Renesas Quick-Connect IoT DA16600 User manual

Quick Start Guide
Quick
-Connect IoT DA16600 Provisioning Demo
R15US0001EU0100 Rev.1.00
Jul 5, 2022
Page 1
© 2022 Renesas Electronics
This quick start guide explains the process of running the Quick-Connect IoT DA16600 (WiFi BLE) Provisioning
demo on an EK-RA6M4. The demo demonstrates provisioning the DA16600 module to a WiFi network using the
BLE interface and reading temperature and humidity data from the HS3001 sensor into the RA6M4
microcontroller.
A smartphone application is used to provision the DA16600 module to an existing WiFi network using the BLE
interface. A web browser is then used to display the temperature and humidity data read from the HS3001
sensor. Instructions for loading the example project are included at the end of the document as a next step after
running the demo.
Target Devices
■RA6M4 MCU (R7FA6M4AF3CFB)
■HS3001 Temperature / Humidity Sensor (HS3001)
■DA16600 WiFi BLE Module (DA16600MOD)
Contents
1. Kit Contents.................................................................................................................................................... 2
1.1 Hardware Components.......................................................................................................................... 2
1.2 Software Components........................................................................................................................... 3
2. Features.......................................................................................................................................................... 3
3. Overview......................................................................................................................................................... 3
4. Build Environment......................................................................................................................................... 4
5. Building and Downloading ........................................................................................................................... 4
6. Preparing the Demo....................................................................................................................................... 5
6.1 Download the Smartphone Application ................................................................................................. 5
6.2 Obtain WiFi Network Details.................................................................................................................. 5
6.3 Status Indication.................................................................................................................................... 5
6.4 Start the Hardware................................................................................................................................. 5
7. Running the Demo......................................................................................................................................... 6
7.1 Provision Module to WiFi Network......................................................................................................... 6
7.1 View Sensor Data.................................................................................................................................. 8
7.2 Resetting the Demo............................................................................................................................... 8
8. Starting Development with the Application Project................................................................................... 8
9. Reference Documents................................................................................................................................... 9
10. Revision History ............................................................................................................................................ 9

Quick-Connect IoT DA16600 Provisioning Demo Quick Start Guide
R15US0001EU0100 Rev.1.00
Jul 5, 2022
Page 2
1. Kit Contents
To set up this demo, the following components are needed. Please ensure the PmodTM boards are connected in
the correct order, including on the correct Pmod ports. Connect the micro USB cable between the EK-RA6M4
MCU development board and the Windows PC.
1.1 Hardware Components
■EK-RA6M4 (RTK7EKA6M4S00001BE)
■HS3001 Pmod (US082-HS3001EVZ)
■Pmod Interposer Board (US082-INTERPEVZ)
■DA16600MOD WiFi Bluetooth LE Combo Pmod (US159-DA16600MEVZ)
■Micro USB cable

Quick-Connect IoT DA16600 Provisioning Demo Quick Start Guide
R15US0001EU0100 Rev.1.00
Jul 5, 2022
Page 3
1.2 Software Components
The following software is required. The demo and application projects are both contained inside the
Quick_Connect_IoT_DA16600_Provisioning_Demo.zip file that accompanies this document.
Category
Item
Note
e2studio project Quick_Connect_IoT_DA16600_Provisioning_Demo.zip
Project can be directly imported to e2
studio and the FSP (v3.4 and higher).
Mobile App
Dialog WiFiProvisioning Tool for iOS
Apps available globally on Google Play
and Apple App Store.
Dialog WiFiProvisioning Tool for Android
2. Features
■System power supplied by micro USB cable
■RA6M4 MCU reads measured data from HS3001 temperature and humidity sensor
■BLE connectivity provided by DA16600 allows easy provisioning to WiFi networks
■WiFi connectivity allows the web browser to display raw humidity and temperature values
3. Overview
The DA16600 Module contains both WiFi and Bluetooth LE radios. A typical use case for such a module is to
use the Bluetooth LE interface to quickly and easily join (provision) the WiFi radio to an existing network. This
demonstration uses an app running on a smartphone to provision the DA16600 module to an existing WiFi
network by using the Bluetooth LE interface to select the network and enter the password.
After the DA16600 is provisioned to the network, the RA6M4 Microcontroller reads temperature and humidity
data via the HS3001 sensor and embeds this information into a simple webpage. This data can be displayed by
connecting a PC to the same WiFi network as the DA16600 and then using a web browser to view the webpages
served by the RA6M4 Microcontroller.
WiFi Communication
WiFi Communication
WiFi Communication
WiFi Communication
WiFi
Network
WiFi
Access Point (AP)
EK-RA6M4
DA1600MOD
PC Running
Web Browser
Smartphone
Provisioning App
Bluetooth LE Communication

Quick-Connect IoT DA16600 Provisioning Demo Quick Start Guide
R15US0001EU0100 Rev.1.00
Jul 5, 2022
Page 4
4. Build Environment
The example application was developed using the following environment.
Item
Description
IDE
e2Studio 2021-10
C Compiler
GCC ARM Embedded 9.3.1.20200408
FSP
3.4.0
RTOS
None
Emulator
On board (J-LINK)
If this environment is not already installed, see the Official Renesas RA Family Beginner’s Guide for complete
installation instructions.
5. Building and Downloading
When the build environment is installed, import the project contained within the zip file into e2Studio and build
the Debug or Release targets. Then, load the application onto the EK-RA6M4 board using the debugger. If you
are not familiar with the build/debug process, see sections 3, 4, and 5 in the Official Renesas RA Family
Beginner’s Guide.

Quick-Connect IoT DA16600 Provisioning Demo Quick Start Guide
R15US0001EU0100 Rev.1.00
Jul 5, 2022
Page 5
6. Preparing the Demo
6.1 Download the Smartphone Application
The DA16600 module is provisioned to a WiFi network using a smartphone application that is available on the
Apple App and Google Play stores. This app can be downloaded using the following QR code links:
6.2 Obtain WiFi Network Details
You will need to know the SSID and password of the WiFi network to which you want to provision the DA16600
module. When you have this information, keep them at hand because they are required in the next section.
6.3 Status Indication
The red, green, and blue LEDs on the EK-RA6M4 evaluation kit board indicate the status of the demo software
as follows:
LED State
Description
Device is booting.
Device is waiting to be provisioned to a WiFi network.
Device is provisioned and waiting to join a WiFi network.
Device is provisioned and connected to a WiFi network.
Device is provisioned, connected to a WiFi network, and a TCP client is connected.
An error has occurred; check boards are connected correctly and restart.
6.4 Start the Hardware
Apply power to the EK-RA6M4; the red, green, and blue LEDs should illuminate for a few seconds while the
device boots. When completed, the red LED should begin to blink indicating the demo is ready to be provisioned
to a WiFi network.

Quick-Connect IoT DA16600 Provisioning Demo Quick Start Guide
R15US0001EU0100 Rev.1.00
Jul 5, 2022
Page 6
7. Running the Demo
7.1 Provision Module to WiFi Network
Open the WiFiProvisioning Tool application on your smartphone and then perform the following steps.
Note: The following instructions are based on the use of an iOS device. When using an Android device the
interface may appear different.
Step 1: Start the WiFiProvisioning Tool
and select the Start DA1600-based
option.
Step 2: Press the Start button to begin
scanning the DA16600 device.
Step 3: Devices discovered during the
scan are listed in the display.
Step 4: When the scan is complete press
the Connect button next to the DA16600-
xxxx device.
Step 5: When connected press the Start
Wi-Fi network scan button to start
searching for a WiFi network to join.
Step 6: The DA16600 starts searching for
available WiFi networks.

Quick-Connect IoT DA16600 Provisioning Demo Quick Start Guide
R15US0001EU0100 Rev.1.00
Jul 5, 2022
Page 7
Step 7: Select the WiFi network you want
the DA16600 to join.
Step 8: Enter the password for the WiFi
network then press OK.
Step 9: Connect the DA16600 device to
the select WiFi network by pressing the
Connect to xxx button.
Step 10: The DA16600 attempts to
connect to the select network. This might
take up to 1 minute.
Step 11: When connected to the WiFi
network, press Complete to finish the
process.
Step 12: When provisioning is completed,
the red LED on the EK-RA6M4 EK turns
on. It turns green when the DA16600 has
connected to the WiFi network.

Quick-Connect IoT DA16600 Provisioning Demo Quick Start Guide
R15US0001EU0100 Rev.1.00
Jul 5, 2022
Page 8
7.1 View Sensor Data
Now that the DA16600 Module has been provisioned to a WiFi network, the sensor data can be read using a
web browser as follows:
1. Discover the IP Address of the DA16600. To do this, log in to the WiFi AP that the DA16600 joined and
determine what IP address it has been assigned. The assigned IP address is also output using the serial
debug interface and can be viewed using the Segger J-Link RTT Viewer.
2. Use a web browser to access the sensor data. When the browser has connected to the DA16600, the blue
LED on the EK-RA6M4 turns on.
3. Press the S1 button on the EK-RA6M4 and the value displayed in the Button Push Count field increments.
7.2 Resetting the Demo
When provisioned, the DA16600 stores information about the WiFi network it has joined in non-volatile memory,
allowing it to re-join the network if it is reset or the power is turned off and on. If you want to provision the
DA16600 to a different WiFi network, this information must be erased. This can be achieved using the following
procedure:
1. Press and hold switch SW1 (factory reset) on the DA16600 Pmod for 20 seconds, then release and wait 10
seconds.
2. Reset the EK-RA6M4 board by pressing switch S3. The red led on the EK-RA6M4 should be flashing,
indicating the DA16600 it not provisioned.
8. Starting Development with the Application Project
The source code used to create the demo project is also included in the zip bundle. This project can be imported
into the RA Flexible Software Package (FSP), version 3.4 or higher. The FSP must be downloaded and installed
on a Windows or Linux machine. The e2 studio IDE is included as part of the FSP install. For more information
on the FSP and how it can be downloaded and installed to your local machine, see the resource links in the
following section.

Quick-Connect IoT DA16600 Provisioning Demo Quick Start Guide
R15US0001EU0100 Rev.1.00
Jul 5, 2022
Page 9
9. Reference Documents
■Renesas Quick-Connect
■Renesas RA6M4 MCU
■EK-RA6M4
■Renesas RA Flexible Software Package (FSP)
■Renesas DA16600MOD
■Renesas HS3001
■Technical Updates / News - The latest information can be downloaded from the Renesas Electronics Website.
Website and Support:
■Renesas Electronics
■Inquiries
10. Revision History
Revision
Date
Description
1.00
Jul 5, 2022
Initial release.

© 2020 Renesas Electronics Corporation. All rights reserved.
Notice
1. Descriptions of circuits, software and other related information in this document are provided only to illustrate the
operation of semiconductor products and application examples. You are fully responsible for the incorporation or any
other use of the circuits, software, and information in the design of your product or system. Renesas Electronics
disclaims any and all liability for any losses and damages incurred by you or third parties arising from the use of these
circuits, software, or information.
2. Renesas Electronics hereby expressly disclaims any warranties against and liability for infringement or any other
claims involving patents, copyrights, or other intellectual property rights of third parties, by or arising from the use of
Renesas Electronics products or technical information described in this document, including but not limited to, the
product data, drawings, charts, programs, algorithms, and application examples.
3. No license, express, implied or otherwise, is granted hereby under any patents, copyrights or other intellectual
property rights of Renesas Electronics or others.
4. You shall be responsible for determining what licenses are required from any third parties, and obtaining such licenses
for the lawful import, export, manufacture, sales, utilization, distribution or other disposal of any products incorporating
Renesas Electronics products, if required.
5. You shall not alter, modify, copy, or reverse engineer any Renesas Electronics product, whether in whole or in part.
Renesas Electronics disclaims any and all liability for any losses or damages incurred by you or third parties arising
from such alteration, modification, copying or reverse engineering.
6. Renesas Electronics products are classified according to the following two quality grades: “Standard” and “High
Quality”. The intended applications for each Renesas Electronics product depends on the product’s quality grade, as
indicated below.
“Standard”:Computers; office equipment; communications equipment; test and measurement equipment; audio and
visual equipment; home electronic appliances; machine tools; personal electronic equipment; industrial robots; etc.
“High Quality”:Transportation equipment (automobiles, trains, ships, etc.); traffic control (traffic lights); large-scale
communication equipment; key financial terminal systems; safety control equipment; etc.
Unless expressly designated as a high reliability product or a product for harsh environments in a Renesas
Electronics data sheet or other Renesas Electronics document, Renesas Electronics products are not intended or
authorized for use in products or systems that may pose a direct threat to human life or bodily injury (artificial life
support devices or systems; surgical implantations; etc.), or may cause serious property damage (space system;
undersea repeaters; nuclear power control systems; aircraft control systems; key plant systems; military equipment;
etc.). Renesas Electronics disclaims any and all liability for any damages or losses incurred by you or any third
parties arising from the use of any Renesas Electronics product that is inconsistent with any Renesas Electronics
data sheet, user’s manual or other Renesas Electronics document.
7. No semiconductor product is absolutely secure. Notwithstanding any security measures or features that may be
implemented in Renesas Electronics hardware or software products, Renesas Electronics shall have absolutely no
liability arising out of any vulnerability or security breach, including but not limited to any unauthorized access to or
use of a Renesas Electronics product or a system that uses a Renesas Electronics product. RENESAS
ELECTRONICS DOES NOT WARRANT OR GUARANTEE THAT RENESAS ELECTRONICS PRODUCTS, OR ANY
SYSTEMS CREATED USING RENESAS ELECTRONICS PRODUCTS WILL BE INVULNERABLE OR FREE FROM
CORRUPTION, ATTACK, VIRUSES, INTERFERENCE, HACKING, DATA LOSS OR THEFT, OR OTHER SECURITY
INTRUSION (“Vulnerability Issues”). RENESAS ELECTRONICS DISCLAIMS ANY AND ALL RESPONSIBILITY OR
LIABILITY ARISING FROM OR RELATED TO ANY VULNERABILITY ISSUES. FURTHERMORE, TO THE EXTENT
PERMITTED BY APPLICABLE LAW, RENESAS ELECTRONICS DISCLAIMS ANY AND ALL WARRANTIES,
EXPRESS OR IMPLIED, WITH RESPECT TO THIS DOCUMENT AND ANY RELATED OR ACCOMPANYING
SOFTWARE OR HARDWARE, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF
MERCHANTABILITY, OR FITNESS FOR A PARTICULAR PURPOSE.
8. When using Renesas Electronics products, refer to the latest product information (data sheets, user’s manuals,
application notes, “General Notes for Handling and Using Semiconductor Devices” in the reliability handbook, etc.),
and ensure that usage conditions are within the ranges specified by Renesas Electronics with respect to maximum
ratings, operating power supply voltage range, heat dissipation characteristics, installation, etc. Renesas Electronics
disclaims any and all liability for any malfunctions, failure or accident arising out of the use of Renesas Electronics
products outside of such specified ranges.

Corporate Headquarters
TOYOSU FORESIA, 3-2-24 Toyosu,
Koto-ku, Tokyo 135-0061, Japan
www.renesas.com
Contact Information
For further information on a product, technology, the most
up-to-date version of a document, or your nearest sales
office, please visit:
www.renesas.com/contact/
Trademarks
Renesas and the Renesas logo are trademarks of Renesas
Electronics Corporation. All trademarks and registered
trademarks are the property of their respective owners.
© 2020 Renesas Electronics Corporation. All rights reserved.
9. Although Renesas Electronics endeavors to improve the quality and reliability of Renesas Electronics products,
semiconductor products have specific characteristics, such as the occurrence of failure at a certain rate and
malfunctions under certain use conditions. Unless designated as a high reliability product or a product for harsh
environments in a Renesas Electronics data sheet or other Renesas Electronics document, Renesas Electronics
products are not subject to radiation resistance design. You are responsible for implementing safety measures to
guard against the possibility of bodily injury, injury or damage caused by fire, and/or danger to the public in the event
of a failure or malfunction of Renesas Electronics products, such as safety design for hardware and software,
including but not limited to redundancy, fire control and malfunction prevention, appropriate treatment for aging
degradation or any other appropriate measures. Because the evaluation of microcomputer software alone is very
difficult and impractical, you are responsible for evaluating the safety of the final products or systems manufactured
by you.
10. Please contact a Renesas Electronics sales office for details as to environmental matters such as the environmental
compatibility of each Renesas Electronics product. You are responsible for carefully and sufficiently investigating
applicable laws and regulations that regulate the inclusion or use of controlled substances, including without
limitation, the EU RoHS Directive, and using Renesas Electronics products in compliance with all these applicable
laws and regulations. Renesas Electronics disclaims any and all liability for damages or losses occurring as a result
of your noncompliance with applicable laws and regulations.
11. Renesas Electronics products and technologies shall not be used for or incorporated into any products or systems
whose manufacture, use, or sale is prohibited under any applicable domestic or foreign laws or regulations. You shall
comply with any applicable export control laws and regulations promulgated and administered by the governments of
any countries asserting jurisdiction over the parties or transactions.
12. It is the responsibility of the buyer or distributor of Renesas Electronics products, or any other party who distributes,
disposes of, or otherwise sells or transfers the product to a third party, to notify such third party in advance of the
contents and conditions set forth in this document.
13. This document shall not be reprinted, reproduced or duplicated in any form, in whole or in part, without prior written
consent of Renesas Electronics.
14. Please contact a Renesas Electronics sales office if you have any questions regarding the information contained in
this document or Renesas Electronics products.
(Note 1) “Renesas Electronics” as used in this document means Renesas Electronics Corporation and also includes
its directly or indirectly controlled subsidiaries.
(Note 2) “Renesas Electronics product(s)” means any product developed or manufactured by or for Renesas
Electronics.
(Rev. 4.0-2 April 2020)
