Cypress CHDBX-1C User manual

CHDBX-1C
HDBaseT Repeater
Operation Manual
Operation Manual
5-Play™


DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 26/07/12 Preliminary Release
RDV2 29/10/12
VS0 25/01/13 Updated format/diagrams

CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Front Panel.........................................3
6.2 Rear Panel .........................................4
7. Connection Diagram ............................ 5
8. Specications ........................................ 7
9. Acronyms ............................................... 8

1
1. INTRODUCTION
The HDBaseT™ Repeater allows HDBaseT systems to be extended and
cascaded. Supporting the highest quality of uncompressed high-
denition HD video up to 4K×2K, up to 8 channels of uncompressed
multi-channel audio, RS-233 and IR control systems, PoE and
Ethernet, complete HDBaseT 5 Play™ convergence with just a simple
connection over a single CAT5e/6/7 cable.
2. APPLICATIONS
• HDBaseT signal extension up to 200m (300m with additional
Repeater unit)
• Cascading HDBaseT Matrixes
• Cascading HDBaseT equipment
3. PACKAGE CONTENTS
• HDBaseT Repeater
• 24 V/1.25 A Power Adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
HDBaseT Transmitter and HDBaseT Full or Lite Receiver with CAT5e/6/7
connection cables.

2
5. FEATURES
• HDCP and DVI Compliant
• Supports 3D over HDMI and 4k×2k resolution
• Supports CEC bypass
• Transmission of uncompressed data up to 200m/656ft with single
device
• Uncompressed video 1080p, 60Hz, 36-bit
• Audio support up to LPCM 7.1CH, Dolby TrueHD and DTS-HD Master
Aduio
• 5Play™ Convergence: Full uncompressed HD Video, Audio, Ethernet,
Power and Controls (IR and RS-232) over a single CAT5e/6/7 cable
• Powered by transmitter without power supply connection (PoE)
• Installation friendly
Note: The PoE function is designed for powering compatible receiver
units only—do not use with non-PoE receivers or receivers of another
brand.

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
CAT5e/6 OUT
HDBaseT Repeater
CHDBX-1C
MODELINK
1 2 3
1MODE LED
The yellow LED will ash when the unit is powered or when an
active transmitter is connected.
2CAT5e/6 OUT
Connect to the receiver unit with a single CAT5e/6/7 cable (up to
100m).
3LINK LED
The green LED will illuminate when output is connected to an
active receiver. The LED will ash if there is a problem with the
connection.

4
6.2 Rear Panel
DC 24V
CAT5e/6 IN
POWER
MODE LINK
1 2 4 53
1MODE LED
The yellow LED will ash when the unit is powered or when an
active transmitter is connected.
2CAT5e/6 IN
Connect to the transmitter unit with a single CAT5e/6/7 cable (up
to 100m).
3LINK LED
The green LED will illuminate when output is connected to an
active receiver. The LED will ash if there is a problem with the
connection.
4POWER
The LED will illuminate blue when the unit is connected to a power
supply or to an active transmitter.
5DC 24V
Connect the 24V DC power adaptor included in the package to
the unit and plug it into an AC outlet.
Note: This device can be powered without the power adaptor
when a PoE (Power over Ethernet) enabled active transmitter
connected to the 'CAT5e/6 IN' port.However, for cascading 2 units, it
is recommended that power supplies be used.

5
7. CONNECTION DIAGRAM
CAT5e/6 OUT
HDBaseT Repeater
CHDBX-1C
MODE LINK
DC 24V
CAT5e/6 IN
POWER
MODELINK Front
Rear
RS-232 In
LAN
HDMI In
HDMI to CAT5e/6 with LAN/IR/RS232
Transmitter TX
RS-232 Out
LAN
HDMI Out
CAT5e/6 to HDMI with LAN/IR/RS232
Receiver
RX
Blu-ray Player
HDMI Input
HDMI Output RS-232
HDTV PC/Laptop
RS-232 Device to
be controlled
RS-232
Power
Supply
Power
Supply
Power Supply
(or Power over
Ethernet with suitable
Transmitters)
100 m
100 m
Modem Router
PC or RS-232
Control System
Example 1

6
CAT5e/6 OUT
HDBaseT Repeater
CHDBX-1C
MODE LINK
DC 24V
CAT5e/6 IN
POWER
MODELINK Front
Rear
RS-232 In
LAN
HDMI In
HDMI to CAT5e/6with LAN/IR/RS232
Transmitter TX
RS-232 Out
LAN
HDMI Out
CAT5e/6to HDMI with LAN/IR/RS232
Receiver
RX
CAT5e/6 OUT
HDBaseT Repeater
CHDBX-1C
MODE LINK
DC 24V
CAT5e/6 IN
POWER
MODELINK Front
Rear
Blu-ray Player
HDMI Input
HDMI Output RS-232
HDTV PC/Laptop
RS-232 Device to
be controlled
RS-232
Power
Supply
Power
Supply
Power Supply
(or Power over
Ethernet with suitable
Transmitters)
Power
Supply
Optional 2nd Repeater
extends the operating
distance by another 100 m
100 m
100 m
100 m
Modem Router
PC or
RS-232
Control
System
Example 2

7
8. SPECIFICATIONS
Video Bandwidth 300 MHz/10.2 Gbps
Input Port 1×RJ-45
Output Port 1×RJ-45
Resolution Support 480i~1080p@50/60, 1080p@24, 4k×2K
CAT5e/6 In/Out Distance Up to 100/100 meters
Power Supply 24 V/1.25 A DC (US/EU Standards, CE/
FCC/UL certied)
Dimensions 102 mm (W)×145 mm (D)×25 mm (H)
Weight 324 g
Chassis Material Metal
Silkscreen Color Silver
Operating Temperature 0°C ~ 40°C/32°C~104°C
Storage Temperature -20˚C ~ 60˚C / -4˚F ~ 140˚F
Relative Humidity 20~90% RH (non-condensing)
Power Consumption 9 W (powered without power supply)
16.2 W (powered with power supply)

8
9. ACRONYMS
ACRONYM COMPLETE TERM
CAT5e Category 5 Cable
CAT6 Category 6 Cable
CEC Consumer Electronics Control
HDCP High-bandwidth Digital Content Protection
HDMI High Denition Multimedia Interface
PoE Power over Ethernet
