Canon FINISHER-C1 User manual

COPYRIGHT © 1998 CANON INC. FINISHER-C1/SADDLE FINISHER-C2 REV. 0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
FINISHER-C1/
SADDLE FINISHER-C2
SERVICE
MANUAL
REVISION 0
DEC. 1998 FY8-13F6-000

COPYRIGHT © 1998 CANON INC. FINISHER-C1/SADDLE FINISHER-C2 REV. 0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
IMPORTANT
THE INFORMATION CONTAINED HEREIN PUBLISHED BY CANON, INC., JAPAN.
SPECIFICATIONSANDOTHERINFORMATION CONTAINEDWHEREINMAY SLIGHTLYFROM
ACTUAL MACHINE VALUES OR THOSE FOUND IN ADVERTISING AND OTHER PRINTED
MATTER.
ANY QUESTIONS REGARDING INFORMATION CONTAINED HEREIN SHOULD BE DI-
RECTED TO THE COPIER SERVICE DEPARTMENT OF THE COMPANY.
COPYRIGHT © 1998 CANON INC.
Printed in Japan
Imprimé au Japon
Use of this manual should be strictly super-
vised to avoid disclosure of confidential in-
formation.
Prepared by
OFFICE IMAGING PRODUCTS TECHNICAL SUPPORT DEPARTMENT 1
OFFICE IMAGING PRODUCTS TECHNICAL SUPPORT DIVISION
CANON INC.
5-1, Hakusan 7-chome, Toride-shi Ibaraki, 302-8501 Japan

COPYRIGHT © 1998 CANON INC. FINISHER-C1/SADDLE FINISHER-C2 REV. 0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
i
This Service Manual contains basic data and figures for the Finisher-C1/Saddle Fin-
isher-C2 needed to service the machine in the field.
Chapter 1 ‘General Description’ introduces the finisher’s features, specifications, and
names of parts, and shows how to operate the sorter.
Chapter 2 ‘Finisher Unit Basic Operation’discusses the principles of operation used for
the finisher mechanical and electrical systems. It also explains the timing at
which these systems are operated.
Chapter 3 ‘Saddle Stitcher Unit Basic Operation’ discusses the principles of operation
used for the saddle stitcher unit’s mechanical and electrical systems. It also
explains the timing at which these systems are operated.
Chapter 4 ‘Mechanical System’discusses how the finisher is constructed mechanically,
and shows how it may be disassembled/assembled and adjusted.
Chapter 5 ‘Maintenance and Inspection’ provides tables of periodically replaced parts
and consumables and durables, together with a scheduled servicing chart.
Chapter 6 ‘Troubleshooting’ provides tables of maintenance/inspection, standards/ad-
justments, and problem identification (image fault/malfunction).
‘Appendix’ contains diagrams showing tables of signals, tables of solvents/
oils, and a general timing chart.
The descriptions in this Service Manual are subject to change without notice for prod-
uct improvement or other purposes, and major changes will be communicated in the form
of Service Information bulletins.
All service persons are expected to have a good understanding of the contents of this
Service Manual and all relevant Service Information bulletins and be able to identify and
isolate faults in the machine.
INTRODUCTION

COPYRIGHT © 1998 CANON INC. FINISHER-C1/SADDLE FINISHER-C2 REV. 0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
ii

COPYRIGHT © 1998 CANON INC. FINISHER-C1/SADDLE FINISHER-C2 REV. 0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
iii
CHAPTER 1 GENERAL DESCRIPTION
CONTENTS
I. FEATURES ..................................1-1
II. SPECIFICATIONS .......................1-2
A. Specifications ...........................1-2
B. Cross Section ...........................1-7
III. USING THE MACHINE ................1-9
A. Removing Paper Jams from
the Finisher Unit .......................1-9
B. Supplying the Finisher Unit
with Staples ........................... 1-10
C. Removing Staple Jams from
the Finisher Unit .................... 1-11
D. Removing Paper Jams from
the Saddle Sticher Unit.......... 1-13
E. Supplying the Saddle Stitcher
Unit with Staples.................... 1-14
F. Removing Staple Jams from
the Saddle Stitcher Unit......... 1-15
G. Removing Paper Jams from the
Interrupt Tray.......................... 1-17
IV. MAINTENANCE BY THE USER 1-18
A. Maintenance by the User ...... 1-18
I. BASIC OPERATION ....................2-1
A. Outline ......................................2-1
B. Outline of Electrical
Circuitry ....................................2-2
C. Inputs to and Outputs
from the Finisher
Controller PCB..........................2-3
II. FEED/DRIVE SYSTEM................2-9
A. Outline ......................................2-9
B. Types of Delivery Paths ......... 2-13
C. Feeding and Delivering.......... 2-16
D. Job Offset .............................. 2-19
E. Stapling Operation................. 2-22
F. Stapler Unit............................ 2-28
G. Tray Operation ....................... 2-35
H. Detecting the Height of the Stack
on the Tray ............................. 2-37
I. Shutter Operation .................. 2-39
J. Buffer Path Operation ............ 2-43
K. Interrupt Tray Delivery ............ 2-47
L. Detecting Jams...................... 2-49
III. POWER SUPPLY SYSTEM ...... 2-55
CHAPTER 2 FINISHER UNIT BASIC OPERATION

COPYRIGHT © 1998 CANON INC. FINISHER-C1/SADDLE FINISHER-C2 REV. 0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
iv
I. BASIC OPERATION ....................3-1
A. Outline ......................................3-1
B. Electrical Circuitry.....................3-2
C. Inputs to and Outputs
from the Saddle Stitcher
Controller PCB..........................3-3
II. FEEDING/DRIVE SYSTEM .........3-8
A. Outline ......................................3-8
III. PAPER DEPOSITING
MECHANISM ............................ 3-14
A. Outline ................................... 3-14
B. Controlling the Inlet
Flappers................................. 3-17
C. Controlling the Movement
of Sheets................................ 3-21
D. Aligning the Sheets ............... 3-22
E. Controlling the Phase of
the Crescent Roller................ 3-25
IV. STITCHING SYSTEM............... 3-27
V. FOLDING/DELIVERY
SYSTEM ................................... 3-30
VI. CHECKING FOR A JAM........... 3-35
VII. POWER SUPPLY...................... 3-39
CHAPTER 3 SADDLE STITCHER UNIT
BASIC OPERATION
(A) FINISHER UNIT...........................4-1
I. EXTERNALS AND
CONTROLS .................................4-1
A. External Covers ........................4-1
II. FEEDING SYSTEM .....................4-8
III. PCBs ......................................... 4-15
(B) SADDLE STITCHER UNIT ....... 4-16
CHAPTER 4 MECHANICAL CONSTRUCTION
I. PERIODICALLY REPLACED PARTS
.....................................................5-1
A. Finisher Unit .............................5-1
B. Saddle Stitcher Unit..................5-1
II. CONSUMABLES AND
DURABLES..................................5-1
A. Finisher Unit .............................5-1
B. Saddle Stitcher Unit..................5-1
III. PERIODICAL SERVICING ..........5-1
CHAPTER 5 MAINTENANCE AND INSPECTION

COPYRIGHT © 1998 CANON INC. FINISHER-C1/SADDLE FINISHER-C2 REV. 0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
v
I. ADJUSTMENTS ..........................6-1
A. Electrical System
(finisher unit).............................6-1
B. Electrical System
(saddle stitcher unit) .................6-3
II. ALIGNMENT OF ELECTRICAL
PARTS..........................................6-8
A. Finisher Unit .............................6-8
B. Saddle Stitcher Unit............... 6-14
C. Variable Resistors (VR),
Light-Emitting Diodes (LED),
and Check Pins by PCB ........ 6-20
III. TROUBLESHOOTING .............. 6-22
A. Finisher Unit .......................... 6-22
B. Saddle Stitcher Unit............... 6-30
VI. SELF DIAGNOSIS .................... 6-37
A. Finisher Unit .......................... 6-37
B. Saddle Stitcher Unit............... 6-39
C. Alarm ..................................... 6-41
D. Copier I/O Notations.............. 6-43
CHAPTER 6 TROUBLESHOOTING
APPENDIX
A. Finisher Unit General Timing
Chart ........................................... A-1
B. Finisher Unit General Timing
Chart ........................................... A-2
C. Saddle Stitcher Unit General
Timing Chart ............................... A-3
D. Signal and Abbreviations ............ A-4
E. Finisher Unit General Circuit
Diagram....................................... A-5
F. Saddle Stitcher Unit General
Circuit Diagram ........................... A-6
G. Solvents and Oils ........................ A-7

COPYRIGHT © 1998 CANON INC. FINISHER-C1/SADDLE FINISHER-C2 REV. 0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 1
GENERAL DESCRIPTION
I. FEATURES ..................................1-1
II. SPECIFICATIONS .......................1-2
A. Specifications .............................1-2
B. Cross Section .............................1-7
III. USING THE MACHINE ................1-9
A. Removing Paper Jams from
the Finisher Unit .........................1-9
B. Supplying the Finisher Unit
with Staples ............................. 1-10
C. Removing Staple Jams from
the Finisher Unit ...................... 1-11
D. Removing Paper Jams from
the Saddle Sticher Unit ........... 1-13
E. Supplying the Saddle Stitcher
Unit with Staples ..................... 1-14
F. Removing Staple Jams from
the Saddle Stitcher Unit .......... 1-15
G. Removing Paper Jams from the
Interrupt Tray ........................... 1-17
IV. MAINTENANCE BY THE USER 1-18
A. Maintenance by the User ........ 1-18

COPYRIGHT © 1998 CANON INC. FINISHER-C1/SADDLE FINISHER-C2 REV. 0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
1-1
CHAPTER 1 GENERAL DESCRIPTION
I. FEATURES
1. Accommodates large quantities of sheets
●Normally, the finisher holds a stack of sheets 220.6 mm in height in its three bins (small-
sized paper of 80 g/m2; no stapling).
2. Has high paper transportation performance.
●The finisher is capable of handling papers between 50 and 157 g/m2.
3. Offers a job offset function.
●The finisher’s job offset function delivers the first or the last sheet of each job by displacing
it to the front, enabling sorting of copies on the tray.
4. Offers four types of auto stapling.
●The finisher offers a choice of four stapling modes (1-point stapling at rear, diagonal sta-
pling at front, diagonal stapling at rear, 2-point stapling).
5. Uses a buffer roller.
●The use of a buffer roller enables the finisher to accept copies without interruption from the
copier even during stapling or offset operation (small-size paper only).
6. Offers an interrupt delivery function.
●Installation of the interrupt delivery tray will enable an interruption of an ongoing op-
eration (up to 50 copies of small-size paper or up to 30 copies of large-size paper; both
of 80 g/m2).
7. Has a saddle stitch function (Saddle Finisher-C2).
●The finisher can staple along the center of paper and fold it in two (up to 15 sheets).
8. Offers an incoming fax indicator (option).
●When installed, the incoming fax indicator lamp (LED) will turn on to indicate the arrival of
a fax on tray 2/3.

COPYRIGHT © 1998 CANON INC. FINISHER-C1/SADDLE FINISHER-C2 REV. 0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
1-2
CHAPTER 1 GENERAL DESCRIPTION
Description
Trays 1 through 3: by lifting tray
Interrupt tray: by fixed tray
Face-down
Face-up (1 to ncopies only)
AB: A3, A4, A4R, A5, A5R, B4, B5, B5R, postcard
Inch: 279 × 432 mm (11 × 17), LGL, LTR, LTRR, STMT, STMTR
50 to 128 g/m2
Interrupt tray, trays 1 through 3
Non-sort: trays 1 through 3 and interrupt tray
Sort: trays 1 through 3
Staple: trays 1 through 2
Interrupt tray Small size: 50 sheets
Large size: 30 sheets
Non staple sort Small-size Tray 1: 44 mm high (300 sheets)
(Note 1) Tray 2: 146.6 mm high (1000 sheets)(Note 2)
Tray 3: 30 mm high (200 sheets)
Large-size Tray 1: 22 mm high (100 sheets)
(Note 1) Tray 2: 74 mm high (500 sheets)
Tray 3: 15 mm high (100 sheets)
Staple sort Small-size Tray 1: 47 mm high/50 sets (300 sheets)
(Note 1) Tray 2: 146.6 mm high/50 sets (1000 sheets)
Tray 3: Not possible
Large-size Tray 1: 22 mm high/30 sets (150 sheets)
(Note 1) Tray 2: 74 mm high/30 sets (500 sheets)
Tray 3: Not possible
Size mixing: 44 mm or less (300 sheets)
Stapling: 22 mm or less (150 sheets)
Face-up/face-down
II. SPECIFICATIONS
A. Specifications
1. Finisher Unit
Item
Stacking method
Stacking orientation
Stacking size
Paper weight
Bins
Modes
Stacking capacity
Size mixing
Stacking mixing
Notes:
1. Approximate when computed with reference to 80 g/m2paper.
2. Alignment may not be correct if 750 or more small-size sheets are stacked on tray 2.
3. The accuracy of the stack height is ±7 mm.
Table 1-201

COPYRIGHT © 1998 CANON INC. FINISHER-C1/SADDLE FINISHER-C2 REV. 0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
1-3
CHAPTER 1 GENERAL DESCRIPTION
Description
By rotating cam
See Figure 1-201.
Small-size 50 sheets
Large-size 25 sheets
Special staple cartridge (5000 staples)
Special (staple-E1)
Provided
Not provided
1-point (diagonal) Front A3, B4, A4m, A4R, B5, 279 × 432 mm
(11 × 17), LGL, LTR, LTRR
Rear A3, B4, A4, A4R, B5, 279 × 432 mm (11 × 17),
LTR
1-point Rear A4R, LTRR, LGL
2-point A3, B4, A4, B5, 279 × 432 mm (11 × 17), LTR
Trays 1 through 3: provided Interrupt tray: not provided
Not provided
Incoming fax indicator lamp (option)
669 × 582 × 1047 mm (W × D × H; including saddle stitcher unit)
45 kg (including saddle stitcher unit)
From copier (24 VDC)
170 W or less
ZLJXXXXX (Finisher-C1)
Table 2-202
Item
Stapling
Stapling position
Stapling capacity
Staple supply
Staples
Staple detection
Manual stapling
Stapling size
Paper detection
Control panel
Display
Dimensions
Weight
Powr supply
Maximum power
consumption
Serial number
Equivalent of 80 g/m2paper
Reference:
Small-size represents A4, A5, A5, B5, postcard, LTR, STMT, STMTR, while large-size
represents A3, B4, A4R, B5R, LTRR, 279 × 432 mm (11 × 17), LGL.

COPYRIGHT © 1998 CANON INC. FINISHER-C1/SADDLE FINISHER-C2 REV. 0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
1-4
CHAPTER 1 GENERAL DESCRIPTION
Stapling Positions (finisher unit)
6±2mm
5±2mm
5±2mm
82.7±4mm
202.7±4mm
4.5±2mm
30
4.4±2mm
6±2mm
30
4±2mm
5±2mm
62.7±4mm
182.7±4mm
5±2mm
73.7±4mm
193.7±4mm
1-point stapling (rear)
2-point stapling
A3 and A4 B4 and B5 279 × 432 mm
(11 × 17), LTR
1-point stapling
(diagonal; front) 1-point stapling (diagonal; rear)
Figure 1-201

COPYRIGHT © 1998 CANON INC. FINISHER-C1/SADDLE FINISHER-C2 REV. 0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
1-5
CHAPTER 1 GENERAL DESCRIPTION
Table 2-203
Description
Center binding (double folding)
See Figure 1-202.
A3, B4, AR4, 297mm × 432mm (11 × 17), LTRR
15 sheets (including single cover page)
64 to 80 g (cover page up to 128 g)
10 sets (stack of 11 to 15 sheets), 20 sets (stack of 6 to 10 sheets),
25 sets (stack of 5 sheets or less)
Stapling position 2 points (center distribution; fixed interval)
Staple accommodation 2000 staples
Staple supply Special cartridge
Staples Special staples (Staple-D1)
Staple detection Provided
Manual stapling Not provided
Folding method Roller contact
Folding mode Double folding
Folding position Paper center
Position adjustment Provided
From finisher unit
(24 V channel × 2)
160 W or less
ZLKxxxxx (Saddle Finisher-C2)
Item
Stapling method
Folding position
Paper size
Capacity
Paper weight
Stackihng capacity
Stapling
Folding
Power supply
Power consumption
Serial number
2. Saddle Stitcher Unit

COPYRIGHT © 1998 CANON INC. FINISHER-C1/SADDLE FINISHER-C2 REV. 0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
1-6
CHAPTER 1 GENERAL DESCRIPTION
Staple and Folding Positions (saddle stitcher unit)
83.5±1.5mm
203.5±1.5mm
210±1.5mm
A3
Staple position
Stack front edge
L (difference between folding
and staple positions) =
±0.5mm
L
63.5±1.5mm
183.5±1.5mm
182±1.5mm
B4
L (difference between folding
and staple positions) =
±0.5mm
L
40±1.5mm
160±1.5mm
148.5±1.5mm
A4R
L (difference between folding
and staple positions) =
±0.5mm
L
43±1.5mm
163±1.5mm
139.7±1.5mm
LTR
L (difference between folding
and staple positions) =
±0.5mm
L
74.7±1.5mm
194.7±1.5mm
216±1.5mm
297mm ◊432mm
(11 ◊17)
L (difference between folding
and staple positions) =
±0.5mm
L
Folding position
Figure 1-202
Specifications are subject to change without notice.

COPYRIGHT © 1998 CANON INC. FINISHER-C1/SADDLE FINISHER-C2 REV. 0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
1-7
CHAPTER 1 GENERAL DESCRIPTION
B. Cross Section
1. Finisher Unit
[1] Tray 1/2/3
[2] Shutter
[3] Delivery roller
[4] Jog guide
[5] Feed roller 2
[6] Height sensor
[7] Interrupt tray
[8] Incoming fax indicator lamp
(option; 115V)
[9] Wrap flapper
[10] Buffer roller
[11] Interrupt flapper
[12] Buffer inlet flapper
[13] Saddle stitcher flapper
[14] Feed roller 1
[15] Vertical path
[16] Stapler
[17] Feed belt
[18] Tray lift motor
[19] Saddle stitcher unit
(Saddle Finisher-C2)
Figure 1-203

COPYRIGHT © 1998 CANON INC. FINISHER-C1/SADDLE FINISHER-C2 REV. 0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
1-8
CHAPTER 1 GENERAL DESCRIPTION
2. Saddle Stitcher Unit
[1] Guide plate
[2] Folding roller
[3] Delivery guide plate
[4] Holding roller
[5] Stitcher (front, rear)
[6] Inlet roller
[7] No. 1 flapper
[8] No. 2 flapper
[9] Stitcher mount (front, rear)
[10] Butting plate
[11] Crescent roller
[12] Paper positioning plate
Figure 1-204

COPYRIGHT © 1998 CANON INC. FINISHER-C1/SADDLE FINISHER-C2 REV. 0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
1-9
CHAPTER 1 GENERAL DESCRIPTION
III. Using the Machine
A. Removing Paper Jams
from the Finisher Unit
Ifthecopier indicatesthefinisherpaperjam
message, perform the following to remove the
jam.
1) Holding the finisher unit as shown, move
it to detach it from the copier.
Figure 1-301
2) Remove any jam visible from the outside.
Figure 1-302
3) Shift up the interrupt tray, open the upper
cover, and check the inside of the finisher.
Figure 1-303
4) Lift the buffer roller cover, and remove the
jam.
Figure 1-304
5) Lift the buffer roller, and remove the jam.
Figure 1-305

COPYRIGHT © 1998 CANON INC. FINISHER-C1/SADDLE FINISHER-C2 REV. 0 DEC. 1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
1-10
CHAPTER 1 GENERAL DESCRIPTION
6) Return the buffer roller and the gray cover
to their original position, and close the up-
per cover and the interrupt tray.
Figure 1-306
7) Connect the finisher to the copier.
Figure 1-307
8) Operate as instructed on the display.
B. Supplying the Finisher
Unit with Staples
If the copier indicates the finisher unit
staple supply message, perform the following
to supply it with staples.
Figure 1-308
2) Shift down the green lever.
Figure 1-309
3) When the staple cartridge has slightly slid
out, hold and pull it out.
Figure 1-310
4) Hold the emptystaplecaseon its sides, and
slide it out.
Figure 1-311
