Product Overview

© 2010
Company Confidential
Notifications to LED indicators:
For RP 12 GSM / CDMA
For RP 12 GSM / CDMA there are 2 LEDs on each RP12-GSM and RP12-CDMA
repeaters ,One is power LED and the other one is alarm LED.
For power LED, it glows when the input power is within 110/220V ±20% ,and power
switch is on.
For alarm LED, one can observe three colors, and each one has distinct meanings
as listed below.
‧Green : Indicates normal operation.
‧Orange: Indicates the AGC(Auto Gain Control) has activated .
‧Red : Indicates the I/O power is too high to be depressed by the AGC and the
repeater is then saturated which might damage itself.
4

© 2010
Company Confidential
Notifications to LED indicators:
For RP 12 DCS / WCDMA
For RP 12 DCS / WCDMA there are 3 LEDs on each repeaters: one LED
indicates the status of the repeater and the other 2 are for uplink/downlink
power.
L1 : Status indicator , it should illuminate green when the repeater is working
properly.
L2 : Downlink indicator , each green ,yellow or red light represent different alarm.
L3 : Uplink indicator , each green ,yellow or red light represent different alarm.
Please see as the following table
5

© 2010
Company Confidential
6

© 2010
Company Confidential
7
RP12WCDMA Repeater Specification
Product Overview
Electrical Specification
Specification Uplink Downlink
1920~1980MHz 2110~2170MHz
Maximum Gain ≧60dB
Auto Gain Control ≧20dB
Max. Output Power ≧15dBm ≧15dBm
Gain Flatness ≦10dB（p-p）≦10dB（p-p）
Adjacent Channel Rejection Ratio(ACRR) ≧20dBc/30KHZ@±HZ&±HZ
Noise Figure ≦6dB
Return Loss ≦- 10dB
Spurious Emission Mask Comply with 3GPP TS 25.106
Spurious Emission Comply with 3GPP TS 25.106/Category B
Group Delay ≦0.5μs
Modulation Accuracy ≦12.5%
Peak Code Domain Error ≦-35dB@Spreading Factor 256
AC adapter DC 9V/3A
2、
、、
、Mechanical specification
Dimensions(H*W*D)
240×135×47mm
Weight ≦2kg
RF Connector
N female
Impedance
50Ω
3、
、、
、Environmental specification
Operating Temperature -10~50℃

© 2010
Company Confidential
8
•RP12 WCDMA Repeater
•Applications
•System Design
•Commissioning
•Troubleshooting
•NOKIA 6680 Tech Mode
Agenda
AgendaAgenda
Agenda

© 2010
Company Confidential
9
–RP12WCDMA repeater is dedicated for indoor coverage, such as
small offices, houses, basements, and public places.
–The amount of service antennas can be one to four; omni or panel.
–The donor antenna is recommended to be mounted at below 7
th
floor.
–Donor signal strength and quality must be good enough. (refer to the
slide of “Selection of Donor Signal”)
Application

© 2010
Company Confidential
10
Installation - Wall Mounted
Application

© 2010
Company Confidential
11
Connection
Application

© 2010
Company Confidential
12
Heat Sink
Application

© 2010
Company Confidential
13
•RP12 WCDMA Repeater
•Applications
•System Design
•Commissioning
•Troubleshooting
•NOKIA 6680 Tech Mode
Agenda
AgendaAgenda
Agenda

© 2010
Company Confidential
14
Flow Chart of Site Survey
1. Use antennas with higher
front-to-back ratio
2. Change location of antennas
to enlarge their separation
1. Use antennas with higher
front-to-back ratio
2. Change location of antennas
to enlarge their separation
Negotiate with house owner to know
the possible places to mount repeater,
donor & service antennas.
Negotiate with house owner to know
the possible places to mount repeater,
donor & service antennas.
Check OK
Change location of donor
antenna Negotiate again?)
Change location of donor
antenna Negotiate again?)
N.G.
Isolation measurement Donor and
service antennas must be brought )
Make a record)
Isolation measurement Donor and
service antennas must be brought )
Make a record)
N.G.
Selection of donor
signal Make a record)
Selection of donor
signal Make a record) On-site measurement:
1).Walk test; 2).CQT
On-site measurement:
1).Walk test; 2).CQT
Site Survey OK
Site Survey OK
Uplink Noise Floor Consideration
Make a record)
Uplink Noise Floor Consideration
Make a record)
N.G.
Change location of donor
antenna to cover it up
enlarge path loss)
Change location of donor
antenna to cover it up
enlarge path loss)
Good
Good
Good
Good
Good
Check OK
Check OK
Reporting
Site Survey Report or
Technical Proposal)
Reporting
Site Survey Report or
Technical Proposal)
System Design

© 2010
Company Confidential
15
Since most of mobile phones nowadays haven’t connecting port of external antenna,
directly measured by a engineering-mode mobile phone is also acceptable.
Tools
Tools
Nokia-6680 Nokia-6630
Software
Software
ield Test Display
Cell Track (Cell ID)
System Design
Selection of Donor Signal (WCDMA Tools)

© 2010
Company Confidential
16
dB 6 )
N
E
( - )
N
E
(
MS_CPICH
0
C
AS_CPICH
0
C
≥
dB 70- ~ 60- )
N
E
( (RSSI) (RSCP)
AS_CPICH
0
C
rTotal_PoweAS_CPICH
=
==
=+
++
+=
==
=
dB 7- )
N
E
(
AS_CPICH
0
C
≥
WCDMA – Three Criteria as below descriptions & formulas
1. Signal Strength — RSCP of donor signal is better ranged from -60 to -70 dBm. Depends)
2. Signal Quality — Ec/No of donor signal must be equal or larger than -7 dB.
3. Signal Stability — RSCP of donor signal must be equal or larger than neighbor signals by 6 dB.
Remark
AS_CPICH: Pilot Channel in Active Set i.e., Serving Cell)
MS_CPICH: Pilot Channel in Monitor Set i.e., Neighbor Cell)
Total_Power: Total power including CPICH, Control &
Traffic Channels for some frequency.
Selection of Donor Signal (WCDMA Tools)
System Design

© 2010
Company Confidential
17
Isolation Measurement
Isolation ≧
≧≧
≧Rpt. Gain + 15 = 60 + 15 = 75 (dB)
75 dB is the minimum requirement for the isolation between antennas.
System Design

© 2010
Company Confidential
18
BTS
BTS
A
50m
+12dBi -6dB Gain: 60 dB
Noise Figure: 6 dB
A
RP
RP A
25m
Noise Floor Consideration (Uplink)
Propagation Loss ≧
≧≧
≧ Rep. Gain + N.F. = 60 + 6 = 66 (dB)
43 dBm -56 -44 -50 dBm
Measured by
NetMonotor Measured by
spectrum analyzer
-121 dBm for GSM/DCS
-108 dBm for WCDMA
(Thermal Noise)
Trough a good
design, noise
floor will be
well controlled.
Propagation Loss= 93 dB (≧
≧ ≧
≧66 dB)
System Design

© 2010
Company Confidential
19
R19
System Design
Technical Proposal / Site Survey Report (Example)

© 2010
Company Confidential
20
System Design
Technical Proposal / Site Survey Report (Example)
