Knife Mill Grindomix GM200

Translation

Retsch GmbH

Haan, Retsch-Allee 1-5

D-42781 Haan

Federal Republic of Germany

1Notes on the Operating Manual ............................................................................................................5

1.1 Explanations of the safety warnings.................................................................................................. 6

1.2 General safety instructions ................................................................................................................ 7

1.3 Repairs............................................................................................................................................... 8

2Confirmation ...........................................................................................................................................9

3Transport, scope of delivery, installation..........................................................................................10

3.1 Packaging........................................................................................................................................ 10

3.2 Transport.......................................................................................................................................... 10

3.3 Temperature fluctuations and condensed water ............................................................................. 10

3.4 Conditions for the place of installation............................................................................................. 10

3.5 Installation of the machine............................................................................................................... 10

3.6 Electrical connection........................................................................................................................ 10

3.7 Type plate description...................................................................................................................... 11

4Technical data.......................................................................................................................................12

4.1 Use of the machine for the intended purpose.................................................................................. 12

4.2 Working instructions ........................................................................................................................ 13

4.3 Protective equipment....................................................................................................................... 13

4.4 Drive output...................................................................................................................................... 13

4.5 Rated power .................................................................................................................................... 13

4.6 Motor rotation speed........................................................................................................................ 13

4.7 Rated voltage................................................................................................................................... 13

4.8 Emissions......................................................................................................................................... 14

4.8.1 Noise measurement Example 1:.................................................................................................. 14

4.8.2 Noise measurement Example 2:.................................................................................................. 14

4.9 Degree of protection ........................................................................................................................ 14

4.10 Dimensions and weight.................................................................................................................... 14

4.11 Required floor space........................................................................................................................ 15

5Operating the machine ........................................................................................................................16

5.1 Views of the Instrument................................................................................................................... 16

5.2 Overview table of the parts of the device ........................................................................................ 18

5.3 Overview Table of the Operating Elements and the Display........................................................... 19

5.4 Operating the Device....................................................................................................................... 20

5.5 Switching On and Off....................................................................................................................... 20

5.6 Opening and closing of the grinding chamber................................................................................. 21

5.7 Inserting the grinding jar .................................................................................................................. 21

5.8 Use of grinding jugs depending on different materials .................................................................... 21

5.8.1 Grinding jars –plastic jugs (PP) .................................................................................................. 22

5.8.2 Grinding jars –glass jugs (borosilicate glass 3.3)....................................................................... 22

5.8.3 Grinding jars –stainless steel jugs.............................................................................................. 22

5.9 Lid and jug combinations................................................................................................................. 22

5.9.1 Lid 1000ml ................................................................................................................................... 23

5.9.2 Lid 500ml ..................................................................................................................................... 24

5.9.3 Gravitation lid............................................................................................................................... 24

5.10 Filling the vessel .............................................................................................................................. 25

5.10.1 Filling –within the device......................................................................................................... 25

5.10.2 Fílling –outside the device...................................................................................................... 26

5.11 Setting the grinding time.................................................................................................................. 27

5.12 Setting the Speed ............................................................................................................................ 28

5.13 Switching on interval or continuous mode....................................................................................... 28

5.14 Reverse grinding.............................................................................................................................. 29

5.15 Store functions................................................................................................................................. 30

5.15.1 Saving programs...................................................................................................................... 30

5.15.2 Starting a saved program ........................................................................................................ 30

5.16 Start –Pause –Stop........................................................................................................................ 30

5.16.1 Pause function......................................................................................................................... 30

5.16.2 Premature termination of grinding ........................................................................................... 30

5.17 Resetting the overload protection.................................................................................................... 30

6Cleaning and service ...........................................................................................................................31

6.1 Cleaning the Grinding Tools............................................................................................................ 32

6.2 Check the sealing lip........................................................................................................................ 33

7Fault messages.....................................................................................................................................34

8Disposal.................................................................................................................................................35

9Index ......................................................................................................................................................36

Appendix ............................................................................................................................... following pages

Notes on the Operating Manual

Pos: 1.1 /00005 Übersc hriften/1. Überschrift en/1 Hinweise zur Bedie nungsanleitung @ 0\ mod_122234741 5287_9.doc @ 2631 @ 1 @ 1

1 Notes on the Operating Manual

Pos: 1.2 /00010 Bedie nungsanleitungen Ka pitelsammlungen /CryoMill/0001 Hinw eisez ur Bedienungsanl eitung/Modul Hinweis zur Bedienu ngsanleitung @ 0\m od_12223473417 73_9.doc @ 2540 @ @ 1

This operating manual is a technical guide on how to operate the device safely and

it contains all the information required for the areas specified in the table of

contents. This technical documentation is a reference and instruction manual. The

individual chapters are complete in themselves.

Familiarity (of the respective target groups defined according to area) with the

relevant chapters is a precondition for the safe and appropriate use of the device.

This operating manual does not contain any repair instructions. If faults arise or

repairs are necessary, please contact your supplier or get in touch with Retsch

GmbH directly.

Application technology information relating to samples to be processed is not

included but can be read on the Internet on the respective device’s page at

www.retsch.com.

Pos: 1.3 /00010 Bedie nungsanleitungen Ka pitelsammlungen/Cr yoMill/0001 Hinweis ez urB edienungsanl eitung/Modul Änder ungen @ 0\mod_12 22347341241_ 9.doc@ 2526 @ @ 1

Changes

Subject to technical changes.

Pos: 1.4 /00010 Bedie nungsanleitungen Ka pitelsammlungen/Cr yoMill/0001 Hinweis ez urB edienungsanl eitung/Modul Urhe berrecht @ 0\mod_1 222347342038_9. doc@ 2547 @ @ 1

Disclosure or reproduction of this documentation, use and disclosure of its contents

are only permitted with the express permission of Retsch GmbH.

Infringements will result in damage compensation liability.

Pos: 2.1 /00010 Bedie nungsanleitungen Ka pitelsammlungen/------- Seiten umbruch -----------@ 0\mod_12223 44373758_0.doc @ 2386 @ @ 1

Notes on the Operating Manual

Pos: 2.2 /00005 Übersc hriften/1.1 Überschrif ten/1.1 Überschrifte n BDA/11 Erklärungen zu d enSic herheitsw arnungen @ 0\mod_ 1222344569771_9.d oc @ 2484 @ 2 @ 1

1.1 Explanations of the safety warnings

Pos: 2.3 /00003 Standard K apitel/General Mo dulW arnhinweise Er klärung neu @ 0\mod_ 1234858329746_9.d oc @ 6190 @ @ 1

In this Operating Manual we give you the following safety warnings

Serious injury may result from failing to heed these safety warnings. We give you

the following warnings and corresponding content.

WARNING

Type of danger / personal injury

Source of danger

–Possible consequences if the dangers are not observed.

•Instructions on how the dangers are to be avoided.

We also use the following signal word box in the text or in the instructions on action

to be taken:

WARNING

Moderate or mild injury may result from failing to heed these safety warnings.

We give you the following warnings and corresponding content.

CAUTION

Type of danger / personal injury

Source of danger

–Possible consequences if the dangers are not observed.

•Instructions on how the dangers are to be avoided.

We also use the following signal word box in the text or in the instructions on action

to be taken:

CAUTION

In the event of possible property damage we inform you with the word

“Instructions” and the corresponding content.

NOTICE

Nature of the property damage

Source of property damage

–Possible consequences if the instructions are not observed.

•Instructions on how the dangers are to be avoided.

We also use the following signal word in the text or in the instructions on action to

be taken:

NOTICE

Pos: 2.4 /00010 Bedie nungsanleitungen Ka pitelsammlungen/------- Seiten umbruch -----------@ 0\mod_12223 44373758_0.doc @ 2386 @ @ 1

Notes on the Operating Manual

Pos: 2.5 /00005 Übersc hriften/1.1 Überschrif ten/1.1 Überschrifte n BDA/11 Generelle Sic herheitshinweise @ 0\ mod_12223445 68974_9.doc @ 2463 @ @1

1.2 General safety instructions

Pos: 2.6 /00004 Warnhi nweise/V0002 VORS ICHT Bedienungs anleitung lesen @ 2\m od_12638949828 15_9.doc @ 18630 @ @ 1

CAUTION

Read the Operating Manual

Non-observance of these operating instructions

–The non-observance of these operating instructions can

result in personal injuries.

•Read the operating manual before using the device.

•We use the adjacent symbol to draw attention to the

necessity of knowing the contents of this operating

manual.

Pos: 2.7 /00003 Standard K apitel/General Mo dulZ ielgruppe und Sicher heit@ 0\mod_1 228722955300_ 9.doc@ 4100 @ @ 1

Target group : All persons concerned with the machine in any form

This machine is a modern, high performance product from Retsch GmbH and

complies with the state of the art. Operational safety is given if the machine is

handled for the intended purpose and attention is given to this technical

documentation.

Pos: 2.8 /00003 Standard K apitel/General Mo dulSic herheitshin weise @ 0\mod_122 8722954800_9.doc @ 4 086 @ @ 1

You, as the owner/managing operator of the machine, must ensure that the people

entrusted with working on the machine:

•have noted and understood all the regulations regarding safety,

•are familiar before starting work with all the operating instructions and

specifications for the target group relevant for them,

•have easy access always to the technical documentation for this machine,

•and that new personnel before starting work on the machine are familiarised

with the safe handling of the machine and its use for its intended purpose,

either by verbal instructions from a competent person and/or by means of

this technical documentation.

Improper operation can result in personal injuries and material damage. You are

responsible for your own safety and that of your employees.

Make sure that no unauthorised person has access to the machine.

Pos: 2.9 /00004 Warnhi nweise/V0015 VORS ICHT+ H INWEIS Sach- und Personens chäden @ 1\mod_ 1236238456676_9 .doc @ 7642 @ @ 1

CAUTION

Changes to the machine

–Changes to the machine may lead to personal injury.

•Do not make any change to the machine and use spare parts and

accessories that have been approved by Retsch exclusively.

NOTICE

Changes to the machine

–The conformity declared by Retsch with the European Directives will lose

its validity.

–You lose all warranty claims.

•Do not make any change to the machine and use spare parts and

accessories that have been approved by Retsch exclusively.

Pos: 2.10 /00010 Bedi enungsanleitungen K apitelsammlungen/------- Seite numbruch -----------@ 0\mod_12 22344373758_0.doc @ 238 6@ @ 1

Notes on the Operating Manual

Pos: 2.11 /00005 Überschrif ten/1.1 Überschrift en/1.1 Überschri ften BDA/11 Reparature n @ 0\mod_12236 24336511_9.doc @ 297 8 @ @ 1

Reperaturen

1.3 Repairs

Pos: 2.12 /00003 Stand ard Kapitel/General M odulR eparaturen @ 0 \mod_122872295 4535_9.doc @ 4079 @ @ 1

This operating manual does not contain any repair instructions. For your own

safety, repairs may only be carried out by Retsch GmbH or an authorized

representative or by Retsch service engineers.

In that case please inform:

The Retsch representative in your country

Your supplier

Retsch GmbH directly

Your Service Address:

Pos: 3.1 /00020 BD A Software/20005 PM GC Kapitelsa mmlung/- - - - Seit enumbruch - - - - @ 0\mod_12088 57688413_0.doc @ 337 @ @ 1

Confirmation

Pos: 3.2 /00020 BDA Soft ware/20005 PMGC Ka pitelsammlung/Üb erschriften/1. Überschrif ten/1 Bestätigu ng( Formular für den Betrei ber) @ 0\mod_12 08870841095_9.d oc @ 430 @ 1@ 1

Bestätigung

2 Confirmation

Pos: 3.3 /00003 Standard K apitel/General Mo dulB estätigung @ 0\ mod_122872296270 7_9.doc @ 4114 @ @ 1

This operating manual contains essential instructions for operating and maintaining

the device which must be strictly observed. It is essential that they be read by the

operator and by the qualified staff responsible for the device before the device is

commissioned. This operating manual must be available and accessible at the

place of use at all times.

The user of the device herewith confirms to the managing operator (owner) that

(s)he has received sufficient instructions about the operation and maintenance of

the system. The user has received the operating manual, has read and taken note

of its contents and consequently has all the information required for safe operation

and is sufficiently familiar with the device.

As the owner/managing operator you should for your own protection have your

employees confirm that they have received the instructions about the operation of

the machine.

I have read and taken note of the contents of all chapters in this operating

manual as well as all safety instructions and warnings.

User

Surname, first name (block letters)

Position in the company

Signature

Service technician or operator

Surname, first name (block letters)

Position in the company

Place, date and signature

Pos: 4.1 /00010 Bedie nungsanleitungen Ka pitelsammlungen/------- Seiten umbruch -----------@ 0\mod_12223 44373758_0.doc @ 2386 @ @ 1

Transport, scope of delivery, installation

Pos: 4.2/ 00005 Überschrift en/1.Üb erschriften/1 Verpac kung, Transport und Aufst ellung@ 0\mod_122 6494451893_9.doc @ 338 0@ 1 @ 1

3 Transport, scope of delivery, installation

Pos: 4.3 /00005 Übersc hriften/1.1 Überschrif ten/1.1 Überschrifte n BDA/11 Verpackung @ 0 \mod_122649 5088973_9.doc @ 33 92@ 2 @ 1

3.1 Packaging

Pos: 4.4 /00003 Standard K apitel/General Mo dul Verpackung @ 0\ mod_122898461835 5_9.doc @ 4892 @ @ 1

The packaging has been adapted to the mode of transport. It complies with the

generally applicable packaging guidelines.

Pos: 4.5 /00005 Übersc hriften/1.1 Überschrif ten/1.1 Überschrifte n BDA/11 Transport @ 0 \mod_1226495 164391_9.doc @ 3398 @ 2 @ 1

3.2 Transport

Pos: 4.6/ 00004 Warnhinweise/H 0017H INWEIS Transport @ 0\ mod_1228918883019 _9.doc @ 4802@ @1

NOTICE

Transport

–Mechanical or electronic components may be damaged.

•The machine may not be knocked, shaken or thrown during

transport.

Pos: 4.7 /00005 Übersc hriften/1.1 Überschrif ten/1.1 Überschrifte n BDA/11 Temperatursc hwankungen @ 0\ mod_1226495 190738_9.doc @ 3404 @ 2 @ 1

3.3 Temperature fluctuations and condensed water

Pos: 4.8/ 00004 Warnhinweise/H 0016H INWEIS Temperaturs chwankungen @ 0\mod _1233564121287_9.d oc @ 5570@ @ 1

NOTICE

Temperature fluctuations

The machine may be subject to strong temperature fluctuations during transport

(e.g. aircraft transport)

–The resultant condensed water may damage electronic components.

•Protect the machine from condensed water.

Pos: 4.9 /00005 Übersc hriften/1.1 Überschrif ten/1.1 Überschrifte n BDA/11 Bedingung enfür den Aufstellort @ 0\mod_12 26497029322_9.d oc @ 3428 @ 2 @ 1

3.4 Conditions for the place of installation

Pos: 4.10 /00003 Stand ard Kapitel/General M odulU mgebungste mperatur 5°C - 40°C @ 0\ mod_1228918538 881_9.doc @ 4745 @ @ 1

Pos: 4.11 /00004 Warn hinweise/H0021 HIN WEIS Umgebungst emperatur 5°C bis 40°C @ 0\ mod_12289188 83441_9.doc @ 4816 @ @1

NOTICE

Ambient temperature

–Electronic and mechanical components may be damaged and the

performance data alter to an unknown extent.

•Do not exceed or fall below the permitted temperature range of the

machine (5°C to 40°C / ambient temperature).

Pos: 4.12 /00005 Überschrif ten/1.1 Überschrift en/1.1 Überschrift enBD A/11 Aufstellen d es Gerätes @ 0\mod_ 1226498849756_9 .doc @ 3464 @ 2 @ 1

3.5 Installation of the machine

Pos: 4.13 /00003 Stand ard Kapitel/General M odul Aufstellungshöhe @ 0\mod_12 28918538349_9.doc @ 4724 @ @ 1

Installation height: maximum 2000 m above sea level

Pos: 4.14 /00005 Überschrif ten/1.1 Überschrift en/1.1 Überschri ften BDA/11 Elektrisc her Anschluss @ 0\mo d_122656506744 5_9.doc @ 3500 @ 2 @ 1

3.6 Electrical connection

Pos: 4.15 /00003 Stand ard Kapitel/General M odul Elektrischer Anschl uss @ 0\mod_1228 918538521_9.doc @ 4731 @ @ 1

WARNING

When connecting the power cable to the mains supply, use an external fusethat

complies with the regulations applicable to the place of installation .

•Please check the type plate for details on the necessary voltage and

frequency for the device.

•Make sure the levels agree with the existing mains power supply.

Transport, scope of delivery, installation

•Use the supplied connection cable to connect the device to the mains power

supply.

Pos: 5.1 /00005 Übersc hriften/1.1 Überschrif ten/1.1 Überschrifte n BDA/11 Typenschil dB eschreibung @ 3\ mod_1280933953 941_9.doc @ 22302 @ 2 @ 1

3.7 Type plate description

Pos: 5.2 /00003 Standard K apitel/General Mo dulT ypenschild @ 3\ mod_128093109244 3_9.doc @ 22278 @ @ 1

Fig. 1: Type plate lettering

1 Device designation

2 Year of production

3 Part number

4 Serial number

5 Manufacturer’s address

6 CE marking

7 Disposal label

8 Bar code

9 Power version

10 Mains frequency

11 Capacity

12 Amperage

13 Number of fuses

14 Fuse type and fuse strength

In the case of questions please provide the device designation (1) or the part

number (3) and the serial number (4) of the device.

Pos: 6/ 00010 Bedienung sanleitungen Kapit elsammlungen/------- Seitenu mbruch -----------@ 0\mod_122234 4373758_0.doc @ 2386 @ @ 1

Technical data

Pos: 7.1 /00005 Übersc hriften/1. Überschrift en/1 Technische Date n @0 \mod_1222344 525522_9.doc @ 240 7@ 1 @ 1

4 Technical data

Pos: 7.2 /00005 Übersc hriften/1.1 Überschrif ten/1.1 Überschrifte n BDA/11 Einsatz der M aschine bei bestimm ungsgemäßer Ver wendung @ 0\mod_122 6476732248_9.doc @ 3 243 @ 2 @ 1

4.1 Use of the machine for the intended purpose

Pos: 7.3/ 00004 Warnhinweise/ V0003 VORSICHT Explosi ons-o der Brandgefahr Sieben @ 1\mod_1 243924323407_9.d oc@ 10 360 @ @ 1

CAUTION

Risk of explosion or fire

Changing sample characteristics

–Note that the characteristics and accordingly the danger presented by a

sample can change during sieving.

•Do not sieve any potentially explosive or combustible materials in

this device.

Pos: 7.4 /00004 Warnhi nweise/V0005 VORS ICHT explosionsg efärdete Atmosphär e @ 1\mod_12398 68668923_9.doc @ 814 0@ @ 1

CAUTION

Risk of explosion or fire

–On account of its design, the device is not suitable for use in hazardous

(potentially explosive) atmospheres.

•Do not operate the device in a hazardous atmosphere.

Pos: 7.5 /00004 Warnhi nweise/V0006 VORS ICHT Gefahr von Perso nenschäden Gefährl iche Stoffe @ 1\mod _1236238456269 _9.doc @ 7634 @ @ 1

CAUTION

Danger of personal injury

Dangerous nature of the sample

–Depending on the dangerous nature of your sample, take the

necessary measures to rule out any danger to persons.

•Observe the safety guidelines and datasheets of your

sample material.

Pos: 7.6 /00010 Bedie nungsanleitungen Ka pitelsammlungen/GM 200( 2010)/0005 GM2 00N Technisch eD aten/0510 GM200_2 010M odul Einsatz bei bestimmungsg emäßer Verwendu ng@ 3\mod_127 9702720657_9. doc@ 2 0888 @ @ 1

Target group: operators

Machine type designation: GM 200

This device is suitable for analytical grinding, homogenisation and mixing of soft to

medium-hard, aqueous, fatty, fibrous and dry materials in seconds. This device is

designed for quantities of approximately 700ml, large volume materials up to

1000ml.

The feed size is < 30 - 40 mm.

The device is specially designed for the grinding of the following materials :

Fish, meat, vegetables, cheese, preserves, seeds, bacon, sausage, dry baked

goods and pastries, all aqueous, fatty and fibrous products and similar materials.

The device is designed as a laboratory device for 8-hour one-shift operation with a

30% ON duration.

It is not intended for use as production machine and not intended for the mixing

and homogenisation of liquids with low viscosity (emulsions and suspensions) .

Technical data

Pos: 7.7 /00005 Übersc hriften/1.1 Überschrif ten/1.1 Überschrifte n BDA/11 Funktionsw eise@ 0\mod_1 222344568271_ 9.doc@ 2442 @ 2 @ 1

Arbeitsweise

4.2 Working instructions

Pos: 7.8 /00010 Bedie nungsanleitungen Ka pitelsammlungen/GM 200( 2010)/0005 GM2 00N Technisch eD aten/0535 GM200_2 010M odul Funkti onsweise @ 3\mod_1 279706968586_9.d oc @2 0996 @ @ 1

The grinding process of the device is effected through cutting and, in reverse

operation, through impact effect.

The cutters are straight and are arranged at right-angles to the direction of rotation.

The cutters are slim with a cutting angle of 15° and a pre-cut (pre-grind) of 30°.

With this cutting geometry the entire inertia resulting from the speed difference

between the sample material particles and the cutters can be used as cutting force.

The speed is between 2000 - 10000min-1 and is altered in stages of 500min-1 and

displayed digitally.

The preselected speed is kept constant during grinding by a speed regulator.

Interval operation has proved to be advantageous in the pre-grinding and

homogenisation of large-piece, tough, fibrous and very soft and elastic products.

The grinding duration can be set up to 3 minutes. After expiry of the grinding

duration the motor automatically switches off and the housing lid opens.

3 memories permit the storage and retrieval of frequently used speed/time

combinations by the press of a button.

Pos: 7.9 /00005 Übersc hriften/1.1 Überschrif ten/1.1 Überschrifte n BDA/11 Schutzei nrichtungen @ 0\ mod_122648631613 0_9.doc @ 3304 @ @ 1

4.3 Protective equipment

Pos: 7.10 /00010 Bedi enungsanleitungen K apitelsammlungen/ GM200 (2010)/000 5 GM200N Technisc heDa ten/0530 GM200_ 2010 Modul Schutz einrichtung @ 3\mod _12797027221 42_9.doc @ 20915 @ @ 1

The grinding chamber of this device is interlocked by a resistant protective hood.

It is only possible to start the device when the protective hood is closed. The motor

must have come to a standstill to open the device.

In the event of fault there is also an electric emergency brake which brings the

cutters to a standstill in fractions of a second from the highest speed.

If the achievable current speed deviates from the setpoint speed by more than 5%

due to an overload, this is shown by flashing displays.

Pos: 7.11 /00005 Überschrif ten/1.1 Überschrift en/1.1 Überschrift enBD A/11 Antrieb @ 1\ mod_12404757 43011_9.doc @ 8557 @ @1

4.4 Drive output

Pos: 7.12 /00010 Bedi enungsanleitungen K apitelsammlunge n/GM200 (2010)/000 5 GM200N Technisc heDa ten/0540 GM200_ 2010 Modul Antrieb @ 3\ mod_127970 6969133_9.doc @ 2100 5@ @ 1

Universal electric motor

Pos: 7.13 /00005 Überschrif ten/1.1 Überschrift en/1.1 Überschrift enBD A/11 Nennleistu ng@ 0\mod_12 26491873164_ 9.doc@ 3334 @ @ 1

4.5 Rated power

Pos: 7.14 /00010 Bedi enungsanleitungen K apitelsammlungen/ GM200 (2010)/000 5 GM200N Technisc heD aten/0520 GM2 00_2010 Modul Nennleis tung @ 3\mod_1 279702721142_9.do c@ 2 0897 @ @ 1

Motor performance: approx. 1000 watts

Pos: 7.15 /00005 Überschrif ten/1.1 Überschrift en/1.1 Überschrift enBD A/11 Motordre hzahl @ 1\mod_1241 508280705_9.doc @ 8763 @ @ 1

4.6 Motor rotation speed

Pos: 7.16 /00010 Bedi enungsanleitungen K apitelsammlungen/ GM200 (2010)/000 5 GM200N Technisc heDa ten/0545 GM200_ 2010 Modul Motor drehzahl @ 3\mod_ 1279706969649_9.d oc @ 21014 @ @ 1

Speed: 2000 rpm-1.... 10,000 rpm-1 ( can be altered in steps of 500 Umin-1)

Pos: 7.17 /00005 Überschrif ten/1.1 Überschrift en/1.1 Überschrift enBD A/11 Nennspa nnungen @ 1\mod_1 240476024494_9. doc@ 8571 @ @ 1

4.7 Rated voltage

Pos: 7.18 /00010 Bedi enungsanleitungen K apitelsammlungen/ GM200 (2010)/000 5 GM200N Technisc heDa ten/0550 GM200_ 2010 Modul Nenns pannungen @ 3\ mod_127970697016 4_9.doc @ 21023 @ @ 1

Rated voltages: 230 V 50 Hz (+/- 5%)

100-120V 50/60 Hz (+/- 5%)

Technical data

Pos: 7.19 /00005 Überschrif ten/1.1 Überschrift en/1.1 Überschrift en BDA/11 Emmisi onen @ 0\mod_12 26487095021_9.d oc @ 3310 @ @ 1

4.8 Emissions

Pos: 7.20 /00004 Warn hinweise/V0020 VOR SICHT Überhören vo n akustischen Signale nLauteM ahlgeräusch e @ 1\mod_12481 85838858_9.doc @ 11 740 @ @ 1

CAUTION

Possibility of acoustic signals not being heard

Loud grinding noises

-Acoustic alarms and voice communication might not be heard.

•Consider the volume of the grinding noise in relation to other

acoustic signals in the work environment. You may wish to use

additional visual signals.

Pos: 7.21 /00010 Bedi enungsanleitungen K apitelsammlungen/ GM200 (2010)/000 5 GM200N Technisc heDa ten/0510 GM200_ 2010 Modul Emmisi onen@ 3\mod _1279702725923_9. doc @ 20969 @ 33 @ 1

Noise values: ~ 56 dB(A) (without sample material, beaker, cutters)

Noise measurement in accordance with DIN 45635-031-01-KL3

The noise values are also influenced by the properties of the sample medium.

4.8.1 Noise measurement Example 1:

Intensity of sound LWA

Workplace-related emission value LpAeq

Operating conditions:

Jug = glass jug with gravitation lid

Grind unit = cutter made of stainless steel

Feed material = tomatoes, quartered approx. 40 x 25mm

Feed quantity = 100g

4.8.2 Noise measurement Example 2:

Intensity of sound LWA

Workplace-related emission value LpAeq

Operating conditions:

jug = glass jug with gravitation lid

Grind unit = cutter made of stainless steel

Feed material = cheese approx. 20 x 20mm

Feed quantity = 100g

Pos: 7.22 /00005 Überschrif ten/1.1 Überschrift en/1.1 Überschrift enBD A/11 Schutzart @ 0\mod_1226 491839164_9.doc @ 3328 @ @ 1

4.9 Degree of protection

Pos: 7.23 /00010 Bedi enungsanleitungen K apitelsammlungen/ GM200 (2010)/000 5 GM200N Technisc heDa ten/0525 GM200_ 2010 Modul Schutz art @ 3\mod_12797 02721626_9.doc @ 2 0906@ @1

–Grinding chamber and keypad - IP 42

–In the area of the ventilation slits - IP 20

Pos: 7.24 /00005 Überschrif ten/1.1 Überschrift en/1.1 Überschrift en BDA/11 Abmessung en und Gewicht @ 0\ mod_12264922121 73_9.doc @ 3352 @ @ 1

4.10 Dimensions and weight

Pos: 7.25 /00010 Bedi enungsanleitungen K apitelsammlungen/ GM200 (2010)/000 5 GM200N Technisc heDa ten/0505 GM200_ 2010 Modul Abmess ungen und Gewicht @ 3\ mod_127970272 0126_9.doc @ 20879 @ @1

Closed:

Height: up to approx. 390mm

Width: 350mm

Depth : 250mm

Technical data

with open hood:

Height: up to approx. 540mm

Width: 350mm

Depth : 410mm

Weight: approx. 10.1kg (without plastic container and cutter)

Pos: 7.26 /00005 Überschrif ten/1.1 Überschrift en/1.1 Überschrift enBD A/11 Erforderlich e Standfläche @ 0\m od_12264926784 14_9.doc @ 3364 @ 2 @ 1

4.11 Required floor space

Pos: 7.27 /00010 Bedi enungsanleitungen K apitelsammlunge n/GM200 (2010)/000 5 GM200N Technisc heDa ten/0515 GM200 _2010 Modul Erforderlich e Standfläche @ 3\ mod_127970272 6470_9.doc @ 20978 @ @1

200 mm x 400 mm; no safety distances required.

Pos: 8.1 /00010 Bedie nungsanleitungen Ka pitelsammlungen/------- Seiten umbruch -----------@ 0\mod_12223 44373758_0.doc @ 2386 @ @ 1

Operating the machine

Pos: 8.2 /00005 Übersc hriften/1. Überschrift en/1 Bedienung des G erätes @ 0\mod_122 6565880211_9.doc @ 3 519 @ 1@ 1

5 Operating the machine

Pos: 8.3 /00005 Übersc hriften/1.1 Überschrif ten/1.1 Überschrifte n BDA/11 Ansichten des G erätes @ 0\mod_1 228990581782_9. doc@ 4966 @ 2 @ 1

5.1 Views of the Instrument

Pos: 8.4 /00010 Bedie nungsanleitungen Ka pitelsammlungen/GM 200( 2010)/0015 GM2 00N Bedienung/ 1504 GM200_201 0Mo dul Grafische Ansic hten des Gerätes @ 3\m od_12797222757 78_9.doc @ 21703 @ @ 1

Fig. 2: Front view of the machine

Operating the machine

Fig. 3: Rear view of the machine

Fig. 4: Detail view of the socket for non-heating apparatus

Pos: 8.5 /00010 Bedie nungsanleitungen Ka pitelsammlungen/------- Seiten umbruch -----------@ 0\mod_12223 44373758_0.doc @ 2386 @ @ 1

Operating the machine

Pos: 8.6 /00005 Übersc hriften/1.1 Überschrif ten/1.1 Überschrifte n BDA/11 Übersichtsta belle der Geräteteile @ 0\ mod_122899 0616846_9.doc @ 49 72@ @1

5.2 Overview table of the parts of the device

Pos: 8.7 /00010 Bedie nungsanleitungen Ka pitelsammlungen/GM 200 (2010)/0015 GM 200N Bedienung/ 1505 GM200_201 0Mo dulT abelle der Geräteteil e@ 3\mod _1279721225379_9. doc @ 21541 @ @ 1

Element

Description

Function

Jar lid

Seals the grinding jar

Knife cylinder

Cuts and grinds the sample material

Grinding jar

Holds the sample material

Jar holder

Holder for the grinding jar

Operating panel with displays

Start / stop / program memory and displays

Grinding chamber hood

Protective hood for safe grinding operations

Pin for knife cylinder

Drive shaft for knife cylinder

Support for grinding jar

Centres the grinding jar and the jar holder

Grinding chamber hood interlock

Locks the grinding chamber hood into place

Thermal fuse

Protective switch against overheating

On/off switch

Separates the machine completely from the mains

Socket for non-heating apparatus

Connection for mains cable

Vent

Ventilation of motor and inside chamber

O ring

Fixes the grinding chamber holder

Pos: 8.8 /00010 Bedie nungsanleitungen Ka pitelsammlungen/------- Seiten umbruch -----------@ 0\mod_12223 44373758_0.doc @ 2386 @ @ 1

Operating the machine

Pos: 8.9 /00005 Übersc hriften/1.1 Überschrif ten/1.1 Überschrifte n BDA/11 Bedien elemente und Funktionen @ 1\mod_12415 10466399_9.doc @ 8 819 @ @ 1

Pos: 8.10 /00010 Bedi enungsanleitungen K apitelsammlunge n/GM200 (2010)/001 5 GM200N Bedienung/ 1506 GM200_20 10M odul Grafische Ansic ht Bedienelemente un dA nzeigen @ 3\ mod_128091103817 9_9.doc @ 22270 @ @ 1

Fig. 5: Operating elements and displays

Pos: 8.11 /00005 Überschrif ten/1.1 Überschrift en/1.1 Überschrift enBD A/11 Übersic htstabelle der Bedienelem ente und der Anzeige @ 0 \mod_12289906 97273_9.doc @ 49 78@ @ 1

5.3 Overview Table of the Operating Elements and the Display
