Handler Junior Sandblaster 51 User manual
PARTS LIST AND PART NUMBERS
01.Red Rubber Air Hose (5Ft) – P51-01
02. Male Insert – P51-02
03. Female Insert – P51-03
04. 1/2 Inch Circle Clamp – P51-04
05. Push Button Air Gun – P51-05
06. Complete Nozzle Assembly – P51-06
07. Nozzle Tip Holder Upper or Lower –
P51-07
08. Stainless Nozzles (set of two) –
P51-08
Nozzels for walnut – P51-08W
09. “L” Bracket, Nozzle Support – P51-09
10. 7/16 Inch hex Jam Nuts (4) – P51-10
11. Rubber Glove – P51-11
12. 4 inch Glove Flange with Screws –
P51-12
13. 4 inch Sil Hose Clamp (for Glove)
14. Light Bulb – P51-13
15. Light Socket – P51-14
16. 4 inch Cord Set – P51-15
17. Line Switch – P51-16
18. Plastic Plug – P51-28
19. Glass – P51-18
20. Rubber Feet with Hardware – P51-19
21. Steel Cabinet – P51-20
22. 1/4 Turn Fastener, Wing Ho. Stud –
P51-26
23. Filter, Polyester Felt and Fiberglass
(inside unit)
24. Door Gasket – P51-27
Replacement filter – P51F
THANK YOU!
Thank you for purchasing a Handler Junior Sandblaster. Unpack your #51 Sandblaster.
Check to make certain all accessories are properly packaged in the carton. Do not discard
any portion of the packing until all parts and accessories have been accounted for.
OPERATING INSTRUCTIONS
Your Handler Junior Sandblaster comes completely equipped for operation. Folllow the
simple instructions to be insured of a product of lasting efficiency.
1. Pour 5 pounds of sand into sandblaster through top front door.
2. Place elongated bulb into bulb socket inside the sandblaster and place the
electrical plug into 115 Volt electrical outlet.
3. Connect the male fitting to the female connection in the lever valve connected to
the front of the sandblaster. We suggest the use of Teflon tape on the threads of
the male connection to aid in sealing this connection.
4. Connect air line to a 30-60 pounds dry air pressure source with the use of female
connection. If you desire to connect your Junior Sandblaster to bench top air line,
which has tapered valve connection, simply cut plastic hose 2 inches above
female fitting and push cut portion onto tapered outlet.
5. Depress the lever on instant action gun to sandblast an item.
NOTE:
1. It may be necessary to clean nozzle assembly of large extraneous particles on
occasion. Simply place thumb over orifices of both nozzles and depress lever
valve two or three times.
2. Use dry air only. Use of damp air may cause abrasive agglomeration resulting in
ineffective abrasive action.
3. Replacement sand is available. Order part No. 51A. Your sandblaster may be
utilized with walnut shells. Please contact your distributor or Handler for a walnut
shell conversion kit.
4. Your sandblaster functions on a simple Venturi process. Air pressure flowing over
a lower orifice creates suction which pulls the abrasive into the air stream. The
#51 utilizes 1.2 CFM of air volume at 30-60 PSI. If the unit is used with walnut
shells, boost the air pressure from 60-80 PSI and change the orifices to allow for
the shells to be drawn through a larger orifice. Request a new set of nozzles for
walnut shells – Part No. P51-08WS.
IMPORTANT NOTICE
WHAT SHOULD YOU DO TO RETURN GOODS
1. Our terms of sale are F.O.B. our plant. Handler makes every effort to insure the
proper delivery of goods, but we cannot guarantee the carrier's performance. Each
product is tested and inspected for proper performance prior to leaving our
facility. The responsibility for damage in transit is the carrier's, whether it is
visible damage or concealed damage.
2. Inspect this shipment IMMEDIATELY. Insist that visible damage or possible
damage be written on the Delivery Receipt by the receiver.
3. Inspect the contents of your shipment within 24 hours of receipt. Using your copy
of our packing list, check for piece count and accuracy immediately to insure
proper billing.
4. If damage is discovered, save all crates, cartons and packaging material until an
inspection has bee made by an agent of the carrier.
5. In case of damage, notify the delivering carrier IMMEDIATELY requesting that
an inspection be made. Retain a copy of the inspection request for claim purposes.
Failure to notify the freight carrier immediately will result in the loss of your
rights to claim damage.
6. We have taken every precaution to insure safe arrival of your products. We cannot
be responsible for negligence by another party.
7. The receiver of the goods must make claims for incorrect shipped goods to the
shipper within 15 days of receipt of delivery.
RETURNING GOODS
1. DO NOT return merchandise without our authorization. You must call first for a
return authorization number.
2. We will not accept returned merchandise from the carrier unless our authorization
NUMBER has been issued, and is clearly marked on the outside of the carton.
3. We will not accept goods (i.e. dust collectors) that are not cleaned and free of dust
and debris. The merchandise will be shipped back.
HANDLER MFG.
612 NORTH AVENUE EAST
WESTFIELD, NEW JERSEY 07090
WARRANTY
This HANDLER product is warranted to be free from defects in material and workmanship,
when used under the conditions recommended by the manufacturer, and/or the purpose for
which the product was intended, for a period of 12 months from the date of shipment from
factory to job site of original owner. Products purchased from distributor warehouse stock
are warranted for a period of 18 months from date of shipment from the manufacturer’s
warehouse.
In all cases, the full name and address of the distributor must be supplied, along with the
name of the customer, product name and number, and serial number. A copy of the original
invoice, showing date of purchase must accompany the warranty repair request.
This warranty will apply to equipment installed, operated and maintained in accordance
with HANDLER procedures and recommendations.
During the life of this warranty, HANDLER will repair or replace (At HANDLER’s option)
free of charge. F.O.B. its plant, any defective part or assembly, if such defect occurred in
normal service and was not due to apparent misuse, abuse, or accident.
Any warranty service performed in the field must be authorized by HANDLER MFG.
Unauthorized service voids the warranty and any resulting charge will not be paid by
HANDLER MFG.
HANDLER MFG. makes no other warranties or guarantees, expressed or implied.
The merchantability of the components is expressly excluded. The manufacturer assumes
no liability for indirect or consequential damages.
Detach or copy and mail back to the address below.
WARRANTY FORM
Customer Name:
Address:
City: State: Zip Code:
Description of Product
Model Number:
Distributor:
Distributor’s Address:
Return to:
HANDLER MFG.
612 NORTH AVENUE EAST, PO BOX 520
WESTFIELD, NEW JERSEY 07090-0520
