Renovator Twist-A-Mini Installation manual

SAFETY AND
OPERATING MANUAL
FOR THE MINI KIT

Twist-A-Mini™ Manual

Twist-A-Mini™Manual Page 1
Contents
Welcome .............................................3
About this manual ....................................3
Mini Kit.............................................3
Support ............................................3
Safety ................................................4
Safety rst!..........................................4
Work area safety .....................................4
Electrical safety ......................................5
Personal safety ......................................6
Dust safety..........................................7
Power tool use and care ...............................8
Technical Data.........................................9
What’s included? .....................................10
Twist-A-Mini™components ............................10
Pin this on your workshop wall, or keep it somewhere safe ... 11
Parts of the Twist-A-Mini™.............................12
Setting up ...........................................13
Which parts do I need? ...............................13
Changing the collets .................................14
Installing bits in the Twist-A-Mini ........................16
Installing the Twist-A-Flex™............................18
Installing a bit in the Twist-A-Flex™......................20
Using the Twist-A-Mini™................................21
Instructional Video ...................................21
Turning the Twist-A-Mini™on and off.....................21
Changing the Variable Speed Dial.......................22
Practice etching and grinding ..........................23
Using the Twist-A-Flex™rotary tool attachment.............24

Page 2 Twist-A-Mini™Manual
Tips and troubleshooting ..............................26
Choosing the right speed..............................26
Tips ..............................................26
Looking after your Twist-A-Mini™........................27
Cleaning ..........................................27
Storage ...........................................27
Servicing and repairs.................................27
Warranty ............................................29
Two (2) year limited replacement warranty statement........29
Warranty conditions..................................29
Dispute Resolution ..................................30

Twist-A-Mini™Manual Page 3
Welcome
About this manual
Congratulations on purchasing your Twist-A-Mini™ rotary tool. Before using it,
please read this manual carefully.
This manual covers how to safely use your Twist-A-Mini™ rotary tool, as well
as tips for using and maintaining it.
Note: All components and accessories listed in this manual are
manufactured using metric measurements. The metric and imperial
comparisons in this manual are approximate (1mm = approximately 1/32”).
We recommend you use the standard imperial size that is closest to the
metric size shown.
Example: 6.35mm = approximately 1/4”.
Mini Kit
The Mini Kit includes 174 rotary accessories. See the Twist-A-Bits workshop
guide or the rotary accessories case insert for details.
Support
If you experience problems with the Twist-A-Mini™ rotary tool or its
performance, please call our Customer Service Team for assistance:
✔1800 890 840 in Australia
✔0800 002 999 in New Zealand
✔1800 200 3111 in United States
For more information and the instructional video, please visit our websites:
✔www.twistamini.com
✔www.twistamini.com.au
✔www.twistamini.co.nz
Welcome
Welcome
Or scan this QR code to go straight
to the Twist-A-Mini™instructional
video.

Page 4 Twist-A-Mini™Manual
Safety
Safety rst!
Your Twist-A-Mini™is an advanced power tool. Your enjoyment will rely on
observing a high level of personal safety as well as protecting the safety of
others.
This section sets out important safety guidelines for operating your
Twist-A-Mini™.
Work area safety
Follow the guidelines below to ensure your work area is safe to use the
Twist-A-Mini™.
Safety guidelines
• Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
• Do not operate power tools in explosive atmospheres, such as in
the presence of ammable liquids, gases or dust. Power tools create
sparks, which may ignite the dust or fumes.
• Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
Safety

Twist-A-Mini™Manual Page 5
Safety
Electrical safety
Follow the guidelines below to prevent electric shock when using the
Twist-A-Mini™.
Recommendation: Power to the tool should always be supplied via a
residual current device with a rated residual current of 30mA or less.
Safety guidelines
• Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with the Twist-A-Mini™.
• Avoid body contact with earthed or grounded surfaces, such as
pipes, radiators, ranges and refrigerators.
• Do not expose power tools to rain or wet conditions. If operating a
power tool in a damp location is unavoidable, use a residual current
device (RCD) protected supply.
• When operating a power tool outdoors, use an extension cord
suitable for outdoor use.
• Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts.
• Hold the Twist-A-Mini™by the insulated grip when working where
hidden wiring may exist or where the power cords may lie. Electric
shock may result when metal parts of the Twist-A-Mini™make
contact with ‘live’ wires.
• Always inspect walls and ceilings to avoid possible hidden power
cables and pipes.
• Inspect power cords and plugs before using the Twist-A-Mini™. If any
damage is apparent, have it repaired rst.
• Always use extension cords that are in good condition. Don’t exceed
25 metres (80 ft) or you may cause damage to the tool.

Page 6 Twist-A-Mini™Manual
Safety
Personal safety
Follow the guidelines below to ensure your personal safety while operating
the Twist-A-Mini™.
Safety guidelines
• Stay alert, watch what you are doing and use common sense when
operating the Twist-A-Mini™. Do not use a power tool while you are
tired or under the inuence of drugs, alcohol or medication.
• Use personal protective equipment. Always wear eye protection and
ear protection. If operating in a dusty environment, wear a dust mask
(see next page).
• Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to power source, picking up or carrying the tool.
• Remove any adjusting key or wrench before turning the Twist-A-
Mini™on. A wrench or a key left attached to a rotating part of the
power tool may result in personal injury.
• Do not overreach. Keep proper footing and balance at all times.
• Dress properly. Loose clothes, gloves, jewellery or long hair can be
caught in moving parts.
• Keep your hands clear of the work.

Twist-A-Mini™Manual Page 7
Safety
Dust safety
Some dust created by Twist-A-Mini™from sanding, grinding, drilling, etching
and other activities on certain materials may contain chemicals known to
cause cancer, birth defects or other harm.
Some examples of these chemicals are:
✔Lead from lead-based paint.
✔Crystalline silica and asbestos from bricks, cement and other
masonry products.
✔Arsenic, boron and chromium from chemically treated timber.
Follow the guidelines below to ensure your personal safety from dust while
operating the Twist-A-Mini™.
Safety guidelines
• Always work in a well-ventilated area.
• Use dust masks specically designed to lter microscopic particles
as well as other approved safety equipment.
• Avoid long periods of exposure to dust from sanding, grinding,
drilling, etching and other construction activities.
• Wear protective clothing and wash exposed areas with soap and
water.
• Do not allow dust to get into your mouth, eyes or on exposed skin.
This may promote the absorption of harmful chemicals.
• Direct dust particles away from your face and body.

Page 8 Twist-A-Mini™Manual
Safety
Power tool use and care
Follow the guidelines below when operating your Twist-A-Mini™.
Safety guidelines
• Do not use the power tool if the switch does not turn it on and
off. Any power tool that cannot be controlled with the switch
is dangerous and must be repaired by an authorised service
technician.
• Disconnect the plug from the power source before making any
adjustments, changing accessories or storing power tools. This
reduces the risk of starting the power tool accidentally.
• Store idle power tools out of the reach of children and do not allow
people unfamiliar with the Twist-A-Mini™or these instructions to
operate the power tool.
• Maintain power tools. If any part is missing or damaged, do not
plug Twist-A-Mini™into the power source until the missing part or
damaged part is replaced.
• Have your Twist-A-Mini™serviced only by an authorised service
technician.
• Use clamps or another practical way to secure and support the
workpiece to a stable platform. Holding the work by your hand or
against the body leaves it unstable and may lead to loss of control.
• Only use accessories that are recommended for Twist-A-Mini™.
• Never use the Twist-A-Mini™ around ammable or volatile
substances or use any volatile substance to clean the Twist-A-Mini™.

Twist-A-Mini™Manual Page 9
Technical Data
Australia & New Zealand
Rated: Voltage 220-240V Speed: 8,000 − 35,000/min
Rated Frequency: 50Hz Protection Class: Double Insulation
Power: 160Watts Weight: 1kg
Technical Data

Page 10 Twist-A-Mini™Manual
Continued on next page…
What’s included?
Twist-A-Mini™components
The following components are included with your Twist-A-Mini™.
Part Description
A Twist-A-Mini™rotary
tool
B Twist-A-Flex™rotary
tool attachment
C 10mm (3/8”)
Twist-A-Flex™Collet
Wrench
D 6.35mm (1/4”) Collet
E 4.76mm (3/16”) Collet
F 3.2mm (1/8”) Collet
What’s included

Twist-A-Mini™Manual Page 11
What’s included?
Accessories & Twist-A-Bits workshop guide
For a list of the accessories
included with Twist-A-Mini™and
their use, refer to the separate
Twist-A-Bits workshop guide.
This handy workshop guide will
help you to quickly match the right
bit and recommended speed to the
material on which you are working.
Pin this on your workshop wall, or
keep it somewhere safe.
Note: All components and accessories listed in this manual are
manufactured using metric measurements. The metric and imperial
comparisons in this manual are approximate (1mm = approximately 1/32”).
We recommend you use the standard imperial size that is closest to the
metric size shown.

Page 12 Twist-A-Mini™Manual
What’s included?
Parts of the Twist-A-Mini™
The following diagrams show the labelled parts of the Twist-A-Mini™rotary
tool and Twist-A-Flex™rotary tool attachment.
Hanging Loop
Spindle Locking Button
Flexible Shaft
Twist-A-Flex™ Tail
Twist-A-Flex™ Head
Spindle Locking Hole
Collet Nut
ON/OFF Switch
Variable Speed Dial
Tool Collar
Twist-A-Flex Collar

Twist-A-Mini™Manual Page 13
Setting up
Which parts do I need?
Before you set up the Twist-A-Mini™, you must rst determine which
components you need for your task.
Part Description
The Twist-A-Mini™contains the
motor, so this will always be used.
The bits are secured to the Twist-A-
Mini™with the collet and nut.
Twist-A-Flex™rotary tool
attachment
The Twist-A-Flex™ is a long exible
shaft that extends from the Twist-
A-Mini™to the rotary tool head. The
bits are attached to the rotary tool
head, which you can hold in your
hand like a pencil, allowing you
greater control for ne tasks.
Setting Up

Page 14 Twist-A-Mini™Manual
Setting up
Changing the collets
The bits for Twist-A-Mini™are secured with the collet nut and collet.
There are three sizes of collet depending on which bits you are attaching.
Note: Ø is the symbol for ‘diameter’.
Follow the steps below to change the collets on your Twist-A-Mini™.
Part Action
1 Remove any bits from the Twist-A-Mini™if applicable. Refer
to Installing bits on page 16.
2 Turn the collet nut (1) counter-clockwise and remove it from
the spindle (3).
3 Remove the collet (2) from the spindle and insert the new
collet.
Note: As each collet is the same on both ends, either end
can be inserted into the spindle.
4 Replace the collet nut and lightly tighten by hand.
Note: Tightening the collet nut without a bit in the collet will
make the collet diameter smaller, which will make installing
bits difcult. Leave the collet nut loose when storing
Twist-A-Mini™with no bit installed.
Continued on next page…

Twist-A-Mini™Manual Page 15
Setting up
Changing the collets
(3) Spindle
(2) Collet
(1) Collet Nut
Tool Collar

Page 16 Twist-A-Mini™Manual
Setting up
Installing bits in the Twist-A-Mini™
Follow the steps below to change the bits on your Twist-A-Mini™.
Part Action
1 Press on the spindle locking button (1).Rotate the collet nut
(2) until the spindle locking button clicks into place. This
prevents the spindle from turning.
2 Press down on the spindle locking button, and use the
Ø 10mm (Ø 3/8”) collet wrench (3) to turn the collet nut
counter-clockwise. Loosen the collet nut several turns.
3 Remove existing bit if one is already in the collet.
Insert the new bit (4) fully into the collet, then pull it back
between 1mm (1/32”) and 3mm (1/8”) to create an air space
between the motor shaft and the bit. This helps protect the
bit from overheating.
Note: If the shank of the bit being installed is a different size
to the bit being removed, install the correct collet. Refer to
Changing the collets on page 14.
4 Once the bit is correctly placed in the collet, press down on
the spindle locking button. Tighten the collet nut clockwise
by hand as far as possible.
5 Use the Ø 10mm (Ø 3/8”) collet wrench to tighten the collet
nut securely.

Twist-A-Mini™Manual Page 17
Setting up
Installing bits in Twist-A-Mini™
(3) Collet Wrench
(4) Bit
(2) Collet Nut
(1) Spindle Locking Button

Page 18 Twist-A-Mini™Manual
Setting up
Installing the Twist-A-Flex™
Part Action
1Switch Twist-A-Mini™OFF and unplug it from the power
source. Refer to turning the Twist-A-Mini™ on and off on
page 21.
2 Remove the existing bit if one is already in Twist-A-Mini™.
Undo the tool collar and remove. refer to page 15.
Ensure the largest diameter collet is in the spindle. Refer to
changing collets on page 14.
3Insert the Twist-A-Flex™rotary tool tail (1) all the way into
the collet (2) until the depth collar (3) is ush against the
collet nut (4).
4When the Twist-A-Flex™rotary tool tail in correctly placed
in the collet, press the spindle locking button (5) and rotate
the collet nut clockwise until the spindle locking button clicks
into place. Tighten the collet nut clockwise by hand as far as
possible.
5 Using the 10mm collet wrench, securely tighten the collet
nut. DO NOT use excessive force when tightening.
6Slide the Twist-A-Flex™collar on to the Twist-a-Mini™and
tighten the Twist-A-Flex™collar (6) clockwise by hand. Do
not over-tighten.
Warning!
When it is not connected to the Twist-A-Mini™, avoid holding the Twist-
A-Flex™upside-down as the driveshaft will fall out.
