extension Assembl
y
3 RF-1010
RF-1011 LH Gage Wheel Arm Assembly (shown)
RH Ga
g
e Wheel Arm Assembl
y
4 RF-1009 Ga
g
e Wheel Mount Assembl
y
5 RF-1013-AS Axle Hinge Pin Assembly
w/ 1”-14 Hex Slotted Nut & Cotter Pin
6 RF-0108 3 x 8 C
y
linder w/ Pins & Clips
7 RF-1049 Ga
g
e Wheel Back Plate Assembl
y
8 RF-0031 Standard 6-Bolt Hub Spindle
9 RF-0037 6-Bolt Spindle Seal
(
CR16289
)
10 RF-0038 6-Bolt Inner Bearin
g
(
JL69349
)
11 RF-0030 Standard 6-Bolt Hub
(
GKN#888
)
12 RF-0039 6-Bolt Outer Bearin
g
(
LM67048
)
13 RF-0040 6-Bolt Spindle Washer
(
GKN #913607
)
14 RF-0041 6-Bolt Spindle 5/32” x 2” Cotter Pin
15 RF-0042 6-Bolt Spindle Nut
(
GKN #912952
)
16 RF-0043 6-Bolt Dust Cap
(
GKN #909905
)
17 RF-0029
RF-0035 7.60L-15 Tire
15-6 6 on 6 Rim
18 RF-0097 Hose Holder Clamp
19 RF-0100 C
y
linder Transport Lock
20 5/8”-11 x 3 1/2” Gr. 5 Bolt
w/ Lock washer & Nut
21 5/8”-11 x 1 1/2” Gr. 5 Bolt
w/ Lock washer & Nut
22 1/2”-20 x 1 1/4” Hub Bolt
23 RF-0115 1/2” x 2 1/2" Clevis Pin
24 RF-0113 Bow-Tie Keeper Clip
25 1/2"-13 x 3” Gr. 5 Bolt w/ Locknut
26 3/8”-16 x 1 1/4” Gr. 5 Bolt w/ Locknut
20
Table of contents
