Retekess TA005 User manual

TA005
USER'S MANUAL

CONTENTS
Features-------------------------------------------------
Package Details --------------------------------------
Keys Instruction -------------------------------------
Operating Instruction ----------------------------------
Specification: ---------------------------------------------
01
01
01
02
05
EU Importer：Germany Retevis Technology GmbH
Address：Uetzenacker 29,38176 wendeburg

Features
●UHF：【US】914&916.4MHz
【EU】863.3&864.5MHz
●Range: about 98 feet (30M)
●Compatible with all TV brands, via 3.5mm jack Analog Or optical
digital jacks
●No latency, accurate sync
●Plug and play
●Advanced ALC, circuit design, delivers surprisingly natural-sounding
audio
●Integrated Grade-A 600mAh rechargeable li-ion battery, offers up to
10 hours of continuous use
Package Details
Headphone x 1
Transmitter x 1
Transmitter USB charge cable x 1
Headphone USB charge cable x 1
5V/1A power supply x 1
1.5M Audio cable x 1
3.5mm-RCA cable x 1
Optical digital cable x 1
User Manual x 1
Brown Box Package x 1
Keys Instruction
ON/OFF: turn the headphone on/off
CH: Channel Switch
MUTE: Mute the sound
V+: Volume Control
V-: Volume Control
01

AUX 3.5MM
Optical Input
Off/A/B
DC 5V
Operating Instruction
Step 1:
Plug the included 5V AC/DC power supply into the DC jack at the rear
of the transmitter, then plug the other end of the power supply into a
wall outlet.
Step 2:
Turn on your audio source(e.g. TV set, HI-FI system, MP3 or iPod),
please set the television, audio amplifier or DVD/ CD player
headphone volume level at approximately half way (50%).
Step 3:
Connect the transmitter with TV/Phone/Computer through the Optical
Input or Aux Input by provided optical cable or 3.5mm audio/RCA
cables. Switch on the transmitter to channel A or B position, RED led
on. When audio device connected and there is with music, the
transmitter BLUE led on. If audio device was unconnected or without
music, 3-6 minutes later, the transmitter will auto turn off.
Like, you could connect the transmitter to a TV in three different
methods.
Method 1: for Connection Through TV Earphone Jack
The TV headphone jack corresponds to the 3.5mm IN socket on the
backside of the transmitter. Connect one end of the 1.5m audio cable
(3.5mm) to the transmitter socket and the other end to the headphone
jack on TV.
02

Now, you can hear sound through headphones, and if not, please
make sure to set your TV speaker to “Headset”.
Method 2: for Connection Through TV RCA sockets
Please connect the included RCA 3.5mm adapter cable to the RCA
Audio Out jack on TV. And connect the included 3.5mm cable to the
RCA adapter cable and the other end of the 3.5mm cable into the
Audio In jack on the backside of the transmitter.
Now, you can hear through headphones, and if not,
A.Make sure the connected sockets are the white/red sockets labeled
“AuDIo ouT”, and other white/red sockets are incorrect.
B.Make sure to set your TV speaker to “External Speaker”.
Methods 3: for Connection Through TV Optical Output
Please connect one end of the included optical digital cable to the
optical output socket on TV and the other end to the optical input
socket on the backside of the transmitter.
03

Now, you can hear sound through headphones, and if not:
A.Make sure to set your TV speaker to “External speakers”.
B.Make sure to set the audio format to “PSC” or turn off “Dolby
Atmos/DTS” (This is important.)
C.Make sure the audio source sampling rate is not more than 16bit /
48KHz.
Notice: when using optical output, please remove any cable from the
3.5mm AUX jack.
Step 4:
Turn on the headphone and make sure the RED signal/power led is
on. If necessary, push the volume control to a medium level. Adjust
the headphone reception by pressing the tune button once. The LED
will turn GREEN, once received audio signal.
Step 5:
When you’re not using the headphone & transmitter, please turn them off.
Wired headphone: Switch the headphone Power On/Off button to
turn off the headphone. Plug in 3.5mm audio cable to the headphone
audio IN, and connect the opposite end to your audio device, like MP3
, phones etc. Then you can use the headphone as a wired
headphone. However, in this mode, you won't be able to adjust the
volume by using the switch key.
04

Headphone Charging: You can charge the headphone with a 5V/1A
USB power supply.
The total charge lasts approximately 2.5 hours.
When start charging, the LED light will keep blue, when the charging
is finished, the light will turn off.
Warning:
1.If the volume is too low, the transmitter switches off after 3-6
minutes of use. This is to comply with the current legislation on
reducing the amount of radio emissions in the environment. Therefore,
to ensure that this function is not accidentally triggered, we suggest
that you set the television, audio amplifier or DVD/ CD player
headphone volume level at approximately half way (50%).
2.On some newer TV sets, it may be necessary to increase the output
level of the headphone jack or the Audio Out jacks. Check your TV’s
owner manual for details.
3.Please make sure all connections are completely successful.
Specification:
Transmitter:
Voltage: DC 5V
Work Current: 80mA
Modulate: 50Khz
Mode: Stereo
Work Range: 98ft (30 meters)
Headphone:
Voltage:3.7V(600mAh built-in rechargeable battery)
Work Current:55mA
Work time: 10 hours
Charge time: 2.5 hours
S/N ratio: ≥60dB
Distortion: <1%
Frequency response: 60 - 15,000Hz
05

Headphone Charging: You can charge the headphone with a 5V/1A
USB power supply.
The total charge lasts approximately 2.5 hours.
When start charging, the LED light will keep blue, when the charging
is finished, the light will turn off.
Warning:
1.If the volume is too low, the transmitter switches off after 3-6
minutes of use. This is to comply with the current legislation on
reducing the amount of radio emissions in the environment. Therefore,
to ensure that this function is not accidentally triggered, we suggest
that you set the television, audio amplifier or DVD/ CD player
headphone volume level at approximately half way (50%).
2.On some newer TV sets, it may be necessary to increase the output
level of the headphone jack or the Audio Out jacks. Check your TV’s
owner manual for details.
3.Please make sure all connections are completely successful.
Specification:
Transmitter:
Voltage: DC 5V
Work Current: 80mA
Modulate: 50Khz
Mode: Stereo
Work Range: 98ft (30 meters)
Headphone:
Voltage:3.7V(600mAh built-in rechargeable battery)
Work Current:55mA
Work time: 10 hours
Charge time: 2.5 hours
S/N ratio: ≥60dB
Distortion: <1%
Frequency response: 60 - 15,000Hz
ATTENTION!
Before using this radio, read this guide which contains
important operating instructions for safe usage and rf
energy awareness and control for compliance with
applicable standards and regulations.
Local Government Regulations
When radios are used as a consequence of employment, the Local
Government Regulations requires users to be fully aware of and able
to control their exposure to meet occupational requirements. Exposure
awareness can be facilitated by the use of a product label directing
users to specific user awareness information. Your Retekess radio has
a RF Exposure Product Label. Also, your Retekess user manual, or
separate safety booklet includes information and operating instructions
required to control your RF exposure and to satisfy compliance
requirements.
Unauthorized modification and adjustment
Changes or modifications not expressly approved by the party
responsible for compliance may void the user’s authority granted by
the local government radio management departments to operate this
radio and should not be made. To comply with the corresponding
requirements, transmitter adjustments should be made only by or
under the supervision of a person certified as technically qualified to
perform transmitter maintenance and repairs in the private land mobile
and fixed services as certified by an organization representative of the
user of those services.
Replacement of any transmitter component (crystal, semiconductor,
etc.) not authorized by the local government radio management
departments equipment authorization for this radio could violate the
rules.
RF ENERGY EXPOSURE AND PRODUCT SAFETY
GUIDE
06

FCC Requirements:
•This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
•(If applicable) This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
CE Requirements:
•(Simple EU declaration of conformity) Henan Eshow Electronic
Commerce Co.,Ltd declares that the radio equipment type is in
compliance with the essential requirements and other relevant
provisions of RED Directive 2014/53/EU and the ROHS Directive
2011/65/EU and the WEEE Directive 2012/19/EU; the full text of the
EU declaration of conformity is available at the following internet
address: www.retekess.com.
•Disposal
The crossed-out wheeled-bin symbol on your product, literature, or
packaging reminds you that in the European Union, all electrical and
07

electronic products, batteries, and accumulators (rechargeable
batteries) must be taken to designated collection locations
at the end of their working life. Do not dispose of these pr-
oducts as unsorted municipal waste. Dispose of them acco-
rding to the laws in your area.
IC Requirements:
Licence-exempt radio apparatus
This device contains licence-exempt transmitter(s)/receiver(s) that
comply with Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is subject to the following
two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélec-
trique subi, même si le brouillage est susceptible d’en compromettre le
fonctionnement.
RF Warning Statements
The device has been evaluated to meet general RF exposure
requirement. The device can be used in portable exposure condition
without restriction.
RF Exposure Information(if appropriate)
•DO NOT operate the radio without a proper antenna attached, as this
may damage the radio and may also cause you to exceed RF
exposure limits. A proper antenna is the antenna supplied with this
radio by the manufacturer or an antenna specifically authorized by the
manufacturer for use with this radio, and the antenna gain shall not
exceed the specified gain by the manufacturer declared.
08

•To avoid interference, turn off the radio in areas where signs are
posted to do so.
•DO NOT operate the transmitter in areas that are sensitive to
electromagnetic radiation such as hospitals, aircraft, and blasting
sites.
Avoid Choking Hazard
Small Parts. Not for children under 3 years.
Protect your hearing:
WARNING
• Use the lowest volume necessary to do your job.
• Turn up the volume only if you are in noisy
surroundings.
• Turn down the volume before adding headset or
earpiece.
• Limit the amount of time you use headsets or earpieces
at high volume.
• When using the radio without a headset or earpiece, do
not place the radio's speaker directly against your ear
• Use careful with the earphone maybe possible
excessive sound pressure from earphones and
headphones can cause hearing loss
Note: Exposure to loud noises from any source for
extended periods of time may temporarily or permanently
affect your hearing. The louder the radio's volume, the
less time is required before your hearing could be
affected. Hearing damage from loud noise is
sometimes undetectable at first and can have
a cumulative effect.
09

•This radio meets the RF exposure guidelines when used
with the Retekess accessories supplied or designated for
the product. Use of other accessories may not ensure
compliance with the RF exposure guidelines and may
violate regulations.
•For a list of Retekess-approved accessories for your
radio model, visit the following website: http://www.Rete-
kess.com
Approved Accessories
WARNING
10

Model Number:
Serial Number:
Purchasing Date:
Dealer: Telephone:
User’s Name: Telephone:
Country: Address:
Post Code: Email:
Guarantee
Remarks:
1.This guarantee card should be kept by the user, no replament if lost.
2.Most new products carry a two-year manufacturer’s warranty from
the date of purchase.
3.The user can get warranty and after-sales service as below: Contact
the seller where you buy.
Products Repaired by Our Local Repair Center
4.For warranty service, you will need to provide a receipt proof of
purchase from the actual seller for verification.
Exclusions from Warranty Coverage:
1.To any product damaged by accident.
2.In the event of misuse or abuse of the product or as a result of
unauthorized alterations or repairs.
11
