Renault KOLEOS User guide
DRIVER’S HANDBOOK
KOLEOS
Photo credit: Total/DPPI Imacom group
ELF has developed a complete range of lubricants for RENAULT:
fengine oils
fmanual and automatic gearbox oils
Benefiting from the research applied to Formula 1,
lubricants are very high-tech products.
Updated with the help of RENAULT’s technical
teams, this range is perfectly compatible with the
specific features of the brand’s vehicles.
fELF lubricants enhance
your vehicle’s performance significantly.
RENAULT recommends approved ELF lubricants for oil changes and top-ups.
Contact your RENAULT Dealer or visit www.lubrifiants.elf.com
Warning: to ensure the engine operates optimally, the use
of a lubricant may be restricted to certain vehicles. Please
refer to your maintenance document.
RENAULT recommends ELF
Une marque de
0.1
ENG_UD19396_3
Bienvenue (X35 - X44 - X45 - X73 - X81 - J81 - X84 - X85 - B85 - C85 - S85 - X91 - X70 - X76 - X83 - X61 - TEST - X77 ph2 - K85 - X95 - X33 - X43 - X38 - X65 PH5 - ENG_NU_977-2_H45_Ph2_Renault_0
Translated from French. Copying or translation, in part or in full, is forbidden unless prior written permission has been obtained from the vehicle manu-
facturer.
This Driver’s Handbook contains the information necessary:
– for you to familiarise yourself with your vehicle, to use it to its best advantage and to benefit fully from the all the functions and
the technical developments it incorporates.
– to ensure that it always gives the best performance by following the simple, but comprehensive advice concerning regular main-
tenance.
– to enable you to deal quickly with minor faults not requiring specialist attention.
It is well worth taking a few minutes to read this handbook to familiarise yourself with the information and guidelines it contains
about the vehicle and its functions and new features. If certain points are still unclear, our Network technicians will be only too
pleased to provide you with any additional information.
The following symbol will help you when reading this handbook:
Welcome to your new vehicle
The descriptions of the models given in this handbook are based on the technical specifications at the time of writing. This hand-
book covers all items of equipment (both standard and optional) available for these models but whether or not these are
fitted to the vehicle depends on the version, options selected and the country where the vehicle is sold.
This handbook may also contain information about items of equipment to be introduced later in the model year.
Throughout the manual, the “approved Dealer” is your RENAULT Dealer.
To indicate a hazard, danger or safety recommendation.
Enjoy driving your new vehicle.
0.2
ENG_UD20783_6
Filler NU (X06 - C06 - S06 - X35 - L35 - X44 - C44 - G44 - X45 - H45 - X65 - L65 - S65 - X73 - B73 - X74 - B74 - K74 - X77 - J77 - F77 - R77 - X81 - J81 - X84 - B84 - C84 ENG_NU_977-2_H45_Ph2_Renault_0
0.3
ENG_UD10779_7
Sommaire Général (X06 - C06 - S06 - X35 - L35 - X44 - C44 - G44 - X45 - H45 - X65 - L65 - S65 - X73 - B73 - X74 - B74 - K74 - X77 - J77 - F77 - R77 - X81 - J81 - X84 - ENG_NU_977-2_H45_Ph2_Renault_0
Getting to know your vehicle ...............................
Driving ...................................................................
Your comfort .........................................................
Maintenance .........................................................
Practical advice ....................................................
Technical specifications ......................................
Alphabetical index ...............................................
Sections
1
CONTENTS
2
3
4
5
6
7
0.4
ENG_UD20783_6
Filler NU (X06 - C06 - S06 - X35 - L35 - X44 - C44 - G44 - X45 - H45 - X65 - L65 - S65 - X73 - B73 - X74 - B74 - K74 - X77 - J77 - F77 - R77 - X81 - J81 - X84 - B84 - C84 ENG_NU_977-2_H45_Ph2_Renault_0
1.1
ENG_UD27163_2
Contents 1 (X45 - H45 - Renault)ENG_NU_977-2_H45_Ph2_Renault_1
Section 1: Getting to know your vehicle
RENAULT cards: general information, use, deadlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2
Doors ......................................................................... 1.9
Automatic locking of opening elements when driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.13
Front headrests/Seats ............................................................ 1.14
Seat belts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.17
to the rear seat belts ....................................................... 1.19
Additional methods of restraint: ..................................................... 1.21
to the front seat belts ....................................................... 1.21
to the rear seat belts ....................................................... 1.25
side protection ............................................................ 1.26
Child safety: general information .................................................... 1.28
choosing a child seat mounting ............................................... 1.31
fitting a child seat .......................................................... 1.33
deactivating/activating the front passenger airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.36
Clock and exterior temperature ..................................................... 1.39
Driving position ................................................................. 1.40
Warning lights .................................................................. 1.44
Instrument panel ................................................................ 1.48
trip computer and warning system ............................................. 1.50
Steering wheel .................................................................. 1.60
Power-assisted steering .......................................................... 1.60
Rear-view mirrors ............................................................... 1.61
Audible and visual signals ......................................................... 1.62
Exterior lighting and signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.63
Electric beam height adjustment .................................................... 1.66
Front windscreen wash/wiper ...................................................... 1.67
Rear windscreen wash/wiper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.69
Fuel tank ...................................................................... 1.70
locking the doors ..................................(up to the end of the DU)
emergency key ..................................... (up to the end of the DU)
child safety............................................(up to the end of the DU)
children (safety) .................................... (up to the end of the DU)
RENAULT card
use ..................................................(up to the end of the DU)
1.2
ENG_UD27274_4
Carte RENAULT : g n ralit s (X45 - H45 - Renault)ENG_NU_977-2_H45_Ph2_Renault_1
Jaune Noir Noir texte
RENAULT cards: general information, use, deadlocking
1 Unlocking the doors and the tailgate;
2 Locking the doors and the tailgate;
3 Switching on the lighting remotely;
4 Unlocking/locking the tailgate;
5 Integrated key.
– locking and unlocking the doors and
tailgate (refer to the following pages);
– depending on the vehicle, automati-
cally closing the electric windows
and sunroof remotely (see the in-
formation on "Electric windows" and
"Electric sunroof" in Section 3);
– switching on the vehicle lighting re-
motely (refer to the following pages);
– starting the engine (refer to the in-
formation on "Starting the engine" in
Section 2).
Make sure that the correct battery type
is being used, and that the battery is in
good condition and inserted correctly.
Its service life is approximately two
years: replace it when the message
"Replace card battery" appears on the
instrument panel (refer to the informa-
tion on the "RENAULT card: Battery" in
Section 5).
This varies according to the surround-
ings: It is important to make sure when
handling the RENAULT card that you
do not lock or unlock the doors by inad-
vertently pressing the buttons.
Never leave your vehicle
with the Renault card inside
and never leave a child
(or a pet) unsupervised, even for a
short while.
They may pose a risk to themselves
or to others by starting the engine,
activating equipment such as the
electric windows or by locking the
doors.
Risk of serious injury.
When the battery is flat, you can
still lock/unlock and start your ve-
hicle. Refer to the information on
“Locking/unlocking the doors” in
Section 1 and “Starting the engine”
in Section 2.
Jaune Noir Noir texte
1.3
ENG_UD27274_4
Carte RENAULT : g n ralit s (X45 - H45 - Renault)ENG_NU_977-2_H45_Ph2_Renault_1
If you lose your RENAULT card or
require another, you can obtain one
from an approved dealer.
If a RENAULT card is replaced, it
will be necessary to take the vehi-
cle and
to an approved dealer to initialise
the system.
You can use up to four RENAULT
cards per vehicle.
Avoid leaving the card in hot, cold or
humid areas.
Do not store the RENAULT card in
an area where it may accidentally
become bent or damaged: this may
occur if, for example, it is sat on
when placed in the back pocket of
a garment.
Press button 6 and pull on key 5 then
release the button.
Refer to the information on "Locking/
unlocking the doors".
5
The integrated key is used to lock or
unlock the front left-hand door if the
RENAULT card does not work:
– when the RENAULT card battery is
drained, discharged battery, etc.
– use of devices using the same fre-
quency as the card;
– if the vehicle is located in a zone of
high electromagnetic radiation.
locking the doors ..................................(up to the end of the DU)
RENAULT card
use ...................................................................(current page)
1.4
ENG_UD27275_4
Cartes RENAULT t l commande : utilisation (X45 - H45 - Renault)ENG_NU_977-2_H45_Ph2_Renault_1
Press the locking button 2.
The hazard warning lights
to indicate that the doors have locked:
if a door or the boot is open or not prop-
erly shut, or if a RENAULT card is still in
the reader, the doors and boot quickly
lock then unlock and the hazard warn-
ing lights and indicator lights
.
Press button 4 to unlock or lock the
boot.
Press unlocking button 1.
The hazard warning lights
to indicate that the doors have been un-
locked.
The card buttons are deactivated
when the engine is running.
This can, for example, identify the ve-
hicle from a distance when parked in a
car park.
The dipped beam headlights, indicator
lights and interior lights come on for ap-
proximately 30 seconds when button 3
is pressed.
pressing button 3 again switches
off the lighting.
The message “Keycard not detected”
and a beep will warn you if you open
a door with the engine running and the
card is not in the reader. The warning
disappears when the card is inserted in
the reader again.
The flashing status of the hazard
warning lights informs you of the ve-
hicle status:
– indicates that the vehi-
cle is unlocked;
– indicates that the
vehicle is locked.
RENAULT card
use ..................................................(up to the end of the DU)
locking the doors ..................................(up to the end of the DU)
1.5
ENG_UD27276_6
Carte RENAULT en mode mains libres : utilisation (X45 - H45 - Renault)ENG_NU_977-2_H45_Ph2_Renault_1
For vehicles with a hands-free
RENAULT card, this allows the vehicle
to be locked/unlocked automatically (in
addition to the functions of the remote
control RENAULT card) if a card is
present in access zone 1.
ensure that the RENAULT card
is not in contact with other electronic
equipment (computer, PDA, phone,
etc.) as this could hinder its operation.
With the RENAULT card in zone 1,
place your hand on a door handle 2: the
vehicle will unlock (in some cases, you
may need to pull door handle 2 twice to
unlock the vehicle and open the door).
Pressing the button 3 also unlocks all
the doors and the tailgate.
The hazard warning lights
to indicate that the doors have been un-
locked.
Never leave your vehicle with the RENAULT card inside.
The flashing status of the hazard
warning lights informs you of the ve-
hicle status:
– indicates that the vehi-
cle is unlocked;
– indicates that the
vehicle is locked.
1.6
ENG_UD27276_6
Carte RENAULT en mode mains libres : utilisation (X45 - H45 - Renault)ENG_NU_977-2_H45_Ph2_Renault_1
Jaune Noir Noir texte
There are two ways to lock the vehi-
cle: using buttons 4 or 5 or using the
RENAULT card.
45
When the doors and tailgate are closed,
press one of the buttons 4 on the door
handles 2 or the button 5 on the tail-
gate. The vehicle will lock. If a door or
the tailgate is open or not closed prop-
erly, the vehicle will quickly lock/unlock.
a RENAULT card must be within
the vehicle's access zone (zone 1) to
be able to lock the vehicle using the
button.
If you wish to check that the doors are
locked after locking with button 4, you
have approximately to
try the door handles without unlocking
them.
After this delay, the hands-free mode
is activated once again and any move-
ment of a handle will unlock the vehicle.
Jaune Noir Noir texte
1.7
ENG_UD27276_6
Carte RENAULT en mode mains libres : utilisation (X45 - H45 - Renault)ENG_NU_977-2_H45_Ph2_Renault_1
if, after
having opened and closed a door, the
card is no longer in the passenger com-
partment, the message “Keycard not
detected” (accompanied by a beep
when the speed passes a certain level)
warns you that the card is no longer
in the vehicle. This avoids you driving
away after having dropped off a pas-
senger who has the card, for example.
The warning disappears when the card
is detected again.
The vehicle will not lock if:
– a door or the tailgate is open or not
properly closed;
– a card is still in zone 7 (or in the card
reader) and no other card is in the
external detection zone.
With the doors and tailgate closed,
press button 6: the vehicle will lock.
The hazard warning lights
to indicate that the doors have locked.
the maximum distance at which
the vehicle locks depends on the sur-
roundings.
After locking or unlocking the vehi-
cle doors or the tailgate only, using
the buttons on the RENAULT card,
hands-free unlocking is deactivated.
To reactivate the “hands-free” mode:
restart the vehicle.
deadlocking the doors ..........................(up to the end of the DU)
RENAULT card
use ..................................................(up to the end of the DU)
doors/tailgate ........................................ (up to the end of the DU)
locking the doors ..................................(up to the end of the DU)
central door locking ..............................(up to the end of the DU)
1.8
ENG_UD27284_5
Carte RENAULT : supercondamnation (X45 - H45 - Renault)ENG_NU_977-2_H45_Ph2_Renault_1
Press button 2 or 3 once.
to raise the windows simulta-
neously, the button must be held down
for more than one second.
The hazard warning lights will
to signal deadlocking.
Press button 2 or 3 twice.
to raise the windows simulta-
neously, the second time the button is
pressed, it must be held down for more
than one second.
The hazard warning lights
to indicate that the doors have locked.
Press button 1.
The hazard warning lights
to indicate that the doors have been un-
locked.
After activating deadlocking using
button 2, “hands-free” unlocking is
deactivated.
To reactivate the “hands-free” mode:
restart the vehicle.
Warning: deadlocking is
activated the first time
button 1 is pressed.
Never use deadlocking if
someone is still inside the vehicle.
If the vehicle is equipped with a dead-
locking function, this allows you to lock
the opening elements and to prevent
the doors from being unlocked using
the interior handles (for example, by
breaking the window and then trying to
open the door from the inside).
doors.....................................................(up to the end of the DU)
locking the doors ..................................(up to the end of the DU)
opening the doors .................................(up to the end of the DU)
closing the doors ..................................(up to the end of the DU)
warning buzzer ...................................................... (current page)
1.9
ENG_UD27285_7
Ouverture et fermeture des portes (X45 - H45 - Renault)ENG_NU_977-2_H45_Ph2_Renault_1
Doors
With the doors unlocked or the “hands-
free” RENAULT card in your posses-
sion, hold handle 1 and pull it towards
you.
In some cases, it may be necessary to
pull the handle twice to open the door.
Pull handle 2 and push the door.
If you have switched off the ignition
and left the lights switched on, a re-
minder buzzer will sound when a door
is opened.
A beep will let you know if you have
left the card in the reader when you
open the driver’s door, and the “Please
remove keycard” message will appear
on the instrument panel.
After switching off the engine, the lights
and some accessories that are in op-
eration (radio, etc.) will continue to op-
erate.
They stop as soon as the driver’s door
is opened.
If a door (or tailgate) is open or not
properly closed, as soon as the vehi-
cle reaches a speed of approximately
9 mph (15 km/h), the message “Boot
open” or “Door open” (depending on
which is open) will appear on the instru-
ment panel accompanied by a warning
light.
As a safety precaution,
the doors should only be
opened or closed when the
vehicle is stationary.
1.10
ENG_UD27285_7
Ouverture et fermeture des portes (X45 - H45 - Renault)ENG_NU_977-2_H45_Ph2_Renault_1
Move lever 3 and check from the inside
that the doors are securely locked, to
prevent the rear doors being opened
from the inside.
Never leave an animal, child or adult who is not self-sufficient alone on
your vehicle, even for a short time.
They may pose a risk to themselves or to others by starting the engine, activating
equipment such as the electric windows or by locking the doors.
Also, in hot and/or sunny weather, please remember that the temperature inside
the passenger compartment increases very quickly.
opening the doors .................................(up to the end of the DU)
closing the doors ..................................(up to the end of the DU)
unlocking the doors ..............................(up to the end of the DU)
central door locking ..............................(up to the end of the DU)
1.11
ENG_UD23661_6
Verrouillage et déverouillage des portes (X45 - H45 - Renault)ENG_NU_977-2_H45_Ph2_Renault_1
This is done using the RENAULT
Card; refer to the information on the
RENAULT Card" in Section 1.
the RENAULT card
may not work:
– when the RENAULT card battery is
drained, flat battery, etc.
– use of appliances operating on the
same frequency as the card (mobile
phone, etc.);
– vehicle located in a high electromag-
netic radiation zone.
It is then possible:
– to use the key integrated into the
card to unlock the front left-hand
door;
– to lock each of the doors manually
(see the following page);
– to use the interior door locking/un-
locking control (refer to the following
pages).
Turn screw 3 with the door open (using
the end of the key) and close the door.
This means that the doors are then
locked from the outside.
The doors may then only be opened
from the inside or by using the key in
the front left-hand door.
– Take out the integrated key (refer
to the section on “RENAULT cards:
general information" in section 1) ;
– remove cover A from the left-hand
door (using the end of key 2) in
notch 1;
– move it upwards to remove cover A;
– insert the key 2 into the lock in the
front left-hand door and lock or
unlock.
1.12
ENG_UD23661_6
Verrouillage et déverouillage des portes (X45 - H45 - Renault)ENG_NU_977-2_H45_Ph2_Renault_1
(if the RENAULT card is not working, for
example)
press switch 4 for
more than five seconds.
When the door is closed, all the doors
and the tailgate will be locked.
Unlocking the vehicle from the outside
will only be possible with the RENAULT
card.
the indicator
light integrated in switch 4 informs you
of the status of the doors and tailgate:
– indicator light on, the doors and tail-
gate are locked;
– indicator light off, the doors and tail-
gate are unlocked.
When you lock the vehicle from the out-
side, the indicator light remains lit for
approximately one minute, then goes
out.
The switch 4 simultaneously controls
the doors and the tailgate.
If a door or the tailgate is open or not
closed properly, the doors and tailgate
lock/unlock quickly.
If transporting an object with a door
or tailgate open:
, press the switch 4 for more
than five seconds to lock the other
opening elements.
Never leave your vehicle
with the RENAULT card
inside.
If you decide to keep the
doors locked when you are
driving, remember that it
may be more difficult for those as-
sisting you to gain access to the
passenger compartment in the
event of an emergency.
RENAULT ANTI-INTRUDER DEVICE (RAID) (up to the end of the DU)
central door locking ..............................(up to the end of the DU)
doors.....................................................(up to the end of the DU)
locking the doors ..................................(up to the end of the DU)
1.13
ENG_UD27286_6
Condamnation automatique des ouvrants en roulage (X45 - H45 - Renault)ENG_NU_977-2_H45_Ph2_Renault_1
Automatic locking of opening elements when driving
When the vehicle is started, the system
automatically locks the doors when the
vehicle reaches approximately 6 mph
(10 km/h).
The door can be unlocked:
– by pressing door unlocking button 1.
– by opening a front door (vehicle sta-
tionary).
if a door is opened or closed,
it will automatically lock again when
the vehicle reaches a speed of 6 mph
(10 km/h).
, you
have approximately 20 seconds to
press and hold door locking switch 1
(for approximately 5 seconds).
The message “Auto door lock on” is dis-
played on the instrument panel and a
beep sounds.
, press
and hold door locking switch 1 for ap-
proximately 5 seconds.
The message “Auto door lock off” is dis-
played on the instrument panel and a
beep sounds.
If you experience an operating fault (no
automatic locking, the indicator light in-
corporated in button 1 does not light up
when trying to lock the doors and tail-
gate, etc.), firstly check that the doors
and tailgate are properly closed. If they
are closed correctly, contact an ap-
proved dealer.
If you decide to keep the
doors locked when you are
driving, remember that it
may be more difficult for those as-
sisting you to gain access to the
passenger compartment in the
event of an emergency.
headrest................................................(up to the end of the DU)
front seats
adjustment ...................................... (up to the end of the DU)
1.14
ENG_UD23932_3
Appuis-tête avant (X45 - H45 - Renault)ENG_NU_977-2_H45_Ph2_Renault_1
Front headrests/Seats
Raise the headrest as far as possible,
then while pressing button 1, raise the
headrest to release it.
Insert the headrest rods into the holes,
with the notches facing forwards.
Hold down button 1 and move the
headrest to the required height.
Pull the headrest upwards to the de-
sired height.
Press button 1 and guide the headrest
down to the desired height.
(depending on vehicle)
Tilt the headrest A forwards or back-
wards to the required position.
The headrest is important
for safety. Ensure that it is in
place and in the correct po-
sition: the top of the head-
rest should be as close as possible
to the top of the head and there must
be a minimal distance between the
head and the A headrest.
Other manuals for KOLEOS
3
Table of contents
Other Renault Automobile manuals
Renault
Renault zoe User manual
Renault
Renault Clio 2004 User manual
Renault
Renault LAGUNA 2000 User manual
Renault
Renault KWID 2023 User manual
Renault
Renault Avantime 2002 User manual
Renault
Renault FLUENCE User manual
Renault
Renault WIND User manual
Renault
Renault ZOE 2018 Technical manual
Renault
Renault zoe User manual
Renault
Renault Latitude User manual
Renault
Renault Duster User manual
Renault
Renault kangoo storia User manual
Renault
Renault Master Van 2004 User manual
Renault
Renault Megane Berline User manual
Renault
Renault GRAND SCENIC User manual
Renault
Renault TWINGO User manual
Renault
Renault KOLEOS Instruction Manual
Renault
Renault 2013 Clio Cup User manual
Renault
Renault Arcana User manual
Renault
Renault 2008 Clio Sport R3 MAXI User manual
