Reso QDOS Q-PIC User manual

CompanyConfidential ResoLtdT/AQDOS
IssueN°14thJuly2014

USERMANUAL
QDOSQ‐PIC
BluetoothSelfieShooter




























CompanyConfidential ResoLtdT/AQDOS
IssueN°14thJuly2014

Welcome

Congratulationsonyourpurchase.YourQDOSQ‐PICSelfieShooterforBluetooth
compatiblesmartphonesandtabletsisAPP‐freeanddesignedtobeyourperfectSelfie
companion.OnceconnectedviaBluetooth,asimplepressoftheQ‐PICbuttonreleases
theshutteronyoursmartphonegivingyouepicSelfiesorgroupportraits.

Wehopeyouwilltakefewmomentstoreadthismanualandfollowalluserinstructionsto
gettoknowyourproduct.


System Specifications of the QDOS Q-PIC Bluetooth Selfie Shooter

ProductSpecifications
oDimensions: 22mmx49.5mm
oWeight: 29gms
oFrequencyrange: ISMband2.4Ghz
oApprovals: CE,ROHS,FCC
oAuto‐off: Smartenergysavingmode
oFunctionality:NoAPPrequired
oCarrybag: 2.8gms

BluetoothSpecifications
oVersion 3.0
oOperationrange:10m


BatterySpecifications
oSpecification:CR1632coincellbattery
Upto2‐yearsbatterylifedependingonoperation
Pre‐installedanduserreplaceable
oCurrent: Peakworkingcurrentaround5mAh
Standbycurrent(connected)around6uAh
Currentafterautooffaround4uAh
Current(whenoff)around1uAh

Compatibility
oiOS7orlater:iPhone4s,iPhone5&5s,iPad4thGen,iPadmini,iPodtouch5th
Genandlatermodels
oAndroid4.4orlater:Android4.4deviceswheretheenterbuttonsaresetupto
controltheonboardcameraandtakephotosorvideos










CompanyConfidential ResoLtdT/AQDOS
IssueN°14thJuly2014
Features & Functions


①Shutterbutton:presstoactivatetheQDOSQ‐PICandtakephotosorvideos
②LEDlight:indicatesoperation
③Batterycover:unscrewtorevealcoincellbatteryforreplacement
④Siliconecarrycase

Features

WirelessremotecamerashutterforyourSmartphone
Snappicturesorvideosfromadistanceofupto10minopenspace
Perfectforblur‐freeselfiesorgroupshots
NoadditionalAPPrequired,justpairtoyourSmartphonewirelesslyvia
Bluetoothinafewseconds
Lightweightsmallandcompactdesign,easytocarryandeasytouse
Easyoperationwithone‐click
Auto‐offwithsmartenergy‐savingmode
Batterycantakeupto40,000selfiepictures
Originalcameraperformanceintact
oFront,self‐portrait,andbackcameracontrol
oTakephotosorvideos
oMulti,continuousburstshot




CompanyConfidential ResoLtdT/AQDOS
IssueN°14thJuly2014
Operation

WhenyoufirstremovetheQDOSQ‐PICfromit’spackaging,youwillneedtoremovethe
smallprotectivefilmfromthebatterycover③.

NB–Thissmallfilmisusedintransittoprotecttheshelflifeofyourbatteryandisno
longerrequiredonceyouarereadytouseyourproductforthefirsttime.


ConnectingyourQDOSQ‐PICselfieshooterviaBluetooth
Ensurethatthefilmhasbeenremovedfromthebatterycoverasper
above
Presstheshutterbutton①to‘wake‐up’or‘activate’theQDOSQ‐PIC
andputitintopairingmode.
TurnonBluetoothonyourdeviceandpresstheQDOSQ‐PICshutter
buttonuntilyouseethegreenlight②flashing.
SearchyourdevicefortheQ‐PICpairingnameandclickconnect
ThegreenLEDlightwillturnoffwhentheQ‐PIChassuccessfullypaired


NB–Thereisnoon/offswitchontheQDOSQ‐PICsoitwillremainassociatedwiththe
lastBluetoothdeviceconnected.

LEDlight
Greenlightflashestoindicatepairingmode
Greenlightflashesfor30seconds
Greenlightturnsoffwhenpairedsuccessfully

NB–TherewillbenolightflashingwhenusingtheQDOSQ‐PICtotakeyourselfie!


UsingyourQDOSQ‐PICselfieshooter
Nowthatyouareconnectedandreadyforfun,youcanchoosetouse
theQDOSQ‐PICwithitshandycarrycaseoronitsownwiththe
matchingsiliconeband
First,simplyopenthecamerafunctiononyoursmartphoneortablet
Selectthefrontfacingoptiononyourdeviceforaselfieorusetheback
cameraforregularshotsandvideos
AsimpleclickontheQDOSQ‐PICbuttontakescontrolofthecamerafor
epicselfies,groupshots,photosorvideos
Forcontinuousshots,simplyholdtheQDOSQ‐PICbuttondown
Nolineofsightisneededandyoucaneventakephotosbypressingthe
shutterbuttoninyourpocket

NB–QDOSQ‐PIChasanauto‐offfunctioninsmartenergysavingmodeafterashort
whileofinactivity(underoneminute).AshortpressoftheQDOSQ‐PICbuttonwillwake
uptheselfieshooterandyouarereadytogoagain!

CompanyConfidential ResoLtdT/AQDOS
IssueN°14thJuly2014


Howtochangethebattery
Thebatteryisdesignedtolastuptotwoyearsbutthatwilldependon
yourusagepatterns
Whenthebatteryislow,youcanreplaceityourself
Pressfirmlythebatterycover③andturnit60°anti‐clockwisetoopen
RemovetheoldbatteryandreplacewithanewCR1632cellbattery
accordingtothebatterymanufacturerinstructions
Fitthebatterycoverbackintoplaceandturn60°clockwisetoclose
Refertothediagramabove③toensurethecoveriscorrectly
positionedtosecurethebatteryinplace



Troubleshooting

Bluetoothisabi‐directionaltransmittingprotocol;transmittingdistanceandperformanceisrelatedto
anddependentonthedevice.
IfyouexperienceissuesconnectingtheBluetoothdevice,pleasedeletetheotherBluetoothdevices
fromthelist,re‐activatetheQDOSQ‐PICselfieshooter,re‐searchitandre‐pairit.
EnsurethatotherdevicesinthevicinitywithBluetoothswitchedonhavealsodeletedtheQDOSQ‐PIC
fromtheirlistssothatyourdevicecanpairwithit.
Poorsignalenvironmentswillaffectperformancebutmovingtoabettersignalareawillrestore
performance.
Lowbatterycapacitymayalsoaffectperformance.
CheckthatyouriOSorAndroiddeviceissetupwiththevolumecontrolsascamerashutters.Ifyour
devicecanoperateitsowncamerausingthevolumeup/downbuttons,thisisthebestwaytotestthe
compatibilitywiththeQDOSQ‐PIC


WHATSINTHEBOX

QDOSQ‐PICselfieshooter
Matchingsiliconeband
Siliconecarrycase
Usermanual


CAREANDMAINTENANCE

Alwaysturnofftheunitfirstbeforeperforminganygeneralcleaning
Onlycleanwithadrycloth.Donotuseliquids,aerosols,chemicals,cleaningsolvents
orstrongdetergents
Toavoiddamagealwaysstoreinaclean,dryanddust‐freeenvironmentanddonot
placeanyheavyobjectsontopoftheunit
Avoidextremehighandlowtemperatures,directsunlight,dustandhumidity.
Maintainventilationduringuseanddonotplaceanythingonoraroundyourproduct
duringoperation
DisposingofyourQDOSQ‐PICselfieshooter

CompanyConfidential ResoLtdT/AQDOS
IssueN°14thJuly2014

1. TheuseoftheWEEEsymbolindicatesthatthisproductmaynotbetreatedas
householdwaste.Byensuringthisproductisdisposedofcorrectly,youwillhelp
protecttheenvironment.Formoredetailedinformationabouttherecyclingof
thisproduct,pleasecontactyourlocalauthority,yourhouseholdwastedisposal
serviceproviderortheshopwhereyoupurchasedtheproduct.
2. Donotincinerateordisposeofyourproductinafireormicrowave

For Your Safety

Failuretoreadandfollowthesesafetywarningscouldresultinfire,explosion,
electricalshockorotherhazard,causingseriousand/orfatalinjuryand/or
propertydamage
Followalloperatingandusageinstructions
Beforeusealwayscheckfordamageanduseonlythebatterysuppliedor
recommended
Donotattempttoopenordismantletheunitandneverdisassembleormodifythe
componentsoftheQDOSQ‐PICselfieshooter
KEEPAWAYFROMFIRE.Avoidthrowingthedeviceintofireorstoringneartoany
heatingsource
Keepawayfromcorrosivematerials
Topreventshortcircuitorotherpotentialhazards,keepsmallelectricallyconductive
partsawayfromtheQDOSQ‐PICanditsconnectingsockets
DonotallowsmallchildrentoplaywiththeQDOSQ‐PICselfieshooterunsupervised
Intheunlikelyeventofover‐heatingorifyounoticeanyunusualsmells,distortions,
discoloringorotherabnormalphenomena,pleasestopusingtheQDOSQ‐PICselfie
shooterimmediatelyandseektheadviceofaqualifiedelectronictechnician
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigi-
taldevice,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovide
reasonableprotectionagainstharmfulinterferenceinaresidentialinstallation.Thise-
quipmentgeneratesusesandcanradiateradiofrequencyenergyand,ifnotinstalled
andusedinaccordancewiththeinstructions,maycauseharmfulinterferencetorad-
iocommunications.However,thereisnoguaranteethatinterferencewillnotoccuri-
naparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradio
ortelevisionreception,whichcanbedeterminedbyturningtheequipmentoffando-
n,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefoll-
owingmeasures:
‐‐Reorientorrelocatethereceivingantenna.
‐‐Increasetheseparationbetweentheequipmentandreceiver.
‐‐
Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthere-
ceiverisconnected.
‐‐Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

Changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompli-
ancecouldvoidtheuser'sauthoritytooperatetheequipment.



CompanyConfidential ResoLtdT/AQDOS
IssueN°14thJuly2014
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowi-
ngtwoconditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisd-
evicemustacceptanyinterferencereceived,includinginterferencethatmaycauseu-
ndesiredoperation.

For Help and More Information

www.qdossound.com
[email protected]
Werecommendyoukeepthisdocumentandtheoriginalpackagingforfuture
reference
Allrightsreserved.Reproductioninwholeorinpartisprohibited.QDOSisatrade‐
markofResoLtd.Allothertrademarksarethepropertyoftheirrespectiveowners.
Specificationsaresubjecttochangewithoutnotice.Actualcolourandcontentsmay
differslightlyfromthosepictured.
MadeinChina.
QDOSwarrantsthisproducttobefreefromdefectsinmaterialsandworkmanshipin
thecourseofnormaluseforaperiodoftwoyearsfromthedateofpurchase.This
guaranteecoversbreakdownsduetomanufacturingordesignfaults;itdoesnot
applyincasessuchasaccidentaldamage,howevercaused,wearandtear,
negligence,adjustment,modificationorrepairnotauthorisedbyus.
Shouldyouhaveaproblemwithyourunitpleasecontactyoursupplierorcontact
QDOSsupportat[email protected]
DISCLAIMER OF WARRANTY
EXCEPT FOR THE LIMITED WARRANTY PROVIDED HEREIN, TO THE EXTENT
PERMITTED BY LAW, RESO LTD DISCLAIMS ALL WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING ALL WARRANTIES OF MERCHANTABILITY AND/OR FITNESS
FOR A PARTICULAR PURPOSE. TO THE EXTENT THAT ANY IMPLIED WARRANTIES
MAY NONETHELESS EXIST BY OPERATION OF LAW, ANY SUCH WARRANTIES ARE
LIMITED TO THE DURATION OF THIS WARRANTY. SOME STATES/PROVINCES DO
NOT ALLOW LIMITATIONS OF HOW LONG AN IMPLIED WARRANTY LASTS, SO THE
ABOVE LIMITATIONS MAY NOT APPLY TO YOU.
LIMITATION OF LIABILITY
REPAIR OR REPLACEMENT OF THIS PRODUCT, AS PROVIDED HEREIN, IS YOUR
EXCLUSIVE REMEDY. RESO LTD SHALL NOT BE LIABLE FOR ANY SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING, BUT NOT LIMITED TO,
LOST REVENUES, LOST PROFITS, LOSS OF USE OF SOFTWARE, LOSS OF
RECOVERY OF DATA, RENTAL OF REPLACEMENT EQUIPMENT, DOWN-TIME,
DAMAGE TO PROPERTY AND THIRD-PARTY CLAIMS ARISING OUT OF ANY THEORY
OR RECOVERY, INCLUDING WARRANTY, CONTRACT, STATUTORY OR TORT.
NOTWITHSTANDING THE TERM OF ANY LIMITED WARRANTY OR ANY WARRANTY
IMPLIED BY LAW, OR IN THE EVENT THAT ANY LIMITED WARRANTY FAILS OF ITS

CompanyConfidential ResoLtdT/AQDOS
IssueN°14thJuly2014
ESSENTIAL PURPOSE, IN NO EVENT WILL RESO LTD’S ENTIRE LIABILITY EXCEED
THE PURCHASE PRICE OF THIS PRODUCT. SOME STATES/PROVINCES DO DOT
ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE
OTHER RIGHTS.
EC Declaration of Conformity available to download here…
http://www.qdossound.com/CE-Declaration-of-conformity-Q-PIC
QDOS is the trading brand of Reso Ltd, a UK company,
MountManorHouse
16,TheMount
Guildford
SurreyGU24HN
UnitedKingdom
www.qdossound.com


