Renesas SLG46621V User manual

SLG46621V GreenPAK DIP Adapter
Quick Start Guide
Revision 1.1
18-Mar-2022
1 of 1
© 2022 Renesas Electronics Corporation
1. Description
The GreenPAK DIP Adapter is a smallPCB that lets youadapt
STQFN packages into a DIP footprint. This board can speed
up your design prototyping and testing. This small board
0.43x1.03 inch uses 20 pins DIP footprint with 0.3 inch width.
You can also use this adapter for prototyping by making
STQFN package compatible with solder free breadboards.
2. Features
•Low cost
•Simplifies prototyping of SMT IC’s
•Optional VDD LED indicator
•Decoupling capacitor included
Note 1 All sizes in inches.
3. Top View
PIN1 (VDD1) PIN20 (GPIO)
PIN2 (GPI)
PIN3 (GPIO)
PIN4 (GPIO)
PIN5 (GPIO)
PIN6 (GPIO)
PIN7 (GPIO)
PIN8 (GPIO)
PIN9 (GPIO)
PIN10 (GPIO)
PIN19 (GPIO)
PIN18 (GPIO)
PIN17 (GPIO)
PIN16 (GPIO)
PIN15 (GPIO)
PIN14 (VDD2)
PIN13 (GPIO)
PIN12 (GPIO)
PIN11 (GND)
VDD1 Chip decoupling capacitor
LED current limit resistor (optional) Chip package type
VDD LED indicator (optional)
Chip part number
GreenPAK chip
Pins Pins
4. Bottom View
PIN20 (GPIO)
PIN19 (GPIO)
PIN18 (GPIO)
PIN17 (GPIO)
PIN16 (GPIO)
PIN15 (GPIO)
PIN14 (VDD2)
PIN13 (GPIO)
PIN12 (GPIO)
PIN11 (GND)
Pins
PIN1 (VDD1)
PIN5 (GPIO)
PIN6 (GPIO)
PIN7 (GPIO)
PIN2 (GPI)
PIN10 (GPIO)
PIN8 (GPIO
PIN9 (GPIO)
PIN3 (GPIO)
PIN4 (GPIO)
Pins
Chip pin number
VDD2 Chip decoupling capacitor
(optional)
5. Board Schematic
