Retigo Gun 25 User manual

Oil Spray Gun
Gun 25
OA20-0025
RETIGO s.r.o.
Lá. 2310, PS 43
CZ 756 64 Rožnov pod Radhoštem
Operation manual

2
12
34
65

Nominal output 60 W
Delivery rate (water) 260 g/min
Viscosity rate 80 DIN-sec
Dynamic pressure 0 - 160 bar
Vibration level 2,5 m/s2
Container capacity approx. 0,7 l
Weight approx. approx. 1,1 kg
Protection rating / II
Technical data
For your safety
This machine can only be operated safely when the operating and the safety
instructions have been completely read and strictly adhered to. It is recommended to
receive practical instruction before using the machine for the first time.
Do not use the tool if damp or if the surroundings are damp.
Always check the tool, power cord and plug before use. In the event of damage, repair work
should only be carried out by specialist.
Danger of Explosion!
There must be no naked flames in the working area. The device must not be used in
locations where explosive gases may occur.
Do not smoke!
Do not spray inflammable or explosive liquids (e.g. petrol or spirit).
Never direct the spray jet towards people or animals. The spray material comes out
of the nozzle at high pressure. Danger of injury and infection.
The noise level of the appliance can exceed 85 dB(A), therefore wear ear protection
Never spray materials of unknown danger!
Only connect the power plug when the tool is OFF. Disconnect the power plug after use.
Always disconnect the power plug before performing any work on the tool. Do not carry
the tool by the power cord.
Always keep the extension cable well away from the workplace.
Keep the tool and accessories out of the reach of children.
Only use original accessories.
3
Before start-up
Observe the supply voltage! The voltage specified on the nameplate must conform to the
supply voltage

Instructions for use
When purchasing spray material, please ensure that they are not harmful to the environment;
for example, the lable with the blue environment symbol. Paint dealers will be able to give
you useful tips on this.
Spray material
Note: for the perfect functioning of the spray gun clean spray material is of the importance.
In case of doubts regarding any impurities, a fine-meshed filtering of the spray material is
recommended.
Products containing granules or bodies must not be sprayed. These act abrasively and
shorten the service life of the pump and valve.
This invalidates the warranty for these parts
Spraying
Danger of fire and explosion! ! Explosive gases may occur when spraying inflammable and
toxic materials.
Regulating the Spray Jet
Turn the regulating knob completely to the left. (Picture 1)
Switch on the device
Turn the regulating knob to the right until the spraying cone and atomization are correct.
The spray mist should be even, fine and without drops.
Readjust the spray jet before every spraying operation.
Spraying
Always screw down the container firmly. (Picture 2)
A test should be carried out to determine the most effective distance from the spraying
surface. Start at a fairly large distance. Ensure that you keep at a constant distance and that
your movements are steady. The distance of the nozzle from the workpiece depends on the
spray material (approx. 20-35 cm spraying distance depending on the cone of the jet and the
thickness of the paint to be applied).
Note: Spraying material tends to drip off vertical surfaces.
Perform an initial spraying from a slightly greater distance and allow the paint to start to dry.
Never spray until the container is empty. The suction pipe must always be immersed in
liquid. Otherwise the paint aerosol will stop and thicker drops will be sprayed. Always hold
the spray gun upright.
Care and Maintenance
Always disconnect the plug from the power socket before carrying out any work on the
appliance.
Always keep the device clean.
Never immerse the device in cleaning agent!
Clean the appliance periodically by spraying a mild alkaline agent which is save for food
through it. Rinse it thoroughly thereafter with fresh water. See instructions of manufacturer.
When spray gun is not used for a longer time, spray through resin-free oil for conservation.
If the appliance should happen to fail despite the care taken in manufacture and testing,
repair should be carried out by an authorised customer service.
or all correspondence and spare parts orders, always include the order number.
4

Dismantling the Pump
1. Remove screw 1. (Picture 3)
2. Separate the motor housing 6 from the pump section. (Picture 4)
3. Unscrew nozzle 3 Take suction pressure valve 4 and pump plunger 8with spring 7 out of the
pump section..Do not use force. (Picture 5)
4. Make the tightly fitting valve ball passable through piston opening with the aid of a copper
or brass pin. (Picture 6)
5. Place all parts in the appropriate solvent and clean them.
Never use hard objects for cleaning! Piston 8 (see spare parts) should move easily
in the pump housing.
Assembling the Pump
Assemble the parts in the reverse order.
After cleaning, spray through the device briefly with resin-free oil as an anticorrosion measure.
Collect cleaning agents in an appropriate receptacle and dispose of in an appropriate manner.
EN Declaration of Conformity CE
We declare at our sole responsibility that this product conforms to the following standards or
normative documents: “EN 50144-2-7:96, EN 55014-1:93+A1:97. EN 61000-3-
2:95+A13:97+A1:98+A2:98, EN 61000-3-3:95
5
Garantie
The appliance is guaranteed for six months subject to the enclosed terms and on condition that
it is only used for processing products approved for the food industry.
The appliance must not be operated continuously for longer than 10 minutes at a time.
The guarantee is based on 50 hours of use within a 6-month period.
Only original spare parts may be used in the event of repairs.
The appliances must be serviced and cleaned as described in the operating instructions.
The guarantee becomes valid with the delivery of the product to the end user.
The duration of the guarantee shall be determined by the end user‘s date of purchase. The
guarantee excludes any damage due to natural wear, overloading or incorrect handling.
Repairs not covered by the guarantee shall be performed by service centres subject to the
applicable price and delivery terms of the country in question.
Product liability
No liability is accepted for damage caused directly or indirectly by the use and spraying of
products. The user assumes full responsibility for the use of the product in accordance with the
laws of food hygiene and other legal regulations.
Pavel Vokatý

Ugello a getto piano
Ugello R4
Ugello R6
Ugello R8
Prolunge per ugello
Contenitore con copericchio
Vite
Ugello
Votrice
Palla
Coperchio d’ aspirazione
Molla pistone
Pisone
Tubo di aspirazione
Contenitore
09-004-004
09-490-006
09-005-000
09-004-014
11-504-023
11-004-013
11-004-023
06-001-027
09-501-016
1
3
4
5
6
7
8
9
10
Flügelschraube
Rundstrahldüse
Drall cplt.
Ventilkugel
Pumpengehäuse
Kolbenfeder
Kolben cplt.
Saugrohr
Behälter
Wing set screw
Round jet nozzle
Swirl piece
Valve ball
Pump housing
Piston spring
Piston cplt.
Suction tube
Paint Container
Vis allée
Buse à jet round
Tête atomiseur
Bille de soupape
Boîter de pompe
Ressort du piston
Piston
Tube d’ aspiration
Récipient
09-490-007
09-490-004
09-490-006
09-490-008
09-008-015
09-490-012
11
12
12
12
13
14
Flachstrahldüse
Düse R4
Düse R6
Düse R8
Düsenverlängerung
Behälter mit Deckel
Fan Nozzle
Round jet nozzle R4
Round jet nozzle R6
Round jet nozzle R8
Bent nozzle extension
Container with lid
Buse à jet plat
Buse R4
Buse R6
Buse R8
Ralloge de base
Récipient avec couvercle
Zubehör / Accessories / Accessoires / Accessori
Ersatzteile / Spare parts / Pièces de rechange / Dei pezzi di ricambio
Pos. Part No.
6

NOTES:
7

RETIGO s.r.o.
Lá. 2310, PS 43
CZ 756 64 Rožnov pod Radhoštem
Tel.: [phone]
Fax: [phone]
e-mail: [email protected]; [email protected]
www.retigo.com
HOT LINE
Sales: [phone]
Service: [phone]
11-844-018 / 06.2010
