Renesas FS3000 Pmod User manual

Evaluation Board Manual
R36UZ0012EU0100 Rev.1.00 Page 1
Jul 13, 2022 © 2022 Renesas Electronics
The US082-FS3000EVZ board enables quick
prototyping of the FS3000 mass air velocity sensor
module for a custom system design. The board
provides a standard Pmod Type 6A (Extended I2C)
connection for the onboard sensor to plug into any
MCU evaluation kit with a matching connector.
The US082-FS3000EVZ features Pmod connectors
on both sides of the board allowing additional Type
6/6A boards to be connected in a daisy-chained
solution with multiple sensors on the same MCU
Pmod connector. Because of the standard connector
and software support, the US082-FS3000EVZ is ideal
for the Renesas Quick-Connect IoT to rapidly create
an IoT system.
Kit Contents
▪US082-FS3000EVZ Board
Features
▪FS3000 sensor sample mounted:
• Thermo-transfer (calorimetric) principle uses
MEMS thermocouples to measure flow, which
provide excellent signal-to-noise ratio
• Silicon-carbide coating protects from abrasive
wear and water condensation
• Digital output with 12-bit resolution
• Resistant to vibration and pressure shock
▪Standardized Type 6A Pmod connector supports
I2C Extended interface
▪Dual connectors allow pass-through signals for
daisy-chained solutions
Figure 1. US082-FS3000EVZ Pmod Board
US082-FS3000EVZ
FS3000 Pmod™ Board

R36UZ0012EU0100 Rev.1.00 Page 2
Jul 13, 2022
US082-FS3000EVZ Evaluation Board Manual
Contents
1. Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.1 Required or Recommended User Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.2 Programming Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.3 Software Installation and Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.4 Kit Hardware Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3. Board Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.1 Schematic Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.2 Bill of Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.3 Board Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4. Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5. Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

R36UZ0012EU0100 Rev.1.00 Page 3
Jul 13, 2022
US082-FS3000EVZ Evaluation Board Manual
1. Functional Description
The US082-FS3000EVZ functions as a sensor building block to create a custom system solution. Use the board
individually or with a combination of other sensors by using the Pmod Type 6A interface. For a full list of available
sensor Pmod boards, visit the Quick-Connect IoT website.
2. Setup
2.1 Required or Recommended User Equipment
The following additional lab equipment is recommended for using the board (and is sold separately):
▪Any MCU board that supports Type 6A Pmod.
▪The US082-INTERPEVZ interposer board when using one of the Renesas MCU kits (Tabl e 1).
2.2 Programming Interface
Programming of the system can be accomplished through the Renesas IDE, e2 studio. See the MCU evaluation
kit documentation to set up the initial project in e2 studio. As the project is initialized, adding the FS3000 sensor to
the project takes five steps:
1. Navigate to the file in the FSP Configuration View. In the case shown in Figure 2, select the FS3000 Flow
Sensor.
2. Select the FS3000 Stack and edit the configuration values for your required operation.
3. Click the Generate Code icon and the system generates the code to configure the sensor with the MCU.
4. Sample calls are shown in below in the Example Code showing the function that opens the sensors; similar
calls are required for the I2C bus. Review the manual related to FSP configuration and function APIs for
additional information.
Note: Renesas recommends downloading and reviewing sample projects available on the Renesas website.
5. Use the data in your application.
Table 1. Renesas MCU Evaluation Kits Capable of Supporting Type 6A PMODs
When Used with the US082-INTERPEVZ[1]
1. This table is not a comprehensive list of supported MCU Kits. See the evaluation kit hardware manual to confirm Pmod pinout.
RA RX Synergy
EK-RA4W1 RX111-Starter-Kit PK-S5D9
EK-RA2A1 RX231-Starter-Kit DK-S3A7
EK-RA4M1 RX23W-Starter-Kit DK-S128
EK-RA6M1 RX23T-Starter-Kit TB-S1JA
EK-RA6M2 RX24T-Starter-Kit TB-S3A6
EK-RA6M3 RX24U-Starter-Kit DK-S7G2
EK-RA6M3G

R36UZ0012EU0100 Rev.1.00 Page 4
Jul 13, 2022
US082-FS3000EVZ Evaluation Board Manual
Example Code to Start the Sensor after Configuration in FSP
/* Quick setup for g_fs3000_sensor0. */
void g_fs3000_sensor0_quick_setup(void)
{
fsp_err_t err;
/* Open fs3000 sensor instance, this must be done before calling any FSXXXX API */
err = g_fs3000_sensor0.p_api->open(g_fs3000_sensor0.p_ctrl, g_fs3000_sensor0.p_cfg);
assert(FSP_SUCCESS == err);
2.3 Software Installation and Usage
Visit the Renesas website for the latest version of the e2 studio and for more information on a full system design,
software development, and the availability of additional hardware.
The minimum FSP version supporting the FS1015 sensor block is FSP 3.8.0. For the latest sensor support, use
the latest release. For the latest connectivity support and details on creating customized IoT system solutions, visit
the Quick-Connect IoT site.
2.4 Kit Hardware Connections
Follow these procedures to set up the kit as shown on Figure 3.
1. Verify that the MCU evaluation kit being used has a Pmod connector set to Type 6A. (For help, see the kit
hardware manual).
a. If no Type 6A Pmod is available, ensure the MCU evaluation kit can use the US082-INTERPEVZ interposer
board and insert the board into the MCU connector before adding any sensor boards.
2. Plug in the US082-FS3000EVZ to the Type 6A connector, being careful to align Pin 1 on the sensor board and
MCU kit.
Figure 2. Stack Selection in Renesas e2Studio
FS3000 Flow Sensor
Generate Code

R36UZ0012EU0100 Rev.1.00 Page 5
Jul 13, 2022
US082-FS3000EVZ Evaluation Board Manual
3. Connect the J4 and J5 jumpers to place 4.7k pull-up resistors on the I2C bus lines.
a. Only one set of pull-up resistors should be used on the I2C bus lines. If multiple sensor boards are used,
only one board should have the jumpers present.
b. MCU kits typically do not have pull-up resistors present on these lines, so make sure to check for them.
4. The sensor is now ready to be used in the system. Follow the MCU kit instructions for connecting and powering
up the evaluation kit.
Figure 3. Evaluation Kit Connections
Jumpers for I2C
Pull-Ups
Connector for
Additional Sensor
Pmod Boards
Air Flow In
Air Flow Out
Connector to MCU
Board

R36UZ0012EU0100 Rev.1.00 Page 6
Jul 13, 2022
US082-FS3000EVZ Evaluation Board Manual
3. Board Design
3.1 Schematic Diagram
Figure 4. US082-FS3000EVZ Schematic Diagram
3.2 Bill of Materials
Qty Reference Designator Description Value Manufacturer Part Number
5 C1, C2, C3, C4, C5 Capacitor, 0.1µF, 50V, 0603 0.1µF C0603C104J5RACTU
1 C6 1µF, X5R, MLCC Ceramic capacitor 1µF C0603C105K4RACTU
1J1
Male Header 0.1" pitch PMOD 2×6
Right Angle Pmod M20-9950645
1J2
Female Header 0.1" pitch PMOD 2×6
Right Angle SSW-106-02-F-D-RA
2 J4, J5 CONN HEADER VERT 2POS 1.27 MM FTS-102-01-L-S
2 R2, R3 Resistor, 4.7k, 0603 4.7k RC0603JR-074K7L
1 U1 Flow Sensor Module FS3001-1005
2 J4, J5 1.27" 1x2 Jumper with Grip, Gold NPB02SVFN-RC
GND
GND
3V3
PMOD Interface System
IIC_SDA
RES_N
IIC_SCL
17
28
39
410
511
612
J2
GND GND
PMOD Interface Slave
IRQ
4.7k
0603
R2
4.7k
0603
R3
3V3
3V3
C1
0.1uF, 50V C2
0.1uF, 50V
1 2
J4
1 2
J5
1 7
2 8
3 9
4 10
511
6 12
J1
VSS
3
SCL 7
VCM 10
VDD
2
SDA 6
VREG
1
NC
4
NC
5
TP1 8
TP2 9
U1
FS3000
C5
0.1uF, 50V
C4
0.1uF, 50V
C3
0.1uF, 50V
GND
C6
1uF, 16V
GND
3V3
BUSY#
ENABLE
POWER_ON
GPIO4
BUSY#
ENABLE
POWER_ON
GPIO4

R36UZ0012EU0100 Rev.1.00 Page 7
Jul 13, 2022
US082-FS3000EVZ Evaluation Board Manual
3.3 Board Layout
Figure 5. Silkscreen Top
Figure 6. Copper Top
Figure 7. Copper L1 Layer

R36UZ0012EU0100 Rev.1.00 Page 8
Jul 13, 2022
US082-FS3000EVZ Evaluation Board Manual
Figure 8. Copper L2 Layer
Figure 9. Copper Bottom
Figure 10. Silkscreen Bottom

R36UZ0012EU0100 Rev.1.00 Page 9
Jul 13, 2022
US082-FS3000EVZ Evaluation Board Manual
4. Ordering Information
5. Revision History
Part Number Description
US082-FS3000EVZ FS3000 Pmod Board
US082-INTERPEVZ Pmod interposer board to convert Type 2A and 3A to Type 6A
on older Renesas MCU kits.
Revision Date Description
1.00 Jul 13, 2022 Initial release.
