Renault FLUENCE Installation guide

Page 1 Technical Training Renault Fluence
RENAULT FLUENCE
Model introduction Training for Auto body repair centres

Page 2 Technical Training Renault Fluence
RENAULT FLUENCE,
ITS SMOOTH SILHOUETTE
HIDES A SPACIOUS
INTERIOR, AN ELEGANT
FINISH AND A WIDE RANGE
OF EQUIPMENT.
AN OUTSTANDING DRIVE.

Page 3 Technical Training Renault Fluence
Contents
Overview
Body
Technical Specifications
Electronics
10
24
4
38

Page 4 Technical Training Renault Fluence
Overview
1.6 16V EXPRESSION
1.6 16V DYNAMIQUE
2.0 16V PRIVILÈGE
ENGINE
1.6 16V
1.6 16V
2.0 16V
Fuel injection type
Multipoint sequential
Multipoint sequential
Multipoint sequential
Number of cylinders / valves
4 in-line / 16
4 in-line / 16
4 in-line / 16
Displacement (cc)
1598
1598
1997
Power (kW @ rpm)
81 at 6 000
81 at 6 000
105 at 6 000
Torque (NM @ rpm)
156 at 4 400
156 at 4 400
195 at 3 750
Fuel requirement
Unleaded Petrol
Unleaded Petrol
Unleaded Petrol
TRANSMISSION
Number of forward gears
5-speed manual
5-speed manual
6-speed manual
STEERING
Power assisted - electric
Standard
Standard
Standard
PERFORMANCE
Acceleration: 0 - 100 km/h (secs)
11.7
11.7
10.4
Maximum speed (km/h)
185
185
195
SUSPENSION
Front:
Mac-Phearson with
Mac-Phearson with
Mac-Phearson with
lower wishbone
lower wishbone
lower wishbone
Rear:
Torsion beam axle
Torsion beam axle
Torsion beam axle
FUEL CONSUMPTION
Litres /100 km (Urban cycle)
8.8
8.8
10.5
Litres /100 km (Extra-urban cycle)
5.3
5.3
6.2
Litres /100 km (Combined cycle)
6.5
6.5
7.8
CO2 emissions (g/km)
159
159
184
eco2
No
No
No
Fuel tank capacity (litres)
60
60
60
SEATING
No. of seats
5
5
5
WEIGHT & VOLUMES
Maximum load volume (litres)
1024
1024
1024
Minimum load volume (litres)
344
344
344
Gross train weight (kg)
2780
2780
3085
Gross vehicle weight (kg)
1736
1736
1793
Kerb weight excluding driver (kg)
1205
1205
1195
Maximum payload including driver (kg)
425
425
425
Maximum towing weight unbraked -
650
650
650
driver only (kg)
BRAKES
Bosch 8.0 system Anti-lock Brakes
Standard
Standard
Standard
EBD (Electronic Brake-Force Distribution)
Standard
Standard
Standard
Emergency Brake Assist (EBA)
Standard
Standard
Standard
Front:
280mm Ventilated discs
280mm Ventilated discs
280mm Ventilated discs
Rear:
260mm Solid discs
260mm Solid discs
260mm Solid discs

Page 5 Technical Training Renault Fluence
Overview
WHEELS & TYRES
1.6 16V EXPRESSION
1.6 16V DYNAMIQUE
2.0 16V PRIVILÈGE
Wheels size
6.5 J16
6.5 J17
6.5 J17
Wheels type
Alloy
Alloy
Alloy
Tyres
205/60/ R16
205/55/ R17
205/55/ R17
Spare wheel
16"
17"
17"
WARRANTY / SERVICE / MAINTENANCE
5 Year / 150 000 km mechanical warranty
Standard
Standard
Standard
6 Year anti-corrosion warranty
Standard
Standard
Standard
5 Year / 100 000 km service plan Standard
Standard
Standard
Standard
Dimensions in metres:
(A
) 0.908
(B
) 2.702
(C
) 1.010
(D
) 4.620
(E
) 1.545
(F
) (unloaded) 1.478
(G
) 1.563
(H
) 1.809

Page 6 Technical Training Renault Fluence
Overview
Colours
Black Metallic (GXA)
White Pearl (QXA)
Ultra Silver (KXC)
Lava Grey (WXA)
Red (NXA)
White (QXB)

Page 7 Technical Training Renault Fluence
Overview
Interior
Even from afar, it is easy to guess how roomy a Renault Fluence is. Its smooth, modern, stylish
silhouette does nothing to hide its generosity! The Renault Fluence is a truly comfortable
saloon car, with the greatest interior space in its category. The front seats offer excellent
support. In the back, the knee room is extremely generous. The back seat is inclined at an
angle of 27° for bespoke comfort.
The sense of on board comfort is reinforced by the attention to detail in the form of reduced
noise levels and high standards of interior space, including class-topping elbow room.
Backseat passengers also enjoy outstanding legroom and knee room. The cabin provides
more than 23 litres of stowage space, while the boot has a volume of 530dm3 - one of the
largest in its class. The 60/40-split folding rear seat enables the carrying capacity to be
increased to suit the needs of the moment.

Page 8 Technical Training Renault Fluence
Overview
Interior
Comfort is vital, regardless of distance. That is why Renault Fluence offers a comfortable drive
and a full range of equipment designed to make any journey a pleasure for you and your
passengers. Exceptional sound quality is at your fingertips with a 60W Radio Sat Classic
system which includes fingertip remote control and a MP3 compatible CD player. The
Dynamique and Privilège models include tailored temperature control with regulated dual-zone
air conditioning. The atmosphere on board is perfect.[ What's more, with the adjustable air
vents in the back, passengers really feel the benefit of the air-conditioning, wherever they’re
seated.]
Technology in the Renault Fluence is multifaceted. Take the Renault Hands-Free Key card
which can be used to lock, unlock and start the vehicle simply by carrying the card with you.
The Bluetooth® hands free kit and MP3 audio system, enabling you to make phone calls safely
and listen to music with complete freedom. Fluence combines sobriety and performance.
Innovations designed for the driver and expressing a unique philosophy: useful progress.

Page 9 Technical Training Renault Fluence
Overview
Interior
Regulated Dual-Zone air-conditioning offers personalised climate comfort to enable each front-
seat passenger to choose the temperature they prefer. For maximum comfort and a
temperature balanced between the front and rear of the vehicle, rear passengers also have an
adjustable air vent.
The Electro chrome Rear-View Mirror gradually darkens as light levels increase to prevent
dazzling.
The Sunroof lets more light into the passenger compartment and is fitted as option.
The Safety Belts reduce forces in the event of an impact and to ensure your body is held in the
correct position, the system is fitted with a double pretensioner in the front seats and a load
limiter in the rear seats.

Page 10 Technical Training Renault Fluence
Overview
Systems
The ABS anti-lock brake system with EBV electronic brake distribution, combined with
emergency brake assist, helps to control the trajectory.
The Dynamic Driving Control Esc (ESP) the ASR anti-skid system and under steer control logic
(UCL) ensure the vehicle remains stable even in difficult road conditions.
The Rear Parking Aid facilitates parking manoeuvres. The parking assistance system alerts
you to any obstacles behind the car with a series of increasingly rapid beeps.
