Renesas SLG46140V User manual

SLG46140V GreenPAK DIP Adapter
Quick Start Guide
Revision 1.1
17-Mar-2022
1 of 1
© 2022 Renesas Electronics Corporation
1. Description
The GreenPAK DIP Adapter is a small PCB that lets you adapt
STQFN packages into a DIP footprint. This board can speed
up your design prototyping and testing. This small board
0.43x1.03 inch uses 20 pins DIP footprint with 0.3 inch width.
You can also use this adapter for prototyping by making
STQFN package compatible with solder free breadboards.
2. Features
•Low cost
•Simplifies prototyping of SMT IC’s
•Optional VDD LED indicator
•Decoupling capacitor included
Note 1 All sizes in inches.
3. Top View
PIN1 (VDD)
PIN2 (GPI)
PIN3 (GPIO)
PIN4 (GPIO)
PIN5 (GPIO)
PIN11 (GPIO)
PIN10 (GPIO)
PIN9 (GPIO)
PIN8 (GND)
VDD Chip decoupling capacitor
LED current limit resistor (optional) Chip package type
VDD LED indicator (optional)
Chip part number
GreenPAK chip
PIN6 (GPIO)
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
PIN14 (GPIO)
PIN13 (GPIO)
PIN12 (GPIO)
PIN7 (GPIO)
Pins Pins
4. Bottom View
Chip pin number
PIN11 (GPIO)
PIN10 (GPIO)
PIN9 (GPIO)
PIN8 (GND)
Not connected
Not connected
Not connected
PIN14 (GPIO)
PIN13 (GPIO)
PIN12 (GPIO)
PIN1 (VDD)
PIN2 (GPI)
PIN3 (GPIO)
PIN4 (GPIO)
PIN5 (GPIO)
PIN6 (GPIO)
Not connected
Not connected
Not connected
PIN7 (GPIO)
Pins Pins
5. Board Schematic
